Kontron speedMOPSlcdCE User manual

speedMOPSlcdCE
User’s Guide
Document Revision 1.2

KONTRON
speedMOPSlcdCE User’s Guide Contents
i
CONTENTS
1. USER INFORMATION...............................................................................................1
1.1 About This Manual..........................................................................................1
1.2 Copyright Notice............................................................................................1
1.3 Trademarks...................................................................................................2
1.4 Standards ....................................................................................................2
1.5 Warranty......................................................................................................2
1.6 Technical Support ..........................................................................................3
2. INTRODUCTION .....................................................................................................4
2.1 speedMOPSlcdCE............................................................................................4
2.2 The speedMOPS Family ....................................................................................4
3. GETTING STARTED ..................................................................................................6
4. SPECIFICATIONS....................................................................................................7
4.1 Functional Specifications.................................................................................7
4.2 Mechanical Specifications................................................................................9
4.2.1. PC/104 Bus Connector (ISA part).................................................................9
4.2.2. PC/104-Plus Bus Connector (PCI part)...........................................................9
4.2.3. Dimensions.............................................................................................9
4.2.4. Height on Top..........................................................................................9
4.2.5. Height on Bottom.....................................................................................9
4.2.6. Weight...................................................................................................9
4.3 Electrical Specifications ................................................................................10
4.3.1. Supply Voltage ...................................................................................... 10
4.3.2. Supply Voltage Ripple ............................................................................. 10
4.3.3. Supply Current (typical)...........................................................................10
4.3.4. Supply Current (maximum)....................................................................... 11
4.3.5. Real-time Clock (RTC) Battery.................................................................... 11
4.4 MTBF......................................................................................................... 12
4.5 Environmental Specifications ......................................................................... 13
4.5.1. Temperature ......................................................................................... 13
4.5.2. Humidity.............................................................................................. 13
5. CPU, CHIPSET AND SUPER I/O ................................................................................14
5.1 CPU........................................................................................................... 14
5.2 Chipset ...................................................................................................... 15
5.2.1. GMCH (815E Chipset) .............................................................................. 15
5.2.2. ICH4 (82801DB).....................................................................................16
5.3 Super I/O ................................................................................................... 17
5.4 CPU, Chipset and Super-I/O Configuration......................................................... 17
6. SYSTEM MEMORY .................................................................................................18
7. ISA AND PCI BUS EXPANSION.................................................................................19

KONTRON
Contents ii speedMOPSlcdCE User’s Guide
7.1 PC/104 Bus (ISA part)................................................................................... 19
7.1.1. PC/104 Connectors ................................................................................. 19
7.1.2. PC/104 Configuration.............................................................................. 20
7.2 PC/104-Plus (PCI part) .................................................................................. 20
7.2.1. PC/104-Plus Connector ............................................................................ 20
7.2.2. PC/104-Plus Configuration ....................................................................... 20
8. GRAPHICS INTERFACES .........................................................................................21
8.1 Video Controller ..........................................................................................21
8.2 CRT Connector ............................................................................................. 21
8.3 Flat Panel LVDS Interface (JILI) Connector ........................................................ 22
8.4 Display Power Considerations ......................................................................... 22
8.5 Connecting a LCD Panel ................................................................................. 23
8.6 Configuration.............................................................................................. 23
8.7 Graphics Technical Support ............................................................................ 23
8.8 Available Video Modes .................................................................................. 24
8.8.1. Standard IBM-Compatible VGA Modes ......................................................... 24
8.8.2. Extended VESA VGA Modes........................................................................ 24
9. SERIAL-COMMUNICATION INTERFACES.....................................................................25
9.1 Connectors .................................................................................................25
9.2 Configuration.............................................................................................. 25
10. PARALLEL-PORT INTERFACE...................................................................................26
10.1 Connector .................................................................................................. 26
10.2 Configuration.............................................................................................. 27
11. KEYBOARD AND FEATUREINTERFACE .......................................................................28
11.1 Connector .................................................................................................. 28
11.2 Signal Descriptions ...................................................................................... 29
11.2.1. Example Connection AT-keyboard and Other Functions ................................ 30
11.3 Configuration.............................................................................................. 30
12. PS/2 MOUSE INTERFACE........................................................................................31
12.1 Connector .................................................................................................. 31
12.2 Configuration.............................................................................................. 31
13. USB INTERFACES .................................................................................................32
13.1 Connector .................................................................................................. 32
13.1.1. Limitations ........................................................................................ 32
13.2 Configuration.............................................................................................. 33
14. FLOPPY INTERFACE ..............................................................................................34
14.1 Connector .................................................................................................. 34
14.1.1. Connector Diagram .............................................................................. 35
14.2 Configuration.............................................................................................. 35
15. IDE INTERFACES..................................................................................................36

