Kooltronic Advantage Sentry Series User manual

Keep This Manual
With Fan
ADVANTAGE SENTRY SERIES
FILTER FAN
OPERATOR'S MANUAL
KOOLTRONIC, INC.
30 Pennington-Hopewell Road
Pennington, NJ 08534
609•466-3400
FAX: 609 • 466-1114
www.kooltronic.com
900-057-05 (11/21)
(CDR: 20367)
CAUTION
BEFORE INSTALLING AND
USING THIS FILTER FAN, IT IS
IMPORTANT THAT THIS MANUAL
BE READ AND UNDERSTOOD
THOROUGHLY
Advantage Sentry Series
NEMA 3R Filter Fans
READ AND SAVE THESE INSTRUCTIONS
Find additional information on
this model at kooltronic.com or
use the Technical Documents
QR code below.
Technical
Documents

2
TABLE OF CONTENTS
Page
I. Introduction 2
II. Cautions and Warnings 3
III. Incoming Inspection 4
IV. Product Handling 4
V. Product Identification and Nameplate 4
VI. Installation Instructions 4 - 5
VII. Drawings and Dimensions 6
VIII. Specific Model Data 7
Technical Data
Replacement Filters
Optional Grille Assemblies
IX. Packing Procedure for Warranty Return 8
X. Maintenance 8
XI. Warranty 9
I. Introduction
This Manual provides you with the necessary general information for properly installing and operating
Advantage Sentry Series Filter Fans. Unit specific technical data and mounting instructions are presented
later in the Manual.

3
II. Cautions and Warnings
CAUTION
Do not operate fan without fanguard in place.
CAUTION
The risk of fire, electric shock or injury exists when cleaning or performing maintenance on these
units. Disconnect this fan from the power supply before servicing.
WARNING
To Reduce the Risk of Fire or Electric Shock, Do Not Use This Fan With Any Solid-State Speed
Control Device.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY, OBSERVE THE FOLLOWING:
Use this unit only in the manner intended by Kooltronic. If you have questions, contact Kooltronic.
Before servicing or cleaning this unit, switch power off at the service panel and lock service panel
to prevent power from being switched on accidentally. If service panel cannot be locked, securely
fasten a prominent warning device, such as a tag, to the panel.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY, OBSERVE THE FOLLOWING:
Installation work and electrical wiring must be done by qualified person(s) in accordance with all
applicable codes and standards, including fire-rated construction. When cutting or drilling into a
wall or ceiling, do not damage electrical wiring and other hidden utilities.
CAUTION
For general ventilating use only. Do not use these fans to exhaust hazardous or explosive material
and vapors

4
III. Incoming Inspection
Advantage Sentry Series Filter Fans are designed, built, and packaged to withstand the shock and vibration
associated with shipment by common carriers. Occasionally improper handling during shipping causes
damage. Therefore, a thorough inspection should be performed upon receipt of all shipments. Any carton tears,
dents, scratches, or loose articles should be noted on the Freight Bill. Cartons should be opened promptly and
the units inspected for CONCEALED DAMAGE.
An immediate claim MUST be filed with the freight carrier and an inspection requested. Retain all packing
materials. Kooltronic cannot assume responsibility for Consignee's failure to file a timely freight claim.
IV. Product Handling
■Do not attempt to operate your Filter Fan until you read and thoroughly understand this Manual.
■Before operating this unit, all electrical wiring must be checked to assure the proper connections.
■Use only on GFCI Protected Recepticals.
V. Product Identification and Nameplate
Each Filter Fan includes an identification nameplate. This nameplate provides:
CAUTION
Operate this unit only on the proper voltages and frequencies as noted on the nameplate
➀Model Number
➁Electrical Power Characteristics
➂Serial Number
We recommend you copy this information from your
unit.
➀When ordering parts, specify
the Model Number.
➁Before operating, be sure
that the power source
matches these requirements.
WITH THIS FAN
EXTENSION CORD
THERMALLY PROTECTED
CSA STD C22.2 NO. 113
UL STD 50E; CERTIFIED TO
CONFORMS TO UL STD. 507,
E361673
Filter Fan
DO NOT USE AN
OUTDOOR USE
FINAL ASSY. NO.
M.O. NUMBER
MAINTAINED
NEMA TYPE 4
KOOLTRONIC, INC. PENNINGTON, NJ
MANUFACTURED BY:
ALL MOTORS ARE
VIOLATES WARRANTY
UNAUTHORIZED SERVICE OR MODIFICATION
SERVICE AIR FILTERS REGULARLY
AMPSPH.FREQ.VOLTS
SERIAL NO.
MODEL NO.
VI. Installation Instructions
The Advantage Sentry Series NEMA 3R Filter Fans have been engineered to be installed easily. These NEMA 3R
filter fans have been designed for indoor or outdoor use. Prior to mounting, refer to pages 6 for the mounting
drawings showing dimensions and locations of mounting holes and cutouts. Prior to cutting or drilling, make sure
that cutouts and mounting holes do not interfere with components inside the cabinet.
➀
➁
➂

