Kontron SMARC Eval-Carrier-2 User manual


USER GUIDE
SMARC Eval-Carrier-2
Doc-ID: 1061-6432
Doc. Rev. 1.1

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 2

SMARC EVAL
-CARRIER-2 - USER GUIDE
Disclaimer
Kontron would like to point out that the information contained in this manual may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee
on the part of Kontron with respect to technical processes described in the manual or any product characteristics
set out in the manual. Kontron assumes no responsibility or liability for the use of the described product(s), conveys
no license or title under any patent, copyright or mask work rights to these products and makes no representations
or warranties that these products are free from patent, copyright or mask work right infringement unless otherwise
specified. Applications that are described in this manual are for illustration purposes only. Kontron makes no
representation or warranty that such application will be suitable for the specified use without further testing or
modification. Kontron expressly informs the user that this manual only contains a general description of processes
and instructions which may not be applicable in every individual case. In cases of doubt, please contact Kontron.
This manual is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this manual is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products
and thus this manual only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2017 by Kontron S&T AG
Kontron S&T AG
Lise-Meitner-Str. 3-5
86156 Augsburg
Germany
www.kontron.com

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 3
Revision History
Revision Brief Description of Changes Date of Issue
1.0 Basic draft 2017-November-30
1.1 added BIOS chapter 2017-December-20
High Risk Applications Hazard Notice
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE OR RESALE
FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR COMMUNICATION SYSTEMS FOR
AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE SUPPORT OR LIFE SUSTAINING APPLICATIONS,
WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE
PERFORMANCE, OR IN WHICH THE FAILURE OF PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR
SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless
otherwise stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities
and cannot therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or
for resale as device in High Risk Applications. All application and safety related information in this document
(including application descriptions, suggested safety measures, suggested Kontron products, and other materials) is
provided for reference only.
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths
into a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product
expertise coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace
of mind to build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron
training academy, and more visit http://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 4
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order
Terms & Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 5
Symbols
The following symbols may be used in this manual
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE indicates a property damage message.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60 V) when touching
products or parts of them. Failure to observe the precautions indicated and/or prescribed by
the law may endanger your life/health and/or result in damage to your material.
Please refer also to the "High-Voltage Safety Instructions" portion below in this section.
ESD Sensitive Device!
This symbol and title inform that the electronic boards and their components are sensitive
to static electricity. Care must therefore be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
HOT Surface!
Do NOT touch! Allow to cool before servicing.
This symbol indicates general information about the product and the user manual.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 6
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its
compliance with electrical safety requirements. It was also designed for a long fault-free life. However, the life
expectancy of your product can be drastically reduced by improper treatment during unpacking and installation.
Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are
requested to conform with the following guidelines.
High Voltage Safety Instructions
As a precaution and in case of danger, the power connector must be easily accessible. The power connector is the
product’s main disconnect device.
Warning
All operations on this product must be carried out by sufficiently skilled personnel only.
Electric Shock!
Before installing a non hot-swappable Kontron product into a system always ensure that
your mains power is switched off. This also applies to the installation of piggybacks. Serious
electrical shock hazards can exist during all installation, repair, and maintenance operations
on this product. Therefore, always unplug the power cable and any other cables which
provide external voltages before performing any work on this product.
Earth ground connection to vehicle’s chassis or a central grounding point shall remain
connected. The earth ground cable shall be the last cable to be disconnected or the first
cable to be connected when performing installation or removal procedures on this product.
Special Handling and Unpacking Instruction
ESD Sensitive Device!
Electronic boards and their components are sensitive to static electricity. Therefore, care
must be taken during all handling operations and inspections of this product, in order to
ensure product integrity at all times.
Do not handle this product out of its protective enclosure while it is not used for operational purposes unless it is
otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where a safe work station is
not guaranteed, it is important for the user to be electrically discharged before touching the product with his/her
hands or tools. This is most easily done by touching a metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggybacks, ROM devices,
jumper settings etc. If the product contains batteries for RTC or memory backup, ensure that the product is not
placed on conductive surfaces, including anti-static plastics or sponges. They can cause short circuits and damage
the batteries or conductive circuits on the product.

