105VB
1:5 Video Distribution amplifier
The Kramer 105VB is a high performance 1:5 distribution amplifier for composite video signals. It accepts one
input and distributes it to five identical outputs using BNC connectors. Video bandwidth of 280MHz ensures that
the 105VB remains transparent even in the most critical applications. A 12V power supply is included, but the
optional VA-50P can power up to six Kramer devices requiring 12VDC. The 105VB is part of the Kramer TOOLS
family of compact, high quality, and cost effective solutions for a variety of applications.
INPUT:
OUTPUTS:
VIDEO BANDWIDTH:
COUPLING:
DIFF. GAIN:
DIFF. PHASE:
S/N RATIO:
CONTROLS:
K-FACTOR:
MAX. VIDEO OUTPUT:
POWER SOURCE:
DIMENSIONS:
ACCESSORIES:
OPTIONS:
1 video, 1Vpp/75 Ω on a BNC connectors.
5 video, 1Vpp/75 Ω on BNC connectors.
280MHz - 3dB.
AC.
0.1%.
0.1 Deg.
80dB.
Up to +6dB.
< 0.05%.
2 Vpp.
12 VDC, 100mA.
12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”, W, D, H.).
Power supply, mounting bracket.
Model VA-50P power supply with six 12VDC outlets.RK-T1, RK-T3 rack adapters
Video duplication studios.
Any professional display system requiring an identical picture on several monitors.
CCTV and home theater use.
Rental and staging applications.
