Kucht K148AH2 Assembly instructions

BE A PRO IN YOUR KITCHEN
www.kucht.com
APPLICABLE MODEL: K148AH2, K148E1, K280A1, K280AH2, K280AH4, K280AV2,
K280AVH3, K430A1, K430AH2, K430AH4, K430AV2, K430AVH3 & K430AVT3.
INSTALLATION GUIDE AND USER MANUAL
DUAL-ZONE WINE COOLER

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 2of 12
Contents
SAFETY INFORMATION & WARNINGS ......................................................... 3
PARTS AND FEATURES................................................................................. 4
ASSEMBLY INSTRUCTIONS .......................................................................... 5
INITIAL SETUP ........................................................................................... 5
INSTALLATION OF YOUR APPLIANCE......................................................... 5
POSITIONING YOUR WINE AND BEVERAGE COOLER ................................. 6
HANDLE INSTALLATION............................................................................. 7
OPERATING INSTRUCTIONS ........................................................................ 8
SETTING THE TEMPERATURE .................................................................. 10
SAFETY LOCK........................................................................................... 10
SHELVES.................................................................................................. 11
STORING WINE ......................................................................................... 6
CLEANING & MAINTENANCE ..................................................................... 11
TROUBLESHOOTING.................................................................................. 12

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 3of 12
SAFETY INFORMATION & WARNINGS
Before Using Your Wine And Beverage Cooler for the First Time:
Carefully read all instrucons before using this wine and beverage cooler
for the first me. Also make sure the wine and beverage cooler stays in an
upright posion during transportaon. Aer removing the appliance from
its packaging, make sure it is in good condion. If there are any issues with
the wine and beverage cooler, please contact us immediately.
Place the appliance on a level floor surface that will be strong enough
to support it when it is at full capacity. To level the wine and
beverage cooler adjust the leveling feet located at the boom of the
appliance.
Do not use this wine and beverage cooler in applicaons for which it
is not intended. Damage that occurs from improper use or from
unauthorized repairs will void the warranty.
For proper air circulaon,please maintain a 2-inch minimum
clearance in between the back of the wine and beverage cooler and
the wall.
Keep the wine and beverage cooler away from direct sunlight.
Keep the wine and beverage cooler away from hazardous materials
or combusble/flammable substances.
CAUTION:
This wine and beverage cooler is designed for built-in or freestanding
appliances.
DANGER: RISK OF CHILD ENTRAPMENT:
An empty wine and beverage cooler can be dangerous to children.
Remove any latches, lids, locks, and/or doors from unused or
discarded appliances to prevent child entrapment and suffocaon.
Never allow children to operate, play with or crawl inside this
appliance.

Page 4of 12
PARTS AND FEATURES
12.Power Buon
13.Light ON/OFF Buon
14.LCD Temperature Display Panel
15.Temperature Up Buon
16.Temperature Down Buon
17.Door Handle
18.Cup Holder
19.Beech Shelf for Display
20.Beech Shelf
21.Adjustable Leveling Legs
22.Safety Lock
1. Power Buon
2. Light ON/OFF Buon
3. LCD Temperature Display Panel
4. Temperature Up Buon
5. Temperature Down Buon
6. Door Handle
7. Cup Holder
8. Beech Shelf for Display
9. Beech Shelf
10.Adjustable Leveling Legs
11.Safety Lock
1. Power Buon
2. Light ON/OFF Buon
3. LCD Temperature Display Panel
4. Temperature Up Buon
5. Temperature Down Buon
6. Door Handle
7. Cup Holder
8. Beech Shelf for Display
9. Beech Shelf
10.Adjustable Leveling Legs
11.Safety Lock
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 5of 12
ASSEMBLY INSTRUCTIONS
INITIAL SETUP
Remove exterior and interior packing materials and connect the wine and
beverage cooler to power supply. Once it is plugged in, let it run for at least
30 minutes. Co not change the temperate or adjust any sengs at this
me.
INSTALLATION OF YOUR APPLIANCE
Use two or more people to move and install the appliance. Failure to
do so can result in back or other injury.
Place your appliance on a floor that is strong enough to support it
when it is fully loaded.
Choose a well-venlated area with temperatures above 60and
below 90.
This appliance is designed for built-in, recessed or free standing
installaon.
For built-in installaon, leave a 2” (50mm) space on each side and at
the top of the appliance to ensure proper air circulaon to cool the
compressor and condenser.
For freestanding installaon, leave the proper clearance around the
appliance. Below are the recommended clearances:
Sides……………… 2” (50mm)
Top………………… 2” (50mm)
Back………………. 2” (50mm)
Even for built-in installaon, you must keep space on each side and
at the top/ if you plan to use the unit for a built-in applicaon,please
follow the requirements shown below:
Sides……………… 2” (50mm)
Top………………… 2” (50mm)
Back………………. 2” (50mm)