KONTRON
speedMOPSlcdCE User’s Guide Contents
iii
15.1 Connector .................................................................................................. 36
15.2 Configuration.............................................................................................. 37
16. ETHERNET INTERFACES .........................................................................................38
16.1 First Ethernet Controller................................................................................38
16.2 Second Ethernet Controller (optional) .............................................................. 39
16.3 Connectors .................................................................................................40
16.4 Configuration.............................................................................................. 40
16.5 Ethernet Technical Support ............................................................................ 40
17. SOUND INTERFACE...............................................................................................41
17.1 Connector .................................................................................................. 42
17.2 Configuration.............................................................................................. 42
17.3 Technical Support for Sound...........................................................................42
18. FAN INTERFACE ...................................................................................................43
18.1 Connector .................................................................................................. 43
18.2 Configuration.............................................................................................. 43
19. POWER INTERFACE...............................................................................................44
19.1 Main Power Connector................................................................................... 44
19.2 Auxiliary Power Connector ............................................................................. 44
19.3 Power Pins.................................................................................................. 45
19.4 Configuration.............................................................................................. 45
19.5 External Battery ..........................................................................................46
20. WATCHDOG TIMER ...............................................................................................47
20.1 Configuration.............................................................................................. 47
20.2 Programming .............................................................................................. 47
20.2.1. Initializing the WDT.............................................................................. 47
20.2.2. Triggering the WDT............................................................................... 47
21. HARDWARE MONITOR...........................................................................................48
21.1 Configuration.............................................................................................. 48
22. THERMAL MANAGEMENT .......................................................................................49
23. APPENDIX A: SYSTEM-RESOURCE ALLOCATION...........................................................50
23.1 Interrupt Request (IRQ) Lines......................................................................... 50
23.2 Direct Memory Access (DMA) Channels.............................................................. 51
23.3 Memory Map ...............................................................................................51
23.3.1. Using Expanded Memory Managers..........................................................52
23.4 I/O Address Map ..........................................................................................53
23.5 Peripheral Component Interconnect (PCI) Devices............................................... 54
23.6 SM Bus Devices ............................................................................................ 54
24. APPENDIX B: BIOS OPERATION ...............................................................................55
24.1 Determining the BIOS Version......................................................................... 55

