Kurth Electronic KE3500 User manual

Operating Manual
KE3500
xDSL MULTITEST
Version 1.0 / 05/2014 - Copyright 2014 KURTH ELECTRONIC GmbH
All rights reserved, including translations.
All reprints and electronic copies, including excerpts,
require prior written approval of Kurth Electronic GmbH.
All of the brand names and trademarks cited herein are the property of
their registered owners.
®

DSL
CRC
DSL
LOSS
DSL
L1
BATT
CHRG
F1 F2 F4
F3
0
*#
123
ABC DEF
45 6
GHI JKL MNO
78 9
PQRS TUV WXYZ
ESC SEL
ON
OFF
xDSL MULTITEST
KE3500
Keyboard / Display / Ports
Sunlight viewable color TFT
Battery charge
Connection USB 1, SD-Card
and optional KECT3 module
Menu UP - DOWN /
LEFT - Right buttons
Select (enter) button
ESC (back) button
ON/OFF button
Menu-sensitive function keys
F1 - F4
Alphanumeric keypad
Information LEDs
xDSL Test Ports,
Headset connection,
Power supply connection
Ethernet 10/100 Management,
Ethernet 10/100/1000 Test Port
and optional ISDN Interface
Operating Manual KE3500 xDSL MULTITEST
2
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
®
Interface
Help
Date / Time
Broadband
a/b: 0,0 V
1
Terminal Mode
Router Mode
Modem Mode
3
4
5
<xDSL>
xDSL Mode
2<Annex A/M>
Speaker (telephony)
Speaker monitoring (telephone call)
Microphone (telephony)
Fastener for shoulder strap
Please note during application:
We recommend not to connect the power supply while the measurement is running!
This can lead to a distortion of the measurement results when testing critical lines.

Introduction
The KE3500 Multi Tester is a hand-held device suitable for field testing of xDSL, Ethernet, ISDN, Copper and
Triple Play. You have purchased a simple and intuitive solution for line pre-qualification, commissioning and
troubleshooting. In order to use the KE3500 often and successfully as possible, please read this manual
carefully.
The device was manufactured according to the following guidelines:
73/23/EEC
DIN VDE 0800
DIN EN 61010
DIN EN 41003
DIN IEC 60068-2-1, 60068-2-2, 60068-2-3, 60068-2-14, 60068-2-27, 60068-2-6-fc, 60068-2-78,
60068-2-29
Should you have additional questions regarding operation and usage of this device, please contact:
Kurth Electronic GmbH
Access Network Testing
Mühleweg 11
72800 Eningen u.A.
GERMANY
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.kurthelectronic.de
Kurth Electronic is ISO9001 certified and WEEE registered.
Down
IPTV
BIN
Uhrzeit / Datum
Uhrzeit / Datum
Showtime
Showtime
4
Safety Instructions
The KE3500 may only be operated with the accessories originally provided. Using the device with
accessories that are not original or for applications for which it was not intended can lead to incorrect
measurements and may damage the device. The relevant safety regulations in VDE 0100, 0800 and
0805 must be observed.
n The use of circuit points other than intended can damage the device. The device should not
be used with high-voltage current. Kurth Electronic assumes no liability for damage resulting from
improper use.
n Never apply external voltage to the device.
n Open the device only to change the batteries. Compare instructions on page 20. There are no other
parts in the device that need to be serviced or calibrated.
n The measuring device is protected from splashing water and dust by the front film covering.
However, it is not water-tight.
n Never pull unnecessarily on the cables connected to the device.
Operating Manual KE3500 xDSL MULTITEST
3
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]

Contents
Keyboard / Display / Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Informations LED's . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Switching On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Basic Information on Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Terminal Mode <xDSL> . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Saving measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
QR Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Router Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Modem Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Terminal Mode <Ethernet> . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Data Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
KE-Manager Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing the LiPo Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ISDN- and Analog-Interface (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
ISDN Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
BERT Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Analog Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Copper Testing with KECT3 (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Connectors and Test Leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Copper Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Digital Multimeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
xDSL Line Qualification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
KE900 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
TDR - Time Domain Reflectometer (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
VoIP Tests (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
IPTV Tests (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
General Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Operating Manual KE3500 xDSL MULTITEST
4
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]

