Kontron CP6923 User manual

CP6923 Manual ID
2.2 Revision Index
10 May, 2007 Date of Issue
CP6923 USER GUIDE
6U CPCI Ethernet Switch
with 24 Channels

Page ii CP6923 User Guide
Revision History
Imprint
Kontron AG may be contacted via the following:
North America EMEA
Kontron Canada, Inc. Kontron Modular Computers GmbH
616 Curé Boivin Sudetenstrasse 7
Boisbriand, Québec 87600 Kaufbeuren
J7G 2A7 Canada Germany
Tel: [phone] [phone]
[phone]
Fax: [phone] [phone]
E-mail: [email protected] [email protected]
For further information about Kontron AG, our products or services, please visit our Internet
web site: www.kontron.com
Disclaimer
Copyright © 2006 Kontron AG. All rights reserved. All data is for information purposes only and not guaranteed for
legal purposes. Information has been carefully checked and is believed to be accurate; however, no responsibility
is assumed for inaccuracies. Kontron and the Kontron logo and all other trademarks or registered trademarks are
the property of their respective owners and are recognized. Specifications are subject to change without notice.
Publication Title: CP6923: 6U CPCI Ethernet Switch with 24 channels
ID Number: CP6923
Rev.
Index Brief Description of Changes Date of Issue
1.0 Preliminary Issue Oct., 2006
2.0 Initial Issue March, 2007
2.1 Minor changes in Chapter 3, Hardware Description and Chapter
4, Software Description
22 March, 2007
2.2 Minor changes to Preface and Chapter 1 10 May, 2007

CP6923 Preface
Page iii CP6923 User Guide
Table of Content
Revision History .........................................................................................................ii
Imprint ........................................................................................................................ii
Disclaimer ..................................................................................................................ii
Proprietary Note ...................................................................................................... viii
Trademarks ............................................................................................................. viii
Environmental Protection Statement ....................................................................... viii
Explanation of Symbols ............................................................................................ix
For Your Safety .........................................................................................................ix
Safety Instructions .................................................................................................x
Special Handling and Unpacking Instructions ......................................................xi
General Instructions on Usage ............................................................................ xii
Two Year Warranty .................................................................................................. xiii
Chapter
1
1. Introduction .................................................................................................. 1 - 2
1.1 Product Overview .................................................................................... 1 - 2
1.1.1 CP6923 Features ............................................................................ 1 - 2
1.1.2 General compliances ...................................................................... 1 - 4
1.1.3 Hot Swap Capability ....................................................................... 1 - 4
1.2 Technical Specification ........................................................................... 1 - 5
1.3 Software Support ..................................................................................... 1 - 7
Chapter
2
2. Installation ................................................................................................... 2 - 2
2.1 Safety Requirements ............................................................................... 2 - 2
2.2 CP6923 Initial Installation Procedures .................................................... 2 - 3
2.3 Standard Removal Procedures ............................................................... 2 - 4
2.4 Software Installation ................................................................................ 2 - 5

CP6923 Preface
Page iv CP6923 User Guide
Chapter
3
3. Hardware Description .................................................................................. 3 - 2
3.1 Fabric Switch ........................................................................................... 3 - 3
3.1.1 PCI Interface ................................................................................... 3 - 3
3.1.2 Port Mapping .................................................................................. 3 - 3
3.1.3 Standard Fabric Links ..................................................................... 3 - 5
3.1.4 Extended Fabric Uplinks ................................................................. 3 - 5
3.1.5 Copper Uplinks ............................................................................... 3 - 5
3.1.6 1000BASE-xX SFP Uplinks ............................................................ 3 - 6
3.1.7 10GBASE-xX XFP Uplinks ............................................................. 3 - 7
3.2 CPU and Memory .................................................................................... 3 - 8
3.2.1 PCI Interface ................................................................................... 3 - 8
3.2.2 SDRAM ........................................................................................... 3 - 8
3.2.3 FLASH ............................................................................................ 3 - 8
3.2.4 Fast Ethernet Management Interface ............................................. 3 - 8
3.2.5 RS232 Management Interface ........................................................ 3 - 9
3.3 IPMI ....................................................................................................... 3 - 11
3.3.1 PM ................................................................................................ 3 - 11
3.3.2 FUM .............................................................................................. 3 - 11
3.4 Power Supply and Hot Swap ................................................................ 3 - 12
3.4.1 Power Up and Power Down Sequencing ...................................... 3 - 12
3.4.2 Reset ............................................................................................ 3 - 12
3.5 Display Elements ................................................................................... 3 - 13
3.6 CompactPCI Bus Connector ................................................................. 3 - 15
3.6.1 CompactPCI Connectors J1 and J2 Pinouts ................................ 3 - 16
3.6.2 CompactPCI Rear I/O Connectors J3-J5 and Pinouts .................. 3 - 17
Chapter
1
4. Software Description ................................................................................... 4 - 2
4.1 Supported RFCs ..................................................................................... 4 - 2