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 6of 12
The appliance must be installed with all electrical, water and drain
connecons in accordance with state and local codes.
Make certain that the pipes are not pinched, kinked or damaged
during installaon. Check for leaks aer connecon.
Note: Designed for indoor, home use only. The appliance should not
be locate next to sources of high heat or in direct sunlight. Do not
store or install the appliance outdoors, in a garage, basement or in
moist areas. Don’t install in a locaon where the temperate will fall
below 60. For best performance and to ensure proper venlaon,
do not install the appliance behind a cabinet door or block the base
grille.
POSITIONING YOUR WINE AND BEVERAGE COOLER
It is important for the appliance to be leveled in order to work
properly. You may need to make several adjustments to level it.
To level your appliance, adjust the front legs at the boom of the
appliance.
When posioning the appliance, ensure that there is at least a ¼ inch
clearance at the sides and a 1 inch clearance at the back of the cooler
as this is the main outlet for heat. This will allow for adequate
venlaon.
STORING WINE
Many boles may differ in size and dimensions. The actual number of
boles you are able to store may vary. Bole capacies are approximate
maximums when storing tradional Bordeaux 750ML boles and include
bulk storage.

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 7of 12
HANDLE INSTALLATION
Pull away the door gasket in the area where the handle is to be
installed. The gasket is easily removed by hand, no tools are
necessary.
Insert the two (2) screws with the lock washers and flat washers
through the gasket side of the door frame unl the screws pass
through the door frame. Follow the sequence shown in the figure.
Align the handle with the screws installed in the above step. Tighten
the screws using a screwdriver unl the handles secure ghtly
against the door frame. (Do NOT over ghten as this will cause
damage to the handle assembly).
Replace the door gasket to its original posion.
Screw
Handle
Door Frame

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 8of 12
OPERATING INSTRUCTIONS
Power
Powers on/off the appliance. To turn off the appliance, touch the mark
and hold 5 seconds. The light of the display panel will off if no operaons
for 20 seconds.
Light
To control the interior light to turn on/off.
Up
To increase the corresponding zone set temperature by 0.1or 0.1.
Down
To decrease the corresponding zone set temperature by 0.1or 0.1.
Power and Light
Press and hold Power and Light buons for 5 seconds, you can select
the temperature display seng to display in Fahrenheit or Celsius.
Up and Down
Press and hold Up and Down buons for 5 seconds, you can lock or
unlock the display control panel. The display control panel will be
automacally locked if no operaons for 60 seconds.
Power and Down
Press and hold Up and Down buons for 3 seconds, you can switch
the display panel to DISPLAY MODE (LED light on the display panel will
remain ON). And you can switch back to the ENERGY-SAVING MODE
(Default Mode, light on the display panel will automacally OFF aer 20
seconds since the last operaon).

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 9of 12
Self-Error Detecting System
Code Problem
E1
Open circuit in the temperature sensor 1
E2
Short circuit in the temperature sensor 1
E3
Open circuit in the temperature sensor 2
E4
Short circuit in the temperature sensor 2
E8
Communicaon Failure
E9
Communicaon Signal Overme Waing
F0
Fault in the Relay of Compressor
F1
Fault in the Fan (FIC)
F2
Fault in the Fan (FIH)
F3
Fault in the Fan (F2C)
F4
Fault in the Fan (F2H)
F5
Fault in the Relay of Heang Element 1
F6
Fault in the Relay of Heang Element 2
F7
Fault in the Fan (F3C)
F8
Fault in the Fan (F3H)
-The Error Code will appear on the le side of the display panel.
Note:
When the Error Code appears, the display will flash (once per second), the
buzzer will sound 10 seconds per minute. Press the Power Buon can turn
off the alarm. Please ask for a cerfied technician performs the repair
service.