Application
The KE3500 xDSL MULTITEST offers tests in ADSL1/2/2 + and VDSL2 environments with full exams on VDSL-
Vectoring. It performs other functions such as ISDN and POTS test telephone, Triple Play testing for IPTV and
VoIP aptitude and the ability to do extensive copper testing to 30 MHz make it the universal working tool for
installers and service technicians. With its innovative operation concept several tests are performed
simultaneously and are still configurable without the loss of synchronization. Autodetection of the DSL service
and automated measurements on the copper pair allow fast and efficient work.
Fast multi-tasking operating
After a successful synchronization line values or graphs are shown on the large 3.5 " sunlight readable color
display. Waiting periods or complicated and time-consuming switching between menu items and views belong
to the past. The selection keys provide an easy exchange between the DSL line parameters, their impact on the
application layers, results of Up/Download tests, Ping and Trace Route plus VoIP and IPTV parameters. The
Multitester are likely to be used as a PC, with real multitasking functionality the user can scroll between the
windows. Without the loss of the current synchronization, other parameters or tests can be added and thus
enables fast, easy and comprehensive diagnosis.
KE-Manager Software included
The supplied KE-Manager Software is a flexible tool to manage the KE3500, to download the measurements
and for the creation of customized measurement reports. The surface is very clearly arranged and intuitive to
use. Profiles can be easily created and edited in order to transfer them to the KE3500.
Operating Manual KE3500 xDSL MULTITEST
5
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Applications
Fiber
Copper
xDSL Test
Ethernet Test
DSL
CRC
DSL
LOSS
DSL
L1
BATT
CHRG
F1 F2 F4
F3
0
*#
123
ABC DEF
45 6
GHI JKL MNO
78 9
PQRS TUV WXYZ
ESC SEL
ON
OFF
xDSL MULTITEST
KE3500
Hilfe
Up /Far
Dn/Near
Daten VoIP IPTV
Leitung
Mehr Ansichten Test
Uhrzeit / Datum
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
2
134
0:32:22
p
q
Line Values
Resync-Zähler
0
Actl
10497
Max
13483
Leistung
10.8
7.1
Ø SNR-Margin
14.2
9.5
dB
FEC
0
0
CRC
2
8
HEC
0
0
Daten
Daten 2
2
ADSL2+
~6-25 Mb/s
ADSL2+
~6-25 Mb/s
VDSL2
~50 Mb/s
CENTRAL
OFFICE
DSLAM
FTTC
DSLAM
VDSL2
VECTORING
~100 Mb/s
VDSL2
VECTORING
~100 Mb/s
VDSL2
VDSL2
ADSL2+
STB
STB
STB
STB
TV
TV
TV
TV
VoIP
VoIP
VoIP
VoIP
PC
PC
PC
PC
FTTN
FTTN

Setting up the KE3500
Battery charge display
The KE3500 comes with a high-performance Lithium Polymer (LiPo) rechargeable battery. Despite its light
weight, this allows the device to operate for up to 4 hours in measuring mode under a full load. The charger can
simultaneously operate the KE3600 and charge the battery. The battery is safely charged by a special charge
controller taking into account the time, voltage and current to ensure maximum service life.
Note: Please fully charge battery before first use!
Keypad
When the KE3500 was developed, emphasis was placed on fast and easy operation.
F1 – F4
Menu function buttons, quick access to the selection fields
ESC
Similar to a computer, the ESC button means "undo the last step," or Back.
SEL
SELECT button. Use this button for selecting like an Enter key.
ON / OFF
Button for turning the device On and Off.
Arrow buttons ▲▼◄►
The arrow buttons are for menu scrolling UP ▲ / DOWN ▼ and LEFT ◄ / RIGHT ►.
To move in graphical views around the vertical axis use ◄►.
Keypad
Alphanumeric keypad with 1-0, A-Z, special characters.
Text input
F1: abc " 123 Switch between letters and numbers input.
Special characters can be found under the keys * and #.
*: .-/@:_+,[];=?
#: #$%&‛(){}~
F2: Delete the entire entry line with Clr
F3: With Del delete individual digits
F4: With ! deleting individual digits from right to left
Operating Manual KE3500 xDSL MULTITEST
6
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Documentation and Software
Up-to-date operating instructions and software updates can be found in our KE3500 download area
after logging on in the CUSTOMER LOGIN.
You will find it under the Downloads menu item. After entering the serial number, you will find all current
documents available for download in the following window.
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values
Del
Resync-Counter
0
Actl
104973
50000
Kbps
Max
134832
56034
Kbps
Tx-Pwr
10.8
7.1
dBm
Ø SNR-Margin
14.2
9.5
dB
FEC
0
0
CRC
2
8
abc " 123 Clr
Filename
!

