KFS-2621
Web Smart 24-Port 10/100 Fast Ethernet
Switch with 2 Gigabit Combo Ports
User,s Manual
DOC.091229

-2-
(C) 2009 KTI Networks Inc. All rights reserved. No part of this documentation may be reproduced in any form
or by any means or used to make any directive work (such as translation or transformation) without permission
from KTI Networks Inc.
KTI Networks Inc. reserves the right to revise this documentation and to make changes in content from time to
time without obligation on the part of KTI Networks Inc. to provide notification of such revision or change.
For more information, contact:
United States KTI Networks Inc.
P.O. BOX 631008
Houston, Texas 77263-1008
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com/
International Fax: [phone]
E-mail: [email protected]
URL: http://www.ktinet.com.tw/

-3-
The information contained in this document is subject to change without prior notice. Copyright (C) All Rights
Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including the interference that may cause undesired operation.
CE NOTICE
Marking by the symbol indicates compliance of this equipment to the EMC directive of the European
Community. Such marking is indicative that this equipment meets or exceeds the following technical
standards:
EMC Class A
EN55022:2006
EN61000-3-2:2006
EN61000-3-3:1995/A1:2001/A2:2005 Class A
EN 55024:1998/A1:2001/A2:2003
IEC 61000-4-2:2001
IEC 61000-4-3:2002/A1:2002
IEC 61000-4-4:2004
IEC 61000-4-5:2001
IEC 61000-4-6:2003
IEC 61000-4-8:2001
IEC 61000-4-11:2001

-4-
Table of Contents
1. Introduction...................................................................................................................................6
1.1 Features................................................................................................................ 8
1.2 Product Panels...................................................................................................... 9
1.3 LED Indicators .................................................................................................... 10
1.4 Specifications...................................................................................................... 10
2. Installation...................................................................................................................................13
2.1 Unpacking ........................................................................................................... 13
2.2 Safety Cautions................................................................................................... 13
2.3 Mounting the Switch............................................................................................ 14
2.4 AC Power Supply................................................................................................ 16
2.5 DC Power Supply................................................................................................ 16
2.6 Reset Button ....................................................................................................... 17
3. Making Connections and Configuring IP Address .................................................................18
3.1 Making UTP Connections ................................................................................... 18
3.2 Making Fiber Connection .................................................................................... 19
3.3 LED Indication..................................................................................................... 21
3.4 Configuring IP Address and Password for the Switch......................................... 22
4. Web Management .......................................................................................................................23
4.1 Abbreviation ........................................................................................................ 23
4.2 Web Interface...................................................................................................... 24
4.3 Start Browser Software and Making Connection ................................................ 24
4.4 Login to the Switch Unit ...................................................................................... 24
4.5 Main Management Menu .................................................................................... 25
4.6 System Configuration.......................................................................................... 27
4.7 Port Configuration ............................................................................................... 29
4.8 Port Mirroring ...................................................................................................... 31
4.9 Bandwidth Control............................................................................................... 32
4.10 Broadcast Storm Control................................................................................... 34
4.11 VLAN Mode....................................................................................................... 35

-5-
4.12 VLAN Member (Port-based) ............................................................................. 37
4.13 VLAN Member (Tag-based).............................................................................. 39
4.14 Multi to 1 VLAN Setting..................................................................................... 42
4.15 Important Notes for VLAN Configuration........................................................... 43
4.16 QoS Priority Mode............................................................................................. 44
4.17 Priority Classification - Port, 802.1p, IP/DS Based ........................................... 45
4.18 Priority Classification – TCP/UDP Port Based .................................................. 47
4.19 MAC Address Binding....................................................................................... 49
4.20 TCP/UDP Filter ................................................................................................. 51
4.21 STP Bridge Settings.......................................................................................... 53
4.22 STP Port Settings.............................................................................................. 54
4.23 Link Aggregation ............................................................................................... 57
4.24 Miscellaneous Settings ..................................................................................... 59
4.25 Port Counter...................................................................................................... 61
4.26 Backup/Recovery .............................................................................................. 63
4.27 Reboot System ................................................................................................. 63
4.28 Restore Default ................................................................................................. 64
4.29 Update Firmware .............................................................................................. 64
4.30 Logout ............................................................................................................... 66
Appendix. Factory Default Settings..............................................................................................67