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 7
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes
or modifications to the product, that are not explicitly approved by Kontron and described in this User Guide or
received from Kontron’s Technical Support as a special handling instruction, will void your warranty.
This product should only be installed in or connected to systems that fulfill all necessary technical and specific
environmental requirements. This also applies to the operational temperature range of the specific board version,
that must not be exceeded. If batteries are present, their temperature restrictions must be taken into account.
In performing all necessary installation and application operations, only follow the instructions supplied by the
present User Guide.
Keep all the original packaging material for future storage or warranty shipments. If it is necessary to store or ship
the product then re-pack it in the same manner as it was delivered.
Special care is necessary when handling or unpacking the product. See Special Handling and Unpacking Instruction.
Environmental Protection Statement
This product has been manufactured to satisfy environmental protection requirements where possible. Many of the
components used (structural parts, printed circuit boards, connectors, batteries, etc.) are capable of being recycled.
Final disposition of this product after its service life must be accomplished in accordance with applicable country,
state, or local laws or regulations.
Environmental protection is a high priority with Kontron.
Kontron follows the WEEE directive
You are encouraged to return our products for proper disposal.
The Waste Electrical and Electronic Equipment (WEEE) Directive aims to:
Reduce waste arising from electrical and electronic equipment (EEE)
Make producers of EEE responsible for the environmental impact of their products, especially when the
product become waste
Encourage separate collection and subsequent treatment, reuse, recovery, recycling and sound
environmental disposal of EEE
Improve the environmental performance of all those involved during the lifecycle of EEE

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 8
Table of Contents
Symbols .................................................................................................................................................................................................................5
Table of Contents .............................................................................................................................................................................................. 8
List of Tables........................................................................................................................................................................................................9
List of Figures ......................................................................................................................................................................................................9
1/ Introduction...........................................................................................................................................................................................11
2/ Description............................................................................................................................................................................................12
3/ Installation procedure ......................................................................................................................................................................13
3.1. Packing Check List.....................................................................................................................................................................................13
3.2. Requirements IEC60950-1.....................................................................................................................................................................13
4/ System specifications.......................................................................................................................................................................14
4.1. Component Main Data.............................................................................................................................................................................14
5/ Jumpers and Connectors .................................................................................................................................................................17
5.1. Hardware Configuration Setting ..........................................................................................................................................................17
5.1.1. Jumpers and Connectors......................................................................................................................................................................17
5.2. Mainboard views and I/O locations ...................................................................................................................................................18
5.3. Front View..................................................................................................................................................................................................20
5.4. Front Left View.........................................................................................................................................................................................20
5.5. Front Right View........................................................................................................................................................................................21
5.6. Rear Side.....................................................................................................................................................................................................22
6/ Block Diagram.....................................................................................................................................................................................23
7/ Maintenance and Status Information.........................................................................................................................................24
7.1. LEDs ..............................................................................................................................................................................................................24
8/ Pin Definitions..................................................................................................................................................................................... 27
8.1. SMARC Connector (J1).............................................................................................................................................................................28
8.2. LVDS Connector (J3) ...............................................................................................................................................................................33
8.3. Backlight Connector (J40) .................................................................................................................................................................... 35
8.4. eDP connector (embedded Display Port) (J8) ...............................................................................................................................36
8.5. HDMI connector (J42)............................................................................................................................................................................. 37
8.6. DP connector (J12)...................................................................................................................................................................................38
8.7. Mini PCIe Card socket 1 (J13).................................................................................................................................................................38
8.8. Mini PCIe Card socket 2 (J20) ..............................................................................................................................................................39
8.9. SIM card socket (J46)..............................................................................................................................................................................41
8.10. PCIe x1 connector 1 (J2).........................................................................................................................................................................41
8.11. Mini SATA Card Socket (J22) ...............................................................................................................................................................42
8.12. Audio Connector Line In (J24/J43) ...................................................................................................................................................43
8.13. Audio Connector (J10)...........................................................................................................................................................................44
8.14. RTC battery holder (J37)......................................................................................................................................................................44
8.15. μUSB 2.0 OTG connector (J39)...........................................................................................................................................................45
8.16. J21 – USB Connections .........................................................................................................................................................................45
8.17. USB 2.0 Header (J59).............................................................................................................................................................................47
8.18. Double USB 3.0 Connector (J21)........................................................................................................................................................48
8.19. LAN Connector (J36 and J41)..............................................................................................................................................................49
8.20. Micro-μSD Card Connector (J11).......................................................................................................................................................50
8.21. UART-SER Connector (J29/J30).........................................................................................................................................................51
8.22. CAN Connector (J6/J7)......................................................................................................................................................................... 52
8.23. Camera Serial Interface (CSI0) Connector (J36) ......................................................................................................................... 53
8.24. Camera Serial Interface (CSI1) Connector (J61)...........................................................................................................................54

