Kontron pITX-iMX8M User manual


USER GUIDE
pITX-iMX8M
Doc. Rev. 0.7 Preliminary
Doc-ID: 1064-7940

pITX-iMX8M – Rev. 0.7 Preliminary
This page has been intentionally left blank

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 3

PITX
-IMX8M – USER GUIDE
Disclaimer
Kontron would like to point out that the information contained in this manual may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee
on the part of Kontron with respect to technical processes described in the manual or any product characteristics
set out in the manual. Kontron assumes no responsibility or liability for the use of the described product(s), conveys
no license or title under any patent, copyright or mask work rights to these products and makes no representations
or warranties that these products are free from patent, copyright or mask work right infringement unless otherwise
specified. Applications that are described in this manual are for illustration purposes only. Kontron makes no
representation or warranty that such application will be suitable for the specified use without further testing or
modification. Kontron expressly informs the user that this manual only contains a general description of processes
and instructions which may not be applicable in every individual case. In cases of doubt, please contact Kontron.
This manual is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this manual is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products
and thus this manual only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2020 by Kontron S&T AG
Kontron S&T AG
Lise-Meitner-Str. 3-5
86156 Augsburg
Germany
www.kontron.com

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 4
Intended Use
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE OR RESALE
FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR COMMUNICATION SYSTEMS FOR
AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE SUPPORT OR LIFE SUSTAINING APPLICATIONS,
WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE
PERFORMANCE, OR IN WHICH THE FAILURE OF PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR
SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless
otherwise stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities
and cannot therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or
for resale as device in High Risk Applications. All application and safety related information in this document
(including application descriptions, suggested safety measures, suggested Kontron products, and other materials) is
provided for reference only.
Handling and operation of the product is permitted only for trained personnel within a work
place that is access controlled. Please follow the “General Safety Instructions for IT
Equipment” supplied with the system.

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 5
Revision History
Revision Brief Description of Changes Date of Issue Author
0.1 Initial Issue 2018-Nov-20 hjs
0.2 template update 2019-Mar-05 hjs
0.3 BIOS added 2019-Apr-10 hjs
0.4 Corrections from Anas Zakaria 2019-Apr-29 hjs
0.5 Update from Carol 2019-Dec-09 hjs
0.6 Title photo 2020-Feb-26 hjs
0.7 new HWS integrated, block diagram, new
photos
2020-Jun-17 hjs
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths
into a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product
expertise coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace
of mind to build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron
training academy, and more visit http://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order
Terms & Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 6
Symbols
The following symbols may be used in this manual
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE indicates a property damage message.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60 V) when touching
products or parts of them. Failure to observe the precautions indicated and/or prescribed by
the law may endanger your life/health and/or result in damage to your material.
Please refer also to the "High-Voltage Safety Instructions" portion below in this section.
ESD Sensitive Device!
This symbol and title inform that the electronic boards and their components are sensitive
to static electricity. Care must therefore be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
HOT Surface!
Do NOT touch! Allow to cool before servicing.
Laser!
This symbol inform of the risk of exposure to laser beam and light emitting devices (LEDs)
from an electrical device. Eye protection per manufacturer notice shall review before
servicing.
This symbol indicates general information about the product and the user manual.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 7
Table of Contents
Symbols .................................................................................................................................................................................................................6
Table of Contents ...............................................................................................................................................................................................7
List of Tables....................................................................................................................................................................................................... 8
List of Figures ......................................................................................................................................................................................................9
1/ Introduction...........................................................................................................................................................................................11
2/ Description............................................................................................................................................................................................12
2.1. Configurations............................................................................................................................................................................................13
2.2. Scope of Delivery......................................................................................................................................................................................14
3/ Installation procedure ......................................................................................................................................................................15
3.1. Installing the Board ..................................................................................................................................................................................15
3.2. Requirements IEC60950-1.....................................................................................................................................................................16
3.3. Lithium battery precautions .................................................................................................................................................................17
4/ System specifications.......................................................................................................................................................................18
4.1. Component Main Data.............................................................................................................................................................................18
4.2. Environmental Conditions....................................................................................................................................................................20
4.3. Block Diagram ...........................................................................................................................................................................................21
5/ Jumpers and Connectors ................................................................................................................................................................22
5.1. Hardware Configuration Setting .........................................................................................................................................................22
5.1.1. Jumpers and Connectors.....................................................................................................................................................................22
5.2. Mainboard Placement and I/O Locations........................................................................................................................................ 23
5.2.1. Rear Side..................................................................................................................................................................................................26
5.3. Passive Cooler (1064-7069).................................................................................................................................................................26
6/ Pin Definitions..................................................................................................................................................................................... 27
6.1. Processor Support...................................................................................................................................................................................28
6.2. System Memory Support......................................................................................................................................................................29
6.3. MicroSD and MicroSIM (J12).................................................................................................................................................................30
6.4. Ethernet Connectors (I/O area, J4).....................................................................................................................................................31
6.4.1. GBE0..........................................................................................................................................................................................................32
6.4.2. GBE1..........................................................................................................................................................................................................32
6.5. USB Connectors (I/O area, J13)............................................................................................................................................................ 32
6.6. Fan Connector (internal, J8)................................................................................................................................................................. 35
6.7. DC Power Jack Connector (12 Vin Ext., J15)...................................................................................................................................... 36
6.8. Pigtail Battery Header (J22)................................................................................................................................................................. 37
6.9. Internal Power Connector (Vin Int., J16)........................................................................................................................................... 37
6.10. USB internal (J2).....................................................................................................................................................................................38
6.11. GPIO Connector (internal, J17) ............................................................................................................................................................38
6.12. Jumper LVDS Panel Voltage (J18) .....................................................................................................................................................39
6.13. Switches....................................................................................................................................................................................................39
6.13.1. Boot Select (SW1)................................................................................................................................................................................ 39
6.13.2. MicroSD Card Write Protection (SW2).........................................................................................................................................39
6.13.3. PCIE Spread Spectrum Clocking -0.5% (SW2: 2-3)..................................................................................................................40
6.14. Buttons.......................................................................................................................................................................................................41
6.14.1. External ON-OFF Button (J24).........................................................................................................................................................41
6.14.2. External Reset (J23) ...........................................................................................................................................................................41
6.15. LVDS (Industrial Variant, internal, J11) ............................................................................................................................................42
6.16. HDMI connector (J7)..............................................................................................................................................................................43
6.17. Mini Display Port (J14)..........................................................................................................................................................................44

