Korenix JetWave 2800 Series User manual

Korenix JetWave 2800 Series
Industrial Outdoor Wireless Access Point
User Manual
V1.0 Apr. 2013

Copyright
Copyright © 2013 all rights reserved. No part of this publication may be reproduced, adapted, stored in
a retrieval system, translated into any language, or transmitted in any form or by any means without
the written permission of the supplier.
About This Manual
This user manual is intended to guide professional installer to install the JetWave 2800 and how to
build the infrastructure centered on it. It includes procedures to assist you in avoiding unforeseen
problems.
Conventions
For your attention on important parts, special characters and patterns are used in this manual:
This indicates an important note that you must pay attention to.
This indicates a warning or caution that you have to abide.
Bold: Indicates the function, important words, and so on.
Note:
Warning:

Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.

FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
To avoid the possibility of exceeding radio frequency exposure limits, you shall beep a distance of at
least 100cm between you and the antenna of the installed equipment. This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are country
dependent and are firmware programmed at the factory to match the intended destination. The
firmware setting is not accessible by the end user.

Content
Chapter 1 Introduction......................................................................................................................... 1
Introduction......................................................................................................................................... 1
Appearance........................................................................................................................................ 2
Key Features...................................................................................................................................... 2
Typical Application.............................................................................................................................. 3
Chapter 2 Hardware Installation......................................................................................................... 4
Preparation before Installation............................................................................................................ 4
Professional Installation Required.................................................................................................. 4
Safety Precautions.......................................................................................................................... 4
Installation Precautions................................................................................................................... 5
Product Package............................................................................................................................. 5
Hardware Installation.......................................................................................................................... 7
Connect up...................................................................................................................................... 7
Pole Mounting............................................................................................................................... 10
Using the External Antenna .......................................................................................................... 12
Chapter 3 Web Settings..................................................................................................................... 14
Factory Default Settings................................................................................................................... 14
System Requirements...................................................................................................................... 15
How to Login the Web-based Interface............................................................................................ 15
System Setup................................................................................................................................... 17
Wireless Settings.............................................................................................................................. 21
Administration................................................................................................................................... 34
Utility................................................................................................................................................. 38
Status................................................................................................................................................ 42
Logout(admin) .................................................................................................................................. 45
Chapter 4 Utility.................................................................................................................................. 46
JetWave Viewer Utility...................................................................................................................... 46
Chapter 5 Troubleshooting ............................................................................................................... 49
Appendix A. ASCII.............................................................................................................................. 51
Revision History................................................................................................................................. 52

Chapter 1 Introduction Page 1
Chapter 1 Introduction
Introduction
The JetWave 2800 is an industrial IEEE 802.11a/b/g/n Wireless AP which offers a high performance
and reliability wireless solution for both 2.4GHz and 5GHz RF bands. With the JetWave 2800 wireless
access point, a network designer will easily achieve the integration of wired and wireless networks.
With the next generation 802.11n MIMO technology, the AP (up to 3 independent RF modules) offer
high data link rate up to 350Mbps in each single radio options, and provide the redundant wireless
connections to increase the reliability of the entire wireless network. The JetWave 2800 can function
as an access, client, or bridge device.
The advanced features include Korenix patented super roaming technology which seamlessly
enabling the applications of high-speed mobility, RSTP, VLAN, and QoS (WMM). For the wireless
security communication, 64/128/152-bit WEP, WPA/WPA2/802.11i, enable/disable SSID broadcasts,
MAC access control, IEEE 802.11X/RADIUS are supported. The JetWave 2800 provides an industrial
level of immunity to electromagnetic interference and heavy electrical surges. The JetWave 2800
provides PoE compliant power inputs and it can be powered via PoE switch/injector through Ethernet
cable. The IP67 waterproof enclosure (JetWave 2800) with wide -35~70°C operating temperature
design allows users to install the device under harsh environmental conditions.

Chapter 1 Introduction Page 2
Appearance
Figure 1 JetWave 2800
Key Features
Single/Dual/Triple RF Configurable: 802.11a/b/g/n and 2.4G/5G
Superb performance: 3RF with 1GbE up to 350Mbps
Strong TX output power extends distance and coverage
High RX sensitivity enhances receiving signal quality
2x2 MIMO doubles data rate
Supports Super Roaming, Mesh, and Mobility mode (2800-M)
Supports high performance multiple hopping mode (2800-H)
Wireless QoS (WMM) for video precedence transmission

Chapter 1 Introduction Page 3
High gain weatherproof fiberglass antenna by selection
Gigabit PoE power input, PoE injector included
IP67 aluminum housing, -35~70°C outdoor solution
Typical Application
This section describes the typical applications of JetWave 2800. By default, it is set to AP mode which
allows it to establish a wireless coverage; besides, it is also able to join any available wireless network
under wireless client mode. The JetWave 2800 is able to deliver stable and efficient broadband
connectivity for various applications.
Figure 2 Typical Application
Besides, the JetWave 2800 can also be applied into the following environments:
Cost-effectively provide long distance backhaul for remote areas (e.g. village, oil well, island,
mountain and etc.)
Establish local backhaul for campus, farm and factory
Provide and access for video streaming or surveillance for industrial and mining enterprises

Chapter 2 Hardware Installation Page 4
Chapter 2 Hardware Installation
This chapter describes safety precautions and product information you have to know and check before
installing JetWave 2800.
Preparation before Installation
Professional Installation Required
1. Please seek assistance from a professional installer who is well trained in the RF installation and
knowledgeable in the local regulations.
2. The JetWave 2800 is distributed through distributors and system installers with professional
technicians and will not be sold directly through retail stores.
Safety Precautions
1. To keep you safe and install the hardware properly, please read and follow these safety
precautions.
2. If you are installing JetWave 2800 for the first time, for your safety as well as others’, please
seek assistance from a professional installer who has received safety training on the hazards
involved.
3. Keep safety as well as performance in mind when selecting your installation site, especially
where there are electric power and phone lines.
4. When installing JetWave 2800, please note the following things:
♦Do not use a metal ladder;
♦Do not work on a wet or windy day;
♦Wear shoes with rubber soles and heels, rubber gloves, long sleeved shirt or jacket.
5. When the system is operational, avoid standing directly in front of it. Strong RF fields are present
when the transmitter is on.

Chapter 2 Hardware Installation Page 5
Installation Precautions
To keep the JetWave 2800 well while you are installing it, please read and follow these installation
precautions.
1. Users MUST use a proper and well-installed surge arrestor and grounding kit with JetWave 2800;
otherwise, a random lightening could easily cause fatal damage to JetWave 2800. EMD
(Lightning) DAMAGE IS NOT COVERED UNDER WARRNTY.
2. Users MUST use the safety certificated PoE switch/injector with the JetWave 2800. The
Industrial PoE Switch is recommended.
3. Users MUST power off the JetWave 2800 first before connecting the external antenna to it;
otherwise, damage might be caused to the JetWave 2800 itself.
Product Package
The product package you have received should contain the following items. If any of them are not
included or damaged, please contact your local vendor for support.
JetWave 2800 ×1
Pole Mounting Kit ×1
Waterproof Cap for RJ-45 ×1
Quick Installation Guide ×1
ProductCD ×1
Product CD contains Quick Installation Guide and User Manual!
Note:
