KTI Networks KSD-800 User manual

Specifications :
Industrial 8-Port Fast Ethernet Switches
with Fiber Connectivity
Benefits :
 Fast Ethernet switch with 8 10/100Mbps copper ports and optional fiber ports
 Wide operating temperature range for temperature critical environment
 Support DIN rail mounting and panel mounting
 Provide two power input types to meet more application needs
 Accept wide power input voltage range for application flexibility
 Industrial-rated Emission and Immunity performance
Key Features :
 8 10/100M ports support auto-negotiation and auto-MDI/MDI-X configuration
 Port 7 and Port 8 provide either copper or fiber connection (model dependent)
 Provides wire speed store-and-forward switching
 Supports IEEE 802.3x flow control for full-duplex operation
 Supports Back-pressure flow control for half-duplex operation
 Provides Far End Fault function on the fiber ports
Standard IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, 100Base-FX
Network Ports 8 RJ-45 10/100Mbps auto-negotiation, auto-MDI/MDI-X ports
2 100Mbps 100Base-FX ports (model depedent)
(Port 7 and Port 8 provide dual connectivities, either copper or fiber.)
Network Cables 10Base-T : Cat. 3, 4, 5 or higher up to 100m
100Base-TX : Cat. 5 or higher up to 100m
100Base-FX : MMF 50/125µm 60/125µm, SMF 9/125µm
MAC Addresses Table with 1K entries
LEDs Per unit : Power, Management
Per 10/100M port : Link/Activity, 100M, Duplex/Collision status
Per fiber port slot : Link/Activity status status
Relay Output Alarm : Power failure
Interface : 2 terminal contacts
Spec. : 30VDC/1A max. or 120VAC/0.5A max.
DC Power Input Screwed terminator block : 2 pairs of +/- contacts
DC jack : -D 6.3mm / + D 2.0mm
Operating voltage range : +7 - +30VDC
Power Consumption 7.3 watts (max.)
Housing Enclosed metal with no fan
Dimension 140 x 106 x 40 mm (WxDxH)
Mounting Support DIN Rail mounting, Panel mounting
KSD-800
Panel Mounting Bracket
080110

FCC Part 15'Class A
CISPR 22 Class A
Katron Technologies Inc.
15F-7, No. 79, Sec. 1, Hsin Tai Wu Rd.,
Hsi-chih, Taipei Hsien, Taiwan.
Te l :886-2-2698-3878
Fax:[phone]
E-mail:[email protected]
URL:http://www.ktinet.com.tw
KTI Networks Inc.
7400 Harwin Dr., Suite 120 Houston,
Texas 77036 U.S.A.
Te l :713-266-3891
Fax:[phone]
E-mail:[email protected]
URL:http://www.ktinet.com
Trademarks: All brand names are trademarks or registered
trademarks of their respective holders.
This information is subject to change without prior notice.
Environment Operating temperature : -20OC ~ 70OC
Storage temperature : -20OC ~ 85OC
Relative Humidity : 5% ~ 95% non-condensing
Approval FCC Class A
CE/EMC Class A, EN60950 safety
Fiber Optical Specification :
Model FX &Cable Wavelength Tx Power Rx Sensitivity Rx Max.Power
-1T FX8 :ST MMF 1310nm -19 ~-14 dBm -31 dBm -14 dBm
-1C FX8 :SC MMF 1310nm -19 ~-14 dBm -31 dBm -14 dBm
-1C1 FX8 :SC MMF 1310nm -20 ~-14 dBm -31 dBm 0 dBm
-1SA2 FX8 :SC SMF 1310nm -15 ~-8 dBm -31 dBm -7 dBm
-1SL2 FX8 :SC SMF 1310nm -15 ~-8 dBm -30 dBm -7 dBm
-2T FX7 :ST MMF 1310nm -19 ~-14 dBm -31 dBm -14 dBm
FX8 :ST MMF 1310nm -19 ~-14 dBm -31 dBm -14 dBm
-2C FX7 :SC MMF 1310nm -19 ~-14 dBm -31 dBm -14 dBm
FX8 :SC MMF 1310nm -19 ~-14 dBm -31 dBm -14 dBm
-2C1 FX7 :SC MMF 1310nm -20 ~-14 dBm -31 dBm 0 dBm
FX8 :SC MMF 1310nm -20 ~-14 dBm -31 dBm 0 dBm
-2SA2 FX7 :SC SMF 1310nm -15 ~-8 dBm -31 dBm -7 dBm
FX8 :SC SMF 1310nm -15 ~-8 dBm -31 dBm -7 dBm
-2SL2 FX7 :SC SMF 1310nm -15 ~-8 dBm -30 dBm -7 dBm
FX8 :SC SMF 1310nm -15 ~-8 dBm -30 dBm -7 dBm
-C1SL2 FX7 :SC MMF 1310nm -20 ~-14 dBm -31 dBm 0 dBm
FX8 :SC SMF 1310nm -15 ~-8 dBm -30 dBm -7 dBm
EMI EMS Safety Environmental Tests:
Ordering Information :
Specifications
Class A
Class A
< 75 W
Clause 5
Contact:+/-8KV
Air:+/-16KV
+/-4KV
Power:4KV
Signal:0.5KV
Strength:10V/m
Test
FCC/EMI
CE/EMC/EMI
CE/EMC/Harmonic
CE/EMC/VFF
CE/EMC/EMS
ESD Test
RS Test
EFT/BURST
Surge Immunity
Standard
FCC Rule Part 15
EN55022, CISPR 22
EN 61000-3-2
EN 61000-3-3
EN 55024
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
IEC 61000-4-5
Level 3
50Hz 40A/m
Interruption : C
Dips : B
TP, 1500VAC/60sec.
TP, 500VDC/10Mohm
-20OC, 96hrs
+70OC 40%RH 96hrs
+60OC 90%RH 96hrs
CS Test
Magnetic Field Imm.
Voltage Dips Imm.
Safety
Dielectric Voltage
Insulation Resistance
Cold Test
Dry Heat Test
Damp Heat Test
Storage Test
Vibration Test
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
EN 60950, IEC 60950
IEEE 802.3
IEEE 802.3
IEC 68-2-1 Test Ad
IEC 68-2-2 Test Bd
IEC 68-2-3
IEC 68-2-48
IEC 68-2-34
+85OC 40%RH 96hrs
-20OC 96hrs
-1T
-1C
Operating
Temperature
-10 ~ 70OC
-10 ~ 70OC
-20 ~ 70OC
-10 ~ 70OC
FX8 ST MMF
FX Ports
Model
KSD-800-xxx
FX8 SC MMF
FX8 SC MMF-1C1
FX7 ST MMF
FX8 ST MMF
-2T
2km
Ref.
Distance
2km
2km
2km
2km
-10 ~ 70OC
FX7 SC MMF
FX8 SC MMF
-2C 2km
2km
-20 ~ 70OC
FX7 SC MMF
FX8 SC MMF
-2C1 2km
2km
-20 ~ 70OC
FX7 SC SMF
FX8 SC SMF
-2SA2 20km
20km
-20 ~ 70OC
FX7 SC SMF
FX8 SC SMF
-2SL2 20km
20km
-20 ~ 70OC
FX7 SC MMF
FX8 SC SMF
-C1SL2 2km
20km
-20 ~ 70OC
FX8 SC SMF-1SA2 20km
-20 ~ 70OC
FX8 SC SMF-1SL2 20km
080110
