Kullhaus alpha Q13L User manual

alpha Q13L
Instruction Manual
DEHUMIDIFIER
Thank you for choosing Kullhaus.
Please read instructions before using the dehumidier and keep it for future reference

CONTENTS
Safety precautions ..................................................................................................................................3-4
Safety Regulations for Service and Repair Work.....................................................................................5-6
Product Description ....................................................................................................................................7
Placement ................................................................................................................................................. 7
Control Panel Description .......................................................................................................................... 8
Operating Instructions ....................................................................................................................... 9-10
Cleaning and Maintenance ...................................................................................................................... 11
Trouble Shooting ..................................................................................................................................... 12
Display Error Codes ................................................................................................................................ 13
Technical Specications .......................................................................................................................... 13
Conditions of Warranty ............................................................................................................................ 14
1

Only for home use / power source 220-240V/50Hz
Read the USER MANUAL carefully before operation.
This device is for home use only and not for commercial, industrial or outdoor use.
We reserve the right for any error in the text or images and any necessary changes
made to technical data.
Recycle unwanted materials instead of disposing of them. All appliances and packag-
ing should be sorted and tendered at a regional recycling centre and be processed in
an ecological manner.
This unit uses a ammable refrigerant.
If refrigerant leaks and comes in contact with re or heating part, it will create
harmful gas and there is risk of re.
Before putting the device into operation for the rst time, place it in an upright
position for at least 3 hours to stabilize the compressor uids.
Service personnel are required to carefully read the USER MANUAL and SERVICE
MANUAL before operation. Failure to abide by this warning could result in an explo-
sion, injury and property damage.
2

3
SAFETY INSTRUCTION
• Read the operating instructions carefully before using the dehumidier & keep it for future reference.
• To avoid electric shock, re or injury, please read the user manual carefully before using the appliance and keep it for future
reference.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• The unit is designed only for use with R-290 (propane) gas as the designated refrigerant.
• THE REFRIGERANT LOOP IS SEALED. ONLY A QUALIFIED TECHNICIAN SHOULD ATTEMPT TO SERVICE!
• Do not discharge the refrigerant into the atmosphere.
• R-290 (propane) is ammable and heavier than air.
• It collects rst in low areas but can be circulated by the fans.
• If propane gas is present or even suspected, do not allow untrained personnel to attempt to nd the cause.
• The propane gas used in the unit has no odour.
• The lack of smell does not indicate a lack of escaped gas.
• If a leak is detected, immediately evacuate all persons from the store, ventilate the room and contact the local re department
to advise them that a propane leak has occurred.
• Do not let any persons back into the store until the qualied service technician has arrived and that technician advises that it
is safe to return to the store.
• No open ames, cigarettes or other possible sources of ignition should be used inside or in the vicinity of the units.
• Component parts are designed for propane and non-incentive and non-sparking. Component parts shall only be replaced
with identical repair parts.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
• The appliance shall be disconnected from its power source during maintenance.
• Ensure the unit is far away from re, inammable, or explosive objects.
• Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacture.

4
SAFETY INSTRUCTION
The appliance shall be stored in a room without continuously operation sources (for example: open ames, an operating gas ap-
pliance or an operating electric heater).
The appliance shall be stored so as to prevent mechanical damage from occurring.
Do not piece or burn, even after use.
Pipework shall be protected from physical damage.
THE MACHINE MAY ONLY BE INSTALLED IN A ROOM WITH MINIMUM FLOOR AREA OF 4 m².
Compliance with national gas regulations shall be observed.
Keep any required ventilation openings clear of obstruction.
The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specied for opera-
tion.
Warning on Refrigerant R290
• Failure to abide by this warning could result in an explosion, death, injury and property damage.
• Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certicate from
an industry-accredited assessment authority, which authorizes their competence to handle refrigerants safely in accordance
with an industry, recognized assessment specication.
• Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the
assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of am-
mable refrigerants.