KONTRON
Contents iv speedMOPSlcdCE User’s Guide
24.2 Configuring the System BIOS .......................................................................... 56
24.2.1. Start Phoenix BIOS Setup Utility ............................................................. 56
24.2.2. General Information............................................................................. 56
24.3 Main Menu .................................................................................................58
24.3.1. Master or Slave Submenus ..................................................................... 59
24.4 Advanced Menu ........................................................................................... 60
24.4.1. Advanced Chipset Control Submenu......................................................... 60
24.4.2. PCI/PNP Configuration Submenu............................................................. 61
24.4.3. PCI Device, Slot #x Submenu .................................................................. 61
24.4.4. PCI/PNP ISA IRQ Resource Exclusion Submenu ........................................... 62
24.4.5. Memory Cache Submenu........................................................................ 63
24.4.6. I/O Device Configuration Submenu.......................................................... 64
24.4.7. Keyboard Features Submenu .................................................................. 65
24.4.8. Hardware Monitor Submenu................................................................... 65
24.4.9. Watchdog Timer Settings Submenu.......................................................... 66
24.4.10. Display Control Submenu ......................................................................66
24.4.11. Miscellaneous Submenu ........................................................................ 67
24.5 Security Menu ............................................................................................. 68
24.6 Power Menu ................................................................................................ 69
24.6.1. Thermal Management Submenu .............................................................. 70
24.7 Boot Menu and Utilities................................................................................. 71
24.7.1. MultiBoot XP ...................................................................................... 71
24.7.2. Boot First Function .............................................................................. 72
24.8 Exit Menu ................................................................................................... 73
24.9 Kontron BIOS Extensions ............................................................................... 74
24.9.1. JIDA BIOS extension ............................................................................ 74
24.9.2. Remote Control Client Extension ............................................................. 74
24.9.3. LAN PXE ROM ...................................................................................... 75
24.10 Updating or Restoring BIOS Using PhoenixPhlash ............................................ 76
24.10.1. Flashing a BIOS ................................................................................... 76
24.10.2. Preventing Problems When Updating or Restoring BIOS ............................... 77
25. APPENDIX C: BLOCK DIAGRAM ...............................................................................78
26. APPENDIX D: MECHANICAL DIMENSIONS..................................................................79
26.1 Board Dimensions and Mounting Holes ............................................................. 79
26.1.1. Top View ............................................................................................ 79
26.1.2. Side View ........................................................................................... 80
27. APPENDIX E: CONNECTOR LAYOUT...........................................................................81
27.1 Top Side..................................................................................................... 81
27.2 Bottom Side ...............................................................................................82
27.3 Connector Functions and Interface Cables ......................................................... 83
27.4 Pin-out Table .............................................................................................. 84
28. APPENDIX F: PC ARCHITECTURE INFORMATION ..........................................................88
28.1 Buses ........................................................................................................ 88

KONTRON
speedMOPSlcdCE User’s Guide Contents
v
28.1.1. ISA, Standard PS/2 - Connectors ............................................................. 88
28.1.2. PC/104, PCI........................................................................................ 88
28.2 General PC Architecture ................................................................................. 89
28.3 Ports ......................................................................................................... 89
28.3.1. RS-232 Serial...................................................................................... 89
28.3.2. ATA .................................................................................................. 90
28.3.3. USB.................................................................................................. 90
28.4 Programming .............................................................................................. 90
29. APPENDIX G: DOCUMENT REVISION HISTORY.............................................................91

KONTRON
Contents vi speedMOPSlcdCE User’s Guide

KONTRON
speedMOPSlcdCE User’s Guide User Information
1
1. USER INFORMATION
1.1 About This Manual
This document provides information about products from KONTRON Embedded Computers AG
and/or its subsidiaries. No warranty of suitability, purpose, or fitness is implied. While every
attempt has been made to ensure that the information in this document is accurate, the
information contained within is supplied “as-is” and is subject to change without notice.
For the circuits, descriptions and tables indicated, KONTRON assumes no responsibility as far as
patents or other rights of third parties are concerned.
1.2 Copyright Notice
Copyright © 2005 KONTRON Embedded Computers AG.
All rights reserved. No part of this manual may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any form or by any
means (electronic, mechanical, photocopying, recording, or otherwise), without the express
written permission of KONTRON.
JUMPtec Industrielle Computertechnik AG and KONTRON Embedded Computers AG merged in July
2002. JUMPtec is now known as KONTRON Embedded Modules GmbH. Products labeled and sold
under the KONTRON Embedded Modules name (formerly JUMPtec) are now considered KONTRON
products for all practical purposes, including warranty and support.
DIMM-PC®, PISA®, ETX Components SBC, JUMPtec®, and KONTRON Embedded Modules are
registered trademarks of KONTRON Embedded Modules GmbH©.

