Kudux PIXEL ZOOM 285 User manual
PIXEL ZOOM 285
WASH LED
User manual
! Please read the manual before installing and using this
lighting
Keep it for future
reference
WWW.KUDUX.COM 2
Thank you for purchasing our device.
We make every effort to ensure the best
quality of our products and to meet your
expectations.
If you have any remarks or comments,
please share them with us.
We will be grateful for any suggestions
that will help us make products that are
even better and devices that satisfy your
needs.
R&D Team
WWW.KUDUX.COM 3
Table of contents
Statement.................................................................................................................................. 3
1. Safety information............................................................................................................. 4
2. Package.............................................................................................................................. 5
6. Install standard.................................................................................................................. 8
7. Power supply ..................................................................................................................... 9
8. Control panel menu operate ............................................................................................. 9
10. DMX Channels ............................................................................................................. 13
11. Clear and maintenance................................................................................................ 17
12. Contact: ....................................................................................................................... 17
Statement
The product is good packing when ship out the factory. All users should strictly abide by the
warnings and instructions stated in this manual, any damage and results due to misuse and the
neglect of this operating manual will be excluded from the deal responsibility this manual will not
informed in additionally if have technical changes.
WWW.KUDUX.COM 4
1. Safety information
Safety warning:
This product is only suitable for professional use, and does not apply to security for other purposes.
After you got the lights, please check the package whether have any damage caused by
transportation. If there is any damage, do not use this fixture, and please contact the dealer or
manufacturer as soon as possible. This product is only suitable for indoor, IP20 protection class.
Lamps should be kept dry to avoid Moisture, overheating or dusty environment. Prevent lamps
meet water or any other liquid. The use of this product should pay attention to: fire, heat, electric
shock, ultraviolet radiation, the lamp to explode or shedding caused serious or fatal injury. Need
to read the instructions before use energized or installing. Follow through the operation of
security methods and pay attention to the warning signs on the specification and equipment. If
you have any problem for how to safely operate the equipment. Please contact your dealer.
1.1. Anti-high temperature
ta =40°C
Please don’t use the equipment if the temperature above 40℃
1.2. To prevent falling wounding
When Hang the fixture, please must verify that the facilities to be able to withstand at least 10
times or more weight of fixtures. Please make sure the Mounting hardware is strong enough no
any damage, and insurance for the safety rope as auxiliary security fixed in other facilities will need
to verify before installation. Installing or removing the equipment, to make the pulley below the
work location
1.3. UV protection and the bulb explosion
Prohibit straight viewpoint with exposed bulbs to avoid UV damage to the eyes;
Do not use the equipment without the lens screen and the lid;
The lens and the light head covers should be timely replaced if any damage to rupture
1.4. Prevention of electric shock
The electrical connection must only be carried out with corresponding qualifications;
Before installing, make sure you use the power voltage lamps must comply with the identified
power, voltage and have an overload or leakage protection;
Each lamp must be properly grounded, installed in accordance with the relevant standards;
Cut off the power when stall or replace the lamp and the fuse;
Prohibit the use of a lightning storm or wet environment.
1.5. To prevent burning or fire
•The fixture can't be mounted directly on the surface of ordinary combustible material.
•The equipment must be installed away from inflammable and explosive materials.
WWW.KUDUX.COM 5
•The highest temperature is 40 ° C when the equipment is in stable state.
•The equipment cannot have an obstacle at least in the range of 0.5 meters.
•Do not replace the non-original parts.
2. Package
2.1. Attachment
PIXEL ZOOM 285 packed with fly-case of one in one, two in one, or carton box, attach follow
accessory:
CONTENT
QUANTITY
USER MANUL
1 piece
CLAMP (option)
2 pcs
SIGNAL CABLE
1 piece
2.2. Transport protect lock
To protect the light, there is a protect lock; During the transport, the lock will have closed
keeping the item in safety state.
2.3. About pack stage
1. Before packed, make sure power is off, and wait for at least 20mins for cooling down.
2. Before cleaning the fixture, make sure X, Y axis protect lock closed.
3. After packed by plastic bag, high-lift the fixture with two handles besides the product. put
the product into the fly-case up-side-down.
4. After packed the product, put the accessory into the accessory case, then closed and lock
the fly-case.
5. Fly-case only up stacked two layers. Prohibited upside down
6. When packed with carton box, equipment should be put into the foam first, then set into a
carton, pay attention to the vertical position.
2.4. Unpacking
Note: Before unpacking check the damage is whether due to the transportation or not, if you
find any such damage, please do not use this item, and contact with the dealer or
manufacturer as soon as possible.