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 9
8.25. GPIO Header (J38) ................................................................................................................................................................................. 55
8.26. Enhanced Serial Peripheral Interface Bus (eSPI) Connector (J47) ....................................................................................... 56
8.27. Power Management Header (J45)................................................................................................................................................... 56
8.28. Fan Connector (J62)..............................................................................................................................................................................57
8.29. Power-In Connector (J53) ...................................................................................................................................................................57
8.30. Module Power-In Connector (J54)..................................................................................................................................................58
8.31. Button Switch .........................................................................................................................................................................................59
8.32. Boot Selection Jumpers (J28, J32, J33) and other Jumpers.....................................................................................................60
List of Acronyms..............................................................................................................................................................................................63
About Kontron ..................................................................................................................................................................................................64
List of Tables
Table 1: Component Main Data ....................................................................................................................................................................14
Table 2: Environmental Conditions ............................................................................................................................................................16
Table 3: Jumpers and Connectors...............................................................................................................................................................17
Table 4: Power LEDs.......................................................................................................................................................................................24
Table 5: Backlight voltage LEDs.................................................................................................................................................................. 25
Table 6: GPIO LEDs .......................................................................................................................................................................................... 25
Table 7: Watchdog LEDs................................................................................................................................................................................26
Table 8: Audio selection LEDs .....................................................................................................................................................................26
Table 9: SATA Activity LEDs..........................................................................................................................................................................26
Table 10: mPCIe slot A LEDs .........................................................................................................................................................................26
Table 11: mPCIe slot B LEDs..........................................................................................................................................................................26
Table 12: Connector Definitions.................................................................................................................................................................. 27
Table 13: Pin Assignment ..............................................................................................................................................................................45
Table 14: Signal Description.........................................................................................................................................................................45
Table 15: Top SER1/UART1 .............................................................................................................................................................................51
Table 16: Bottom SER0/UART0....................................................................................................................................................................51
Table 17: Top SER3/UART3........................................................................................................................................................................... 52
Table 18: Bottom SER2/UART2 ................................................................................................................................................................... 52
Table 19: Power Button (SW3, J26)............................................................................................................................................................ 59
Table 20: Reset Button (SW1, J25) ............................................................................................................................................................. 59
Table 21: Force Recovery Button (SW4, J27) .......................................................................................................................................... 59
Table 22: Boot Selection Jumpers..............................................................................................................................................................60
Table 23: Display Power Select Jumper (J4)...........................................................................................................................................60
Table 24: Backlight Power Select Jumper (J23).....................................................................................................................................60
Table 25: LID Jumper (J34)............................................................................................................................................................................60
Table 26: TEST Jumper (J35) .........................................................................................................................................................................61
Table 27: LEDs Enable Jumper (J44)...........................................................................................................................................................61
Table 28: RESET Jumper (J25) ......................................................................................................................................................................61
Table 29: Power Jumper (J26) ......................................................................................................................................................................61
Table 30: Force Recovery Jumper (J27).....................................................................................................................................................61
Table 31: Module Power Select Jumper (J55, J56, J57)..........................................................................................................................61
Table 32: Audio Channel Jumper for I2S or HDA (J31).......................................................................................................................... 62
Table 33: mPCIe-1WLAN Disable Jumper (J49, J50) .............................................................................................................................62
Table 34: mPCIe-1WLAN Disable Jumper (J51, J52) ..............................................................................................................................62
Table 35: RTC Jumper (J58) ..........................................................................................................................................................................62
List of Figures
Figure 1: Carrier board with SMARC interface.........................................................................................................................................12
Figure 2: Top View............................................................................................................................................................................................18
Figure 3: Top View with LEDs and Jumper ...............................................................................................................................................19