SAFETY REGULATIONS FOR SERVICE AND REPAIR WORK
Repairs must only be carried out by authorised service personnel and only using genuine
spare parts. Please follow these warnings when servicing a dehumidier with R290.
Checks to the area
Prior to beginning work on systems containing ammable refrigerants, safety checks are necessary to ensure that the
risk of ignition is minimized. For repair to the refrigerating system, the following precautions shall be complied with prior to
conducting work on the system.
Work procedure
Work shall be undertaken under a controlled procedure so as to minimize the risk of a ammable gas or vapour being
present while the work is being performed.
General work area
All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out. Work
in conned spaces shall be avoided. The area around the workspace shall be sectioned off. Ensure that the conditions
within the area have been made safe by control of ammable material.
Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to and during work, to ensure the technician is
aware of potentially ammable atmospheres. Ensure that the leak detection equipment being used is suitable for use with
ammable refrigerants, i.e. no sparking, adequately sealed or intrinsically safe.
Presence of re extinguisher
If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate re extinguishing
equipment shall be available to hand. Have a dry powder or CO² re extinguisher adjacent to the charging area.
No ignition sources
No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or
has contained ammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of re
or explosion. All possible ignition sources, including cigarette smoking, should be kept sufciently far away from the site of
installation, repairing, removing and disposal, during which ammable refrigerant can possibly be released to the surround-
ing space. Prior to work taking place, the area around the equipment is to be surveyed to make sure that there are no
ammable hazards or ignition risks. “No Smoking” signs shall be displayed.
Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any
hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely
disperse any released refrigerant and preferably expel it externally into the atmosphere.
5

SAFETY REGULATIONS FOR SERVICE AND REPAIR WORK
Checks to the refrigeration equipment
Where electrical components are being changed, they shall be t for the purpose and to the correct specication. At all
times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt consult the manufacturer’s tech-
nical department for assistance.
The following checks shall be applied to installations using ammable refrigerants:
– The charge size is in accordance with the room size within which the refrigerant containing parts are installed;
– The ventilation machinery and outlets are operating adequately and are not obstructed;
– If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant;
– Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected;
– Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance
which may corrode refrigerant containing components, unless the components are constructed of materials which are
inherently resistant to being corroded or are suitably protected against being so corroded.
Checks to electrical devices
Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures.
If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfacto-
rily dealt with. If the fault cannot be corrected immediately but it is necessary to continue operation, an adequate temporary
solution shall be used. This shall be reported to the owner of the equipment so all parties are advised.
Initial safety checks shall include:
-those capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking;
-that there no live electrical components and wiring are exposed while charging, recovering or purging the system;
-that there is continuity of earth bonding.
Releasing refrigerant into atmosphere is strictly forbidden!
6

7
PRODUCT DESCRIPTION
Check the dehumidier for any transport damage. In case of damage, you should contact the seller immediately.
• Before putting the device into operation for the rst time, place it in an upright position for at least 3 hours to stabi-
lize the compressor uids.
• Place the dehumidier upright on a stable, at and dry surface. If the appliance falls down, water can leak, caus-
ing damage to objects, electric shock or re.
• Supply power should be in correspondence with the value on the nameplate, power outlet needs to be grounded.
• Do not use the device with power strip, as they may overheat and cause a re. However, if necessary, use a good
quality extension cord and rst make sure that it is in excellent condition.
• Ensure the tank is correctly tted, if the tank is full or not in place, the tank full light comes on and the dehumidi-
er will stop working.
• Turn on the power and run the machine as per instructions below.
• When moving the machine, make sure it is upright.
• Never place the dehumidier near a radiator.
PLACEMENT
1. Front Casing
2. Control Panel
3. Air Outlet
4. Handle
5. Prelter
6. Continuous Drainage Outlet
7. Water Tank
8. Power Cord

1. Power Button
2. Manual Button
3. Timer Button
4. Sleep Button
5. Sleep Mode Indicator
6. Timer Setting Indicator
7. Humidity Display
8. Defrosting Indicator
9. Tank Full Indicator
CONTROL PANEL DESCRIPTION
129
8
34 6
5
7
8
-- Touch panel