•Open the fly-case, and discover the inside plastic bag.
•High-lift the product by two handles beside the bottom base and move it out.
•Before power on, make sure you have opened the X, Y axis lock!
WWW.KUDUX.COM 7
5. Specification
5.1. Specification
Channels mode 14/25/90 CH
Lamp: OSRAM/TAIWAN 15W RGBW 4in1 LED;
Power: 110-240V,50/60Hz;
Total power: 400W;
Display: LCD screen display, can reverse 180°;
Lens: French lens, 8 degree;
Zoom angel : 7.9-38°;
Dimmer : 0-100% l inear adjustment ;
Pan : 540°; 8Bit/16Bit ;
Tilt : 270°; 8Bit/16Bit ;
3-phase motor for Pan/Tilt fast moving speed & noiseless;
IP Rate: IP20;
Flight case : 740x400x490 mm; carton : 460x305x420 mm;
Net weight : 12 KG;
Can make the clear spot when beam angel in7.9-degree, wash effect when in big angle
5.2.Luminous diagram
WWW.KUDUX.COM 8
6. Install standard
6.1. Install lock
PIXEL ZOOM 285 can be placed on the stage, or mounted in an arbitrary direction of the truss.
Two fast locks system could fix the item easily.
6.2. Equipment fixed
•Before installation must verify the fast lock is keep in good state, and can withstand at
least 10 times the weight of product. Verify that the building can withstand at least 10
times of the total weight of the product and accessory equipment’s.
•Fix the hang fixture into the hole, which located on the base of the price.
•Seize handle of fasteners, clockwise rotate 1/4 turn and lock. Installed other one
fastener
•in the same method.
•Using the safety cable which can withstand 10 times the weight of the equipment.
•Make sure the X, Y protect locks are opened, verify that within 3 meters there is no
combustibles.
WARNING
Fixture must use two fixing devices, and make sure the fixing device have locked! And only
fully clockwise rotate 90 ° can lock the hang fixture! Do remember plus a safety rope, and do
not connect the safety rope to plastic handle. It should be connected to the hole on the base!
6.3. Fixture connects
Attention! One product only can accept one input one output.
PIXEL ZOOM 285 DMX cable include 3 contact pins:
Pin 1, FOR GROUND; Pin 2 connected to the negative polarity signal; The pin 3 connected to the
positive polarity signal.
DMX512 cable must use the professional shielded twisted pair cable; standard loudspeaker cable
is not reliable to control the long-range data. 24AWG cable is suitable for more than 300 meters
long-distance signal transmission and must add\ DMX 512 signal amplifier.
Do not use two outputs to separate the connection, if separate a continuous connection to
branch, DMX512 splitter is necessary.
If use the DMX512 splitter. At first connect DMX512 Splitter input terminal to controller, and
then connected from the splitter output terminal to next device.
Do as above guide to connect other device, and finally coupled with terminal insertion as
following:
WWW.KUDUX.COM 9
7. Power supply
7.1. Voltage, power, fuse specification
Input Voltage
Total Power
Frequency
110~240V
400 W
50/60HZ
8. Control panel menu operate
9. LM285 LCD DISPLAY CONTENTS
Main Menu
Submenu 1
Submenu2
Function
SET
Function description
DMX
ADDRESS
<<
001-512
address minimum value 1
<
address + 1
>
address -1
<<
address maximum value 512
SAVE
save date and back to main
interface
ESC
back to main interface
FEATURES
SETTING
Run Mode:
DMX
DMX
Wire
inactive
Aoto
inactive
Channel
Mode:
14CH
14CH
25CH
25CH
90CH
90CH
Pan Reverse:
Off
Pan Scan Normal
On
Pan Scan Reverse
Tilt Reverse:
Off
Tilt Scan Normal
On
Tilt Scan Reverse
Opto Check:
Off
Pan/Tilt optical sensor testing
off
On
Pan/Tilt optical sensor testing
on
WWW.KUDUX.COM 10
PT Speed:
Noml
Pan/Tilt Scan Speed setting
normal
Slow
Pan/Tilt Scan Speed setting
slow
Fast
Pan/Tilt Scan Speed setting
fast
Singl Clear:
Off
keep signal data
On
clear signal data
ADV.
enter advanced function
RST.