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 10
Figure 4: Front View........................................................................................................................................................................................20
Figure 5: Front Left View...............................................................................................................................................................................20
Figure 6: Front Right View .............................................................................................................................................................................21
Figure 7: Rear Side from SMARC Eval-Carrier-2 ...................................................................................................................................22
Figure 8: Block Diagram for the SMARC Eval-Carrier-2 .....................................................................................................................23
Figure 9: Red Jumper on position INT .......................................................................................................................................................23
Figure 10: Power LEDs, see board position 21........................................................................................................................................24
Figure 11: GPIO and Backlight LEDs, see board position 19 ................................................................................................................ 25
Figure 12: GPIO and Backlight LEDs, see board position 25............................................................................................................... 26
Figure 13: 314-pin SMARC Connector for SMARC-Interface..............................................................................................................28
Figure 14: 30-pin LVDS connector.............................................................................................................................................................. 33
Figure 15: 7-pin Backlight Connector ........................................................................................................................................................ 35
Figure 16: 20-pin eDP connector ................................................................................................................................................................36
Figure 17: 19-pin HDMI connector .............................................................................................................................................................. 37
Figure 18: 20-pin DP connector ..................................................................................................................................................................38
Figure 19: 52-pin Mini PCIe Card .................................................................................................................................................................38
Figure 20: 52-pin Mini PCIe Card ................................................................................................................................................................39
Figure 21: 8-pin SIM card socket .................................................................................................................................................................41
Figure 22: 52-pin PCIe x1 connector ...........................................................................................................................................................41
Figure 23: 52-pin SATA Card Socket ..........................................................................................................................................................42
Figure 24: Audio Jacks....................................................................................................................................................................................43
Figure 25: 9-pin Audio Connector Header ...............................................................................................................................................44
Figure 26: RTC battery holder......................................................................................................................................................................44
Figure 27: μUSB 2.0 OTG connector...........................................................................................................................................................45
Figure 28: USB 2.0 / 3.0 socket...................................................................................................................................................................45
Figure 29: USB 2.0 High Speed Cable ........................................................................................................................................................46
Figure 30: USB 3.0 High Speed Cable ........................................................................................................................................................46
Figure 31: 9-pin USB Header ........................................................................................................................................................................47
Figure 32: Double USB 3.0 Connector ......................................................................................................................................................48
Figure 33: LAN Connector .............................................................................................................................................................................49
Figure 34: Micro-μSD Card Connector......................................................................................................................................................50
Figure 35: Double D-SUB 9-pin Connector...............................................................................................................................................51
Figure 36: CAN_0/CAN_1 Connector......................................................................................................................................................... 52
Figure 37: 15-pin Camera CSI Connector .................................................................................................................................................. 53
Figure 38: 20-pin Camera CSI Connector.................................................................................................................................................54
Figure 39: 2x8-pin GPIO Header ................................................................................................................................................................. 55
Figure 40: 2x7-pin eSPI Connector ............................................................................................................................................................56
Figure 41: 2x8-pin Power Management Header ................................................................................................................................... 56
Figure 42: 4-pin Fan Connector...................................................................................................................................................................57
Figure 43: Power-In Connector....................................................................................................................................................................57
Figure 44: Module Power-In Connector ..................................................................................................................................................58
Figure 45: Red Jumper on position INT.....................................................................................................................................................58
Figure 46: Button Switch...............................................................................................................................................................................59
Figure 47: Jumpers for Boot Select............................................................................................................................................................60
Figure 48: Module Power Select Jumper (J55, J56, J57) .......................................................................................................................61
Figure 49: RTC Jumper (J58).........................................................................................................................................................................62