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 8
6.18. SPDIF Internal Audio Header (J10)....................................................................................................................................................45
6.19. SPI/I2C3 (J26)..........................................................................................................................................................................................45
6.20. M.2 Connector (B-Key) (J1) ................................................................................................................................................................46
6.21. Serial COM/RS232 P3 (J19) .................................................................................................................................................................48
6.22. Serial COM/UART P1 (J25) ..................................................................................................................................................................48
6.23. Camera connector (J5, J6)...................................................................................................................................................................49
6.24. Thermal Sensor (U24)..........................................................................................................................................................................51
7/ Bootloader Operation....................................................................................................................................................................... 52
7.1. Copyrights and Licensing of U-Boot .................................................................................................................................................. 52
7.2. Bootloader Quickstart............................................................................................................................................................................ 52
7.3. Bootloader Commands.......................................................................................................................................................................... 53
7.4. Kontron Bootloader Command Extensions ....................................................................................................................................54
7.4.1. kboardinfo - Kontron Board Information......................................................................................................................................54
7.4.2. md5sum – MD5 Message Digest ....................................................................................................................................................54
7.4.3. Watchdog – CPU Watchdog Control.............................................................................................................................................. 55
7.5. Bootloader Environment....................................................................................................................................................................... 55
7.6. Bootloader Environment Update .......................................................................................................................................................56
7.7. Kontron Bootloader Environment Extensions ................................................................................................................................57
7.8. Bootloader Mass Storage Support.....................................................................................................................................................57
7.8.1. QSPI flash .................................................................................................................................................................................................57
7.8.2. SD Card and eMMC Devices...............................................................................................................................................................57
7.8.3. USB Storage Device.............................................................................................................................................................................58
7.9. Bootloader File System Support.........................................................................................................................................................58
7.9.1. EXT4 File System Write Support......................................................................................................................................................58
7.10. Bootloader Network Support.............................................................................................................................................................58
7.11. Bootloader Boot Source Support....................................................................................................................................................... 59
7.12. Bootloader Boot Counter..................................................................................................................................................................... 59
7.13. Bootloader Update ................................................................................................................................................................................59
8/ Technical Support ..............................................................................................................................................................................61
8.1. Warranty......................................................................................................................................................................................................61
8.2. Returning Defective Merchandise ......................................................................................................................................................61
List of Acronyms..............................................................................................................................................................................................63
About Kontron ..................................................................................................................................................................................................64
List of Tables
Table 1: Component Main Data ....................................................................................................................................................................13
Table 2: Scope of Delivery pITX-iMX8M ...................................................................................................................................................14
Table 3: Scope of pITX-iMX8M Kit ..............................................................................................................................................................14
Table 4: Component Main Data ...................................................................................................................................................................18
Table 5: Environmental Conditions............................................................................................................................................................20
Table 6: Connector Definitions.................................................................................................................................................................... 27
Table 7: Processor Support..........................................................................................................................................................................28
Table 8: Pin Assignment MicroSIM Combo Socket...............................................................................................................................30
Table 9: Pin Assignment Dual Ethernet.....................................................................................................................................................31
Table 10: Left LED Signal Description .......................................................................................................................................................32
Table 11: Right LED Signal Description......................................................................................................................................................32
Table 12: Pin Assignment Dual USB........................................................................................................................................................... 33
Table 13: Signal Description......................................................................................................................................................................... 33
Table 14: Fan Header Mapping.................................................................................................................................................................... 35
Table 15: Signal Description ......................................................................................................................................................................... 35

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 9
Table 16: Power Jack Connector .................................................................................................................................................................36
Table 17: Pin Assignment .............................................................................................................................................................................. 37
Table 18: Internal Power Connector.......................................................................................................................................................... 37
Table 19: USB Internal Connection.............................................................................................................................................................38
Table 20: GPIO Connector .............................................................................................................................................................................38
Table 21: LVDS Panel Voltage ......................................................................................................................................................................39
Table 22: Boot Select Switch (SW1)...........................................................................................................................................................39
Table 23: MicroSD Card Write Protection Switch .................................................................................................................................39
Table 24: PCIE Spread Spectrum Clocking -0.5% Switch...................................................................................................................40
Table 25: External ON-OFF Button .............................................................................................................................................................41
Table 26: External Reset Button..................................................................................................................................................................41
Table 27: LVDS Pin Assignment ..................................................................................................................................................................42
Table 28: HDMI Mapping...............................................................................................................................................................................43
Table 29: Mini Display Port...........................................................................................................................................................................44
Table 30: Pin Assignment J9 ........................................................................................................................................................................45
Table 31: SPI/I2C Pin Assignment...............................................................................................................................................................45
Table 32: Pin Assignment .............................................................................................................................................................................46
Table 33: Pin Assignment .............................................................................................................................................................................48
Table 34: Pin Assignment .............................................................................................................................................................................48
Table 35: Pin Assignment (J5)......................................................................................................................................................................49
Table 36: Pin Assignment (J6) .....................................................................................................................................................................49
Table 37: Bootloader Command Extensions ..........................................................................................................................................54
Table 38: Standard Environment Variables............................................................................................................................................ 56
Table 39: Bootloader Environment Extensions......................................................................................................................................57
Table 40: Environment Variables for "boot_sel" .................................................................................................................................. 59
List of Figures
Figure 1: pITX-Board iMX8M .........................................................................................................................................................................13
Figure 2: Block Diagram..................................................................................................................................................................................21
Figure 3: Front Side.........................................................................................................................................................................................23
Figure 4: Interfaces.........................................................................................................................................................................................24
Figure 5: Front View Jumpers/Switches.................................................................................................................................................. 25
Figure 6: Rear Side...........................................................................................................................................................................................26
Figure 7: Passive Cooler ................................................................................................................................................................................26
Figure 8: Block Diagram i.MX8M processor (Source: NXP) ...............................................................................................................29
Figure 9: Combo Connector for MicroSD and MicroSIM .....................................................................................................................30
Figure 10: Ethernet Connector RJ-45 Jack with Integrated Magnetic .............................................................................................31
Figure 11: USB 2.0/3.0 socket.......................................................................................................................................................................33
Figure 12: USB 2.0 High Speed Cable .........................................................................................................................................................34
Figure 13: USB 3.0 High Speed Cable .........................................................................................................................................................34
Figure 14: 3-pin Fan Connector ................................................................................................................................................................... 35
Figure 15: Power Jack Connector ................................................................................................................................................................ 36
Figure 16: Pigtail Battery Header................................................................................................................................................................ 37
Figure 17: Internal Power Connector ......................................................................................................................................................... 37
Figure 18: USB Internal Connector .............................................................................................................................................................38
Figure 19: GPIO Connector.............................................................................................................................................................................38
Figure 20: LVDS Panel Voltage....................................................................................................................................................................39
Figure 21: LVDS Connector (optional) .......................................................................................................................................................42
Figure 22: 19-pin HDMI connector..............................................................................................................................................................43
Figure 23: Mini Display Port .........................................................................................................................................................................44
Figure 24: SPDIF Internal Header ...............................................................................................................................................................45
Figure 25: M.2 Connector (B-Key)..............................................................................................................................................................46
Figure 26: Serial COM/RS232 ......................................................................................................................................................................48
Figure 27: Serial COM UART P1 ....................................................................................................................................................................48
Figure 28: 24-pin Camera CSI Connector.................................................................................................................................................49

