®Getting Started
Connector & Switch Locations:
®Introduction
ETXexpress Eval Type 3
Evaluation Carrier Board
38200-0000-00-0/1
This Quick Reference Guide provides Jumper and Connector locations for the
ETXexpress Eval Type 3, an ETXexpress (ETXe) Carrier Board designed by Kontron
to host ETXexpress Type 2 and Type 3 Modules. You can find Connector and Jumper
names and descriptions on the next page. For complete information on Carrier
Board design, pin-outs, connectors, and Module Types 2 and 3, please refer to the
Design Guide for ETXexpress Carrier Boards, which you can obtain from your local
Kontron America sales office. Please refer to individual ETXexpress Module User
Guides for more information. They also are available on the Kontron Web site.
For Technical Support, please contact: 1-800-480-0044, option 1 (U.S. and Canada) or ([phone] (International)
The following information explains how to set up your ETXexpress Eval Type 3
Carrier Board and ETXexpress-WPM, a Type 3 Module.
1. In an ESD-protected area, remove the ETXexpress Carrier Board and ETXexpress
Module from their packaging.
2. If necessary, install memory and a processor on the ETXexpress Module.
3. Depending on your application, attach a fan, a heat sink, and a heat-spreader
plate to the Module if needed.
4. Insert the ETXexpress Module into Connector J22 on the Carrier Board.
5. Plug the ATX power supply into a surge protector that is plugged into an
electrical outlet. Make sure that the external Power Supply is in the “Off”
position.
6. Insert the ATX power cable into Connector J41 on the Carrier Board. Insert the
AUX power (+12V) cable into Connector J42 to power the ETXexpress Module.
7. Disable the Carrier Board’s BIOS by removing the jumper on Connector J16.
8. Insert a keyboard (bottom) and a mouse (top) into the PS/2 connectors (J5).
9. On the Carrier Board, plug in a storage device to the appropriate Connector:
Compact Flash (J40), IDE hard drive (J38), and SATA (J10, J12, J13, J14).
10. Turn on power.
COMPACT MODULE
BASIC MODULE
EXTENDED MODULE
J21
JP2
JP18
J27
J28
J31
J32
J34
J36
J39
J23
J24
J25
J26
J29 J30
J33
J37
J38
J40 J41 J42
J35
JP19
J22
J10
J12-J14
J11
J15
J16 J17 J18 J19 J20
J4 J6 J2J3 J1 J5
SW1
SW2
J8
J7
U1
U4 J9 JP1
JP20
mounting
hole
Quick Reference

®Jumpers: ®Connectors:
For Technical Support, please contact: 1-800-480-0044, option 1 (U.S. and Canada) or ([phone] (International)
ETXexpress Eval Type 3 Quick Reference
Connector Function Description
J1 VGA Female DB15
J2 USB2/3 Dual USB type A
J3 Audio Connectors 3.5mm Phono Jacks
J4 Ethernet, USB0/1 RJ45, Dual USB type A
J5 Keyboard/Mouse PS/2 Combo
J6 2x Gigabit Ethernet Dual RJ45
J7 Alt. AC97 Audio Interface 2x 5-pin friction header
J8 CD Audio Input 4-pin friction header
J9 Alternate BIOS Socket 32-pin PLCC socket
J10 SATA data port1 7-pin Serial ATA
J11 LPC Slot 60-contact card edge slot
J12 SATA data port3 7-pin Serial ATA
J13 SATA data port0 7-pin Serial ATA
J14 SATA data port2 7-pin Serial ATA
J15 PCI slot 124-pin 5V 32bit PCI
J16 PCI-Express x4 slot4 164-contact card edge slot
J17 PCI-Express x4 slot3 164-contact card edge slot
J18 PCI-Express x4 slot2 164-contact card edge slot
J19 PCI-Express x4 slot1 164-contact card edge slot
J20 PCI-Express x4 slot0 164-contact card edge slot
J21 JTAG Header 8-pin header
J22 COM-Express Interface COM-Express A/B/C/D
J23 USB6/7 2x 5-pin header
J24 CMOS battery backup coin battery slot
J25 LVDS Video Interface 40-pin Hirose ribbon conn.
J26 USB4/5 2x 5-pin header
J27 Fan Header w/Tach and
Speed Control 3-pin friction header
J28 Fan Header 3-pin friction header
J29 COM1 2x 5 header
J30 COM2 2x 5 header
J31 Fan Header 3-pin friction header
J32 Hard Drive Act. LED Interface 2-pin friction header
J33 Parallel Port 2x 13 header
J34 System PWR ON/OFF 2-pin friction header
J35 GPIO 2x 5-pin header
J36 System RESET header 2-pin friction header
J37 COM3 2x 5 header
J38 IDE 2x 20 header
J39 SMBus connector 3-pin friction header
J40 Compact Flash IDE 2x 25 CF Conn.
J41 ATX Power 24-pin Molex
J42 AUX Power 4-pin Molex
SW1 System RESET switch Momentary switch
SW2 System PWR ON/OFF switch Momentary switch
U1 POST Code 7-Seg LED (LSB) POST Code LSB
U4 POST Code 7-Seg LED (MSB) POST Code MSB
Jumper Description
JP1 Firmware Hub Write-Protection for both Module
and Baseboard FWH's
JP2
JP3
PCI SLOT IDSEL & INT SIGNAL SELECT
JP2 = S3, JP3 = S2
Emulate
Slot#
Shunt
S3
Shunt
S2
Signal
IDSEL
Signal
INTA#
Signal
INTB#
Signal
INTC#
Signal
INTD#
0 0 0 AD[20] INTA# INTB# INTC# INTD#
1 0 1 AD[21] INTB# INTC# INTD# INTA#
2 1 0 AD[22] INTC# INTD# INTA# INTB#
3 1 1 AD[23] INTD# INTA# INTB# INTC#
JP4
JP5
PCI SLOT REQ & GNT SIGNAL SELECT
JP4 = S0, JP5 = S1
Emulate
Slot#
Shunt
S1
Shunt
S0
Signal
REQ#
Signal
GNT##
0 0 0 REQ0# GNT0#
1 0 1 REQ1# GNT1#
2 1 0 REQ2# GNT2#
3 1 1 REQ3# GNT3#
JP6 S3_PSON_CNTL#
JP7 S4_PSON_CNTL#
JP8 S5_PSON_CNTL#
JP9 P/S OFF (STBY Only)
JP10 P/S ON (AT Mode)
JP11 Express Card Detect Test for Card0
JP12 Express Card Detect Test for Card1
JP13 THRM# Test
JP14 Alternate SIO Disable
JP15 SIO Disable
JP16 CPU Module BIOS Disable (Boot from Carrier Board BIOS)
JP17 ETX COM Enable for COM3
JP18 Battery Low Test
JP19 +5VSBY Jumper (Remove for 12V Only operation)
JP20 Compact Flash M/S