CP6923 Preface
Page v CP6923 User Guide
4.1.1 Management ................................................................................... 4 - 2
4.1.2 Switching ........................................................................................ 4 - 3
4.1.3 Routing ........................................................................................... 4 - 4
4.1.4 QoS ................................................................................................. 4 - 5
4.1.5 Multicast .......................................................................................... 4 - 5
4.2 Supported MIBs ...................................................................................... 4 - 5
4.2.1 Enterprise MIB ................................................................................ 4 - 5
4.2.2 Switching Package MIBs ................................................................ 4 - 5
4.2.3 Routing Package MIBs ................................................................... 4 - 6
4.2.4 QoS Package MIBs ........................................................................ 4 - 6
4.2.5 Multicast package MIBs .................................................................. 4 - 6
4.2.6 SNMP MIBs .................................................................................... 4 - 7
4.3 Bootloader ............................................................................................... 4 - 7
4.3.1 Power On Self Test ......................................................................... 4 - 7
4.4 IPMI Firmware ......................................................................................... 4 - 9
4.4.1 Sensor Data Record (SDR) .......................................................... 4 - 10
4.4.2 Board FRU Information ................................................................. 4 - 11
4.4.3 PM Firmware Code ....................................................................... 4 - 12
4.4.4 LEDs ............................................................................................. 4 - 12
4.5 Firmware Administration ....................................................................... 4 - 13
4.5.1 Startup Configurations .................................................................. 4 - 14
4.5.2 Updating Firmware ....................................................................... 4 - 15
4.5.3 Updating IPMI ............................................................................... 4 - 17
Appendix
A
A. Getting Help ................................................................................................... A - 2

CP6923 Preface
Page vi CP6923 User Guide
List of Tables
1-1 CP6923 Main Specifications ...................................................................... 1 - 5
1-2 CP6923 Software Specification ................................................................. 1 - 7
3-1 PCI-ID ........................................................................................................ 3 - 3
3-2 Port Mapping .............................................................................................. 3 - 4
3-3 Port Mapping .............................................................................................. 3 - 4
3-4 Copper Uplink RJ45 Pin Assignment ......................................................... 3 - 5
3-5 Copper Uplink LEDs Signification .............................................................. 3 - 6
3-6 SFP Connectors Pin Assignment ............................................................... 3 - 6
3-7 XFP Connectors Pin Assignment ............................................................... 3 - 7
3-8 FE Management RJ45 Connector Pin Assignment ................................... 3 - 9
3-9 FE Management LEDs Signification .......................................................... 3 - 9
3-11 Serial console terminal cable interface: RJ45 Female to DB9 Female .... 3 - 10
3-10 Serial Port (RJ45) Pin Assignment .......................................................... 3 - 10
3-12 Hot Swap LED Signification ..................................................................... 3 - 14
3-13 PM Status LED Signification .................................................................... 3 - 14
3-14 Standard Fabric Interface LED Signification ............................................ 3 - 14
3-15 Extendes Fabric Interface LED Signification ............................................ 3 - 14
3-16 Copper Uplink LEDs Signification ............................................................ 3 - 15
3-17 FE Management LEDs Signification ........................................................ 3 - 15
3-18 Connector J1 Pinout ................................................................................ 3 - 16
3-19 Connector J2 Pinout ................................................................................ 3 - 17
3-20 Connector J3 Pinout ................................................................................ 3 - 17
3-21 Connector J4 Pinout ................................................................................ 3 - 18
3-22 Connector J5 Pinout ................................................................................ 3 - 19
4-1 POST routines and error codes ................................................................. 4 - 8
4-2 POST Boot Steps ....................................................................................... 4 - 8
4-3 CP6923 sensors ...................................................................................... 4 - 10
4-4 Health LED state ...................................................................................... 4 - 12
4-5 Activity LED state ..................................................................................... 4 - 12
4-6 FLASH Partition Scheme (64MB) ............................................................ 4 - 13

