KRAFTWERK 3897 User manual

Please read these instructions carefully to ensure the safe and effective use of this tool.
Art. 3897
www.kraftwerk.eu
Rechargeable 4 x 1 W LED lamp
GB
Download Bedienungsanleitung / Téléchargement du mode d’emploi / Instructions download
Descarga de la instrucción de uso / Download de instruções de operação / Download del manuale
www.kraftwerk.eu
Your dealer:
4
6. Technical Data
7. Warnings
- Do not connect the charger base to main supply if the cable is damaged.
- The charger base is applicable for charging indoors. Please keep it away from water,
extreme temperatures and direct exposure to sunlight, rain and snow.
- Damages or malfunction of the lamp or charger base can be caused by disassembling,
modifying, wrong maintenance and repairing by any unauthorized person,
and will void any warranty claims.
8. Customer services
Contact your local importer of your specialized dealer to obtain address of your service
department. You find our partners under www.kraftwerk.eu
From date of purchase receipt
2 YEARS GUARANTEE
on material- or production-defects
Dimensions: 125 x 130 x 220mm
Voltage: 3.6 V
Battery: Li-ion Battery
LED: 4 pcs at 1 W each
Capacity: 3000 mAh
Charging time: 6-8 hours (90% after 6 hours)
Luminous period: 6-7 hours for normal light (1 LED)
1.5-2 hours for strong light (4 LED)

The additional warning-red front-cover glass can be put over the transparent cover.
Simply unscrew the front cap, insert the red front-cover glass
and screw the front cap back on.
4. Charging Base
There is a special charging base to recharge the 3000 mAh Li-Ion batteries of the lamp.
The green light is on while the base is connected to mains supply and receives power (standby).
When the lamp is put on the base, the red light indicates that the lamp is recharging. Recharging
has completed as soon as the red light has turned off.
5. Protection
The charger base is equipped with an over-heating, over-charging/ -discharging protection.
The lamp itself will shut down the charging process if the battery temperature is too high.
1. Description
The lamp is a hand-hold, rain proof working lamp and spot light in one. It is equipped with 4
strong LED which can be activated either one or all four, for both possibilities either in continu-
ous illumination or blinking mode, so that it can be used for a wide range of long-distance
illumination. An adjustable support lets the lamp stand properly while throwing light on one
spot. The lamp is powered by Li-Ion batteries and can be recharged with the enclosed charger
base.
Accessories included:
- Reflective shoulder belt with quick clamp hooks
- Additional red lens in warning-red
- Protective pouch for red lens
- Soft textile carrying bag
2. Operation
The product is operated by two main buttons:
Button 2 is the main On/Off button.
- Press it once to switch on the 4 LEDs to shine continuously.
- Press it again to switch it off.
- Or press it once to switch off any of the functions
of the second switch.
Button 1 is for operating the LED lights as follows:
- Press once to switch on one LED to shine continuously.
- Press it a second time to get one LED blinking.
- Press it a third time to get all 4 LEDs blinking.
- Press it a fourth time to restart the order by switching on
one LED to shine continuously.
3. Features
The lamp is equipped with an adjustable stand.
It can be carried by hand,
hung over the shoulder with the reflective shoulder belt
or can be used as a hook to hang up.
3
GB
2
2
1
