Korenix JetWave 2316 Series User manual

JetWave 2316 Series
Industrial Cellular + 802.11n 2.4G WIFI IP Gateway, 4xGT+2G SFP
Quick Installation Guide V1.0
JetWave 2316 is an industrial grade Secure Cellular + 802.11n 2.4G WIFI IP Gateway with
4xGT + 2G SFP Switch ports, which enables multiple Ethernet ports and RS232-422-485
serial port access over LTE network.
R&TTE Directive 1999/5/EC Declaration
The product may be operated in all European Union countries. While you see the CE Marking
printed on our product, it indicates the product complies with the requirement of the R&TTE
(1995/5/EC) Directive. You can download the formal document of the product from our
Web site or send inquiry to our Sales/Technical people.
Band Information
General Requirement
Only trained and qualified personnel should be allowed to install, replace, or service this
equipment. The device can only be operated according to the technical specification. Read the
installation instructions/user manual, including Power, Cable, Antenna, Warning info and well
Grounding is must before connecting the system to the power source.
DC Input
Insert the positive and negative wires into the V+ and V- contact on the terminal block
connector. The device supports dual DC power input, the typical power source is DC 24V
(range from 12~48VDC).
Insert the SIM
Unlock the front plate of Dual SIM Socket.
Insert the SIM card into SIM 1 (Default startup SIM Socket is SIM 1) before power on
system. The system may take around 1 minutes to startup, and then it will automatically
connect to your ISP.
If you want to use SIM 2 for carrier provider redundant, please insert the 2 SIM cards
before power on the system. If you want to use SIM 2 as startup SIM socket, please go to
Web GUI to modify the setting.
If you insert the SIM after power on, the system may take around 30 second to re-read the
SIM card info.
If the Cellular connection is not connected, please go to Web GUI to check the Cellular
Status, Settings or download the debug info for us.
Mounting The Unit/Antenna and well Ground is MUST
JetWave 2316 supports Din-Rail mounting, the mounting kit is pre-installed. You can
mount the device to the DIN Rail directly.
Connect the Ethernet cable, Antenna, extended antenna cable and Ground before power
on the system. Grounding is important and MUST in field.
The JetWave 2316 Series provides web management interface for basic and advanced settings.
Before configuration, please make sure your system meets the following requirements:
A computer coupled with 10/100/1000 Base-T(X) adapter.
Configure the computer with a static IP address of 192.168.10.X/192.168.1.x (X cannot be
0, 1, nor 255).
The product works as Router mode in default. The GT1 to GT4, GF1 and GF2 are LAN
ports, the default IP address is “192.168.10.1”.
The default IP Address of WAN port is “192.168.1.1”
The WIFI default setting of JetWave 2316 is AP mode, SSID is “JetWave2300_1”, operate
in 2437MHz (channel 6).
Open web browser (Ex: IE, Chrome, Firefox…) and enter the IP address of the product.
You will see the System Login page.
The default User Name is “admin”.
The default Password is “admin”.
Check User Manual for advanced settings.
IF the web browser is not access, please check your firewall, JAVA version or contact your
support window for further help.
Note: If you forget the IP Address, you can use Korenix View Utility to search the device’s
IP address, it can be found at Download page of the Korenix web site:
http://www.korenix.com
Appearance Web GUI
Installation
The Korenix View Utility provides you convenient tool to scan the network and configure the
connected Korenix device.
Step 1: Open the Korenix View Utility. (Must later than JetView V1.6)
Step 2: Select the correct NIC (Network Interface Card) from the NIC list.
Step 3: Click “Discovery”, and then the Nodes and its IP address can be found and listed in
Node list.
Step 4: After you scan the network, select the
device and click “Open Web GUI” to access
the web management interface. You can also
modify the IP address/Netmask directly on the
selected entry and then click “Change IP“ to
change IP settings.
Note: Please check the User Manual to
configure the other software settings.
5 Years Warranty
Each of Korenix’s product is designed, produced, and tested with high industrial standard.
Korenix warrants that the product(s) shall be free from defects in materials and
workmanship for a period of five (5) years from the date of delivery provided that the
product was properly installed and used.
This warranty is voided if defects, malfunctions or failures of the warranted product are
caused by damage resulting from force measure (such as floods, fire, etc.), other external
forces such as power disturbances, over spec power input, or incorrect cabling; or the
warranted product is misused, abused, or operated, altered and repaired in an unauthorized
or improper way.
Attention! To avoid system damage caused by sparks, please DO NOT plug in
power connector when power is on.
The product is in compliance with Directive 2002/95/EC and 2011/65/EU of the
European Parliament and of the Council of 27 January 2003 on the restriction of the use of
certain hazardous substances in electrical and electronics equipment (RoHS Directives &
RoHS 2.0)
Korenix Customer Service
KoreCARE is Korenix Technology's global service center, where our professional staffs are
ready to solve your problems at any time.
Korenix global service center: [email protected].
Document download: http://www.korenix.com -> Download
Support
Korenix View Utility
Dual
SIM :
Antenna:
Antenna 2316-LTE-E
A
B
C
D
LTE-Aux
LTE-Main
WIFI 1-1
WIFI 1-2
2316-LTE-U
LTE-Aux
LTE-Main
-
-
Model Name JetWave 2316-LTE-E JetWave 2316-LTE-U
Operating
Frequency
2.412~2.472GHz -
LTE Band 20/8/3/7/1 LTE Band 17/5/4/2

Patent No. (Taiwan):
Granted Invention: I 313547
Granted Invention: I 321415
Granted Invention: I 344766
Granted Invention: I 346480
Granted Invention: I 356616
Granted Invention: I 364684
Granted Invention: I 376118
Granted Invention: I 393317
Granted Invention: I 398066
Granted Invention: I 398125
Granted Invention: I 459757
Utility Model: M 339841
Utility Model: M 339840
JetWave 2316 系列
工业用 Cellular + WIFI IP, 4千兆电口+2千/百兆光口IP 网关
快速安装指南 V1.0
JetWave 2316 是工业级的 Cellular + WIFI IP Gateway 安全网关 ，并配置有4个千兆以
太电口与2个千/百兆光口，它能提供客户可以透过 Cellular 联机存取工业以太网络。
2316 也支援 802.11n(2.4G)，可达 2T2R 300兆带宽，可应用于 WIFI/Cellular 需整合
或备援之场合。
频段信息
R&TTE指令1999/5/EC宣告
本产品可以在所有欧洲联盟成员国遴行。当您看到CE标志印在我们的产品，表示产
品符合R＆TTE(1995/5 / EC)指令的要求。您可以从我们的网站下载该产品的正式文
件或发送请求到我们的销售/技术人员。
一般要求
只有经过培训的合格人员才能安装，更换或维修此设备。该设备只能按照技术规范
操作。系统连接到电源之前，请阅读安装说明，包括电源，接地，电缆，天线和警
示手册的信息。
直流输入
将正负极导线分别接入V+与V-的终端连接器.，此装置支持双直流电源，标准电压为
直流 24V (直流电压范围为 12V~48V)。
安装SIM卡
卸下双SIM卡插槽的前版。
关闭电源，安装 SIM 卡到 SIM 1 的插槽
(SIM 1 为预设启用的 SIM 卡插槽)。
系统会在一分钟的启动时间去侦测 SIM 1 插槽的 Cellular 卡片，并自动联机上电