reset and back to main interface
SAVE
save date and back to main
interface
ESC
back to main interface
ADVANCED
FUNCTION
Redress
ZEROSETTING
Pan:
0-255
Motor zero calibration
Tilt:
Focus:
SAVE
save date and back to last
interface
>
the current value + 1
<
the current value - 1
ESC
back to last interface
ChanlDef
inactive
FactSett
UseManage
Limit
LimitTime
inactive
limitCont
inactive
DefConfig
YES
restore default and exit from
the current interface
NO
exit from the current interface
FacConfig
SAVE
save factory configuration ,exit
from current interface
EPRT
export factory configuration
exit from current interface
ESC
exit from current interface
ESC
back to last interface
UNLOCK
Verify1:
0-255
unlocking code
Verify2:
WWW.KUDUX.COM 11
KEY
password to enter the next
interface, Otherwise the exit
from the current interface
ESC
exit from current interface
MANUAL
LAMP
REST
ALL MOTER
all motors
XY MOTER
function inactive
PART MOTER
function inactive
YES
Reset the selected motor
ESC
back to last interface
TEST RUN
AUTO
auto
SOUND
sound control
ESC
back to last interface
SMULATE
DMX
Beam Strobe:
0-255
manual control
Beam Dimmer:
Focus:
Pan:
Pan Fine:
Tilt:
Tilt Fine:
Function:
Beam Macro:
Beam Red:
Beam Green:
Beam Blue:
Beam White:
Colour Grad:
Gobo:
Shape Selection:
Shape Speed:
Shape Fade:
Shape R:
Shape G:
Shape B:
Shape W:
Shape Dim:
Background Dim:
Reserved:
>
current value + 1
<
current value - 1
ESC
back to last interface
WWW.KUDUX.COM 12
ESC
back to main interface
SYSTEM
INFO
DMX
VALUE
CH00-CH25
0-255
DMX value number
REST INFO
Pan:
Right/Erro
Motor reset state
Tilt:
Focus:
Pan Opto:
Tilt Opto:
ESC
back to last interface
OTHER
INFO
Run Time:
0-9999
fixture running how many
hours
Run Count:
0-9999
fixture running times
Residue T:
Most
running hours unlimited
Residue C:
Most
running time unlimited
Type:
LM285
light model
Temp:
xxx
led temperature
Fan 1:
0-9999
Fan 1 rotate speed
Fan 2:
0-9999
Fan 2 rotate speed
Lamp brand:
CN/OSM
LED brand
DisVersion:
Vxxx
Panel software version number
XY Version:
Vxxx
XY Driver software version
number
M1 Version:
Vxxx
M1 software version number
ESC
back to last interface
ESC
back to main interface
DISPLAY
SETTING
Light Set:
1-7Lev
Backlight brightness Settings
Light Off:
On
backlight keeps on
1Min
backlight off in 1 minutes
2Min
backlight off in 2 minutes
3Min
backlight off in 3 minutes
Menu Back:
Off
close menu to return
automatically
1Min
The menu returns in 1 minute
2Min
The menu returns after 2
minute
3Min
The menu returns after 3
minute
Light Flash:
Off
Closing backlight flashing
WWW.KUDUX.COM 13
On
open backlight flashing
Touch Cali:
Off
Close touch calibration
On
open touch calibration
SAVE
save the date and back to main
interface
ESC
back to main interface
DIMMER
SETTING
Dimmer
Mode:
Fast
fast
Noml
smooth
Balance
SW:
Off
The white balance off
On
The white balance on
Balance
Red:
0-255
The white balance red
Balance
Green:
The white balance green
Balance
Blue:
The white balance blue
Balance
White:
The white balance white
10.DMX Channels
14CH
25CH
90CH
Function
DMX
value
Description
1
1
1
Strobe
0 -19
Strobe OFF
20 -24
Strobe ON
25 -64
Strobe Fast-Slow
65 -69
Strobe ON
70 -84
Slow input Strobe Fast-Slow
85 -89
Strobe ON
90 -104
Slow output Strobe Fast-Slow
105-109
Strobe ON
110-124
Random Strobe Fast-Slow
125-129
Strobe ON
130-144
Random Slow input Strobe Fast-Slow
145-149
Strobe ON
WWW.KUDUX.COM 14
150-164
Random Slow output Strobe Fast-Slow
165-169
Strobe ON
170-184
Pulse Strobe Fast-Slow
185-189
Strobe ON
190-204
Random Pulse Strobe Fast-Slow
205-209
Strobe ON
210-224
Strobe Fast-Slow
225-229
