KTI Networks KPOE-100 User manual

1
Mid-span 802.3af PoE Injector
Installation Guide
KPOE-100
Doc. 070521

2
(C) 2005 KTI Networks Inc. All rights reserved. No part of this documentation may be
reproduced in any form or by any means or used to make any directive work (such as
translation or transformation) without permission from KTI Networks Inc.
KTI Networks Inc. reserves the right to revise this documentation and to make changes in
content from time to time without obligation on the part of KTI Networks Inc. to provide
notification of such revision or change. For more information, contact::
United States KTI Networks Inc.
P.O. BOX 631008
Houston, Texas 77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [e-mail]
URL: http://www.ktinet.com.tw/

3
The information contained in this document is subject to change without prior notice.
Copyright (C) All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
FCC NOTICE
This device complies with Class B Part 15 the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received including the interference that may cause.
CE NOTICE
Marking by the symbol indicates compliance of this equipment to the EMC directive of the
European Community. Such marking is indicative that this equipment meets or exceeds the
following technical standards:
EMC Class B
EN 50081-1/1992 :EN55022:1994/A1:1995/A2:1997 Class B
EN61000-3-2:2000
EN61000-3-3:1995/A1:2001
EN 55024:1998/A1:2001
IEC 61000-4-2:1995
IEC 61000-4-3:1995
IEC 61000-4-4:1995
IEC 61000-4-5:1995
IEC 61000-4-6:1996
IEC 61000-4-8:1993
IEC 61000-4-11:1994
SAFETY CAUTION
To reduce the risk of bodily injury, electrical shock, fire, and damage to the product, observe
the following precautions.
• Do not service any product except as explained in your system documentation.
• Opening or removing covers may expose you to electrical shock.
• Only a trained service technician should service components inside these compartments.
• If any of the following conditions occur, unplug the product from the electrical outlet and
replace the part or contact your trained service provider:
- The power cable, extension cable, or plug is damaged.
- An object has fallen into the product.
- The product has been exposed to water.
- The product has been dropped or damaged.
- The product does not operate correctly when you follow the operating instructions.
• Do not push any objects into the openings of your system. Doing so can cause fire or
electric shock by shorting out interior components.
• Operate the product only from the type of external power source indicated on the electrical
ratings label. If you are not sure of the type of power source required, consult your service
provider or local power company.

4
Introduction
The KPOE-100 is a device designed as a mid-span Power over Ethernet PSE,
which is equipped with one-input and one-output RJ-45 connectors to connect
directly to an Ethernet cable. It delivers power together with the Ethernet data
lines over the Cat.5 cable to a PoE Powered Device such as a Wireless
Access Point or a media converter located at place where no commercial
outlet is available.
Features
 IEEE 802.3af PSE standard compliance
 Mix Ethernet signals and 48V power into one RJ-45 port
 Delivers 48VDC power up to 15.4W
 Delivers power over Cat.5 up to 100 meters
 Discovery of IEEE 802.3af compliant powered devices (PD)
 Auto power shutdown when no connection
 Auto power shutdown protection when non-802.3af PD is detected
 Overload power shutdown protection
 Over-current power shutdown protection
 Short circuit power shutdown protection
 Compact
 Wall mounting support
 Plug and play

5
Specifications
 Ethernet RJ-45 (IN Jack)
Connector Shielded RJ-45
Connection Support Ethernet, Fast Ethernet, Gigabit Ethernet
Cable Cat. 5, 5e
 PoE PSE RJ-45 (OUT Jack)
Connector Shielded RJ-45
PSE Pin 4,5 Positive VPORT (48VDC)
PSE Pin 7,8 Negative VPORT (48VDC)
Cable 4-pair Cat. 5, 5e
Length Mid-span up to 100m
(LAN IN cable + PoE OUT cable)
 PoE PSE
Discovery resistance 15K ~ 33K
Classification Class 0 ~ 4
Power delivery 15.4W max.
Under voltage protection VPORT < 43V
Over voltage protection 53V < VPORT
Over current detection 350 mA < IPORT < 400 mA for 75ms
Maximum current limit 400 mA < IPORT < 450 mA for 75ms
Under current detection 7.5mA for 300~400ms
DC disconnect 5 mA < IPORT < 10 mA

6
 LED Indication
POWER Power status (green)
PoE PoE power status (green)
 DC IN Jack
Connector Power Jack
Input voltage +48VDC supplied by external power adapter
Input current DC 0.4A min.
 Environment
Temperature Operating: -5 ~ 50oC,
Storage: -20 ~ 85 oC
Relative humidity 5% ~ 95% non-condensing
 Mechanical
Housing Plastic
Mounting Wall mounting (screw support)

7
Dimension 50mm x 80mm x 21mm
 AC-DC48V Power Adapter
Rated input voltage 100 ~ 240VAC
Rated frequencies 50 ~ 60Hz
Input voltage range 90 ~ 264VAC
Input frequency range 47~63Hz
Input AC plug IEC320 C14 plug (3-pin)
Output voltage +48VDC (+/-5%)
Output current DC 0.5A max.
Max. output power 24W
Consumption at no load 0.5W max.
Output DC plug −..... (Ο ..... +.
Power cord IEC320 type

8
Installation
Screw mounting on a wall
The case is featured two holes on the case. Screw the injector over the screw
holes on a wall securely.
Wall mounting
The case bottom is designed with a hole for mounting the injector on a wall.

9
Inserting DC power plug first
Insert the DC cable of the power adapter to the injector DC IN jack as shown
below:
Applying AC power
The AC-DC48V power adapter used to supply the 48VDC power for the
injector can receive AC voltage within a range of +90 ~ 264VAC. It supports
the commercial power available worldwide. Use a proper AC power cable
matching the AC outlet in your area.
Note: Make sure the DC plug is properly seated in the DC jack before
applying AC power.
Connecting network cables
1. Connect IN jack to the switched port of a Fast Ethernet switch or Gigabit
Ethernet switch.
2. Connect OUT jack to the 802.3af compliant powered device via PoE over
Cat.5.

10
Application
Supporting PoE wireless Access Point (802.3af PD)
Supporting PoE media converter (802.3af PD)