5

6
VII. Drawings and Dimensions
TAMPER-PROOF
SCREW
INSIDE VIEW
BOTTOM VIEW
(4) .25 [6.0]
DIA. HOLES
A
TOP
MOUNTING PLAN
B
C
D
E
F
A
G
H
J
B
K
L
M
N
P
R
S
Dimensions, inches[mm] are for reference only and subject to change.
Model A B C D E F G H
KNP40F 6.50 [165.0] 7.00 [178.0] 4.88 [124.0] 6.00 [152.0] .81 [21.0] .25 [6.0] 10.90 [277.0] 8.03 [204.0]
KNP60F 8.00 [203.0] 7.00 [178.0] 6.75 [171.0] 7.36 [187.0] .63 [16.0] .25 [6.0] 12.40 [315.0] 9.44 [240.0]
KNP100F 12.00 [305.0] 11.00 [279.0] 10.25 [260.0] 10.88 [276.0] .88 [22.0] .25 [6.0] 16.40 [417.0] 13.53 [344.0]
Model J K L M N P R S
KNP40F 4.81 [122.0] 1.76 [45.0] 4.74 [121.0] 3.06 [78.0] 2.75 [70.0] 3.97 [101.0] .76 [19.0] 5.66 [144.0]
KNP60F 5.35 [136.0] 1.79 [46.0] 6.37 [162.0] 3.56 [90.0] 4.25 [108.0] 4.13 [105.0] .77 [19.0] 7.10 [180.0]
KNP100F 8.12 [206.0] 3.56 [90.0] 10.00 [254.0] 4.56 [116.0] 4.25 [108.0] 4.39 [112.0] .81 [21.0] 10.60 [269.0]
Dimensions, inches [metric], are for reference only and subject to change.
Power Cord location differs between models.

7
VIII. Specific Model Data
Technical Data
KNP40F 115 VAC 50/60 .22/.22 18/17 60/69 14 158 5
K2NP40F 230 VAC 50/60 .10/.11 15/17 50/51 14 158 5
K6NP40F 12 VDC - 0.4 4.8 52 14 140 5
K7NP40F 24 VDC - 0.3 7.2 51 14 140 5
K8NP40F 48 VDC - <.1 - 57 14 158 5
Unit Operating Approximate
Frequency Imput Imput Airflow Temp. ºF Weight
Model Voltage Hz Amps Watts CFM Min. Max. (lbs.)
KNP60F 115 VAC 50/60 .27/.32 31/37 116/134 -40 158 6.5
K2NP60F 230 VAC 50/60 .12/.15 28/34 111/133 -40 158 6.5
K8NP60F 48 VDC - 0.4 19.2 132 14 158 6.5
Unit Operating Approximate
Frequency Imput Imput Airflow Temp. ºF Weight
Model Voltage Hz Amps Watts CFM Min. Max. (lbs.)
KNP100F 115 VAC 50/60 .35/.38 36/38 141/172 -40 158 12.5
K2NP100F 230 VAC 50/60 .50/.45 64/62 151/188 -40 158 12.5
Unit Operating Approximate
Frequency Imput Imput Airflow Temp. ºF Weight
Model Voltage Hz Amps Watts CFM Min. Max. (lbs.)
Standard Features
Integrated Fan Guards
Integrated Sealing Gasket
Secure Mounting
Baked Powder Finish
UL/CSA Shielded Ball Bearing Motors
UL/CUL Listed
Washable, Reuseable Filter
Replacement Filters
Filter
Model Part Number
KNP40F 531F
K2NP40F 531F
K6NP40F 531F
K7NP40F 531F
K8NP40F 531F
KNP60F 681F
K2NP60F 681F
K8NP60F 681F
KNP100F 1081F
K2NP100F 1081F
Optional Grille
Assemblies
Grille Assembly
Model Part Number
KNP40F KNPA40F
K2NP40F KNPA40F
K6NP40F KNPA40F
K7NP40F KNPA40F
K8NP40F KNPA40F
KNP60F KNPA60F
K2NP60F KNPA60F
K8NP60F KNPA60F
KNP100F KNPA100F
K2NP100F KNPA100F