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 10
Figure 29: Sensor Location (red circle) .....................................................................................................................................................51
Figure 30: U-Boot Start Screen................................................................................................................................................................... 53

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 11
1/ Introduction
This manual describes the pico-ITX board with five processors from NXP: i.MX8M QuadLite with 1.5 GHz, i.MX8M
Dual with 1.3 GHz and 1.5 GHz, i.MX8M Quad with 1.3 GHz and 1.5 GHz. This board will also be denoted pITX-iMX8M
within this Users Guide.
The use of this Users Guide implies a basic knowledge of PC hard- and software. This manual is focussed on
describing the pITX-iMX8M board’s special features and is not intended to be a standard PC textbook.
New users are recommended to study the short installation procedure stated in the following chapter before
switching-on the power.
All configuration and setup of the CPU board is either done automatically or manually by the user via the U-Boot
setup menus.
Latest revision of this manual, datasheet, U-Boot scripts, drivers, BSPs (Board Support Packages) can be
downloaded from Kontron Web Page.

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 12
2/ Description
The board is based on the NXP´s i.MX8M processor with either dual or quad core ARM. It is mechanically compliant
to the Pico-ITX (pITX) specification. Board key features are:
1x 200-pin 32-bit LPDDR4 3200 MT/s memory (up to 4 GB),
1x 153-pin eMMC v5.1 storage (Up to 128 GB MLC/64 GB pseudoSLC),
Support graphic interfaces of 1x mini DP, 1x Internal Dual Channel LVDS Header, 1x HDMI, 2x Internal MIPI-
CSI (2 lanes each) headers,
1x M.2 B-Key half-size connector with PCIe, USB 3.0/2.0 and micro SIM interface,
1x Dual-Stacked USB 3.0 Rear Port,
1x USB OTG microUSB Type AB socket
1x USB 2.0 via Internal Header
2x 10/100/1000 Gigabit Ethernet Rear Port
1x 4-wire RS-232 Serial Port via Internal Header
2x 2-wire RS-232/UART Serial Port via Internal Header
1x Internal Front Panel Header for Line-In/Out and Microphone
1x SPDIF Internal Header
TPM 2.0
1x Internal Header for up to 8x configurable GPIOs
1x 5 V Fan Connector
Temperature Sensor
+12V DC Input via locking barrel-type connector or Internal Power Header
pITX form factor and cooling solution
Built with these functions, pITX-iMX8M Mother Board is ideal for ATM, Automation, Kiosk applications, medical
equipment, industrial automation, financial automation, process control, semiconductor equipment and network
security markets.

