Version 1.5 / 01/2016 - Copyright 2014 KURTH ELECTRONIC GmbH
All rights reserved, including translations.
All reprints and electronic copies, including excerpts, require prior written
approval of Kurth Electronic GmbH.
All of the brand names and trademarks cited herein are the property of
their registered owners.
®
Operating Manual
KE3600
xDSL MULTITEST

Keyboard / Display / Ports
Operating Manual KE3600 xDSL MULTITEST
2
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
DSL
CRC
DSL
LOSS
DSL
L1
BATT
CHRG
F1 F2 F4
F3
0
*#
123
ABC DEF
45 6
GHI JKL MNO
78 9
PQRS TUV WXYZ
ESC SEL
ON
OFF
xDSL MULTITEST
KE3600
Sunlight readable color TFT
Battery charge
Connection USB 1, SD-Card
and optionale KECT module
Menu UP - DOWN /
LEFT - RIGHT buttons
Select (enter) button
ESC (back) button
ON/OFF button
Menu-sensetive function keys
F1 - F4
Alphanumeric keypad
Information LEDs
xDSL Test Ports,
Headset connection,
Power supply connection
Ethernet 10/100 Management Port,
Ethernet 10/100/1000 Test Port
and optional ISDN Interface
®
Interface
Help
Date / Time
Broadband
a/b: 0,0 V
1
Terminal Mode
Router Mode
Modem Mode
5
6
7
<xDSL>
<Enabled>
xDSL Mode
2<Annex A/M>
Speaker (telephony)
Speaker monitoring (Telephone call)
Microphone (telephony)
Fastener for shoulder strap
DSL
L2
MAC Address
Vectoring Mode
3
4
Please note during application:
We recommend not to connect the power supply while the measurement is running!
This can lead to a distortion of the measurement results when testing critical lines.

Introduction
The KE3600 Multi Tester is a hand-held device suitable for field testing of xDSL, Ethernet, ISDN, Copper, Triple
Play, SHDSL, Bonding and GPON. You have purchased a simple and intuitive solution for line pre-
qualification, commissioning and troubleshooting. In order to use the KE3600 often and successfully as
possible, please read this manual carefully.
The device was manufactured according to the following guidelines:
73/23/EEC
DIN VDE 0800
DIN EN 61010
DIN EN 41003
DIN IEC 60068-2-1, 60068-2-2, 60068-2-3, 60068-2-14, 60068-2-27, 60068-2-6-fc, 60068-2-78,
60068-2-29
Should you have additional questions regarding operation and usage of this device, please contact:
Kurth Electronic GmbH
Access Network Testing
Mühleweg 11
72800 Eningen u.A.
GERMANY
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.kurthelectronic.de
Kurth Electronic is ISO9001 certified and WEEE registered.
Down
IPTV
BIN
Uhrzeit / Datum
Showtime
Showtime
4
Safety Instructions
The KE3600 may only be operated with the accessories originally provided. Using the device with
accessories that are not original or for applications for which it was not intended can lead to incorrect
measurements and may damage the device. The relevant safety regulations in VDE 0100, 0800 and
0805 must be observed.
n The use of circuit points other than intended can damage the device. The device should not
be used with high-voltage current. Kurth Electronic assumes no liability for damage resulting from
improper use.
n Never apply external voltage to the device.
n Open the device only to change the batteries. Compare instructions on page 20. There are no other
parts in the device that need to be serviced or calibrated.
n The measuring device is protected from splashing water and dust by the front film covering.
However, it is not water-tight.
n Never pull unnecessarily on the cables connected to the device.
Operating Manual KE3600 xDSL MULTITEST
3
KURTH ELECTRONIC www.kurthelectronic.de [email protected]

Contents
Keyboard / Display / Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Informations LED's . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Switching On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Basic Information on Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Terminal Mode <xDSL> . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Saving measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
QR Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Router Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Modem Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Terminal Mode <Ethernet> / <SFP> . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Data Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
KE-Manager Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing the LiPo Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ISDN- and Analog-Interface (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
ISDN Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
BERT Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Analog Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Copper Testing with KECT3 (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Connectors and Test Leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Copper Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Digital Multimeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
xDSL Line Qualification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
KE900 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
TDR - Time Domain Reflectometer (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
VoIP Tests (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
IPTV Tests (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SHDSL Tests (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
General Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Operating Manual KE3600 xDSL MULTITEST
4
KURTH ELECTRONIC www.kurthelectronic.de [email protected]