OPERATING INSTRUCTIONS
Note:
• Supply power should be in correspondence with the value on the nameplate, power outlet needs to be grounded.
• Do not use the device with power strip, as they may overheat and cause a re. However, if necessary, use a good qual-
ity extension cord and rst make sure that it is in excellent condition.
• Ensure the tank is correctly tted, if the tank is full or not in place, the “Tank Full” indicator comes on and the dehumidi-
er will stop working.
• If the dehumidier is turned off and then turned back on again immediately, it will take approximately 3 minutes to reach
full power (compressor back to work).
• If the dehumidier switched off by a power cut, it will automatically switch back on once the power is restored.
• The dehumidier works best at normal room temperature, its efciency is reduced if the ambient temperature falls to
below 15°C.
Switching On/Off the Unit
• Connect the mains lead to socket.
• Press power button once to turn on the unit. By default, it runs on Manual Dehumidifying Mode.
• Press Power button once again to turn off the unit.
Humidity Setting Control
Press Manual button once to enter Manual Dehumidifying Mode or to select desired level of humidity from CO-30%-35%-
40%-45%-50%-55%-60%-65%-70%-75%-80%-CO. When CO [Continuous Operation] is set the unit will operate continu-
ously, regardless the relative humidity.
KULLSAVE
The Energy Savings Smart Operation
When the target relative humidity is reached, the unit will operate only the fan in low speed for
about 3 minutes, then will stop for 17 minutes. The fan will then run for 2 minutes to check the
relative humidity.
If the relative humidity has risen above the target humidity (HS)+3%, the unit will start operating
again. If the relative humidity remains below the target level, the unit will fall back to sleep for
an additional fan works in low speed for about 3 minutes, then stop for 17 minutes.
Timer Setting
At ON Mode, press timer button consecutively to select your preferred timer duration for automatic shutoff setting.
Its corresponding Timer indicator will be displayed on screen.
9

10
OPERATING INSTRUCTIONS
Sleeping Mode
At Manual Mode, press Sleeping Button once to enter Sleeping Mode. Its corresponding Sleeping indicator will be dis-
played on screen, 5 seconds later, other indicators will be off. At Sleeping Mode, the unit operates in low fan speed.
Note: At Sleeping Mode, press any button to wake up the unit rst, then to operate as usual.
Child Lock Function
To prevent the mishandling by young children, the unit is equipped with a Child Lock function. Press “Sleep Button“ for 2
seconds to activate or deactivate the Child Lock function.
Note: After activating the Child Lock function, the LC will be displayed on screen 3 seconds later and the screen will show
the current room humidity.
Automatic Shutoff
When the water tank is full during normal use, the unit shuts off automatically. The “Tank Full” indicator comes on and
buzzer alarm goes off for 5 times.
Note: If water tank is removed or not placed properly, above phenomenon will appear also.
Automatic Defrost Feature
The unit is equipped with an automatic defrost feature. When room temperature drops to 4°C and below, compressor shuts
off and unit runs on high fan speed setting until the frost has disappeared, no other setting can be made for this feature.
The “Defrosting Indicator” will light on screen.
Memory Feature
When power failure and after recovering, the unit will work with the mode prior to the shutdown. Means the timer setting,
humidity setting and working mode setting will be kept.
Continuous Drainage Option
Continuous drainage option allows easy removal of collected water instead of manually emptying from the water tank when
the environment is very high humidity:
1. Press Manual button to select the desired humidity value.
2. Remove the rubber plug covering the drain hose connection.
3. Connect a suitable drain hose (14mm inner diameter) through the drainage outlet. Ensure that the hose is secure and
tight to prevent leakage.
4. Always make sure that the drainage hose is not blocked or obstructed to maintain a smooth slow.
Drainage
Outlet Cover Drainage Pipe

11
CLEANING AND MAINTENANCE
Cleaning the dehumidier
To ensure the effectiveness of the dehumidier, it is recommended to clean the
unit at least every two weeks.
1. Turn the dehumidier off and pull out the plug before cleaning.
2. Use a soft cloth to gently wipe the outer case to remove dust.
3. Vacuum clean the air inlet and outlet grilles of the dehumidier.
4. Remove the water tank and wash it by hand using a mild detergent.
Rinse it with Clean Water.
Note: Do not spray water directly onto the unit.
Cleaning the Air Filter
1. Remove the pre-lter from the back.
2. Vacuum or wash the prelter carefully in warm water, use a mild detergent if
necessary.
3. Rinse the pre-lter in clean water and let it dry before reinserting it.
4. Fit the lter frame back onto the unit
Note: DO NOT use the dehumidier without the Air Filter in place.
Never wash the pre-lter in the dishwasher.
STORAGE
If the dehumidier will not be used for a long period of time, take the following steps:
1. Remove the plug from the socket and empty the tank, make the tank and the dehumidier dry completely, this
may take a couple of days.
2. Clean the air lter as described above.
3. Ensure that the dehumidier is in perfect condition for a safe use of the unit after a long period of storage.
4. Pack the device with the suitable packaging.
5. Store the dehumidier in a dust-free and out of direct sunlight location, preferably covered with a sheet of plastic.
Pre-filter