KONTRON
User Information 2 speedMOPSlcdCE User’s Guide
1.3 Trademarks
The following lists the trademarks of components used in this board.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business
Machines Corp.
Microsoft is a registered trademark of Microsoft Corp.
Intel is a registered trademark of Intel Corp.
All other products and trademarks mentioned in this manual are trademarks of their
respective owners.
1.4 Standards
KONTRON Embedded Modules is certified to ISO 9000 standards.
1.5 Warranty
This KONTRON Embedded Modules product is warranted against defects in material and
workmanship for the warranty period from the date of shipment. During the warranty period,
KONTRON Embedded Modules will at its discretion decide to repair or replace defective products.
Within the warranty period, the repair of products is free of charge as long as warranty conditions
are observed.
The warranty does not apply to defects resulting from improper or inadequate maintenance or
handling by the buyer, unauthorized modification or misuse, operation outside of the product’s
environmental specifications or improper installation or maintenance.
KONTRON Embedded Modules will not be responsible for any defects or damages to other products
not supplied by KONTRON Embedded Modules that are caused by a faulty KONTRON Embedded
Modules product.

KONTRON
speedMOPSlcdCE User’s Guide User Information
3
1.6 Technical Support
Technicians and engineers from KONTRON Embedded Modules and/or its subsidiaries and official
distributors are available for technical support. We are committed to making our product easy to
use and will help you use our products in your systems.
Before contacting KONTRON Embedded Modules technical support, please consult our Web site for
the latest product documentation, utilities, and drivers. If the information does not help solve the
problem, contact us by telephone.
Asia Europe North/South America
Kontron Embedded
Technology (Asia Pacific)
Kontron Embedded Modules GmbH Kontron America
Far East Science Park, 2nd
Floor No. 2, Lane 50, Nan
Kang Road Section 3, Nan
Kang District Taipei, Taiwan
Brunnwiesenstr. 16
94469 Deggendorf – Germany
6260 Sequence Drive
San Diego, CA 92121-4371
Tel: [phone] Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone] Fax: [phone]

KONTRON
Introduction 4 speedMOPSlcdCE User’s Guide
2. INTRODUCTION
2.1 speedMOPSlcdCE
The speedMOPSlcdCE hosts either an ULV Intel® Celeron® processor or an LV Intel® Celeron®
processor in combination with an Intel®815E chipset that includes an integrated graphics
memory-controller hub. A SDRAM-SODIMM socket can hold either PC100 or PC133 SODIMM memory
modules up to 512MB. Two USB 2.0 ports and one 10/100 MBit Ethernet interfaces extend the
standard connectivity of two serial ports, one parallel port, a PS/2 mouse and keyboard interface.
The speedMOPSlcdCE is a member of Kontron Embedded Modules GmbH’s speedMOPS family.
2.2 The speedMOPS Family
Each speedMOPS module features the same pinout and interface for the following components and
peripherals:
PC/104 and PC/104+ connector
Sound
2xUSB 2.0
10 / 100BaseT Ethernet
Keyboard
PS/2 Mouse
VGA
RS232 serial port
LPT
FDC
IDE1 and IDE2
These family features allow the use of the same chassis over the whole product line and maximize
design reuse.

KONTRON
speedMOPSlcdCE User’s Guide 5 Introduction
speedMOPSmodules allow the use of standard notebook SODIMM memory modules.
Display connections aresimplified when using the onboard standard JILI Interface (JUMPtec®
Intelligent LVDS Interface). JILI automatically recognizes which display is connected and
independently sets all video parameters. All speedMOPS modules are plug-and-work enabled to
further reduce time-to-market.
As part of the standard features package, all speedMOPS modules come with a JUMPtec Intelligent
Device Architecture (JIDA) interface, which is integrated into the BIOS. This interface enables
hardware independent access to features that cannot be accessed via standard APIs. Functions such
as watchdog timer, brightness and contrast of LCD backlight, and user bytes in the EEPROM can be
configured with ease by taking advantage of this standard speedMOPS module feature.
The speedMOPS line products support the PC/104-Plus (PCI) and the PC/104 (ISA) standard via
Kontron’s own PCI-to-ISA bridge. Because of the availability of both extension buses, all past and
future PC/104 expansion assemblies with state-of-the-art processor performance can be
accommodated.