Application
The KE3600 is a fast, easy to use and affordable multitester for the installation and troubleshooting of DSL
services in hybrid ADSL1/2/2 + / VDSL2 and combined networks. With its numerous interfaces, it supports the
entire range of broadband network technology such as VDSL2-Vectoring, xDSL-Bonding, SHDSL, Gigabit
Ethernet and GPON.
Operation
The KE3600 is a powerful troubleshooting tool for quickly finding faults in the network, outside wiring, customer
devices or inside wiring. Even in hybrid networks where FTTH is installed, measurements can be made at any
LAN connection using the Ethernet ports of the KE3600. For this reason, the KE3600 is the ideal solution for all
broadband technologies.
Use
With its small size, robust design and intuitive operation, it is the perfect tester for installers and service
technicians. The user can perform his tasks quickly and efficiently with automatic detection of the xDSL service
and definable test procedures. The large display increases operating convenience and, when storing results,
the technician has numerous options for exporting the tests and for compiling reports.
Operating Manual KE3600 xDSL MULTITEST
5
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
PON/PTB
100+ Mb/s
ADSL2+
~10-20 Mb/s
VDSL2
~40 Mb/s
CENTRAL
OFFICE
FTTB/
FTTC
VDSL2
VECTORING
~100 Mb/s
VDSL2
VECTORING
~100 Mb/s
VDSL2
BONDING
~80 Mb/s
VDSL2
~50 Mb/s
Fiber
Copper
xPON
DSL Bonding
VDSL2
ADSL2+
Test xDSL
Test Ethernet
STB
STB
STB
STB
TV
TV
TV
TV
VoIP
VoIP
VoIP
VoIP
PC
PC
PC
PC
Applications
DSL
CRC
DSL
LOSS
DSL
L1
BATT
CHRG
F1 F2 F4
F3
0
*#
123
ABC DEF
45 6
GHI JKL MNO
78 9
PQRS TUV WXYZ
ESC SEL
ON
OFF
xDSL MULTITEST
KE3600
®
Interface
Help
Date / Time
Broadband
a/b: 0,0 V
1
Terminal Mode
Router Mode
Modem Mode
3
4
5
<xDSL>
xDSL Mode
2<Annex A/M>
DSL
L2

Setting up the KE3600
Battery charge display
The KE3600 comes with a high-performance Lithium Polymer (LiPo) rechargeable battery. Despite its light
weight, this allows the device to operate for up to 4 hours in measuring mode under a full load. The charger can
simultaneously operate the KE3600 and charge the battery. The battery is safely charged by a special charge
controller taking into account the time, voltage and current to ensure maximum service life.
Note: Please fully charge battery before first use!
Changes the charging LED from orange to green the charging is completed. To check the charge
indicator after the initial charging turn off the device and then turn it on again with the AC adapter
connected for about 1 minute. During this time, the battery indicator will be calibrated and now
displays the correct value.
Keypad
When the KE3600 was developed, emphasis was placed on fast and easy operation.
F1 – F4
Menu function buttons. F1: Help function if provided.
ESC
Similar to a computer, the ESC button means "undo the last step," or Back.
SEL
SELECT button. Use this button for selecting like an Enter key.
ON / OFF
Button for turning the device On and Off.
Arrow buttons ▲▼◄►
The arrow buttons are for menu scrolling UP ▲ / DOWN ▼ and LEFT ◄ / RIGHT ►.
Keypad
Alphanumeric keypad with 1-0, A-Z, special characters.
Text input
F1: abc " 123 Switch between letters and numbers input.
Special characters can be found under the keys * and #.
*: .-/@:_+,[];=?
#: #$%&‛(){}~
F2: Delete the entire entry line with Clr
F3: With Del delete individual digits
F4: With ! deleting individual digits from right to left
Operating Manual KE3600 xDSL MULTITEST
6
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values
Del
Resync-Counter
0
Actl
104973
50000
Kbps
Max
134832
56034
Kbps
Tx-Pwr
10.8
7.1
dBm
Ø SNR-Margin
14.2
9.5
dB
FEC
0
0
CRC
2
8
abc " 123 Clr
Filename
!
Documentation and Software
Up-to-date operating instructions and software updates can be found in our KE3500 download area
after logging on in the CUSTOMER LOGIN.
You will find it under the Downloadarea menu item. After entering the serial number, you will find all
current documents available for download in the following window.

Information LEDs
The KE 3600 has five LEDs that display a range of important but easy-to-use information about the current
status of the device. From left to right the LEDs mean:
DSL CRC – orange
This LED lights when a CRC (checksum error) near end or far end is recognized. These errors (fewer than 10)
can arise after a connection has been established. In any case, check if the counter is still counting to
determine if other causes (faults) exist. You can access the error counter menu in the respective test menu.
DSL LOSS – orange
After a connection is established in non-resync mode, a DSL loss event is displayed here and also signaled
with an intermittent tone for 10 seconds. The tone can be stopped by pressing SEL once.
DSL L1 – green
When the KE3600 is activated in xDSL Mode, this LED begins to flash at 2 Hz to signal Ready Status. It is
waiting for a carrier. As soon as this is detected LED flashes at 4 Hz until the connection is established, and then
it is lit steadily as long as the connection exists.
DSL L2 – green
For DSL connection on Line 2 (bonding).
BATT CHRG – green and red
This display is active even when the KE3600 is turned off. The green LED indicates that the power supply or
charger is inserted and is supplying power. The red LED signals that the battery is in charging mode. This
produces a green/red or orange display during charging. Once controlled charging is complete, the red LED
turns off and only the green LED lights to signal that the power supply or automatic charger is still active and
that charging is complete.The power supply enables the KE3600 to be charged and operated
SIMULTANEOUSLY. The car charger only charges the battery.
Switching On
The KE3600 works with an operating system that has to be
booted. The boot menu with various device parameters
such as the hardware and software versions appears at the
end of the booting process. You can bring up the main menu
immediately by pressing any button.
Operating Manual KE3600 xDSL MULTITEST
7
KURTH ELECTRONIC Fernmeldetechnik www.kurthelectronic.de [email protected]
Serial: xxxxxxxxxxxxxxxx
Firmware: 1.1-0
Modem: 0000000 / 000 / 00 / 000
Options: ADSL, VDSL, Annex J,
Annex M ......
HW-ID: B00000000B0000000

Operating Manual KE3600 xDSL MULTITEST
8
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
USB 2
100 Mb1000 Mb
USB 3
xDSL Test Port
POTS
ISDN-U
ISDN-S
Ethernet Ports (upper side)
ISDN (BRI) POTS / optional (upper side)
KECT Copper Testing / optional (side ports)
xDSL Ports (bottom)
SHDSL Interface / optional (upper side)
See chapter SHDSL, page 40.
USB 2: Extend the functionality
(not yet in use)
USB 1: Extend the functionality
(not yet in use)
USB 1: Extend the functionality
(not yet in use)
SD-Card e.g. for longterm measurements.
Insert/remove SD-Card when the device is
switched off!
Connections for Copper Tests KECT3 Line 1
and Line 2 for 2 x shielded test leads with
device side three prong plug TF
SFP
Yellow LED: Link / Data
LED lights continuously: Connection has been established
LED flashes: Transmit / receive activity
Green LED: Transmission speed
RJ11 / RJ45 - xDSL Test Ports
- Analogue Phone Port (POTS)
- U Port
k0
- S Port
0
Headset Connection
Power Supply Connection
1 GBit/s-Port for Ethernet Tests
10/100/1000 MBit/s
Device Management Port
10/100 MBit/s
Slot for SFP modules Copper / Fiber
for GPON- and Ethernet-Measurements
RJ11
RJ45
Connections
LINE 1 LINE 2
A AB BGND GND
GND GNDTIP TIPRING RING
USB 1 SD