CP6923 Preface
Page vii CP6923 User Guide
List of Figures
3-1 Functional Block Diagram CP6923 ............................................................ 3 - 2
3-2 Front Panels of the CP6923 .................................................................... 3 - 13

CP6923 Preface
Page viii CP6923 User Guide
Proprietary Note
This document contains information proprietary to Kontron AG. It may not be copied or trans-
mitted by any means, disclosed to others, or stored in any retrieval system or media without
the prior written consent of Kontron AG or one of its authorized agents.
The information contained in this document is, to the best of our knowledge, entirely correct.
However, Kontron AG cannot accept liability for any inaccuracies or the consequences thereof,
or for any liability arising from the use or application of any circuit, product, or example shown
in this document.
Kontron AG reserves the right to change, modify, or improve this document or the product de-
scribed herein, as seen fit by Kontron AG without further notice.
Trademarks
Kontron AG and the Kontron logo are trade marks owned by Kontron AG, Germany. In addition,
this document may include names, company logos and trademarks, which are registered trade-
marks and, therefore, proprietary to their respective owners.
Environmental Protection Statement
This product has been manufactured to satisfy environmental protection requirements where
possible. Many of the components used (structural parts, printed circuit boards, connectors,
batteries, etc.) are capable of being recycled.
Final disposition of this product after its service life must be accomplished in accordance with
applicable country, state, or local laws or regulations.

CP6923 Preface
Page ix CP6923 User Guide
Explanation of Symbols
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary
to ensure its compliance with electrical safety requirements. It was also designed for a long
fault-free life. However, the life expectancy of your product can be drastically reduced by im-
proper treatment during unpacking and installation. Therefore, in the interest of your own safety
and of the correct operation of your new Kontron product, you are requested to conform with
the following guidelines.
CE Conformity
This symbol indicates that the product described in this manual is in compli-
ance with all applied CE standards. Please refer also to the section “Applied
Standards” in this manual.
Caution, Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60V) when
touching products or parts of them. Failure to observe the precautions indi-
cated and/or prescribed by the law may endanger your life/health and/or
result in damage to your material.
Please refer also to the section “High Voltage Safety Instructions” on the fol-
lowing page.
Warning, ESD Sensitive Device!
This symbol and title inform that electronic boards and their components are
sensitive to static electricity. Therefore, care must be taken during all han-
dling operations and inspections of this product, in order to ensure product
integrity at all times.
Please read also the section “Special Handling and Unpacking Instructions”
on the following page.
Warning!
This symbol and title emphasize points which, if not fully understood and
taken into consideration by the reader, may endanger your health and/or
result in damage to your material.
Note...
This symbol and title emphasize aspects the reader should read through
carefully for his or her own advantage.

CP6923 Preface
Page x CP6923 User Guide
Safety Instructions
Warning!
All operations on this device must be carried out by sufficiently skilled person-
nel only.
Warning!
Do not connect a switch port to a telephone line.
Warning!
For intallation in a Hot-Plug system, observe the safety instructions specific to
the system. Read the relevant documentation.
Caution, Electric Shock!
High voltages are present inside the chassis when the unit’s power cord is
plugged into an electrical outlet. Turn off system power, turn off the power
supply, and then disconnect the power cord from its source before removing
the chassis cover. Turning off the system power switch does not remove
power to components.
Caution, Laser Light!
Laser light from fiber-optic transmission cables and components can damage
your eyes. The laser components plugged into the switch are Class 1 laser
components. Class 1 laser is considered incapable of producing damaging
radiation levels during normal operation or maintenance.
To avoid damaging your eyes and to continue safe operation in case of
abnormal circumstances:
•Never look directly into the outlets of fiber-optic transmission compo-
nents or fiber-optic cables with unprotected eyes.
•Never allow fiber-optic transmission path to operate until all the connec-
tions have been made.
•Always fit protective plugs to any unused ports of the switch.

CP6923 Preface
Page xi CP6923 User Guide
Special Handling and Unpacking Instructions
Do not handle this product out of its protective enclosure while it is not used for operational pur-
poses unless it is otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where
a safe work station is not guaranteed, it is important for the user to be electrically discharged
before touching the product with his/her hands or tools. This is most easily done by touching a
metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing mezza-
nines, ROM devices, jumper settings etc. If the product contains batteries for RTC or memory
back-up, ensure that the board is not placed on conductive surfaces, including anti-static plas-
tics or sponges. They can cause short circuits and damage the batteries or conductive circuits
on the board.
ESD Sensitive Device!
Electronic boards and their components are sensitive to static electricity.
Therefore, care must be taken during all handling operations and inspections
of this product, in order to ensure product integrity at all times.