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 13
2.1. Configurations
Kontron offers the pITX-iMX8M in different configurations. The products can be ordered in four different flavors.
Table 1: Component Main Data
Product Number Article Dedcription
44011-0408-13-4
pITX-iMX8M Quad Core
Industrial
pITX-imx8m with NXP Arm® Cortex®-A53 Quad
Core™ Industrial, 1300 MHz, 4 GByte LPDDR4, 8
GByte eMMC (pSLC), Industrial Temp.
44011-0408-15-4
pITX-iMX8M Quad Core
Consumer
pITX-imx8m with NXP Arm® Cortex®-A53 Quad
Core Commercial, 1500 MHz, 4 GByte LPDDR4, 16
GByte eMMC (MLC), Consumer Temp.
44011-0416-15-4lit
pITX-iMX8M Quad Lite
Consumer
pITX-imx8m with NXP Arm® Cortex®-A53 Quad
Lite Commercial, 1500 MHz, 4 GByte LPDDR4, 16
GByte eMMC (MLC), Consumer Temp.
44011-0208-13-2 pITX-iMX8M Dual Core
Industrial
pITX-imx8m with NXP Arm® Cortex®-A53 Dual
Core Industrial, 1300 MHz, 2 GByte LPDDR4, 8
GByte eMMC (pSLC), Industrial Temp.
44011-0216-15-2 pITX-iMX8M Dual Core
Consumer
pITX-imx8m with NXP Arm® Cortex®-A53 Dual
Core Commercial, 1500 MHz, 2 GByte LPDDR4, 16
GByte eMMC (MLC), Dolby Feature, Consumer
Temp.
Warning: If changing the premounted cooling system, then the system might get overheated
resulting in instable system or defects if the cooling system is insufficient.
Figure 1: pITX-Board iMX8M

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 14
2.2. Scope of Delivery
Table 2: Scope of Delivery pITX-iMX8M
Part Description
Module pITX-iMX8M
Miscellaneous Quick Installation Guide
Table 3: Scope of pITX-iMX8M Kit
Part Part No. Description
Module pITX-iMX8M
Power Supply 1067-1755 12 V Power Supply: SCM PSU AC/DC
60W 12V KYCON (0-40°C), AC Power
Cord Europe
Cooling 1064-7069 Passive Cooler: heatsink with
adhesive tape Fischer ICK S 25 X 25 X
12,5 + WLFT404
Software Linux-Image
Miscellaneous Foam Package, Quick Installation
Guide

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 15
3/ Installation procedure
3.1. Installing the Board
ESD Sensitive Device!
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry.
•Wear ESD-protective clothing and shoes
•Wear an ESD-preventive wrist strap attached to a good earth ground
•Check the resistance value of the wrist strap periodically (OK: 1 MΩto 10 MΩ)
•Transport and store the board in its antistatic bag
•Handle the board at an approved ESD workstation
•Handle the board only by the edges
To get the board running follow these steps. If the board shipped from Kontron has already components like RAM
and CPU cooler mounted, then relevant steps below can be skipped.
1.
Turn off the PSU (Power Supply Unit)
Turn off PSU (Power Supply Unit) completely (no mains power connected to the PSU)
or leave the Power Connectors unconnected while configuring the board. Otherwise
components (RAM, LAN cards etc.) might get damaged. Make sure to use +5V single supply
only. Alternatively use a standard ATX PSU with suitable cable kit and PS_ON# active.
2.
Cooler Installation
Normally the cooler is premounted, but in case not, then make sure that the heat paste etc. on the cooler is
intact and cover the full area of the SoC. Connect cooler fan electrically to the FAN_CPU connector.
3.
Connecting Interface
s
Insert all external cables for keyboard etc.
4.
Connect and turn on PSU
Connect PSU to the board by the ATX+5 V-4pin connector or alternatively connect an external 5 V DC power
adapter to the rear DC jack.
5.
U-Boot Setup
Enter the U-Boot setup, more information in Chapter 7/.
6. Mounting the board in chassis