Main Menu
The battery display is at the top left. After calibration, it
shows the actual battery charge using 16 levels.
In the center, the line voltage is shown in xTU-R mode in the
main menu with a precision of approximately +/- 5%. This
tells you if there is any line voltage and its level so that you
can distinguish between an analog and ISDN connection.
This also reveals if the measurement is before or after a
splitter.
The date and time are shown to the right.
Four selection positions are available in the main menu:
1. Broadband
2. Telephony
3. Copper Test
4. Setup
General Operation
In all the menus and submenus that have selection functions, the selectable parameters are either identified
with left and right arrows (◄ and ►) or without arrows. When the entry is marked with the left and right arrows,
you can switch between parameters by pressing the ◄ / ► buttons. When the entry is without the arrows,
press SEL (SELECT) to move to a submenu where you can change settings. Press ESC to exit and save the
selection in the menu. In the main menus, the previously selected menu item is saved. The next time you turn
on the device, the scrollbar is automatically set to the previously selected item.
Markings
disabled
activated, all inputs in order > test possible
Red bar:
Input / verification
required!
< >
< >
< >
< >
?
!
activated, complement inputs > test possible
activated, correct entries > test not possible
Operating Manual KE3600 xDSL MULTITEST
9
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Broadband
Help
Date / Time
Main Menu
a/b: 0,0 V
1
Telephony
Copper Test
Setup
2
3
4
Display Line voltage
Help
Date / Time
VoIP Parameters
a/b: 0,0 V
Caller ID
3
<Aus>
Authentication
1
Password
2
p
q
UDP/RTP Port
UDP/RTP Port Range
6
7<0>
User Agent
5
<5.060>
Registrar
Proxy
9
0<Off>
Stun Server
8
<Off>
<Off>
Domain
4

Setup (Basic Device Settings)
1. Automatic Off
Automatic shutoff after the last button is pushed. Possible settings: Always On / 3 minutes / 5 minutes / 15
minutes / 30 minutes / 60 minutes. When a test is running the KE3600 does not shut off even after the time
has elapsed.
2. Backlight
Possible settings: Always On / Always Off / 30 sec /3 min. Lets you specify the duration before the screen
is dimmed in order to preserve the battery. In the selection of Always Off / 30 sec /3 min additionally
appears 3. Brightness Dimmed as another menu item. Possible values are from Level 1 to 7, where 1 is
dark and 7 is light.
3. Language
Menu languages: German, English, French, Italian, Dutch. Others on request, German is the default.
4. Date & Time
Date and time setting: 12 or 24 hour format
5. Software Updates
Verifies that an update is available and allows ist installation. See the detailed firmware update instructions
with the KE-Manager-Firmware-Update.pdf
6. Signals & Display
You can find more settings:
1. Keybord Beep On or Off
2. LOSS Beep On or Off
3. Low Battery Beep On or Off
4. Brightness Level 1 to 7 (1 dark, 7 light)
7. Show Min/Max Value
Shows or hides the display of the Min / Max values inside the DMM measurement results in Copper Test.
8. Reset Management IF
Reset and restart the Management Interface.
9. Systeminformation
Here you will find information about the built-in modules, such as hardware version and software version.
0. License information
Display of open source software and its license terms used in the device.
Operating Manual KE3600 xDSL MULTITEST
10
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Module
More
Date / Time
Systeminformation
Versions
a/b: 0,0 V
HW-Version SW-Version
UPD 001.005.016
APP 000.012.032
BCM
CU
TDR
UTI
ISDN
LPC
001.406.030
001.007.000
001.005.001
001.008.000
004.018.001
001.010.000
KE000150
18D6CF118414
002.000.241
003.000.000
Licences
Module/Feature
More
Datum / Zeit
Systeminformation
Versions
a/b: 0,0 V
Lizenz granted
ADSL Yes
Annex J
Annex M
ContSave
CopQual
Licences
DslExpert
Ethernet
Hardware
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Interface
Interface
More
Date / Time
Systeminformation
Versions
a/b: 0,0 V
IP-Address
Management xxx.xxx.xxx.xxx
Licences
Interface Interface
Systeminformation
1
2