Information LEDs
The KE 3500 has five LEDs that display a range of important but easy-to-use information about the current
status of the device. From left to right the LEDs mean:
DSL CRC – orange
This LED lights when a CRC (checksum error) near end or far end is recognized. These errors (fewer than 10)
can arise after a connection has been established. In any case, check if the counter is still counting to
determine if other causes (faults) exist. You can access the error counter menu in the respective test menu.
DSL LOSS – orange
After a connection is established in non-resync mode, a DSL loss event is displayed here and also signaled
with an intermittent tone for 10 seconds. The tone can be stopped by pressing SEL once.
DSL L1 – green
When the KE3500 is activated in xDSL Mode, this LED begins to flash at 2 Hz to signal Ready Status. It is
waiting for a carrier. As soon as this is detected LED flashes at 4 Hz until the connection is established, and then
it is lit steadily as long as the connection exists.
BATT CHRG – green and red
This display is active even when the KE3500 is turned off. The green LED indicates that the power supply or
charger is inserted and is supplying power. The red LED signals that the battery is in charging mode. This
produces a green/red or orange display during charging. Once controlled charging is complete, the red LED
turns off and only the green LED lights to signal that the power supply or automatic charger is still active and
that charging is complete. However, this does not necessarily mean that the battery is fully charged!
The power supply enables the KE3500 to be charged and operated SIMULTANEOUSLY. The car charger only
charges the battery.
Switching On
The KE3500 works with an operating system that has to be
booted. The boot menu with various device parameters
such as the hardware and software versions appears at the
end of the booting process. After this you can bring up the
main menu immediately by pressing any button.
Operating Manual KE3500 xDSL MULTITEST
7
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Serial: xxxxxxxxxxxxxxxx
Firmware: 1.1-0
Modem: 0000000 / 000 / 00 / 000
Options: ADSL, VDSL, Annex J, '
Annex M
HW-ID: B00000000B0000000
Please note during application:
We recommend not to connect the power supply while the measurement is running!
This can lead to a distortion of the measurement results when testing critical lines.

Connections
xDSL TEST Ports
The test port has one shielded RJ11 and one RJ45 port. This is the connection point for the test cables.
However, a connection cable for a modem can also be inserted. Do not plug in a RJ11 plug into a RJ45 jack.
This may damage the jack.
Ethernet Ports
The Ethernet ports have different functions. One serves as a download port in conjunction with the KE-
Manager for the stored measurements, or to upload any software upgrades. In modem mode and router mode,
it is the Ethernet test port to the customer devices.
USB Port
Port for USB connections. (Not yet activated)
Connections for copper test (optional)
For two two-conductor shielded measurement cables with device end, three-pin plug TF.
ISDN interface (optional)
ISDN and analogue connections RJ11 and RJ45.
LINE 1 LINE 2
A AB BGND GND
GND GNDTIP TIPRING RING
USB 1 SD
100 Mb
Management
1000 Mb
xDSL Test Port
POTS
ISDN-U
ISDN-S
Ports upper side
ISDN Interface (optional)
Side ports
Bottom Ports
USB 1
SD-Card e.g. for longterm measurements.
Insert/remove SD-Card when the device is switched off!
Connections KECT3 for copper testing (optional)
Yellow LED: Link / Data
LED lights continuously:
Connection has been established
LED flashes: Transmit /
receive activity
Green LED:
Transmission speed
xDSL Test Ports RJ11 and RJ45
ISDN/Analog Test Ports RJ11 and RJ45
Headset connection
Power supply connection
Operating Manual KE3500 xDSL MULTITEST
8
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
1 GBit/s Pots
for Ethernet-Tests
10/100/1000 MBit/s
Device Management Port
10/100 MBit/s

Main Menu
The battery display is at the top left. After charging, it shows
the actual battery charge using 6 levels.
Next to that the line voltage is shown in all Broadband
modes of approximately +/- 5%. This tells you if there is any
line voltage and its level so that you can distinguish
between an analog and ISDN connection. This also reveals
if the measurement is before or after a splitter.
The date and time are shown to the right.
Four selection positions are available in the main menu:
1. Broadband
2. Telephony (optional)
3. Copper Test (optional)
4. Setup
General Operation
In all the menus and submenus that have selection functions, the selectable parameters are either identified
with left and right arrows (◄ and ►) or without arrows. When the entry is marked with the left and right arrows,
you can switch between parameters by pressing the ◄ / ► buttons. When the entry is without the arrows,
press SEL (SELECT) to move to a submenu where you can change settings. Press ESC to exit and save the
selection in the menu. In the main menus, the previously selected menu item is saved. The next time you turn
on the device, the scrollbar is automatically set to the previously selected item.
Markings
disabled
activated, all inputs in order > test possible
Red bar:
Input / verification
required!
< >
< >
< >
< >
?
!
Help
Date / Time
VoIP Parameters
a/b: 0,0 V
Caller ID
3
<Aus>
Authentication
1
Password
2
activated, complement inputs > test possible
activated, correct entries > test not possible
Operating Manual KE3500 xDSL MULTITEST
9
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Broadband
Help
Date / Time
Main Menu
a/b: 0,0 V
1
Telephony
Copper Test
Setup
2
3
4
p
q
UDP/RTP Port
UDP/RTP Port Range
6
7<0>
User Agent
5
<5.060>
Registrar
Proxy
9
0<Off>
Stun Server
8
<Off>
<Off>
Domain
4
Display Line voltage

Setup (Basic Device Settings)
1. Automatic Off
Automatic shutoff after the last button is pushed. Possible settings:
Always On / 3 minutes / 5 minutes / 15 minutes / 30 minutes / 60 minutes.
When a test is running the KE3500 does not shut off even after the time has elapsed.
2. Backlight
Possible settings: Always On / Always Off / 3 minutes. Lets you specify the duration before the screen is
dimmed in order to preserve the battery. In the selection of 3 minutes additionally appears 3. Brightness
Dimmed as another menu item. Possible values are from Level 1 to 7, where 1 is dark and 7 is light.
3. Language
Menu languages: German, English, French, Italian, Dutch. German is the default. Spanish, Portuguese,
4. Date & Time
Time and date setting: 12 or 24 hour format
Format DD.MM.YY HH:MM e.g. 21.12.07 13:14
5. Software Updates
Checks to see if an update is available and allows ist installation.
Basically, the power supply must be plugged for safety during an update / upgrade, the LED for Batt Chrg
must light up green or green and red (orange). Power loss during update / upgrade can have the consequence
that the KE3500 stops working and needs to be returned to the manufacturer. The possible need new
installation by faulty software can only be downloaded from the manufacturer for a fee. After a successful
update / upgrade process for KE3500 is rebooted. The update or upgrade is only possible with the respective
current matching KE-Manager.
6. Signals & Display
You can find more settings:
1. Keybord Beep On or Off
2. LOSS Beep On or Off
3. Low Battery Beep On or Off
4. Brightness Level 1 to 7 (1 dark, 7 light)
7. Reset Management IF
With this, the KE3500 can comfortably perform a software reset on connection difficulties with the KE-
Manager software.
8. System Information
Here you will find information about the built-in modules,
such as hardware version and software version.
Operating Manual KE3500 xDSL MULTITEST
10
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Modul
More
Date / Time
System Information
a/b: 0,0 V
HW-Version SW-Version
UPD 001.002.007
APP 000.012.032
BCM 001.002.007
KE000150
18D6CF118414

Interface selection among ”Broadband”
1. Interface
Setting options:<xDSL> and <Ethernet>. The menu
view changes depending on the selected interface.
2. xDSL Mode
Setting options: <Annex A/M>/ <Annex B/J>. In Annex
J, a second synchronization approach is needed
because the filter from Annex B to Annex J has to be
switched over.
3. Terminal (xDSL) with automatic
detection of DSL Services
Synchronization with 1 / or press START to run the
test ...
Line Values Display
Actl: Actual Up/Downstream
Max: Maximum Up/Downstream
Tx Pwr: Transmission power / dBm
Ø SNR-Margin: Difference between
line SNR and required SNR in dB
FEC: Forward Error Correction
CRC: Checksum error
HEC: ATM-Header Error Check
Bitswap: Redirected data of a disturbed
communication channel to other channels
Ø Line Atten.: Attenuation in dB
INP: Impulse Noise Protection
Interleave: Delay in ms or 0 for Fast-Path
Line Loss: Loss of the synchronized connection
LOF: ATM receiving station has lost the frame
description
LOM: Loss of Margin
SES: Severely Errored Second:
a second with bit error rate
UAS: Number of seconds during which no transfer
was possible
ES: Errored Second: one second of measurement time
during which one or more bit errors are present
Function keys and options
F1 More (select with SEL)
Help (reserved for help functions)n
Resert errors (shown errors will n
be set to zero)
Save measurement or directly n
during the measurement by pressing
the SEL key. It opens up a Window
where the file name can be entered
as a name / number. After confirming with SEL
the measurement is stored on the internal memory,
and can be edited using the supplied
KE Manager software.
Operating Manual KE3500 xDSL MULTITEST
11
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Interface
Help
Date / Time
Broadband
a/b: 0,0 V
1
Endgeräte Mode
Router Mode
Modem Mode
3
4
5
<xDSL>
xDSL Mode
2<Annex A/M>
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values
Duration of the synchronized connection
Tests
Resync-Counter
0
Actl
104973
50000
Kbps
Max
134832
56034
Kbps
Tx Pwr
10.8
7.1
dBm
Ø SNR-Margin
14.2
9.5
dB
FEC
0
0
CRC
2
8
HEC
0
0
More Views
Help
Reset errors
Save measurement
Line Values
PPP Status
Bands
Vectoring
SNR
BAT
Hlog
QLN
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values - Bands
Tests
SNR Margin 0
N/A
dB
SNR Margin 1
14.3
10.8
dB
SNR Margin 2
14.1
9.1
dB
SNR Margin 3
14.2
N/A
dB
SNR Margin 4
N/A
dB
Line Attenuation 0
0
dB
Line Attenuation 1
0.0
0.1
dB
Line Attenuation 2
0.0
1.0
dB
More Views
Ping
Traceroute
Http Download
FTP Download
FTP Upload
VoIP Log
VoIP Statistics
VoIP Dial
IPTV Log
IPTV Statistics
IPTV Preview

Operating Manual KE3500 xDSL MULTITEST
F2 Views (Line Values, Bands, Vectoring, ...)
Line Values (see page 11)n
PPP Status n
Bands (Displays individual bands for SNR Margin, Line n
Attenuation, Signal attenuation and TX Power,
see page 11)
Vectoring (Vectoring status, VCE MAC address, n
possible errors)
SNR/BAT/Hlog/QLN: Graphs for Bits per tone, SNR per n
tone, Hlog and QLN can be called up here (Downstream
blue, Upstream green)
This information is helpful to detect sources of inter-
ference that affect the signal to noise ratio.
By pressing the ◄►keys, the yellow pointer moves and
displays below the graph the numeric value
F3 Test
Data Tests, VoIP- and IPTV-Testsn
Saving Measurements
You can save the data during the measurement by pressing
the SEL button. A window opens where you can enter the
memory as a name or number. After confirmation with SEL,
the measurement is stored in the internal memory.
After entering and confirming by selecting the character, this
measurement is saved with the name or number you entered.
Very useful is a specification, for example with Customers
name or telephone number. The limitation is given only by the
internal memory (2 GB). However, you should ensure that the
stored data is regularly downloaded and deleted. The deletion
is easily possible with the supplied KE-Manager.
QR code generation
When you press the "7" key a QR code is calculated from a
portion of the displayed data. This is then displayed on the
screen and can be read with appropriate readers.
Profiles
All parameters can also be created in the profiles menu from
the KE-Manager. The profiles are then called to load and save
profiles using the menu item. The loaded data can always be
revised as described previously or changed. The change is
only until they leave the test is valid if it is not saved before.
12
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Line
G993.2 VDSL2 (Vendor)
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J
VTU-R (Annex B/J
1
Up /Far
Dn/Near
Data VoIP IPTV
Uhrzeit / Datum
Date / Time
Showtime
Showtime
a/b: 0,0 V
a/b: 0,0 V
234
0:32:22
0:32:22
p
q
Line Values - Vectoring
Bits per tone
Tests
Tests
More
More
Views
Views
Vectoring state: 1
VCE MAC Address: 0:19:8f:16:27:ce
Total error samples Ethernet pkts sent: 0
Total error samples Ethernet pkts sent discarded: 0
Total error samples statuses sent: 0
Total error samples statuses sent discarded: 0
Tone: 2047, 8,8277 MHz
27
54
0
01.365 2.730 4.096
43 Bits
Up /Far
Dn/Near
Data VoIP IPTV
Line
Date / Time
G993.2 VDSL2 (Vendor)
VTU-R (Annex B/J Showtime
a/b: 0,0 V
1234
0:32:22
p
q
Line Values
Del
Resync-Counter
0
Actl
104973
50000
Kbps
Max
134832
56034
Kbps
Tx Pwr
10.8
7.1
dBm
Ø SNR-Margin
14.2
9.5
dB
FEC
0
0
CRC
2
8
HEC
0
0
abc " 123 Clr
Filename
!

Router Mode
Connection of the KE3500 to the xDSL port and to the PC.
Replaces the modem and the router. See the Menu
Structure for possible settings.
In Ping mode, the KE3500, after the Ping test was
successfully performed used as a router. This means that
via the Ethernet interface, Internet access can be
performed.
Modem Mode (Bridge Modus)
Connection of the KE3500 to the xDSL port and to the PC.
Replaces the modem. See the Menu Structure for
possible settings. This mode is intended as a replacement
modem mode. The Ethernet interface is connected by
smooth here (bridge or through mode), and is now the
DSL port on the terminal. Now the KE3500 can be
employed as a full modem, both ADSL and VDSL in mode
can be employed. This makes it possible to draw
conclusion errors. Save the measurement with SEL, exit
with ESC. The Ethernet interface is transparently
switched to have the modem functions.
Terminal Mode <Ethernet>
Connection to the Ethernet interface of a modem / router
or a hub / switch. See the Menu Structure for possible
settings for Ping, Trace route, HTTP download, FTP
download and FTP upload
Operating Manual KE3500 xDSL MULTITEST
13
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
START...
START...
Help
Help
Date / Time
Date / Time
Router Mode
Modem Mode
a/b: 0,0 V
a/b: 0,0 V
1
1
Auto Re-Sync
Auto Re-Sync
xDSL Mode
xDSL Mode
Seamless Rate Adaption
Seamless Rate Adaption
3
3
4
4
5
5
<xDSL>
<xDSL>
Load and Save Profiles
Load and Save Profiles
2
2
<Annex A/M>
<Annex B/J>
<Off>
<Off>
<AAL5>
<AAL5>
ATM Type
ATM Type
6
6
p
p
q
q
<Off>
<On>
VPI
VPI
VCI
VCI
PTM Priority
PTM Priority
7
7
8
8
9
9
<32>
<32>
<Normal>
<Normal>
<Off>
<Off>
VLAN Tagging
VLAN Tagging
0
0
<0>
<0>
<PPPoE>
Encapsulation

Operating Manual KE3500 xDSL MULTITEST
14
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Data Test (Description available soon)

Operating Manual KE3500 xDSL MULTITEST
15
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Data Test (Description available soon)

Operating Manual KE3500 xDSL MULTITEST
Menu Structure
1 bis 7
Some of the interfaces and functions are shown in the menu structure but have no function
because they are not contained in the service package chosen.
16
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
1 Broadband
2 Telephony*
3 Copper Test*
4 Setup
1 Interface
2 xDSL Mode
3 Terminal Mode
4 Router Mode
5 Modem Mode
<xDSL>
Select Terminal:
Main Menu
Always On / 3 minutes ... 60 minutes
Always Off / Always On / 3 minutes
German / English / ...
Input
Execution
1 Automatic Off
2 Backlight
Brightness Dimmed
3 Language
4 Date & Time
5 Software Updates
6 Signals & Display
7 Reset Management IF
8 System Information
Off / On
Setup
Off / On
Off / On
1 to 7
Update (only active when update available)
Display device info
see page 10
1 to 7
<Annex B/J> <Annex A/M>
1 Keyboard Beep
2 LOSS Beep
3 Low Battery Beep
4 Brightness
1 Interface
2 Ethernet Interface
<Ethernet>
3 Terminal Mode
1 Autonegotiation
2 Speed
3 Duplex Mode
Off
Off / On
10MBit/s/100MBit/s/1000MBit/s
10MBit/s
100MBit/s Off / On
* optional