信运营商。
如果要使用 SIM 2 做为 Cellular 联机备援，请在开机前分别安装好两张SIM 卡到
SIM 1 与SIM 2 插槽。
如果要使用 SIM 2 做为 SIM 卡的启动插槽，可以透过网页接口来修改设定。当3G
无法联机时，请到网页接口检查3G状态与设定。
如果上电后才插入SIM卡，请等待30秒，系统需重新侦测SIM卡。
本机与天线的安装及接地
JetWave 2310/2311 支援导轨安装，相关导轨配件已先安装完成，您可以直接将装
置挂在导轨上。
请根据您的型号，参照 “外观说明” 的部份将 WIFI 天线 (和/或) Cellular 天线安装
到相对应的天线接孔位置。
本设备必须接地。接通电源前，為本设备及电源皆接地。
JetWave 2316 系列提供了网页接口可管理基本配置与进阶配置。
开始配置前，请先确认您的系统满足以下需求：
一台具有10/100/1000 Base-T(X) 网络接口的计算机。
设定一组静态IP地址 192.168.10.X (X 不可为0、1或255) 到这台计算机。若是连接
在WAN接口,請设定一组静态IP地址 192.168.1.X 。
默认这WAN和6个LAN以太千兆接口是路由模式，分属不同网段，您可以任选一
个接口来存取网页管理接口。
JetWave 2316 LAN 的默认 IP 地址为 192.168.10.1。
JetWave 2316 WAN 的默认 IP 地址为 192.168.1.1。
JetWave 2316 系列的 WIFI 默认设置为 AP 模式，SSID为JetWave2300_1，运作在
2437MHz (channel 6)。
打开网页浏览器(如: IE, Chrome, Firefox…)并输入IP地址(预设: 192.168.10.1)，您将
会开启系统登入画面。
默认的使用者名称为 “admin”。
默认的密码为 “admin”。
如需进阶设定请参考使用手册。
如果网页浏览器无法存取，请检查计算机的防火墙、JAVA 版本或连系您的技术支
持窗口提供更进一步的协助。
备注: 若您不清楚设备的IP地址，您可以使用Korenix View Utility 来搜寻设备的IP
地址，您可以在 Korenix 网页的Download(下载)页面下载。网站
http://www.korenix.com
产品名称 JetWave 2316-LTE-E JetWave 2316-LTE-U
操作频段 2.412~2.472GHz -
LTE Band 20/8/3/7/1 LTE Band 17/5/4/2
Web 软件接口
JetWave 2316 可支持最新版本的 Korenix View Utility管理软件，这个管理软件方便
您搜寻网络地址与部分基本设定。
步骤 1：打开 Korenix View Utility管理软件 (必须是V1.6 版之后) 。
步骤 2：在网络卡列表中选取指定的网络卡或选All Interface(全部) 。
步骤 3：按下 “Discovery” (搜寻), 接着所有此网络的Korenix交换机/AP/网关和它们
的产品名称,IP地址,MAC地址,Netmask 位址与软件版本…等讯息将可以被找到，并
显示在设备列表下。
步骤 4：在搜寻到设备后，选取指定设备按
下鼠标右键“Open Web GUI”即可允许您直
接连上Web设定接口，妳也可以于此直接
修改IP/Netmask地址后按下“Change IP“ 直
接修改其设定。
备注: 其他进阶软件设定部分请参考用户使
用手册。
5 年质保
每个Korenix的产品，在设计，生产和测试过程都遵循高的工业标准。Korenix保证
其产品从交货起五年内无材料和工艺缺陷，但必须确保产品被正确地安装和使用
。
质保产品由下情况造成的缺陷，失效或故障不在质保范围：
由强制实施造成的（如洪水，火灾等），其它外部力量，如电源干扰，过规格电
源输入，或者接线错误，或者产品被误用，滥用，或者由未授权或不当的方式运
行，改造和维修。
注意! 为了避免火花损坏系统, 请不要在带电的情况下插入电源接头。
我们的产品符合欧洲2002/95/EC ，2011/65/EU标准和理事会在2003年1月21日关于
限制电气和电子设备使用某些有害物质条例 (RoHS 条例 & RoHS 2.0)。
Korenix 客户服务
KoreCARE是Korenix科技的全球服务中心，在那里我们的专业人员随时为你解决问
题。
Korenix 全球服务中心: [email protected].
文件下载: http://www.korenix.com -> Download
技术支持
Korenix 查看工具
雙 SIM
卡槽
接地
天线
2316-LTE-E
A
B
C
D
LTE-Aux
LTE-Main
WIFI 1-1
WIFI 1-2
2316-LTE-U
LTE-Aux
LTE-Main
-
-
外观说明
概述
安装
天线 Korenix Technology Co., Ltd.
(A Beijer Electronics Group Company)
Tel:[phone]
Fax:[phone]
Business service:[email protected]
Customer service:[email protected]
www.korenix.com
CPQ000W2316000