KONTRON
Getting Started 6 speedMOPSlcdCE User’s Guide
3. GETTING STARTED
The easiest way to get the speedMOPSlcdCE board running is to use a starter kit from
Kontron Embedded Modules GmbH. Take the following steps:
1. Turn off the power supply (part of the starter kit).
2. Connect the power supply to the starter kit baseboard (part of the starter kit).
3. Plug a suitable SDRAM memory module into the SODIMM socket of the speedMOPS.
4. Plug the speedMOPS to the PC/104 and PC/104Plus bus connectors on the starter kit
baseboard.
5. Make all necessary connections from the speedMOPS to the starter kit board. (the cables come
with the starter kit). The starter kit board offers various interfaces on standard connectors.
6. Connect the CRT monitor to the CRT interface or a LCD panel to the JILI interface by using the
corresponding adapter cable.
7. Plug a keyboard to the starter kit’s keyboard connector.
8. Connect the floppy drive (part of the starter kit) with the data cable (part of the starter kit) to
the speedMOPS floppy interface.
9. Connect the power supply to the floppy’s power connector.
10. Plug a hard-drive data cable to the speedMOPS hard-disk interface. Attach the hard disk to the
connector at the opposite end of the cable.
11. If necessary, connect the power supply to the hard disk’s power connector.
12. Make sure all your connections have been made correctly.
13. Turn on the power.
14. Enter the BIOS by pressing the F2 key during boot-up. Make all changes in the BIOS setup. See
the BIOS chapter of this manual for details.

KONTRON
speedMOPSlcdCE User’s Guide 7 Specifications
4. SPECIFICATIONS
4.1 Functional Specifications
Processor
ULV Intel® Celeron® @ 400MHz or LV Intel® Celeron® @ 733MHz
1GHz LV Celeron available only upon request andis not RoHS compliant (lead-free)
Chipset
Intel® 815E Chipset graphics memory-controller hub
Power Supply
+5V-only
Super I/O
Winbond W83627HF
Cache
On-die 256KB second level cache
Memory
One 144-pin SODIMM interface that runs in synchronous (133/133) mode and in
pseudo-synchronous (133/100) mode with FSB133 3.3V PC-133 or PC-100 unbuffered
SDRAM, up to 512MB
Two Serial Ports (COM A and COM B)
RS232Cserial ports (10-pin headers)
16550-compatible
One Parallel Port (LPT1)
Enhanced Parallel Port (EPP) and Extended Capabilities Port (ECP) with bi-directional
capability
Floppy Interface
Enhanced Intelligent Drive Electronics (EIDE)
Two Peripheral Component Interconnect (PCI) Bus Master IDE ports (up to 4 devices)

KONTRON
Specifications 8 speedMOPSlcdCE User’s Guide
Universal Serial Bus (USB)
2 USB 2.0 ports
USB legacy keyboard support
USB floppy, CDROM, USB stick boot support
Ethernet Controller
Integrated Intel® 82562 10/100BASE-T LAN
Follows the common criteria of the embedded technology market segment
Onboard Video Graphics Array (VGA)
Intel® 815E Chipset graphics memory controller hub
CRT (Cathode Ray Tube)
LCD (Liquid Crystal Display) flat panel 24bit LVDS interface that uses JILI
Audio
Integrated Intel® SoundBlaster™AC97
Windows Sound System™compatible
Phoenix BIOS, 1024KB Flash BIOS
NV-EEPROM for CMOS Setup Retention without Battery
PS/2 Keyboard Controller
PS/2 Mouse Controller
Watchdog Timer (WDT)
Real Time Clock (RTC) with Onboard Battery Supply