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 11
1/ Introduction
This manual describes the Smart Mobility ARChitecture SMARC Eval-Carrier-2 board. This document describes the
electronic, mechanical and thermal design of the SMARC evaluation carrierboard. It is designed for the testing of
SMARC-sXAL (2), SMARC_SMX7 and other SMARC 2.0 modules. The board will be equipped with DP++ connector,
HDMI connector, LVDS connector, two full-size or half-size mPCIe card slot (PCIe + USB 2.0), two PCIe x1 slot and
full-size mSATA slot to easily use and test additional cards.
The use of this Users Guide implies a basic knowledge of PC hard- and software. This manual is focussed on
describing the special features and is not intended to be a standard PC textbook. New users are recommended to
study the short installation procedure stated in the following chapter before switching on the power. All
configuration and setup of the CPU board is either done automatically or manually by the user via the BIOS setup
menus. Latest revision of this manual, datasheet, BIOS, drivers and BSP’s (Board Support Packages) can be
downloaded from Kontron Web Page.

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 12
2/ Description
The SMARC Eval-Carrier-2 is designed on the latest SMARC 2.0 specification. The board will be equipped with
DP++ connector,
HDMI connector,
LVDS connector,
two full-size or half-size mPCIe card slot (PCIe + USB 2.0),
two PCIe x1 slot,
full-size mSATA slot,
two USB 3.0 connectors one USB 2.0 OTG connector,
SIM card slot,
Battery holder and super cap
Camera interface,
CAN interface,
two Ethernet connectors,
HDA and I2S audio codec,
one USB 2.0 on header,
µSD connector,
4x COM ports.
Figure 1: Carrier board with SMARC interface

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 13
3/ Installation procedure
3.1. Packing Check List
The package includes the following basic items accompany with this manual.
One board
If this item is damaged or missed, please contact your vendor and save all packing materials for future replacement
and maintenance.
Note: The above packing list is for standard single box packing only.
3.2. Requirements IEC60950-1
Take care when designing chassis interface connectors in order to fulfil the IEC60950-1 standard.
Users of board must evaluate the end product to ensure compliance the requirements of the IEC60950-1 safety
standard are met:
The motherboard must be installed in a suitable mechanical, electrical and fire enclosure.
The system in its enclosure must be evaluated for temperature and air flow considerations.
For interfaces having a power pin such as external power or fan, ensure that the connectors and wires are suitably
rated. All connections from or to the product shall be with Safety Extra Low Voltage (SELV) circuits only.
Wires have suitable rating to withstand the maximum available power.
The enclosure of the peripheral device fulfills the fire protecting requirements of IEC60950-1.

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 14
4/ System specifications
4.1. Component Main Data
The table below summarizes the features of the motherboard.
Table 1: Component Main Data
SMARC Eval-Carrier-2
Form factor Testing Hardware with 210 mm x 200 mm, max. thickness 3
mm
Memory
EEPROM System
(U78)
The EEPROM type 24LC64 on carrier board connected to SMARC I2C_PM bus.
SPI flash socket
(J48)
SPI flash socket (SOIC8 – 1045-8636) with flash memory W25Q128FW
EEPROM DDC
optional (U72)
The EDID EEPROM type 24C04 on carrier board connected to LVDS_I2C bus. Holding display
relevant DDC information. Used by BIOS to initialize LCD. KEAPI support with module.
External I/O
LAN two Gbit-Ethernet ports
USB two USB 3.0 double stack and one μUSB connector for On The Go (OTG) function: powered
for host, not powered for client. The 5 V output from USB 2.0 and USB OTG is separately
electronically fused to 500 mA. The 5V output from USB 3.0 is electronically fused to 1000
mA each port.
HDMI HDMI connector from SMARC module
DP++ DP++ Display port connector from SMARC module
COM1-4 4x COM RS232, 9-pin DSUB
Camera interfaces Two Camera Header for cameras, including power, GPIO, I2C. Recommended Power should
be 3.3
V, fused with 0.75
A resettable fuse.
Audio Line-in and line-out 3.5mm jack; Front Panel 2x5 Pin Header (2.54mm), supporting both
interfaces I2S and HDA selectable by jumper. On audio header is also Microphone and
Headphone output.
Internal I/O
LVDS 30-pin LVDS dual channel from SMARC module. Configurable 3.3 V / 5V voltage levels of
power for different panels via jumper.
USB 2.0 Header 2.54
mm pitch 2x10-pin USB header with one USB pair
Backlight Backlight PWM and power. Configurable 12 V/ 5 V voltage levels of backlight power for
different panels via jumper. Maximum Power is 12 W continuous. If the selected panel
exceeds, the provided power by this carrier evaluation of the SMARC module with LVDS can
still be done with external panel power.
eDP eDP connector, shared with LVDS as an option via resistors. PWR Out must provide
+3.3 V+/-10 % with a maximum current of 500 mA and a minimum power capability of
1.5
W.
mSATA 1x slot (full size / half size ; SATA port)
LVDS one LVDS and one LVDS/eDP1.4
PCIe X1 two PCIe 1X slots
mPCIe two card slots (full size / half size) - PCIe & USB; support all MC3 mPCIe cards
SIM Card SIM Card connected to both mPCIe
µ
SD microSD card socket from SMARC module

