INSTRUCTION MANUAL
Healthy Fryer
Model Number KA0151
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

Contents
02 Warranty Details
03 Welcome
04 General Information and Safety Instructions
05 Product Overview
06 Getting Started
07 HealthyFryer Instructions
11 Cooking and Baking Guide
13 Other Useful Information
14 Repair and Refurbished Goods or Parts Notice
15 Notes
1
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

2
Warranty Details
Healthy Fryer
The product is guaranteed to be free from defects in workmanship and parts for a period of 36
months from the date of purchase. Defects that occur within this warranty period, under normal
use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by
this warranty are in addition to all rights and remedies in respect of the product that the
consumer has under the Competition and Consumer Act 2010 and similar state and territory
laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage.You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does notamount to a
major failure.
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUSYEAR WARRANTY
3

Welcome
Congratulations on choosing to buy a Kuchef®product.
All products brought to you by Kuchef®are manufactured to the highest standards of performance and safety,
and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year
Warranty. We hope you enjoy using your purchase for many years to come.
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

General Information and
Safety Instructions
Please keep this instruction manual in a safe place, along with the warranty card, purchase receipt and carton
for future reference. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury
when correctly adhered to.
- Read all instructions before using the Healthy Fryer.
- Do not use the Healthy Fryer for other than its intended use.
- Before turning on, ensure the electrical voltage and frequency of the circuit correspond to those indicated on
the appliance.
- To protect against the risk of electric shock, do not immerse the appliance, cord set or plug in water or any
other liquid.
- The Healthy Fryer is not intended to be operated by means of an external timer or any type of separate remote
control system.
- The use of attachments not recommended or sold by the appliance manufacturer may cause fire, electric
shock, or injury.
- Do not use outdoors.
- Do not operate or place any part of this appliance on or near any hot surfaces (such as a gas or electric burner,
or in a heated oven).
- Do not use an extension cord unless completely necessary with this appliance. If an extension cord is used
please ensure that it has a rating equal or exceeding the rating of this appliance.
- Do not let cord hang over the edge of the table or counter or touch hot surfaces.
- Always check power cord for damage before plugging the appliance into the mains socket. Do not use the
appliance if the power cord or insulation is damaged. If the power cord is damaged, it must be replaced by
the manufacturer, its service agent or a similarly qualified person in order to avoid a hazard.
- Do not bend or damage the power cord.
- Always unplug the Healthy Fryer when not in use. Ensure the Healthy Fryer is turned off before unplugging the
appliance. To disconnect from the power supply, grip the plug and pull from the power socket. Never pull by
the cord. The power plug must be removed from power socket before cleaning, servicing, maintenance or
moving the appliance.
- Never move the Healthy Fryer while it’s working or containing hot oil or other hot liquid. Always ensure the
appliance is switched off and cool down before moving.
- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
- Improper installation may result in the risk of fire, electric shock and/or injury to persons.
- The manufacturer is not responsible for any eventual damages caused by improper or faulty use.
- The unit has no user-serviceable parts contained within. Do not attempt to repair, disassemble or modify the
appliance.
- Do not touch hot surfaces, use handles or knobs only. Ensure the appliance has completely cooled down
before removing any parts after use.
4
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

5
1
2
3
4
5
6
9
10
11
12
13
7
8
1. Lid Handle
2. Lid
3. Heating Element
4. Rotating Ring
5. Lid Open Button
6. ON/OFF Switch
7. Digital Timer Display
8. Time Setting Key
9. Mixing Arm Detachable Handle
10. Mixing Arm
11. Non-stick Pot
12. Detachable Pot Handle
13. Grill Rack
Product Overview
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

Before using your Healthy Fryer, please read all safety and operating instructions thoroughly. Please ensure
you follow the steps below before using this appliance.
1. Remove all packaging materials and literature from inside the gift box.
2. Remove the twist-tie which is securing the electrical cord. Uncoil the cord and straighten it to remove any
kinks.
3. Wipe the exterior housing and inner surface of the Healthy Fryer with a damp cloth, do not immerse it in
water or other liquids. Then dry thoroughly.
4. On first use, wash the pot in warm soapy water, then leave it soaking for 30 minutes. Then rinse and dry the
pot thoroughly.
5. Wash the mixing arm and the grill rack in warm soapy water, then rinse and dry thoroughly.
6. Attach the mixing arm detachable handle to the mixing arm by pushing the handle firmly into the hole in the
mixing arm until it clicks. Once assembled, do not try to remove the handle from the mixing arm otherwise
it may be damaged.
7. Select a flat, stable, dry surface to operate your Healthy Fryer.
Getting Started
NOTE: The Healthy Fryer may emit a slight burning smell when it is first being used. Do not
be alarmed, this is normal.
6
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