1. Interface
Setting
options:<xDSL>/<Ethernet>/ . <SFP>/<SHDSL>
The menu view changes depending on the selected
interface.
2. xDSL Mode
Setting options: <Annex A/M>/ <Annex B/J>. In
Annex J, a second synchronization approach is
needed because the filter from Annex B to Annex J has
to be switched over.
3. Terminal (xDSL) with automatic
detection of DSL Services
Synchronization with 1 / or press START to run the
test ...
Line Values Display
Actl: Actual Up/Downstream
Max: Maximum Up/Downstream
Tx Pwr: Transmission power / dBm
Ø SNR-Margin: Difference between
line SNR and required SNR in dB
FEC: Forward Error Correction
CRC: Checksum error
HEC: ATM-Header Error Check
Bitswap: Redirected data of a disturbed
communication channel to other channels
Ø Line Atten.: Attenuation in dB
INP: Impulse Noise Protection
Interleave: Delay in ms or 0 for Fast-Path
Line Loss: Loss of the synchronized connection
LOF: ATM receiving station has lost the frame
description
LOM: Loss of Margin
SES: Severely Errored Second:
a second with bit error rate
UAS: Number of seconds during which no transfer
was possible
ES: Errored Second: one second of measurement time
during which one or more bit errors are present
Function keys and options
F1 More (select with SEL)
Help (reserved for help functions)n
Resert errors (shown errors will n
be set to zero)
Save measurement or directly n
during the measurement by pressing
the SEL key. It opens up a Window
where the file name can be entered
as a name / number. After confirming with SEL
the measurement is stored on the internal memory,
and can be edited using the supplied
KE Manager software.
Operating Manual KE3600 xDSL MULTITEST
11
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Interface
Help
Date / Time
Broadband
a/b: 0,0 V
1
MAC Address
Vectoring Mode
Terminal Mode
3
4
5
<xDSL>
xDSL Mode
2<Annex A/M>
<friendly>
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values
Duration of the synchronized connection
Tests
Resync-Counter
0
Actl
104973
50000
Kbps
Max
134832
56034
Kbps
Tx Pwr
10.8
7.1
dBm
Ø SNR-Margin
14.2
9.5
dB
FEC
0
0
CRC
2
8
HEC
0
0
More Views
Help
Reset errors
Save measurement
Line Values
PPP Status
Bands
Vectoring
SNR
BAT
Hlog
QLN
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values - Bands
Tests
SNR Margin 0
N/A
dB
SNR Margin 1
14.3
10.8
dB
SNR Margin 2
14.1
9.1
dB
SNR Margin 3
14.2
N/A
dB
SNR Margin 4
N/A
dB
Line Attenuation 0
0
dB
Line Attenuation 1
0.0
0.1
dB
Line Attenuation 2
0.0
1.0
dB
More Views
Ping
Traceroute
Http Download
FTP Download
FTP Upload
VoIP Log
VoIP Statistics
VoIP Dial
IPTV Log
IPTV Statistics
IPTV Preview
Router Mode
Modem Mode
4
5