CP6923 Preface
Page xii CP6923 User Guide
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in
any way. Changes or modifications to the device, which are not explicitly approved by Kontron
AG and described in this manual or received from Kontron’s Technical Support as a special
handling instruction, will void your warranty.
This device should only be installed in or connected to systems that fulfill all necessary techni-
cal and specific environmental requirements. This applies also to the operational temperature
range of the specific board version, which must not be exceeded. If batteries are present their
temperature restrictions must be taken into account.
In performing all necessary installation and application operations, please follow only the in-
structions supplied by the present manual.
Keep all the original packaging material for future storage or warranty shipments. If it is neces-
sary to store or ship the board please re-pack it as nearly as possible in the manner in which it
was delivered.
Special care is necessary when handling or unpacking the product. Please, consult the special
handling and unpacking instruction on the previous page of this manual.

CP6923 Preface
Page xiii CP6923 User Guide
Two Year Warranty
Kontron AG grants the original purchaser of Kontron’s products a TWO YEAR LIMITED HARDWARE
WARRANTY as described in the following. However, no other warranties that may be granted or
implied by anyone on behalf of Kontron are valid unless the consumer has the express written
consent of Kontron AG.
Kontron AG warrants their own products, excluding software, to be free from manufacturing
and material defects for a period of 24 consecutive months from the date of purchase. This war-
ranty is not transferable nor extendible to cover any other users or long-term storage of the
product. It does not cover products which have been modified, altered or repaired by any other
party than Kontron AG or their authorized agents. Furthermore, any product which has been,
or is suspected of being damaged as a result of negligence, improper use, incorrect handling,
servicing or maintenance, or which has been damaged as a result of excessive current/voltage
or temperature, or which has had its serial number(s), any other markings or parts thereof al-
tered, defaced or removed will also be excluded from this warranty.
If the customer’s eligibility for warranty has not been voided, in the event of any claim, he may
return the product at the earliest possible convenience to the original place of purchase, togeth-
er with a copy of the original document of purchase, a full description of the application the
product is used on and a description of the defect. Pack the product in such a way as to ensure
safe transportation (see our safety instructions).
Kontron provides for repair or replacement of any part, assembly or sub-assembly at their own
discretion, or to refund the original cost of purchase, if appropriate. In the event of repair, re-
funding or replacement of any part, the ownership of the removed or replaced parts reverts to
Kontron AG, and the remaining part of the original guarantee, or any new guarantee to cover
the repaired or replaced items, will be transferred to cover the new or repaired items. Any ex-
tensions to the original guarantee are considered gestures of goodwill, and will be defined in
the “Repair Report” issued by Kontron with the repaired or replaced item.
Kontron AG will not accept liability for any further claims resulting directly or indirectly from any
warranty claim, other than the above specified repair, replacement or refunding. In particular,
all claims for damage to any system or process in which the product was employed, or any loss
incurred as a result of the product not functioning at any given time, are excluded. The extent
of Kontron AG liability to the customer shall not exceed the original purchase price of the item
for which the claim exists.
Kontron AG issues no warranty or representation, either explicit or implicit, with respect to its
products’ reliability, fitness, quality, marketability or ability to fulfil any particular application or
purpose. As a result, the products are sold “as is,” and the responsibility to ensure their suit-
ability for any given task remains that of the purchaser. In no event will Kontron be liable for
direct, indirect or consequential damages resulting from the use of our hardware or software
products, or documentation, even if Kontron were advised of the possibility of such claims prior
to the purchase of the product or during any period since the date of its purchase.
Please remember that no Kontron AG employee, dealer or agent is authorized to make any
modification or addition to the above specified terms, either verbally or in any other form, written
or electronically transmitted, without the company’s consent.