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 10 of 12
SETTING THE TEMPERATURE
The temperature can be set between 5 and 22.
The temperature will increase by 0.1or 0.1if you touch UP
once;
Or the temperature will decrease by 0.1or 0.1if you touch
DOWN once.
In order to adjust the temperature, you have to first unlock the
control panel by press and hold and together for 5 seconds.
The control panel is unlocked when the buzzer sounds twice. (The
control panel will be automacally locked if it is not operated for 5
seconds.)
The set temperature will appear on the right side on the temperature
display window and the internal storage temperature will appear on
the le side.
NOTE: If the unit is unplugged, turned off, or power is lost, you must
wait 3 to 5 minutes before restarng the unit. If you aempt to restart
before this me delay the unit will not start. When you use the unit
for the first me or restart the unit aer having been shut off for a
long me, there could be a few degrees variance between the
temperature you select and the one indicated on the LED readout.
This is normal and it is due to the length of the acvaon me. Once
the unit is running for a few hours everything will normalize.
SAFETY LOCK
Your unit is provided with a lock and key combinaon. The keys are located
inside the plasc bag that contains the owner’s manual. Insert the key into
the lock and turn it counter clockwise to unlock the door. To lock the door,
do the reverse operaon while making sure the metal pin is engaged
completely. Remove the key and place it in a secure place for safekeeping.

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 11 of 12
SHELVES
To prevent damaging the door gasket, make sure to have the door
completely opened when pulling the shelves out of the rail compartment.
For easy access to the storage content, you must pull the shelf out of
the rail compartment; however this unit was designed with a plasc
post on each side of the shelf track to prevent boles from falling.
When removing the shelf out of the inner rail, make sure to remove
all items first. Then move the shelf to the posion when the notch of
the shelf is exactly under the plascpost and lithe shelf. In order to
replace the shelf, repeat these direcons in reverse.
To ensure maximum performance and efficiency, be sure to place
your wine and beverage cooler in an area where there is proper air
circulaon. Also make sure the plumbing and electrical connecons
are correct.
For proper internal air circulaon,do not overfill your wine and
beverage cooler.
Do not place the unit in direct sunlight.
Do not place heated beverages in your wine and beverage cooler.
Do not store perishable food in your wine and beverage cooler. The
unit’s interior temperature may not be low enough to prevent
spoilage.
Do not place heavy objects on top of the wine and beverage cooler.
CLEANING & MAINTENANCE
Shut off the power supply before cleaning the unit’s cabinet.
Remove all cans and storage shelves.
Clean the unit’s interior with a warm water and neutral detergent
soluon.
Thoroughly dry all surfaces.

FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM
INSTALLATION GUIDE AND USER MANUAL
Page 12 of 12
Please Note:
a. Do not use abrasive cleaners to clean the wine & beverage cooler.
b. Use mild, soapy water to clean the unit’s door seal.
c. To ensure efficient operaon, also thoroughly clean the back and
boom of the wine and beverage cooler.
TROUBLESHOOTING
Problem
Possible Causes
Solution
The wine and
beverage
cooler does
not cool.
The unit may be plugged
in using a different
voltage.
Check if using the wrong
voltage.
The circuit breaker may be
tripped or there is a blown
fuse.
Reset the circuit breaker or
check for a broken fuse.
The wine and
beverage
cooler does
not get cold
enough.
The unit may be placed
too close to a heat source.
Keep the unit away from
direct sunlight or other
heat sources.
There is insufficient
venlaon.
Place the unit in an area
with proper venlaon and
clearances.
The door is not completely
closed or the door seal is
not working properly.
Close the door ghtly. Do
not open the door
frequently or keep the door
open for extended periods.
The wine and
beverage
cooler seems
to make too
much noise.
The unit is not leveled or
posioned properly.
Adjust the unit’s feet and
ensure the product is level.
There is insufficient
venlaon.
Allow sufficient clearance
around the unit.
The unit is too close to a
wall or other surface.
Allow sufficient clearance
around the unit.
Frost is
building up in
the unit.
There is excess humidity
or the interior
temperature is too low.
Turn the unit off, unplug it
and remove the frost
manually. Reconnect once
the ice has thawed.