Operating Manual KE3600 xDSL MULTITEST
F2 Views (Line Values, Bands, Vectoring, ...)
Line Values (see page 11)n
PPP Status n
Bands (Displays individual bands for SNR Margin, Line n
Attenuation, Signal attenuation and TX Power,
see page 11)
Vectoring (Vectoring status, VCE MAC address, n
possible errors)
SNR/BAT/Hlog/QLN: Graphs for Bits per tone, SNR per n
tone, Hlog and QLN can be called up here (Downstream
blue, Upstream green)
This information is helpful to detect sources of inter-
ference that affect the signal to noise ratio.
By pressing the ◄►keys, the yellow pointer moves and
displays below the graph the numeric value
F3 Test
Data Tests, VoIP- and IPTV-Testsn
Saving Measurements
You can save the data during the measurement by pressing
the SEL button. A window opens where you can enter the
memory as a name or number. After confirmation with SEL,
the measurement is stored in the internal memory.
After entering and confirming by selecting the character, this
measurement is saved with the name or number you entered.
Very useful is a specification, for example with Customers
name or telephone number. The limitation is given only by the
internal memory (2 GB). However, you should ensure that the
stored data is regularly downloaded and deleted. The deletion
is easily possible with the supplied KE-Manager.
QR code generation
When you press the "7" key a QR code is calculated from a
portion of the displayed data. This is then displayed on the
screen and can be read with appropriate readers.
Profiles
All parameters can also be created in the profiles menu from
the KE-Manager. The profiles are then called to load and save
profiles using the menu item. The loaded data can always be
revised as described previously or changed. The change is
only until they leave the test is valid if it is not saved before.
12
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Line
G993.2 VDSL2 (Vendor)
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J
VTU-R (Annex B/J
1
Up /Far
Dn/Near
Data VoIP IPTV
Uhrzeit / Datum
Date / Time
Showtime
Showtime
a/b: 0,0 V
a/b: 0,0 V
234
0:32:22
0:32:22
p
q
Line Values - Vectoring
Bits per tone
Tests
Tests
More
More
Views
Views
Vectoring state: 1
VCE MAC Address: 0:19:8f:16:27:ce
Total error samples Ethernet pkts sent: 0
Total error samples Ethernet pkts sent discarded: 0
Total error samples statuses sent: 0
Total error samples statuses sent discarded: 0
Tone: 2047, 8,8277 MHz
27
54
0
01.365 2.730 4.096
43 Bits
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values
Del
Resync-Counter
0
Actl
104973
50000
Kbps
Max
134832
56034
Kbps
Tx Pwr
10.8
7.1
dBm
Ø SNR-Margin
14.2
9.5
dB
FEC
0
0
CRC
2
8
HEC
0
0
abc " 123 Clr
Filename
!
xDSL Mode
Help
Date / Time
xDSL Interface
a/b: 0,0 V
1
Vectoring Mode
Auto Re-Sync
Seamless Rate Adaption
3
4
5
<Annex A/M>
MAC Address
2
<Friendly>
<Off>
<Off>
<Off>
<AAL5>
G.INP
ATM Type
4
5

Router Mode
Connection of the KE3600 to the xDSL port and to the PC.
Replaces the modem and the router. See the Menu
Structure for possible settings.
In Ping mode, the KE3600, after the Ping test was
successfully performed used as a router. This means that
via the Ethernet interface, Internet access can be
performed.
Modem Mode (Bridge Modus)
Connection of the KE3600 to the xDSL port and to the PC.
Replaces the modem. See the Menu Structure for possible
settings. This mode is intended as a replacement modem
mode. The Ethernet interface is connected by smooth here
(bridge or through mode), and is now the DSL port on the
terminal. Now the KE3600 can be employed as a full
modem, both ADSL and VDSL in mode can be employed.
This makes it possible to draw conclusion errors. Save the
measurement with SEL Exit with ESC. The Ethernet
interface is transparently switched to have the modem
functions.
Terminal Mode <Ethernet>, <SFP>
Connection to the Ethernet interface of a modem / router or
a hub / switch. See the Menu Structure for possible settings
for ping, trace route, HTTP download, FTP download and
FTP upload
Profile
All parameters can also be created in the profiles of the KE
Manager. The profiles are then invoked to load and save
profiles using the menu item. The loaded data can always
be revised or amended. The change is only until they leave
the test is valid if not previously stored.
Operating Manual KE3600 xDSL MULTITEST
START...
START...
Help
Date / Time
Date / Time
Modem Mode
Router Mode
a/b: 0,0 V
a/b: 0,0 V
1
1
Load and Save Profiles
Load and Save Profiles
Auto Re-Sync
xDSL Mode
Seamless Rate Adaption
ATM Type
VPI
VPI
VCI
VCI
PTM Priority
PTM Priority
VLAN Tagging
2
2
3
4
5
7
8
3
9
4
0
5
6
<Off>
<Annex B/J>
<Off>
<AAL5>
<0>
<0>
<32>
<32>
<Normal>
<Normal>
<Off>
Help
13
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Encapsulation
Authentication
Secondary Interface
7
8
9
<0>
<Off>
G.INP
6<Off>
VLAN Filter/Tagging <Off>

Operating Manual KE3600 xDSL MULTITEST
14
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Data Test (Description soon available )

Operating Manual KE3600 xDSL MULTITEST
15
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Data Test (Description soon available )