CP6923 Introduction
Page 1 - 1 CP6923 User Guide
Introduction
Chapter
1

CP6923 Introduction
Page 1 - 2 CP6923 User Guide
1. Introduction
1.1 Product Overview
The Kontron CP6923 is a PICMG 2.16 compliant Standard Fabric 6U CompactPCI managed
Gigabit Ethernet Switch with 24 channels.
Four different variants of the CP6923 are available:
CP6923-C (Copper)
In addition to the 20 backplane links (19 node boards and one fabric board), four GbE switch
ports are available on the front plate via RJ45 connectors.
CP6923-O (Optical)
The four front plate ports are implemented as SFP cages, two 10 GbE ports are accessible via
XFP cages. SFP and XFP modules are not included with the CP6923-O.
CP6923-R (Rear)
All 24 GbE ports connect to the backplane (four additional extended node board links).
CP6923-E (Extended)
Like the CP6923-R but for operation in extended temperature range of -40 to +85°C.
1.1.1 CP6923 Features
The board is composed of the following building blocks:
• Ethernet Infrastructure
• Ethernet Switch Controller and Memory
•IPMI
• Power Supply
Ethernet Infrastructure
• Broadcom StrataXGS®III Chip BCM56500: 24 Port Gigabit Ethernet Layer-3 Switch
(CP6923-C, CP6923-E)
• BCM56502: 24 Port Gigabit Ethernet Layer-3 Switch with 2 10GbE Uplinks (CP6923-
O)
• PCI 32b/66MHz Management IF.
• Line rate switching for all packet sizes and conditions.
• Supports 19x Link Ports to Node boards [10/100/1000Base-T via external Copper PHY]
• Supports 1x Link Port to Fabric board [10/100/1000Base-T via external Copper PHY].

CP6923 Introduction
Page 1 - 3 CP6923 User Guide
• Supports optional 4x 10/100/1000Base-T Copper based uplinks to front (CP6923-C).
• Supports optional 4x 1GbE SFP uplinks to front (CP6923-O).
• Supports optional 2x 10GBase-R XFP uplinks to front (CP6923-O).
• Supports optional 4x Link Ports to extended Node boards [10/100/1000Base-T via exter-
nal Copper PHY] to rear (CP6923-R and CP6923-E)
• Broadcom BCM5488 OctalPHY for copper based links
• Broadcom BCM8704 single 10GbE PHY for uplinks (CP6923-O)
Ethernet Switch Controller and System Memory
• Socketless PowerPC IBM PPC405GPr 400 MHz
• Used for switch provisioning, diagnostics and protocol handling
• 256 MBytes SDRAM 133 MHz
• 64 MBytes FLASH
IPMI
• Renesas H8S2166 16-bit µController (PM)
• PICMG 2.9 / IPMI 1.5 compliant
• Renesas R5F21144 Firmware Update Manager (FWUM)
• 512 kByte Flash (Boot Image)
• 64 kByte PROM (FRU)
• Voltage, current monitoring with ADC of PM
• Temperature monitoring with LM83
Power Supply
• 5V and 3.3V only board, no 12V or -12V required
• IPMB_PWR or 5V used for 3.3V PM (generated by LDO)
• Hot Swap support
• PoL converter with 2.5V, 1.8V, 1.25V and 1.0V
Miscellaneous
• Management connection to Switch Controller (CLI, SNMP) via RS232 and Fast Ethernet
via RJ45 connectors.
• Management connection to Switch Controller via RS232 on J4.
• Serial EEPROM for FRU storage (serial ID).
• Board support package includes Montavista Linux, device drivers, protocol stacks and di-
agnostics.
• Metalwork compliant to PICMG® 2.0 6U/4HP (233.35 mm by 160 mm) / (20.32 mm typ.)

CP6923 Introduction
Page 1 - 4 CP6923 User Guide
1.1.2 General compliances
The CP6923 is conform to the following specifications:
• PICMG® 2.0 R3.0 CompactPCI® Specification, as amended by ERN 2.0-3.0-002;
• PICMG® 2.1 R2.0 CompactPCI® Hot Swap Specification;
• PICMG® 2.5 R1.0 CompactPCI® Computing Telephony Specification;
• PICMG® 2.9 R1.0 CompactPCI® System Management Specification;
• PICMG® 2.10 R1.0 Keying of CompactPCI® System Management Specification;
• PICMG® 2.16 R1.0 Sep. 5, 2005 Packet Switching Backplane Specification
• Intelligent Platform Management Interface Specification V1.5
• IEEE 802.3, 2000
• IEEE 802.3ae 2002
• Small Form-factor Pluggable (SFP) Transceiver MultiSource Agreement (MSA), Sept.
14th, 2000
• SFF Committee, INF-80077i, rev. 4.0, 10 Gigabit Small Form Factor Pluggable Module
(XFP)
• ANSI/Vita 30.1-2002 American National Standard for 2mm Connector Equipment Prac-
tice on Conduction Cooled Euroboards (option).
1.1.3 Hot Swap Capability
The board supports Full Hot Swap capability as required by PICMG 2.1 R2.0. It can be removed
or inserted in a powered slot. Please refer to the PICMG 2.1 R2.0 specification for additional
details.

