KRS 02THIL15 User manual

Roof Racks
Page 1 of 4
Installation Guide
P#: 02THIL15
Toyota Hilux - 2 Bar
Ed. 2, 22-02-2018
Check List
Check the product part number on the Installation Guide matches the product
supplied.
Check that all parts listed in the Installation Guide are present in the kit.
Do you have all of the required tools for installation including appropriate eye and
hearing protection (PPE)?
Always check for wiring looms and cables before drilling the vehicle.
QTY
8
M8 x 30 Bolt
QTY
18
4.8mm x
12.8mm Rivets
QTY
4
Vehicle Track
Bracket
QTY
2
Roof Rack Bars
QTY
4
Roof Rack Feet
QTY
8
M6 Spring
Washer
QTY
8
M6 Washer
QTY
8
M6 x 35 Bolt
QTY
8
M8 Spring
Washer
QTY
8
M8 Washer
QTY
4
End Cap
QTY
4
End Cap Screw
QTY
8
Rack Mount
Caps
QTY
4
Rubber Pad

Roof Racks - Hilux Page 2 of 4
Installation Guide
Ed. 2, 22-02-2018
1 . 3 .
2 . 4 .
180mm 180mm
Front
230mm 230mm
Rear
1400mm
280mm
180mm
Front -Drivers Side
700
NO DRILL
ZONE
260
370mm
^Measure from the windscreen edge and mark where to cut rubber
strip.
^Lift rubber strip away from car (it is held on with double sided
tape) and cut.
^WARNING : Beware of the AIR-BAG Canister Zone, This is a NO
DRILL ZONE.
^Place bracket in channel, position to the specified measurements
and mark the holes. Using a drill bit and drill stop specified
carefully drill the holes. Note: A drill stop must be used.
Allan Key Blade/Scissors
Masking Tape Silicone Sealant
Rivet GunDrill, Drill bit &
Drill stop
Pen & Centre punch for
marking
5mm6mm
Tools Required
Vehicle Roof Rack Installation
5mm
7mm

Roof Racks - Hilux Page 3 of 4
5 .
7 .
9 .
6 .
8 .
10.
Apply
Silicone
Here
180mm 180mm
Front
230mm 230mm
Rear
1400mm
180mm 180mm
Front
230mm 230mm
Rear
1400mm
370mm
^Vacuum all swarf from drilling.
^Apply silicone around rivet holes, press the bracket firmly down
and rivet the bracket on (it should have cage nuts).
^Loosely mount roof rack feet to bar.
^Place the roof rack onto the vehicle and slide the feet to line up
with the brackets. Remove the rack and tighten the fixings.
^Bolt the rack onto the vehicle using the fixings specified.
11.
^Repeat steps 6-10 for the passenger side bracket.
^Insert the rubber strip on the top of the bar and cut to length.
^Cut to size, and insert the wind buffer strips underneath the bar.
^Insert the plastic caps on the ends of the bar.
^Insert the plastic caps over the fixing holes.
5mm
7mm
M6x35 Hex Head Screw,
Spring Washer, Washer
Captive Thread Plate
QTY
4
M8x30 Cap Screw, Spring
Washer, WasherCaptive
Thread
QTY
4
12.
NO DRILL
ZONE
260
1200
700
^Repeat steps for installing rear brackets. Bracket location as shown
above - **be careful to avoid the no drill zone.
^Fit end caps using the fixings provided. Note: Ensure endcap fits on
the correct way up - with plastic tab flush against aluminium.
