Kucht K430D Assembly instructions

BE A PRO IN YOUR KITCHEN
www.kucht.com
APPLICABLE MODEL: KD430D
INSTALLATION GUIDE AND USER MANUAL
K430D - 166 Bottles
BUIT-IN DUAL-ZONE
WINE COOLER
LOW
NOISE 166

2
WARNING To reduce the risk of fire, electrical shock, or injury when using you
appliance, follow these basic precautions
·Read all instructions before using the Wine Cooler.
Technical specifications may be subject to the entity or rating label without notice since products
are under continuous improvement. No prior notice will be given for any changes of technical
specifications or spare parts .
·DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances
are still dangerous…even if they will “just sit in the garage a few days”.
·Before you throw away your oldWine Cooler or any appliance: Remove the door. Leave
the shelves in place so that children may not easily climb inside.
·Never allow children to operate, play with, or crawl inside the appliance.
· Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or
explosion.
·Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any
otherappliance. The fumes can create a fire hazard or explosion.
.This product can not be taken alone by infants, disabled, sensory disabled, psychotic, those who
lack of experiences and civilization.
.If the power cord is damaged, in order to avoid risks, it must be repaired by the manufacturer, the
maintenance department or similar professionals.
-Save these instructions-
INSTALLATION INSTRUCTIONS
Before Using YourWine Cooler
·Remove the exterior and interior packing.
·Before connecting the Wine Cooler to the power source, let it stand upright for
approximately 2 hours. This will reduce the possibility of a malfunction in the cooling
system from handling during transportation.
·Clean the interior surface with lukewarm water using a soft cloth.
·Install the handle on the left side of the door.
Installation of YourWine Cooler
·This appliance is designed for free standing or built-in (full recessed) installation.
· Place your Wine Cooler on a floor that is strong enough to support it when it is fully
loaded. To level your Wine Cooler, adjust the front leveling legs at the bottom of the
Wine Cooler .
·Locate the Wine Cellar away from direct sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may
increase electrical consumption. Extreme cold ambient temperatures may also cause
the unit not to perform properly.
·Avoid locating the unit in moist areas.
·Plug the Wine Cooler into an exclusive, properly installed-grounded wall outlet. Do notunder
any circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified or an authorized
products service center.
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM

3
Defrosting:
During its running, wine cooler has got onetime defrosting process per 8 hours and defrosting will
last about 30 minutes. The defrosting water will collected by evaporator drip tray and
automatically evaporated. At the process of defrosting, the temperature display may be higher than
the setting temperature.
OPERATING YOUR WINE COOLER
Recommended temperatures for Chilling Wine.
Red Wines: 15-180C (59-64.40F)
Dry /White Wines 9-140C (48.2-57.20F)
Sparkling Wine 5-80C (41-46.40F)
The above temperatures may vary slightly depending on whether or not the interior bulb is
ON or OFF or whether the bottles are located on the upper/middle or lower section.
·The controls of your wine cooler
The Wine cooler should be placed in where the ambient temperature is between
16-35℃.If the ambient temperature is above or below this range, the performance of the
unit may be affected. For example, placing your unit in extreme cold or hot conditions may
cause interior temperatures to fluctuate.
ON/OFF Power
To turn the appliance on or off, press the ON/OFF button.
Setting the temperature Control
-Each cooling compartment of the Wine Cooler (upper and lower) is independently
controlled. To set the temperature:
Connect the power cord to a properly grounded outlet. In the event of a power
interruption, all previous temperature settings are automatically erased and each
compartment will default to a preset temperature setting of : 5℃for upper compartment
and 12℃for lower compartment.
-Set the desired cooling temperature by pressing the corresponding buttonsfor “set
upper / set lower” program. Each depression of the buttons willscroll through the
available temperature settings (for each compartment) in reduction of 1 degree. The
temperature selected will flash in the LED display for approximately 5 seconds, then
revert back to display the temperature of the internal cooler.
Upper compartment :
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM

4
The temperature setting can be adjusted from 5℃to 10℃.
Lower compartment :
The temperature setting can be adjusted from 10℃to 18℃.
-To view the “set” temperature (anytime) press one time, the “set” temperature will
temporarily “flash” in the LED display for 5 seconds.
-This unit has the option to display temperatures in either Celsius or Fahrenheit. To
change the setting, press and hold both buttons (Set Upper/Set Lower) simultaneously for
approximately 5 seconds,
Cooling
Indicator lightilluminates to signify the cooling mode is currently in operation.
Interior Light
You can turn the interior light ON or OFF by pushing the button marked with the “bulb”
symbol. The light will be turned off automatically if it remains ON for 10 minutes. You have
to push the button marked with the “bulb” symbol again and the light will turn back on. For
best storage of wine, keep the light off except when viewing.
NOTE:
-If the unit is unplugged, turned off or if there is a power failure, you must wait 3 to 5
minutes before restarting the unit. If you attempt to restart before this time delay, the
Wine Cooler will not start working.
-When you use the Wine Cooler for the first time, or restart the Wine Cooler after having
been shut off for a long time, there could be a few degrees variance between the
temperature you select and the one indicated on the LED readout. This is normal and is
due to the length of the inactivation time. Once the wine Cooler is running for a few hours
everything will be back to normal.
.
CARE AND MAINTENANCE
Cleaning YourWine Cooler
·Turn off the power, unplug the appliance, and remove all items including shelves and
racks.
·Wash the inside surfaces with a warm water and baking soda solution. The solution
should be about 2 tablespoons of baking soda to a quart of water.
·Wash the shelves with a mild detergent solution.
·Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts.
·Wash the outside cooler with warm and mildliquid detergent. Rinse well and wipe dry
with a clean soft cloth.
-Defrosting occurs automatically inside of the wine cooler during operation. Approximately
every 8 hours, the compressor will stop running for about 30 minutes. During defrosting
the temperature will higher than you set. The defrost water is collected by the
evaporating tray and evaporates automatically。
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM

5
Power Failure
·Most power failures are corrected within a few hours and should not affect the
temperature of your appliance if you minimize the number of times the door is opened. If
yourpower is going to be off for a longer period of time, you need to take the proper
steps to protect your contents.
Vacation Time
·Short vacations: Leave the Wine Cooler operating during vacations of less then three
weeks. If you turn off the Wine Cooler for extended periods, leave the door slightly ajar
to prevent odor building inside the appliance.
Transporting you Wine Cooler
If you need to move your Wine Cooler once the box has been discarded:
·Securely tape down all loose items (shelves) inside your appliance.
·Turn the adjustable leg up to the base to avoid damage.
·Tape the door shut.
·Be sure the appliance stays secure in the upright position during transportation. Also
protect the outside of the appliance with a blanket, or similar item.
Energy saving Tips
·The Wine Cooler should be located in the coolest area of the room, away from heat
producing appliances ,and out of the direct sunlight.
FOR MORE DETAILS AND INFORMATION, PLEASE VISIT OUR WEBSITE WWW.KUCHT.COM

6
PROBLEMS WITH YOUR WINE COOLER
You can solve many common Wine Cooler problems easily, saving you the cost of a
possible service call. Try the suggestions below to see if you can solve the problem
before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Wine Cooler does not operate. Not plugged in.
The appliance is turned off.
The circuit breaker has tripped or a fuse has
blown
Wine Cooler is not cold enough. Check the temperature control setting.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Turns on and off frequently. The room temperature is hotter than normal.
A large amount of contents has been added
to the Wine Cooler.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work. Not plugged in.
The circuit breaker tripped or a blown fuse.
The bulb has burned out.
The light button is “OFF”.
Vibrations. Check to assure that the Wine Cooler is level.
The Wine Cooler seems to make too
much noise.
Some noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in
your Wine Cooler.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The Wine Cooler is not level.
The door will not close properly. The Wine Cooler is not level.
The door was reversed and not properly
installed.
The gasket is dirty.
The shelves are out of position.