Strobe ON
230-244
Exposure Strobe Fast-Slow
245-255
Strobe ON
2
2
2
Dimmer
0 -255
Linear Dimmer Dark-Bright
3
3
3
Focus
0 -255
Linear Focus
4
4
4
Pan Rotation
0 -255
0~540 degree
5
5
5
Pan Fine
0 -255
Pan Fine
6
6
6
Tilt Rotation
0 -255
0~270 degree
7
7
7
Tilt Fine
0 -255
Tilt Fine
8
8
8
Function set
0 -9
No function
10 -14
Whole light Reset
15 -39
No function
40 -44
XY Normal mode
45 -49
XY Fast mode
50 -54
XY Slow mode
55-255
No function
9
9
9
Color
temperature or
color
0 -9
No function
10 -14
Moroccan Pink
15 -19
Pink
20 -24
Special rose Pink
25 -29
Follies Pink
30 -34
Fuchsia Pink
35 -39
Surprise Pink
40 -44
Congo Blue
45 -49
Tokyo Blue
50 -54
Deep Blue
55 -59
Just Blue
60 -64
Medium Blue
65 -69
Double CT Blue
70 -74
State Blue
75 -79
Full CT Blue
80 -84
Half CT Blue
WWW.KUDUX.COM 15
85 -89
Steel Blue
90 -94
Lighter Blue
95 -99
Light Blue
100-104
Medium Blue Green
105-109
Dark Green
110-114
Primary Green
115-119
Moss Green
120-124
Fern Green
125-129
JAS Green
130-134
Lime Green
135-139
Spring Yellow
140-144
Deep Amber
145-149
Chrome Orange
150-154
Orange
155-159
Gold Amber
160-164
Millennium Gold
165-169
Deep Golden Amber
170-174
Flame Red
115-179
180-201
Color clockwise run from fast to slow
202-207
Stop
208-229
Color anticlockwise run from slow to fast
230-234
No function
235-249
Random color Fast-Slow
250-255
No function
10
10
10
Red beam
0-255
Red Dimmer Dark-Bright
11
11
11
Green beam
0-255
Green Dimmer Dark-Bright
12
12
12
Blue beam
0-255
blue dark - bright
13
13
13
White beam
0-255
white dark- bright
14
14
14
Color slow
change
0 -7
--F82
8 -39
Red to Yellow
40 -71
Yellow to Green
72 -103
Green to Cyan
104-135
Cyan to Blue
136-167
Blue to Magenta
168-199
Magenta to Red
200-231
Red to White
232-255
Color change slow - fast
15
LED gobo
0 -4
-F91
WWW.KUDUX.COM 16
5 -9
Gobo 1
10 -14
Gobo 2
15 -19
Gobo 3
20 -24
Gobo 4
…
…
185 -189
Gobo 37
190 -194
Gobo 38
195 -199
Gobo 39
200 -204
Gobo 40
205 -224
Gobo clockwise run from fast to slow
225 -234
Stop
235 -255
Gobo anticlockwise run from slow to fast
16
Built-in
effects
0 -4
No function
5 -14
LED built-in effect1
15 -24
LED built-in effect2
25 -34
LED built-in effect3
35 -44
LED built-in effect4
…
…
155-164
LED built-in effect16
165-174
LED built-in effect17
175-184
LED built-in effect18
185-194
LED built-in effect19
195-255
Switch Auto. after 1 minute
17
Effect speed
0 -255
LED built-in effect speed Slow-Fast
18
Effect slow
input
0 -255
LED built-in effects Gradient Overlay
19
Effect red
0 -255
Red Dimmer Dark-Bright
20
Effect green
0 -255
Green Dimmer Dark-Bright
21
Effect blue
0 -255
Blue Dimmer Dark-Bright
22
Effect white
0 -255
White Dimmer Dark-Bright
23
Effect
Dimmer
0 -255
Dimmer Dark-Bright
24
Effect
backlight
0 -255
Dimmer Dark-Bright
25
Reserve
0 -255
15
R1Dimmer
0 -255
R1Dimmer Dark-Bright
16
G1Dimmer
0 -255
G1Dimmer Dark-Bright
17
B1Dimmer
0 -255
B1Dimmer Dark-Bright
18
W1Dimmer
0 -255
W1Dimmer Dark-Bright
WWW.KUDUX.COM 17
…
…
…
87
R19Dimmer
0 -255
R19Dimmer Dark-Bright
88
G19Dimmer
0 -255
G19Dimmer Dark-Bright
89
B19Dimmer
0 -255
B19Dimmer Dark-Bright
90
W19Dimmer
0 -255
W19Dimmer Dark-Bright
11.Clear and maintenance
Warning: Please make sure cut off the power before open the covers.
(Kind Remind: Non-Professional don’t do this)
1. Cut off the power supply, cool down the lamp and open the covers.
2. Using vacuum or pressure blows gently blow any dust and floating structures.
12.Contact:
Please check who is our dealer in your country at our website
www.kudux.com
or write direct to us by email: office@kudux.com
Table of contents
Other Kudux Dj Equipment manuals