12
TROUBLE SHOOTING
Check the following before contacting technical support.
PROBLEM POSSIBLE CAUSE SOLUTION
The device does not work
The power is not connected Insert the plug into the wall outlet
The water tank is full Empty the tank
The tank has not been placed correctly Place the tank correctly
Water removal capacity is too low
Runtime is too short Be patient and wait
Ambient temperature or humidity is too low It is normal that the device does not
dehumidify in these conditions
The device works, but reduces the
relative humidity insufciently
The house is too big We recommend using a dehumidier with
a greater capacity
There is too much ventilation Reduce ventilation (e.g. close windows
and shut doors)
The air lter is clogged Clean the lter
The ambient humidity level is lower than
the target humidity level set
Set the target humidity lower than
ambient humidity
Dehumidier is blowing out warm air
The dried air is passed over heating coils
before it is blown into the room as part of
the dehumidifying process
This is normal
Unusual noises
The dehumidier is tilted or standing on an
uneven surface
Place the dehumidier upright on a
stable, at and dry surface
The air lter is clogged Clean the lter
Loose or foreign particles inside the unit Contact technical support
Sound of owing refrigerant This is normal
Water on oor
There is residual water in tank, and the
device is lurched too much by moving Be careful when moving the tank
Water tank may be damaged Contact technical support
Float for water auto-sensor is not in place Contact technical support
Internal drainage passage is blocked or
obstructed Contact technical support

13
The above technical data are for reference only. We reserve the right to modify them without notice.
TECHNICAL SPECIFICATIONS
Model alpha Q13L
Voltage / Frequency 220-240V~ 50Hz
Moisture Removal Capacity
13L/day (30°C 80%rh)
7L/day (27°C 60%rh)
Rated Power 145 watts / 0.95A (27°C 60%)
Air Flow H: 95 | L: 70 m³/h
Fan speeds 2
Water Tank Capacity 2.3L
Noise level H: 39 | L: 35 dB(A)
Operating Temperature 5°C−35°C
Timer 1−24h
Refrigerant / Charge R290 / 0.045kg
Weight 11 kg
Dimension (W×D×H) 308 x 209 x 445 mm
Display Error Codes
Please contact local distributor if any of the error codes below appears.
Display Code Error Solution
E1 Temperature sensor error Contact technical support
E2 Humidity sensor error Contact technical support

14
CONDITIONS OF WARRANTY
There is a two-year warranty on your dehumidier from the date of purchase.
The following applies:
1. Any repairs or replacement of components during the warranty period will be not result in an extension of the warranty
period.
2. The warranty will expire if any alterations have been made, not genuine components have been tted or if the dehumidi-
er has been repaired by a third party.
3. Components subject to normal wear and tear, such as the air lters, are not covered by the warranty.
4. The warranty is only valid on presentation of the original, unaltered, and date-stamped purchase receipt.
5. The warranty is not valid for:
• Damages is caused by actions that deviate from those as described in the user’s manual or by neglect.
• Damages caused from intervention of unauthorized personnel.
• Bad or insufcient maintenance.
• Factors for which the production factory does not have any responsibility (variations in power supply beyond the speci-
cations of the unit, etc.), connection in non-grounded power supply socket etc.
• All claims for compensation, including consequential damage, will not be entertained.
6. In case of any unit’s damage you should refer to the company that sold the unit.
7. The transportation costs from and back to technical department and the probable insurance of the units are under the
customer’s choice and responsibility.

www.kullhaus.com
SANI HELLAS
IMPORT EXPORT TECHNICAL SA
5-7 Kosti Palama Str.
143 43 Athens, Greece
Tel. [phone]
Fax [phone]
e-mail: [email protected]
www.sanihellas.gr
SANI HELLAS IMPORT EXPORT TECHNICAL SA - distributor of Kullhaus products in Greece.