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 15
Controller Area
Network (CAN)
two CAN interfaces
LEDs SMD LEDs for storage activity, board status, device and power status (power good)
Internal Header and Jumper
GPIO GPIO Header 2.54
mm
eSPI header eSPI header (2.54
mm pin header, dual row)
Power
Management
Header
2.54 mm pin header, dual row
Battery 1.5F Goldcap and/or CR2032 battery. Optional parallel usage supported.
Fan 4-pin fan connector, Voltage can be 5
V or 12
V (default)
Carrier Board Controllers
I2C EEPROM General purpose EEPROM I2C
SPI Socket SPI socket with 64
MB Flash
HDA Codec TSI 92HD73C HDA Codec
I2S Codec WM8904 I2S Codec
EEPROM DDC Holding display relevant DDC information. Used by BIOS to initialize LCD.
Carrier Board Power
Power input 12 V input power connector, used as an alternative power for module to support wide
voltage range. 12 V DC power connector for powering carrier and module 5 V. Separate
input power connector for module with voltage range: 3.0
V to 5.25
V
DC
LED status
Power LEDs Power good of carrier power lanes
CARRIER_PWR_ON Power on
CARRIER_STB# CARRIER_STB#
SATA_ACT# SATA activity LED
Power rails 1.8
V; 3.3
V; 5
V
GPIO GPIO indication LEDs
Watchdog Watchdog indication LED
Danger of explosion if the lithium battery is incorrectly replaced.
•Replace only with the same or equivalent type recommended by the manufacturer
•Dispose of used batteries according to the manufacturer’s instructions

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 16
Table 2: Environmental Conditions
Operating 0°C to +70°C
Some connectors and supercap has operating temperature only 0°C to +70°C, relative
humidity (non-condensing) 10
% to 93
% at 40°C
Storage -40°C to +85°C
relative humidity (non-condensing) 10 % to 95 % at 40°C
Electromagnetic
Compatibility
(EMC) and
Interference (EMI)
The board shall be designed to meet the following requirements: EMC Emission EN 55022
Class B, FCC CFR part 15 Class B
Shock/Vibration/
Bump
Shock & Vibration according to IEC/EN60068-2-6 and IEC/EN60068-2-27
Theoretical MTBF not applicable
Restriction of
Hazardous
Substances
(RoHS) II
Compliance
RoHS II compliant
Safety The board shall be designed to meet the following requirements:
UL 60950, 3rd edition (US and Canada)
EN 60950-1 (Europe)