KONTRON
speedMOPSlcdCE User’s Guide 9 Specifications
4.2 Mechanical Specifications
4.2.1. PC/104 Bus Connector (ISA part)
One 2 X 32 pin stackthrough and one 2 X 20 pin stackthrough connector
4.2.2. PC/104-Plus Bus Connector (PCI part)
One 4 x 30 pin 2mm stackthrough connector
The PC/104plus connector does not have a connector shroud. This mechanical limitation does not
reduce the functionality of a speedMOPSlcdCE board.
4.2.3. Dimensions
Length x Width: 96mm x 147mm (3,8" x 5,8")
4.2.4. Height on Top
Maximum 31.25mm (1.23”)
Height is depending upon CPU cooler/fan.
4.2.5. Height on Bottom
Maximum 10.67mm (0.42”) including PC/104plus connectors
4.2.6. Weight
About 195g (full featured version without SDRAM-SODIMM)

KONTRON
Specifications 10 speedMOPSlcdCE User’s Guide
4.3 Electrical Specifications
4.3.1. Supply Voltage
+5V DC +/- 5%
4.3.2. Supply Voltage Ripple
100mV peak to peak 0 - 20MHz
4.3.3. Supply Current (typical)
The speedMOPSlcdCE is equipped with power-saving features. Different power-consumption tests
were executed to give an overview of the electrical conditions for several operational states. The
board used a 256MB SDRAM module for test results shown below. An attached hard disk was not
supplied through the measurement path, and there was no extension module in the system.
speedMOPSlcdCE400MHz
Operational State @ +5V
DOS Prompt 2.60A
DOS Standby 2.02A
Windows Idle 2.12A
Windows 3D performance 3.03A
Windows 100% CPU Load 2.44A
speedMOPSlcdCE733MHz
Operation State @ +5V
DOS Prompt 3.28A
DOS Standby 2.30A
Windows Idle 2.38A
Windows 3D performance 3.84A
Windows 100% CPU Load 3.31A
speedMOPSlcdCE 1GHz
Operational State @ +5V
DOS Prompt 3.83A
DOS Standby 2.47A
Windows Idle 2.55A
Windows 3D performance 4.49A
Windows 100% CPU Load 3.89A

KONTRON
speedMOPSlcdCE User’s Guide 11 Specifications
4.3.4. Supply Current (maximum)
Board @ +5V
speedMOPSlcdCE 400MHz 3.79A
speedMOPSlcdCE 733MHz 4.81A
speedMOPSlcdCE 1GHz 5.61A
(Calculated theoretical values from all components maximum supply currents)
4.3.5. Real-time Clock (RTC) Battery
Voltage range: 2.0 - 4.0V (typ 3.0V)
Quiescent current: max. 3,5uA@ 3.0 V

KONTRON
Specifications 12 speedMOPSlcdCE User’s Guide
4.4 MTBF
The following MTBF (Mean Time Between Failure) values were calculated using a combination of
manufacturer’s test data (if the data was available) and a Bellcore calculation for the remaining
parts. The Bellcore calculation involved the “Method 1 Case 1” method. In that particular method,
the components were assumed to be operating at a 50% stress level in a 40° C ambient
environment, and the system was assumed to have not been burned in. Manufacturer’s data was
used wherever possible. The manufacturer’s data, when used, was specified at 50° C, which means
that the following results were slightly conservative. The MTBF values shown below were for a 40° C
office or telecommunications environment. Higher temperatures and other environmental stresses
(extreme altitude, vibration, and salt water exposure) will lower the MTBF values.
System MTBF (hours) : 184220
Notes: Fans shipped with Kontron Embedded Modules GmbH products have an
operating life of up to 50,000 hours.
The estimates above assumed that a passive heat-sinking arrangement was
used instead of a fan.
Estimated RTC battery life (as opposed to battery failures) was not accounted for
in the above figures and needs separate consideration. Battery life depends on
temperature and operating conditions. When the Kontron unit uses external
power, the battery drain comes from leakage paths.