Operating Manual KE3600 xDSL MULTITEST
Menu Structure
16
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
1 bis 7
Some of the interfaces and functions are shown in the menu structure but have no function
because they are not contained in the service package chosen.
1 Broadband
2 Telephony*
3 Copper Test*
4 Setup
1 Interface
2 xDSL Mode
3 Terminal Mode
4 Router Mode
5 Modem Mode
<xDSL>
Select Terminal:
Main Menu
Always On / 3 minutes ... 60 minutes
Always Off / Always On / 3 minutes
German / English / ...
Input
Execution
1 Automatic Off
2 Backlight
Brightness Dimmed
3 Language
4 Date & Time
5 Software Updates
6 Signals & Display
7 Reset Management IF
8 System Information
Off / On
Setup
Off / On
Off / On
1 to 7
Update (only active when update available)
Display device info
see page 10
1 to 7
<Annex B/J> <Annex A/M>
1 Keyboard Beep
2 LOSS Beep
3 Low Battery Beep
4 Brightness
1 Interface
2 Ethernet Interface
<Ethernet>, <SFP>
3 Terminal Mode
1 Autonegotiation
2 Speed
3 Duplex Mode
Off
Off / On
10MBit/s/100MBit/s/1000MBit/s
10MBit/s
100MBit/s Off / On
* optional

Operating Manual KE3600 xDSL MULTITEST
17
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
1 START...
2 Load and Save Profiles
3 Data
4 VoIP
5 IPTV
6 VOD
1 START...
2 Load and Save Profiles
3 Auto Re-Sync
4 xDSL Mode
5 Seamless Rate Adaption
6 ATM Type
7 VPI
8 VCI
9 PTM Priority
0 VLAN Filter/Tagging
1 Load Profile
2 Save Profile
3 Delete Profile
Annex A/M / Annex B/J
Off / On
Off / On
AAL5 / AALOPKT / AALOCEIL
0 ... 255
32 ... 65.535
Normal / High / Both
Off / On
Input
Selection
Selection
Terminal Mode
Modem Mode
0 ... 4.095
On
VLAN ID
1 Service Configuration
Yes / No
1 START...
2 Load and Save Profiles
3 Auto Re-Sync
4 xDSL Mode
5 Seamless Rate Adaption
6 ATM Type
7 VPI
8 VCI
9 PTM Priority
0 VLAN Tagging
Encapsulation
Authentication
Annex A/M / Annex B/J
Off / On
Off / On
AAL5 / AALOPKT / AALOCEIL
0 ... 255
32 ... 65.535
Normal / High / Both
Off / On
PPPoA / PPPoE / IPoA / IPoE
Off / On
Router Mode
0 ... 4.095
On
VLAN ID
Username...
Password ...
On Input
Input
Secondary Interface
Yes / No
PTM / ATM
0 ... 255
32 ... 65.535
On
0 ... 4.095
IPoE
On
1 Eigenes Interface
2 ATM/PTM
3 VPI
4 VCI
5 VLAN Tagging
6 VLAN ID
7 Encapsulation
8 IP Configuration
via DHCP
< >
< >
< >
Secondary Interface
Yes
see on top
see on top
1 Service Configuration
2 Select Profile
1 Design Interface
Yes / No
VPI
VCI
VLAN Tagging
VLAN ID
Encapsulation
0 ... 255
Off / On
On
IPoA
0 ... 4.095
p
q
Das Erste HD
BR Sd HD
NDR HD
SWR BW HD
SWR RP HD
WDR HD
3sat HD
ARTE HD
KIKA HD
IPTV
2 IP Configurat. via DHCP
32 ... 65.535
Yes