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 16
When mounting the board to chassis etc. please notice that the board contains components
on both sides of the PCB which can easily be damaged if board is handled without
reasonable care. A damaged component can result in malfunction or no function at all.
When fixing the Motherboard on a chassis it is recommended to use screws with integrated washer and a
diameter of >7 mm. Do not use washers with teeth, as they can damage the PCB and cause short circuits.
3.2. Requirements IEC60950-1
Take care when designing chassis interface connectors in order to fulfil the IEC60950-1 standard. Users of pITX-
iMX8M must evaluate the end product to ensure compliance the requirements of the IEC60950-1 safety standard
are met:
The motherboard must be installed in a suitable mechanical, electrical and fire enclosure.
The system in its enclosure must be evaluated for temperature and air flow considerations.
The motherboard must be powered by a CSA or UL approved power supply that limits the maximum input
current to 6A to an external 5 V locking barrel-type DC jack or to an internal 5 V 4-pin DC power
connector.
For interfaces having a power pin such as external power or fan, ensure that the connectors and wires are
suitably rated. All connections from/to the product shall be with SELV circuits only.
Wires have suitable rating to withstand the maximum available power.
The enclosure of the peripheral device fulfils the fire protecting requirements of IEC60950-1.

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 17
3.3. Lithium battery precautions
Danger of explosion if the lithium battery is incorrectly replaced.
•Replace only with the same or equivalent type recommended by the manufacturer
•Dispose of used batteries according to the manufacturer’s instructions
VORSICHT! Explosionsgefahr bei unsachgemäßem Austausch der Batterie.
•Ersatz nur durch denselben oder einen vom Hersteller empfohlenen Typ
•Entsorgung gebrauchter Batterien nach Angaben des Herstellers
ATTENTION! Risque d'explosion avec l'échange inadéquat de la batterie.
•Remplacement seulement par le même ou un type équivalent recommandé par le
producteur
•L'évacuation des batteries usagées conformément à des indications du fabricant
PRECAUCION! Peligro de explosión si la batería se sustituye incorrectamente.
•Sustituya solamente por el mismo o tipo equivalente recomendado por el fabricante
•Disponga las baterías usadas según las instrucciones del fabricante
ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering.
•Udskiftning må kun ske med batteri af samme fabrikat og type
•Levér det brugte batteri tilbage til leverandøren.
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri.
•Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
•Brukte batterier kasseres i henhold til fabrikantens instruksjoner
VARNING! Explosionsfara vid felaktigt batteribyte.
•Använd samma batterityp eller en ekvivalent typ som rekommenderas av
apparattillverkaren.
•Kassera använt batteri enligt fabrikantens instruktion.
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu.
•Vaihda paristo ainoastaan lalteval- mistajan suosittelemaan tyyppiln
•Hävitä käytetty paristo valmistajan ohjeiden mukaisesti

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 18
4/ System specifications
4.1. Component Main Data
The table below summarizes the features of the pITX-iMX8M embedded motherboard.
Table 4: Component Main Data
Motherboard pITX-iMX8M
Form factor Pico-ITX (100 mm by 72 mm by 1.6 mm/Length x Width x Thickness)
Mechanical
Dimensions with
cooling
100 mm x 72 mm x 41 mm (Length x Width x Height)
Processor Onboard CPU variants, SKU dependent:
8M Quad (1.3 GHz/Industry)
8M Quad (1.5 GHz/Consumer)
8M QuadLite (1.5 GHz/Consumer)
8M Dual (1.3 GHz/Industry)
8M Dual (1.5 GHz/Consumer)
SPI Flash 
Winbond W25Q128
Macronix MX25L128
Micron N25Q128
EEPROM Atmel AT24C32 for board information
Memory up to 4 GB LPDDR4 3200 MTps Memory Down
eMMC up to 128 GB MLC or 64GB pSLC eMMC Memory v5.1
Onboard Controllers
Display Switches DSI -DP
DSI - LVDS
USB Hub 1x USB3.0 Hub
1x USB2.0 Hub
Audio 1x Cirrus WM8904 Audio Codec
Ethernet PHY 2x 10/100/1000 Gigabit Ethernet PHY
Serial Port 1x Texas Instruments MAX3232 RS-232 Transceiver
Temp Sensor 1x Texas Instruments LM75B
Fan Regulator and
Monitor
1x Maxim Integrated MAX6650
TPM Infineon SLB9670XQ2.0
Input /Output
PCIe 1x PCIe from M.2 B-Key Half-size connector
Storage 1x eMMC v5.1 with up to 128 GB MLC/64 GB pseudoSLC capacity
Ethernet 2x 10/100/1000 Gigabit Ethernet with integrated magnetic and LEDs at rear I/O
USB 1x Dual-stacked USB3.0 at rear I/O
2x USB2.0 from internal headers
1x USB 3.0 from M.2 B-Key half-size connector
Power 1x Locking barrel-type DC Power Jack
1x Internal 4-pin Power connector