-6-
1. Introduction
The KFS-2621 is a managed Fast Ethernet switch which is featured with the following switched ports and
advantages in a 19” rack mountable box:
24 10/100Mbps Fast Ethernet copper ports
2 combo ports - 10/100/1000Mbps copper & 1000Base-X SFP
Model Definition
Model Description Management Power Input
KFS-2621-S AC power model Managed AC 100 ~ 240V
KFS-2621-D DC power model Managed DC 36 ~ 72V
Plug and Play
The switch is shipped with factory default configuration which behaves like an unmanaged Fast Ethernet
switch for workgroup. It provides 24 10/100Mbps copper ports for connections to Ethernet and Fast Ethernet
devices. With the featured auto-negotiation function, the switch can detect and configure the connection speed
and duplex automatically. The switch also provides auto MDI/MDI-X function, which can detect the connected
cable and switch the transmission wire pair and receiving pair automatically. This auto-crossover function can
simplify the type of network cables used.
Gigabit Ethernet Connectivity
Two Gigabit combo ports are provided in the switch. The combo port provides one 10/100/1000Mbps RJ-45
for connecting to Gigabit copper device and one 1000M SFP slot, which can be installed with optional SFP
optical fiber transceivers to support one Gigabit 1000Base-X fiber connections respectively when needed.
Fiber Connectivity
The 1000M SFP slot provided in a combo port, which can be installed with optional SFP optical fiber
transceivers to support one Gigabit 1000Base-X fiber connection when needed.
Management
The switch is embedded with an Http server which provides management functions for advanced network
functions including Port Control, Quality of Service, and Virtual LAN functions. The management can be
performed via Web browser based interface over TCP/IP network.
Quality of Service

-7-
For advanced application, the switch is featured with powerful Quality of Service (QoS) function which can
classify the priority for received network frames based on the ingress port and frame contents. Furthermore,
many service priority policies can be configured for egress operation in per-port basis.
Virtual LAN (VLAN)
For increasing Tagged VLAN applications, the switch is also featured with powerful VLAN function to fulfill
the up-to-date VLAN requirements. The switch supports both port-based VLAN and tagged VLAN in per-port
basis.
AC & DC Power Options
In addition to standard AC power input, the switches provide DC options for applications with DC power
system.

-8-
1.1 Features
zProvide 24 10/100Mbps Fast Ethernet ports & 2 Gigabit combo ports
zAll copper ports support auto-negotiation and auto-MDI/MDI-X detection
zWire speed reception and transmission
zSupports 802.3x flow control for full-duplex and backpressure for half-duplex
zStore-and-Forward switching method
zSelf learning for active MAC addresses up to 4K entries
zProvide in-band web-based management interface
zProvide port status, statistic monitoring and control function
zProvide port bandwidth control function
zProvide static and LACP port link aggregation function
zSupport port-based and 802.1Q Tag-based VLAN
zProvide QoS function
zProvide IGMP snooping function
zSupport 802.1w RSTP and 802.1D STP
zSupport DHCP for dynamic IP configuration
zNo fan design
z19” rack mountable
zWide operating temperature range

-9-
1.2 Product Panels
The following figure illustrates the front panel and rear panel of the switch:
Front panel
Rear panel –AC power model
Rear panel –DC power model