Operating Manual KE3600 xDSL MULTITEST
18
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
SD-Card / Generated
1 Dial-in a. Modem Conf.
2 BERT
3 Ping
4 Traceroute
5 HTTP Download
6 FTP Download
7 FTP Upload
8 Update Download
1 Destination Address...*
2 Packet Length
3 Packet Number
1 Destination Address...*
2 Number of Hops
3 Timeout
1 URL
2 Username...
3 Password...
4 Several Downloads
5 Number of Downloads
1 Server... (Dest. Address...*)
2 Path
3 Filename
4 Data Source
Parallel / Serial
None / 0 ... 120 s
0 ... 20 / unlimited
1 ... 100
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
1 ... unlimited
0 ...10
0 ...10
1 URL
2 Username...
3 Password...
4 Simultaneous Downloads
1 URL
2 Username...
3 Password...
Input
Input
Input
1 IP Address
2 Hostname
Destination Address*
Off / On
Off / On
AAL5 / AALOPKT / AALOCEIL
PPPoA / PPPoE / IPoA / IPoE
0 ... 255
32 ... 65.535
0 ... 4.095
Off / On
1 Auto Re-Sync
3 Seamless Rate Adaption
4 ATM Type
5 Encapsulation
6 VPI
7 VCI
8 VLAN Tagging
9 Authentication
56 ... 2.048 Bytes
Off / On
On
On
Generated
Input
Input
VLAN ID
Stun Server
5 Filesize
Username...
Password...
On Input
Input
Data
< >
< >
< >
< >
< >
< >
see above
Input
5 Username...
6 Password...
7 Simultaneous Uploads
1 MB ... 1 GB
1 VoIP Parameters
2 Jitter Buffer
3 JitterThreshold
4 MOS Threshold
5 Session Expiration
6 Auto Accept Calls
7 Silence detection
8 Echo
1 Authentication
2 Password
3 Caller ID
4 Domain
5 User Agent
6 UDP/RTP Port
7 UDP/RTP Port Range
8 Stun Server
9 Registrar
VoIP
VoIP Parameter
Input
1...960 ms
1...960 ms
0,0...5,0
0...6400 s
1...65.535
Off / On
Off / On
Off / On
Off / On
Input
Input
Input
Input
Input
On
Registrar
0 Proxy
On
Proxi Address
1...65.535
Off / On
Input
Off / On
Input
< >

Operating Manual KE3600 xDSL MULTITEST
19
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
KE-Manager
The KE-Manager is a flexible tool to manage the
KE3600 and download the data of the measurements.
The KE-Manager is like the KE3600 very clearly
designed and largely intuitive and comes with the
included CD-ROM (or Kurth Electronic Homepage).
Setup of the PC
When installing the KE-Manager, the user must have
administrative rights and possibly turn off the virus
protection and the Windows Firewall.
Connection to the PC
The KE3600 can be connected directly via the device
management port to the Ethernet port of the PC.
Optimally, however, is the use of an available Ethernet
interface on the same network, so the PC can remain
in the network. It will automatically determine an IP
address (UPnP address) and the KE3600 appears
with the IP address and serial number in the select list
of the KE-Manager.
Opening the KE-Manager
Click on the KE-Manager icon on your PC desktop.
The KE-Manager starts and displays by various colors
on the connection status to the PC. If there are
problems getting a connection to the device you can
use the option Reset Management IF in the Setup
menu.
The green coloured background indicates the
established connection.You are now ready to control
KE3600 through the KE-Manager.
Configuration
Settings for several basic options and
licensing, transmitter list (IPTV profiles) and
the profil set can be executed here.
x-DSL
Gives close information to the active and
stored tests.

Operating Manual KE3600 xDSL MULTITEST
20
KURTH ELECTRONIC www.kurthelectronic.de [email protected]
Changing the LiPo Battery
The decreasing battery charge is clearly identifiable on the display provided that the initial adjustment was
done during first start-up.
The battery can be charged, the charge control display red LED goes off, but the battery display still will not
show full. As long as the displayed capacity does not go under 50%, the KE3500 can be safely used; it only
has to be charged more frequently. If the display goes below 50%, you need to change the battery. You can
either send in the device and the battery will be changed for a fee, or you can order a replacement battery.
Changing the battery
First remove the two lower compartment screws. Pull the bottom downward. The battery is in a plastic holder
in the bottom part and it is plugged into the board with a plug protected against polarity reversal. After the
housing is opened, this must be pulled out. Insert the new battery and securely fasten the holder. Plug the
connection cable into the board and screw on the housing. Make sure to only hand-tighten the housing
screws.
Loop Test
Here you can consider the stored loop
analysis tests from KECT3 Cooper
Interface
ISDN
Here you can consider the ISDN tests