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 19
Dual Channel LVDS Dual channel LVDS, 18 bit support, 24 bit (VESA mapping) support, 24 bit (Open LDI
mapping) support,
Resolution: up to 60 fps at 1920 x 1080 pixel
HDMI 1x HDMI2.0a at rear I/O
Suitable for 60 fps 1920 x 1080 pixel (24 b/px), 30 fps 3840 x 2160 pixel (24 b/px), 3840 x
2160 pixel (24 b/px) 30 fps
Mini DP 1x Mini Display port at rear I/O
Resolution: up to 60 fps at 1920 x 1080 pixel
Audio 1x SPDIF internal headers
1x Line-In, Line-Out and Microphone-In headers at rear I/O
GPIO 8x GPIO (Interrupt Capable)
MIPI-CSI 2x MIPI-CSI (2-lane) routed to onboard MIPI CSI Connector
COM 1x RS232 2-wire serial port from internal header
Battery 1x 2-pin header for BR2032/CR2032 external pigtail battery
Software BSPs
Software Linux 64-bit Yocto, Android Version 7.0 or higher
U-Boot LAN Enable/Disable with TFTP Server
Danger of explosion if the lithium battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer
Dispose of used batteries according to the manufacturer’s instructions

pITX-iMX8M – Rev. 0.7 Preliminary
www.kontron.com // 20
4.2. Environmental Conditions
Table 5: Environmental Conditions
Storage
Temperature
IEC 60068-2-1 60068-2-2
-40°C to +85°C
Operating
Temperature
IEC 60068-2-1 60068-2-2
-40°C to +85°C for Extended Consumer Variants
0°C to +60°C for Commercial Temperature Variants
Humidity IEC 60068-2-78
50% to 95% Relative Humidity at 25°C to 30°C, non- condensing
RoHS RoHS II compliant
REACH Compliance Regulation (EC) No 1907/2006
EMC and EMI EN55022 [Must compliance with no deviation allowed] Class B radiated and conducted
EN 61000-6-3:2007 [Must compliance with no deviation allowed]
(EMC) Generic emission standard Part 6-4: Emission standard for commercial
environments
IEC 61000 PT4-2, (EN 61000-4-2) Electrostatic discharge immunity ESD
IEC 61000 PT4-3, (EN 61000-4-3 and ENV 50204) Radiated
Field
IEC 61000 PT4-4, (EN 61000-4-4) Electrical fast transient/burst (EFT) BURST
IEC 61000 PT4-5, (EN 61000-4-5) Surge immunity test
IEC 61000 PT4-6, (EN 61000-4-6) Immunity to conducted disturbances
IEC 61000 PT4-8, (EN 61000-4-8) Immunity to magnetic fields (LOW)
IEC 61000 PT4-11, (EN 61000-4-11) Testing and measuring techniques-voltage dips, short
interruption, and voltage variations immunity tests
Safety EN 62368-1
Safety for information technology equipment including electrical business equipment
Altitude 2000m max
Shock IEC 60068-2-27
Half-sine wave, Acceleration: 2g Pulse duration: 11ms
Number of shocks: 600 shocks (100 shocks for each face)
Vibration IEC 60068-2-64
Test Fh, Random Vibration, 90 min per axis, 3 axes at 1.9 grms, with PSD: 10-20Hz: 0.05
g²/Hz and 20-500 Hz:- 3dB/octave.
Reliability
including MTBF
5 years x 365 days x 24 hours
The MTBF value according to Telcordia standard
Power Supply Specifications
Voltage Ripple Voltage Ripple maximum 100 mV peak to peak 0-20 MHz
Rise Time 2 ms to 20 ms rise time from input voltage <10% to nominal VCC
If any of the supply voltages drops below the allowed operating level longer than the
specified hold-up time, all the supply voltages should be shut down and left OFF for a time
long enough to allow the internal board voltages to discharge sufficiently.
If the OFF time is not observed, parts of the board or attached peripherals may work
incorrectly or even suffer a reduction of MTBF.
The minimum OFF time depends on the implemented PSU model and other electrical factors
and needs to be measured individually for each case.