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 17
5/ Jumpers and Connectors
5.1. Hardware Configuration Setting
This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the
configuration jumpers on the board are in the proper position. The default settings shipped from factory are marked
with an asterisk (*).
In general, jumpers on the board are used to select options for certain features. Some of the jumpers are designed to
be user-configurable, allowing for system enhancement. The others are for testing purpose only and should not be
altered. To select any option, cover the jumper cap over (SHORT) or remove (NC) it from the jumper pins according to
the following instructions. Here, NC stands for “Not Connect”.
5.1.1. Jumpers and Connectors
Table 3: Jumpers and Connectors
Connector Function Remark
High current jumper
(H8 with contacts J55,
J56 and J57)
Module power selection: Either internal power
via J53 (5 V supply), or external via J54 (3 to
5.25 V supply).
ATTENTION: J54 powers the module ONLY!
Carrier still needs to be powered via 12V,
through J53.
1x3-pin Jumper
5 V/3.3 V (J4) Display voltage selection (3.3 V or 5 V) 1x3-pin Jumper
5 V/12 V (J23) Display backlight voltage selection (5 V or 12 V) 1x3-pin Jumper
A_W_Disable_1 (J49) Disable miniPCIe radio operation 1x2-pin Jumper
A_W_Disable_2 (J50) Disable miniPCIe radio operation 1x2-pin Jumper
B_W_Disable_1 (J51) Disable miniPCIe radio operation 1x2-pin Jumper
B_W_Disable_2 (J52) Disable miniPCIe radio operation 1x2-pin Jumper
CODEK_OPTION_SW_I
2S_HDA# (J31)
Audio Codec Multipexor HDA (default)/I2S
Codec
1x2-pin Jumper
LEDs ENABLE (J44) Enable/Disable status and power LEDs 1x2-pin Jumper
V_BAT_JP (J58) Selection between Battery or Goldcap 1x3-pin Jumper
USB 2.0 (J59) 2.54
mm pitch USB header with one USB pair 2x5 pin header
SMARC (J1) SMARC connector 1x314-connector
LVDS/eDP (J3) LVDS dual channel. From SMARC module.
Configurable 3.3 V / 5 V voltage levels of
power for different panels via jumper.
HDMI (J42) HDMI connector from SMARC module
DP++ (J12) Display port connector from SMARC module
PCIe x1 (J2) 2x PCIe 1x slot standard
mPCIe (J13/J20) 2x card slot (full size / half size) - PCIe & USB;
support all MC3 mPCIe cards
standard
mSATA (J22) 1x slot (full size / half size ; SATA port) standard
Audio (J24 IN/J43 OUT) Line-in and line-out 3.5mm jack; Front Panel
2x5 Pin Header (2.54mm)
2x5 header
CAN (J6/J7) 2x CAN, Molex 53261-0471 or similar 1x4 header
Power Management
Header (J45)
SYS-Signals Header (2.54mm pin header) 2x8 header

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 18
Connector Function Remark
SD Card (J9) SD card write protect setting
Fan (J62) Fan 1x4 header
GPIO (J38, U33, U34,
U35)
GPIO Header 2.54mm 2x8 header
5.2. Mainboard views and I/O locations
Figure 2: Top View
1. Power Management Header
2. USB 2.0 internal
3. eSPI Header
4. Fan Connector
5. Camera Serial Interface (J60)
6. Camera Serial Interface (J61)
7. SMARC Interface
8. Button Switches
9. GPIO
10. mPCIe
11. 2x PCIe x1
12. Audio
13. mSATA
14. Micro-SD Card Connector
15. SIM Card
16. Goldcap
17. Battery
1
15
17
2 3 5
16
6 7 8
9
10
14
13
12
11
4

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 19
Figure 3: Top View with LEDs and Jumper
18. Jumper Boot Sel 0/1/2, LID, TEST, LED EN, RESET, POWER, F. REC, V DISP 5V 3V3
19. LEDs GPIO 0-10, 12 V/5 V BKLT, WDT
20. Jumper BKLT 12 V/5 V
21. LEDs S5, S0, PCI, 2V5 STB, CRR STB, CRR ON
22. Jumper V_MOD 5V/EXT
23. Jumper C_W_DI, D_W_DI
24. Jumper HDA/I2S
25. LEDs SATA ACT, WPAN, WLAN, WWAN
26. Jumper µSD WP
27. Jumper RTC BATT/SCAP
18
19
21
20
22
23
24
25
26
27

SMARC Eval-Carrier-2 – . Rev. 1.1
www.kontron.com // 20
5.3. Front View
Figure 4: Front View
28. CAN Connector CAN_0
29. CAN Connector CAN_1
30. UART SER_0
31. UART SER_1
32. UART SER_2
33. UART SER_3
5.4. Front Left View
Figure 5: Front Left View
34.
μUSB 2.0 OTG Connector
35. USB 3.0 Port 3
36. USB 3.0 Port 2
37. LAN GbE_1
38. LAN GbE_0
39. MicroSD Connector
40. Audio IN
41. Audio OUT
28
30
35
38
34
41
39
29
31
32
33
36
37
40