7
Healthy Fryer Instructions
1. Press the lid open button, the lid will open automatically.
2. Fitting the rotating ring assembly:
The rotating ring assembly must be fitted the correct way up as shown in figure 1 below.
Two of the wheel axles are stamped with word “UP”. This must face upwards when the roller is correctly
fitted. If, during use, the pot makes excessive noise or fails to rotate properly, make sure that the rotating
ring assembly is fitted the right way up.
1) Place the rotating ring assembly centrally into the bottom of your Health Fryer.
2) Place the pot into the body of your fryer as shown in figure 2 below.
3) Fit the mixing arm onto the spindle in the pot in figure 3 below.
3. Mix food with one spoon of oil evenly in a separate container and pour into the pot.
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS
Figure 1 Figure 2 Figure 3

8
Healthy Fryer Instructions
continued
5. Plug the Healthy Fryer into the power outlet, the digital timer will illuminate blue and display ‘00’.
6. Press the time setting key to set the desired time referring to the Cooking and Baking guide (found on page
11 and 12). Then press the ON/OFF switch to start. The digital timer will illuminate red and start to count down
automatically.
NOTE: The appliance is incorporated with an internal high temperature protection function,
so it will automatically stop when the maximum temperature is reached (around 200 +/- 10%
degree). It will automatically restart once the ideal cooking temperature is reached.
If your Healthy Fryer stops while cooking, do not reset the timer or temperature.
4. Close the lid.
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

9
CAUTION: Always turn off the appliance at the power socket after cooking and let it cool
down for a few minutes before opening the lid.
Healthy Fryer Instructions
continued
8. Press the lid open button to open the lid and take the mixing arm out of the pot. To do so, ensure that the
mixing arm handle is attached to the end of the mixing arm by pushing it firmly into the slot provided. Never
take the mixing arm out without attaching the handle, as it will be very hot.
9. Next, position the open mouth of the detachable pot handle over the edge of the pot. Press the lever found
on the top of the pot handle, to the forward position. The clamp at the end of the pot handle will then close
and it will now be attached to the pot. The lever will then return back to its original position and the pot can
be lifted out of the Fryer. To release the detachable pot handle from the pot, simply press the round button
on the top of the pot handle.
7. When cooking is completed, a beep will sound and the digital timer will once again illuminate blue.
NOTE: During cooking, you may open the lid at any time by pressing the lid release button.
Doing this will switch off the halogen heater, fan and pot rotation, but the timer will continue
to count down. Closing the lid will restart cooking. If you have had the lid open for some time,
you many need compensate with additional cooking time after the original time has elapsed.
During cooking, the halogen heater will switch on and off from time to time. This is normal
and allows your Health Fryer to maintain an even cooking temperature.
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

10
Healthy Fryer Instructions
continued
CAUTION: Do not let the Healthy Fryer heat up without food inside. Attempting to operate
this appliance without food in the pot will result in permanent damage to the internal safety
mechanism of this appliance, thus invalidating your warranty.
CAUTION: Do not touch any of the surfaces of the Healthy Fryer, as they get very hot during
use. When opening the lid, please ensure there is space between you and the appliance as
hot air will escape from inside the appliance. This hot air is a scalding hazard. Always move
the appliance mixing arm and the non-stick pot by using the handles provided.
10. This appliance can also bake food with the use of the special baking rack that has been provided. To bake
food under 20mm thick, please use the side of the baking rack with the highest height to ensure that the food
is further away from the bottom of the pot. For food that is thicker than 20mm, please turn the rack over and
use the lower height.
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