CP6923 Introduction
Page 1 - 5 CP6923 User Guide
1.2 Technical Specification
Table 1-1: CP6923 Main Specifications
CP6923 SPECIFICATIONS
Mechanical •6U/4HP form factor mechanically compliant to PICMG 2.0
•233.35 mm x 160 mm
•Weight: 600g typ
Power Requirements •Maximum: 50W
•Operating Voltage: 5V (5A max), 3.3V (7A max)
Temperature •Operating: 0°C to +55°C (standard version) and -40°C to +85°C for temperature
extended version (CP6923-E)
Humidity Designed to meet or exceed the following:
•Bellcore GR63, Section 4.1
•Operating: 15%-90% (non-condensing) at 55°C (131°F)
•Non-Operating: 5%-95% (non-condensing) at 40°C (104°F)
Altitude Designed to meet or exceed the following:
•Operating: 4000 m (13123ft)
•Non-operating: 15000 m (49212 ft)
Vibration Designed to meet or exceed the following:
•Bellcore GR-63, Section 4.4
•Operating: 1.0G, 5-500Hz each axis
•Non-operating: 0.5G, 5-50Hz, 3.0G, 50-500Hz each axis
Shock Designed to meet or exceed the following:
•DIN/IEC 60068-2-27
•MIL-STD-810E, Method 516
•30G, half-sine 11ms, each axis
Safety Designed to meet or exceed the following:
•UL 60950-1
•EN 60950
•LVD 73/23/EEC
•Denan Law
EMC Designed to meet or exceed the following:
•FCC 47 CFR Part 15, Subpart B
•EN55022, EN55024
•EN 300 386
Reliability •MTBF: > 198,000 hours @ 30°C/86°F (Telcordia SR-332, Issue 1)

CP6923 Introduction
Page 1 - 6 CP6923 User Guide
LEDs •IPMB Status LED
•Hot Swap LED
•“Healthy“ and “Activity“ LED (LED 1 and 2, green)
•Gigabit Ethernet Link Port Status LED
•20 LEDs (status indication for standard fabric interfaces)
•PowerPC 10/100BASE-T Management LEDs
•Green LED: Link/Activity
•Amber LED: Speed
Board Management •based on IPMI 1.5
•FRU Management
•Sensors (Voltage, Current, Temperature, Fuse)
•Status and Alerting
•Hot Swap Management
•Local SEL
Table 1-1: CP6923 Main Specifications (Continued)
CP6923 SPECIFICATIONS

CP6923 Introduction
Page 1 - 7 CP6923 User Guide
1.3 Software Support
The following table contains information related to software supported by the CP6923.
Table 1-2: CP6923 Software Specification
CP6923 SPECIFICATIONS
General •Reliable field upgrades for all software components
•Dual boot images with roll-back capability
•Management via SNMP and Command Line Interface
•System access via TELNET, SSH and serial line
•Hot-Swap support (IPMI)
Ethernet/Bridging •Static link aggregation (IEEE 802.3ad) on any port combination
•Classic and rapid spanning tree algorithms shall be supported (IEEE 802.1D,
IEEE 802.1w)
•Quality Of Service on all ports (IEEE 802.1p)
•Full Duplex operation and flow control on all ports (IEEE 802.3x)
•Static MAC filtering
•Port Authentication (IEEE 802.1X)
•Auto negotiation of speeds and operational mode on all external GE interfaces
as well as on all base fabric interfaces
•Layer 2 multicast services using GARP/GMRP (IEEE 802.1p)
•VLAN support including VLAN tagging (IEEE 802.3ac), dynamic VLAN registration
with GARP/GVRP (IEEE 802.1Q) and Protocol based VLANs (IEEE 802.1v)
•Double VLAN tagging
•Port Mirroring
IP Routing •Redundancy of routing functionality using a second switch hub board
•IPv4 Forwarding on all base channels and connected uplink ports
•Quality of service according to the DiffServ standards
•ARP for all routable interfaces
•ICMP for all routable interfaces
•OSPF routing protocol version 2
•RIP routing protocol version 2
•VRRP (virtual router redundancy protocol) for transparent fail over of default routers
•IGMP snooping
QoS •CoS (Class of Service )
•DifffServ (Differentiated Services)
•ACL (Access Control List)
