Koolr red rack User manual

BASE AND TRIM
ASSEMBLY & INSTALLATION GUIDE

TOOLS AND COMPONENTS
ASSEMBLE RACK TO BASE
TRIMNails x 8
BASE
7/8” Screws x 8
Phillips ScrewdriverHammer
ATTACHING RACK TO BASE
Screw through bottom horizontal bars into BASE* with 7/8” screws or nails
( gure A ). With base section in place, check level and adjust with shims
as required.
A
Usable as Crown molding

END CAP
(optional)
NAIL IN TRIM
Nail through TRIM* into BASE at groove to hide nails ( gure A ). Nail
moldings to face of base and racks (see DETAIL B).
A
* If END CAP will be installed replace the trim with the one supplied in the END CAP set F23C
ADD TRIM TO RACK AND BASE
3/16"
6
9"
1"
1/8"
1/2"
TRIM
BASE
1
SHIM AS REQUIRED
TO LEVEL
RACK
WALL
DETAIL B

LIMITED WARRANTY
Koolr Products Inc. warrants this product to be free from defects due to workmanship
or material, under normal use and service, for a period of one (1) year after the date of
purchase. Please call our customer service department at 1-888-274-8813 or e-mail us
at [e-mail]
This warranty does not cover normal cosmetic wear, cosmetic defects, damage resulting
from improper assembly or maintenance, shipping damage, accident, or any misuse,
abuse or use contrary to the written instructions. This product is not warranted for com-
mercial use.
The warranties expressed above constitute the entire warranty of Koolr Products Inc. with
regard to its products and are in lieu of and exclusive of all other warranties, express or
implied, including any of merchantability or tness for a particular purpose. In no event
shall Koolr Products Inc. be liable or responsible for incidental or consequential dam-
ages, including spoilage or breakage of wine. It is your own responsibility to insure your
wine, and to take all reasonable and necessary precautions to safeguard its condition.
© Koolr Products Inc. 2011
TEST BEFORE USE
Use of Red Rack is strictly at your own risk. Koolr Products Inc. will not
accept any responsibility or liability for damages resulting from units not
assembled precisely as directed, or not securely fastened to a wall or
support with suitable fasteners.
Before placing any bottles in your Red Rack, test it thoroughly to make
sure all fasteners are secure.