-10-
1.3 LED Indicators
LED Color Function
Power Green Power status
Mngt Green Management status
LINK/Act. ( Port 1-24) Green Link & activity status
100M (Port 1-24) Yellow Port speed 100Mbps
LINK/Act. (Port 25-26) Green Link & activity status
1000M (Port 25-26) Yellow Port speed 1000Mbps
F25 Link Green SFP Fiber is selected and link up on Port 25
F26 Link Green SFP Fiber is selected and link up on Port 26
1.4 Specifications
10/100 Copper Ports
Compliance IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Connectors Shielded RJ-45 jacks
Pin assignments Auto MDI/MDI-X detection
Configuration Auto-negotiation or software control
Transmission rate 10Mbps, 100Mbps
Duplex support Full/Half duplex
Network cable Cat.5 UTP
Combo Port 25 26 with 10/100/1000 RJ-45 and 1000Mbps SFP
10/100/1000 Copper Port Interface
Compliance IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3u 1000Base-T
Connectors Shielded RJ-45 jacks
Pin assignments Auto MDI/MDI-X detection
Configuration Auto-negotiation or software control
Transmission rate 10Mbps, 100Mbps, 1000Mbps
Duplex support Full/Half duplex
Network cable Cat.5 UTP
Fiber interface

-11-
Compliance IEEE 802.3z 1000Base-SX/LX (mini-GBIC)
Connectors SFP for optional SFP type fiber transceivers
Configuration Auto/Forced, 1000Mbps, Full duplex
Transmission rate 1000Mbps
Network cables MMF 50/125 60/125, SMF 9/125
Eye safety IEC 825 compliant
Switch Functions
MAC Addresses Table 4K entries
Forwarding & filtering Non-blocking, full wire speed
Switching technology Store and forward
Maximum packet length 1536 bytes
Flow control IEEE 802.3x pause frame base for full duplex operation
Back pressure for half duplex operation
VLAN function Port-based VLAN and IEEE 802.1Q Tag-based VLAN
QoS function Port-based, 802.1p-based, IP/DS-based
Port control Port configuration control via software management
Storm control Broadcast storm protection control via software management
Aggregation Link aggregation (or called port trunking)
Port Mirroring Mirror received frames to a sniffer port
IGMP Snooping IGMP snooping configuration
Software Management Functions
Interfaces Web browser
Management objects System settings, port status/statistics, port control, VLAN, QoS,
Link aggregation, port mirroring, Firmware upgrade
STP/RSTP, Configuration backup and restore
AC Power Input
Interfaces IEC320 receptacle
Operating Input Voltages 100 ~ 240VAC
Power Consumption 20W max. @110VAC
DC Power Input
Interfaces Screw-type terminal block
Operating Input Voltages +36 ~ +72VDC
Power Consumption 20W max. @48VDC

-12-
Mechanical
Dimension (base) 295 x 160 x 43 mm (WxDxH)
Housing Enclosed metal
Mounting Desktop mounting, 19” rack mounting
Environmental
Operating Temperature Typical -20oC ~ +60oC
Storage Temperature -30oC ~ +85oC
Relative Humidity 10% ~ 90% non-condensing
Electrical Approvals
FCC Part 15 rule Class A
CE EMC, CISPR22 Class A
Safety LVD, IEC60950-1

-13-
2. Installation
2.1 Unpacking
The product package contains:
The switch unit
zOne AC power cord (Models with AC power)
zOne 19” rack mounting kit
zOne product CD-ROM
2.2 Safety Cautions
To reduce the risk of bodily injury, electrical shock, fire and damage to the product, observe the following
precautions.
zDo not service any product except as explained in your system documentation.
zOpening or removing covers may expose you to electrical shock.
zOnly a trained service technician should service components inside these compartments.
zIf any of the following conditions occur, unplug the product from the electrical outlet and replace the part
or contact your trained service provider:
- The power cable, extension cable, or plug is damaged.
- An object has fallen into the product.
- The product has been exposed to water.
- The product has been dropped or damaged.
- The product does not operate correctly when you follow the operating instructions.
zDo not push any objects into the openings of your system. Doing so can cause fire or electric shock by
shorting out interior components.
zOperate the product only from the type of external power source indicated on the electrical ratings label. If
you are not sure of the type of power source required, consult your service provider or local power
company.

-14-
2.3 Mounting the Switch
Desktop Mounting
The switch can be mounted on a desktop or shelf. Make sure that there is proper heat dissipation from and
adequate ventilation around the device. Do not place heavy objects on the device.
Rack Mounting
Two 19-inch rack mounting brackets are supplied with the switch for 19-inch rack mounting.
The steps to mount the switch onto a 19-inch rack are:
1. Turn the power to the switch off.
2. Install two brackets with supplied screws onto the switch as shown in above figure.
2. Mount the switch onto 19-inch rack with rack screws securely.