Cooking and Baking Guide
Please see below instructions which will assist you in making tasty, crispy meals in your Kuchef
®
Healthy Fryer.
Cooking Guide
The cooking guide given in the charts below is only a guide and should be adjusted according to the quantity.
Potatoes
Food Weight (g) Oil (spoon) Time (minute)
French fries 500 1 25-30
Potatoes (fresh) 450 1 35-40
Frozen French fries 400 1 24-30
Diced potatoes 750 1 30-40
Other Vegetables
Food Weight (g) Oil (spoon) Time (minute)
Zucchini 500 160ml cold water 23-28
+ 1 spoonful of oil
Sweet peppers 400 160ml cold water 18-25
+ 1 spoonful of oil
Mushrooms 400 1 12-15
Onions 450 1 12-15
Meat Poultry
Food Weight (g) Oil (spoon) Time (minute)
Chicken nuggets (Fresh) 500 (30×50)mm without 20-25
Pork chops 350 (30×50)mm without 16-25
Beef (Fresh) 400 1 8-12
Onions 450 1 12-15
Chilli Con Carne 350 1 15-25
Sausages 300 1 8-12
Chicken legs 700 without 28-35
Lamb chops 2 to 3 pieces 25mm thick without 20-25
Chicken breasts 350 1 8-15
Pork fillet (thin) 250 1 8-12
Fish
Food Weight (g) Oil (spoon) Time (minute)
Breaded prawns 14 (PCS) without 25-30
Tilapia 350 1 18-22
Jumbo king prawns 300 without 12-15
Small fresh prawns 350 without 8-12
11
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

12
Cooking and Baking Guide
continued
Baking guide
The baking time given in below chart is only a guide and should be adjusted according to the quantity.
Food Weight(g) Oil (spoon) Time (minute) Parts
Fish 700g, Thickness: 20mm without 10 minutes Bottom grill
for each side
Beef chop 700g, Thickness: 20mm without 5 minutes Bottom grill
for both sides
Chicken legs 700 without 30-35 minutes Bottom grill
on one side
Corn 500 without 10 minutes Bottom grill
for both sides
Pork chop 350 without 15-20 minutes Bottom grill
on one side
Sausages 300 without 8 minutes Bottom grill
for both sides
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

13
Other Useful Information
- When adding herbs, garlic and other spices, please mix them with a bit of oil before adding them to the
Healthy Fryer.
- Where necessary (for fresh produce), always thinly slice the produce before adding them to the Healthy Fryer
(onions, garlic, herbs etc). The produce can block the rotating arm if they are not sliced thin enough.
- Always separate food before adding it to the Healthy Fryer (eg nuggets, frozen chips)
- When cooking meat and chicken, it may be necessary to stop the Healthy Fryer and stir the pot once or twice
during cooking. This will ensure that the food does not dry out.
- Do not add salt to chips or fries while cooking. Wait until the food is removed from the pan before seasoning
to taste.
- Do not cook stews, casseroles and other food with high liquid content in this appliance. It must primarily be
used for frying and baking food only.
Cleaning and Maintenance
1. Before cleaning, please always ensure the unit is disconnected from the power outlet and appliance has
completely cooled down.
2. Wipe the housing and inner surface of the Healthy Fryer with a damp cloth, do not immerse it in water or
other liquids. Then dry thoroughly.
3. Wash the pan and mixing arm in warm soapy water, then rinse and dry thoroughly. The pan and mixing arm
are both dishwasher safe.
4. If you require to clean under the mixing arm centre knob (there can be a build-up of food over time), turn the
centre knob in a clockwise direction to release the cover. After finish cleaning, then place the mixing arm
centre knob into pot, turn the centre knob in anti-clockwise direction to close the cover.
5. Store the unit indoors in a dry location.
CAUTION: Never use harsh, abrasive, caustic or oven cleaners to clean this appliance. Never
immerse the appliance into water or other liquid for cleaning.
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

14
Repair and Refurbished Goods
or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to be returned to
the Supplier for repair.
Please be aware that if your product iscapable of retaininguser-generated data (such as files
stored on a computer hard drive,telephone numbers stored onamobile telephone, songs stored
on a portable media player, games saved onagames console or files stored ona USB memory
stick) during the process of repair, some or all of your stored data may be lost.
We recommend you save this data elsewhere prior to sending theproduct for repair.
You should also be aware that rather than repairing goods, we may replace them with
refurbished goods of the same type or use refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are only used where they
meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you may escalate your
complaint. Please telephone us on SUPPLIER TELEPHONE or write to us at:
Hifu Electronics Help Desk
1A Redbank Road, Northmead NSW 2152
Please contact customer service 1800 813 866
(Operating Hours: Mon-Fri 08:30AM to 06:00PM AEST)
Email: [email protected]
Healthy Fryer
YEAR WARRANTY
3
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS

15
Notes
AFTER SALES SUPPORT
AUS Hotline Costs
1800 813 866
MODEL: KA0151 PRODUCT CODE: 42312 06/2014
AUS
Table of contents
Other Kuchef Fryer manuals