X. Maintenance
Kooltronic Advantage Sentry Series Indoor/Outdoor Filter Fans require no maintenance. These Filter Fans are
designed to require only the routine cleaning of air filters to assure unimpeded airflow through the unit. It is not possible
to recommend specific cleaning intervals, since the level and nature of airborne particulate matter differs widely with
each installation. It is generally sufficient to remove and wash the reuseable aluminum mesh air filters when the outer
surfaces of these filters appear covered with a thin layer of dust or lint. Filter coating adhesive, available from
Kooltronic, is recommended (Part number A-16 - 10 oz. container). Replacement filters are also available from
Kooltronic. See page 7 for part numbers.
If filter service is neglected or delayed, the filter fans will not perform at there design capacity. The first indication of an
excessively clogged filter is usually a gradual increase of temperature within the equipment cabinet.
Filter removal and service
Kooltronic Advantage Sentry Series Indoor/Outdoor Filter Fans feature an easily removable filter to facilitate
necessary cleaning.
CAUTION
1) Remove the Torx tamper resistant screw at the bottom of the unit. Remove the cover to expose the filter.
2) Pull the filter downward until the top of the filter clears the upper filter retainer. Tilt the filter upward to remove
filter and/or filter retainer.
3) After removal, the filters should be flushed under warm running water with the clean side up, driving
contaminants out of the dirty side of the filter. If the accumulated dirt is oily, washing in a detergent bath is
recommended, followed by a warm water rinse as above.
4) The aluminum mesh filters may be sprayed with Kooltronic A-16 Filter Recoating Adhesive to trap fine, airborne
contaminants, or they may simply be dried and reinstalled as strainer-type filters.
5) Reinstall the filter and/or filter retainer.
6) Reinstall the cover with tamper resistant screw.
Do not operate the filter fan for extended periods of time with the filter removed. Operation with
the filter in place is necessary for the fan to maintain its NEMA rating.
8
IX. Packing Procedure For Warranty Repair
Pack the Filter Fan in an appropriate carton (preferably the original carton), with adequate internal protective
packaging, making sure carton is marked properly.

XI. Standard Warranty
THIS WARRANTY CONSTITUTES THE ENTIRE WARRANTY WITH RESPECT TO THE PRODUCT AND IS IN
LIEU OF ALL OTHERS, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY
AND WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND IN NO EVENT IS KOOLTRONIC
RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER.
RETURN AUTHORIZATION (RA) PROCEDURE
KOOLTRONIC products are warranted to be free of defects
in workmanship, materials and components. The following
warranty periods apply from date of shipment:
■Air moving devices/components and hermetic system
components: 1 year
■Spare parts, except filters: 90 days
The above warranty applies when the equipment is operated
under the following conditions:
■Ambient temperature not in excess of 125°F (52°C) in
normal atmosphere or as stated on product nameplate
■Voltage variation no greater than ± 10% from nameplate
rating
■Frequency variation no greater than ±3Hz from nameplate
rating
■Maximum cooling load no higher than air conditioner
nameplate rating
■Waiting five minutes before restarting air conditioner after
intentional or accidental shutoff
■Compliance to all other installation, maintenance and
operating instructions, as supplied
■The purchaser assumes the responsibility of grounding
the unit and installing it in accordance with local electrical
and safety codes, as well as the National Electric Code
(NEC) and OSHA
KOOLTRONIC cannot assume responsibility for
mis-application of its products or the erroneous
selection of an inappropriate product by a non-
authorized KOOLTRONIC representative. Our
applications engineers will gladly assist in the
selection of the proper product, provided all
required details of the application are furnished.
■All returns require a Return Authorization number whether
the return is for warranty or non-warranty repair, rotation of
stock, damage or any other reason. Returns without an RA
number will be refused.
■Customer must call KOOLTRONIC After Sale Kare (ASK),
Pennington, New Jersey (609 • 466 • 3400) to obtain an RA
number, or email [email protected].
■The following information is required when an RA is
requested:
- Original customer Purchase Order number and date
- Date product was received by customer
- Number of parts to be returned
- Product description, model and serial number
- Reason for return
- Action requested
- Contact name, telephone, FAX numbers and e-mail address
■Pack unit in a suitable container for shipment, preferably the
original packaging if available. All Air Conditioners must be
returned in an upright position properly secured to a pallet.
Improper packaging may void warranty claim. If an Air
Conditioner is received laying down or shipped via UPS or
similar small parcel service the warranty will be void.
■Mark carton prominently with KOOLTRONIC’s Return
Authorization Number.
■Enclose all pertinent documents.
■Freight charges on all products returned to KOOLTRONIC
shall be paid by the customer. Unauthorized collect shipments
will be refused.
■If a unit is repaired under Warranty, KOOLTRONIC will pay
the freight charges both ways within the Continental USA
at KOOLTRONIC’s negotiated rates. Warranty repaired
units will be returned to customer at KOOLTRONIC expense
only within the Continental USA.
■All authorized returns are subject to a restocking fee.
KOOLTRONIC assumes no liability beyond the repair or
replacement of its own product. This Warranty does not
cover:
■Labor or reimbursement of labor for evaluation, removal,
installation, repair, or cost of any warranted part, unless
authorized in writing by KOOLTRONIC
■Use of equipment for other than its designed purpose or
operating conditions
■Operation in harsh, oily, corrosive or other abnormal
environmental conditions, without the proper filtration,
sealing, protective coatings and/or weather protection
■Damage to hermetic system resulting from continuous
operation with dirty or clogged air filters or improper or
negligent maintenance
■Use of refrigerant other than designated
■Customer modification or abuse
■Shipping damage or other accident (Claims for shipping
damage are the responsibility of the customer. Timely
claims must be filed by the customer with the freight carrier)
■Cracked or broken hermetic tubing, brazed joints or other
internal damage caused by shipping or mishandling
■Damage caused by shipping units attached to an
enclosure
■Any and all conditions resulting from noncompliance with
the preceding operating conditions
■Returned freight must be paid by customer
■This standard warranty does not apply to custom
products. Consult your KOOLTRONIC representative
for limitations
9