-15-
3. Turn the power to the switch on.

-16-
2.4 AC Power Supply
If the purchased switch is with AC power input, one AC power cord which meets the specification of your
country of origin was supplied in package. Before installing AC power cord to the switch, make sure the AC
power is OFF and the AC power to the power cord is turned off.
AC power input specifications
Connector: IEC320 type
Power Rating: 100 ~ 240VAC, 50/60Hz
Voltage Range: 90 ~ 264VAC
Frequency: 47 ~ 63 Hz
Power Consumption: 20W max.
2.5 DC Power Supply
If the purchased switch is with DC power input, the power connector is shown below:
DC power input specifications
Receptacle: Screw-type terminal block
Operating Voltages: +36 ~ +72VDC
Power Consumption: 20W max.@48VDC

-17-
2.6 Reset Button
The reset button is used to perform a reset to the switch. It is not used in normal cases and can be used for
diagnostic purpose. If any network hanging problem is suspected, it is useful to push the button to reset the
switch without turning off the power. Check whether the network is recovered.
The button can also be used to restore the software configuration settings to factory default values. The
operations are:
Operation Function
Press the button more than ˇseconds when power up Restore factory default settings
Press the button and release during switch operation Reboot the switch

-18-
3. Making Connections and Configuring IP Address
3.1 Making UTP Connections
The 10/100 and 10/100/1000 RJ-45 copper ports support the following connection types and distances:
Network Cables
10BASE-T: 2-pair UTP Cat. 3, 4, 5, EIA/TIA-568B 100-ohm
100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568B 100-ohm
1000BASE-T: 4-pair UTP Cat. 5 or higher (Cat.5e is recommended), EIA/TIA-568B 100-ohm
Link distance: Up to 100 meters
Auto MDI/MDI-X Function
This function allows the port to auto-detect the twisted-pair signals and adapts itself to form a valid MDI to
MDI-X connection with the remote connected device automatically. No matter a straight through cable or
crossover cable are connected, the ports can sense the receiving pair automatically and configure themselves to
match the rule for MDI to MDI-X connection. It simplifies the cable installation.
Auto-negotiation Function
The ports are featured with auto-negotiation function and full capability to support connection to any Ethernet
devices. The port performs a negotiation process for the speed and duplex configuration with the connected
device automatically when each time a link is being established. If the connected device is also
auto-negotiation capable, both devices will come out the best configuration after negotiation process. If the
connected device is incapable in auto-negotiation, the switch will sense the speed and use half duplex for the
connection.
Port Configuration Management
For making proper connection to an auto-negotiation INCAPABLE device, it is suggested to use port control
function via software management to set forced mode and specify speed and duplex mode which match the
configuration used by the connected device.

-19-
3.2 Making Fiber Connection
The SFP slot must be installed with an SFP fiber transceiver for making fiber connection. Your switch may
come with some SFP transceivers pre-installed when it is shipped.
Installing SFP Fiber Transceiver
To install an SFP fiber transceiver into SFP slot, the steps are:
1. Turn off the power to the switch.
2. Insert the SFP fiber transceiver into the SFP slot. Normally, a bail is provided for every SFP transceiver.
Hold the bail and make insertion.
3. Until the SFP transceiver is seated securely in the slot, place the bail in lock position.

-20-
Connecting Fiber Cables
LC connectors are commonly equipped on most SFP transceiver modules. Identify TX and RX connector
before making cable connection. The following figure illustrates a connection example between two fiber
ports:
Make sure the Rx-to-Tx connection rule is followed on the both ends of the fiber cable.
Network Cables
Multimode (MMF) - 50/125Pm, 62.5/125Pm
Single mode (SMF) - 9/125Pm
Fiber Port Configuration
For 1000M fiber application on Port 25 and Port 26, just leave the default port configuration Auto for fiber
connection.