Operating Manual KE3500 xDSL MULTITEST
17
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
1 START...
2 Load and Save Profiles
3 Data
4 VoIP
5 IPTV
6 VOD
1 START...
2 Load and Save Profiles
3 Auto Re-Sync
4 xDSL Mode
5 Seamless Rate Adaption
6 ATM Type
7 VPI
8 VCI
9 PTM Priority
0 VLAN Filter/Tagging
1 Load Profile
2 Save Profile
3 Delete Profile
Annex A/M / Annex B/J
Off / On
Off / On
AAL5 / AALOPKT / AALOCEIL
0 ... 255
32 ... 65.535
Normal / High / Both
Off / On
Input
Selection
Selection
Terminal Mode
Modem Mode
0 ... 4.095
On
VLAN ID
1 Service Configuration
Yes / No
1 START...
2 Load and Save Profiles
3 Auto Re-Sync
4 xDSL Mode
5 Seamless Rate Adaption
6 ATM Type
7 VPI
8 VCI
9 PTM Priority
0 VLAN Tagging
Encapsulation
Authentication
Annex A/M / Annex B/J
Off / On
Off / On
AAL5 / AALOPKT / AALOCEIL
0 ... 255
32 ... 65.535
Normal / High / Both
Off / On
PPPoA / PPPoE / IPoA / IPoE
Off / On
Router Mode
0 ... 4.095
On
VLAN ID
Username...
Password ...
On Input
Input
Secondary Interface
Yes / No
PTM / ATM
0 ... 255
32 ... 65.535
On
0 ... 4.095
IPoE
On
1 Eigenes Interface
2 ATM/PTM
3 VPI
4 VCI
5 VLAN Tagging
6 VLAN ID
7 Encapsulation
8 IP Configuration
via DHCP
< >
< >
< >
Secondary Interface
Yes
see on top
see on top
1 Service Configuration
2 Select Profile
1 Design Interface
Yes / No
VPI
VCI
VLAN Tagging
VLAN ID
Encapsulation
0 ... 255
Off / On
On
IPoA
0 ... 4.095
p
q
Das Erste HD
BR Sd HD
NDR HD
SWR BW HD
SWR RP HD
WDR HD
3sat HD
ARTE HD
KIKA HD
IPTV
2 IP Configurat. via DHCP
32 ... 65.535
Yes

Operating Manual KE3500 xDSL MULTITEST
SD-Card / Generated
1 Dial-in a. Modem Conf.
2 BERT
3 Ping
4 Traceroute
5 HTTP Download
6 FTP Download
7 FTP Upload
8 Update Download
1 Destination Address...*
2 Packet Length
3 Packet Number
1 Destination Address...*
2 Number of Hops
3 Timeout
1 URL
2 Username...
3 Password...
4 Several Downloads
5 Number of Downloads
1 Server... (Dest. Address...*)
2 Path
3 Filename
4 Data Source
Parallel / Serial
None / 0 ... 120 s
0 ... 20 / unlimited
1 ... 100
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
1 ... unlimited
0 ...10
0 ...10
1 URL
2 Username...
3 Password...
4 Simultaneous Downloads
1 URL
2 Username...
3 Password...
Input
Input
Input
1 IP Address
2 Hostname
Destination Address*
Off / On
Off / On
AAL5 / AALOPKT / AALOCEIL
PPPoA / PPPoE / IPoA / IPoE
0 ... 255
32 ... 65.535
0 ... 4.095
Off / On
1 Auto Re-Sync
3 Seamless Rate Adaption
4 ATM Type
5 Encapsulation
6 VPI
7 VCI
8 VLAN Tagging
9 Authentication
56 ... 2.048 Bytes
Off / On
On
On
Generated
Input
Input
VLAN ID
Stun Server
5 Filesize
Username...
Password...
On Input
Input
Data
18
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
< >
< >
< >
< >
< >
< >
see above
Input
5 Username...
6 Password...
7 Simultaneous Uploads
1 MB ... 1 GB
1 VoIP Parameters
2 Jitter Buffer
3 JitterThreshold
4 MOS Threshold
5 Session Expiration
6 Auto Accept Calls
7 Silence detection
8 Echo
1 Authentication
2 Password
3 Caller ID
4 Domain
5 User Agent
6 UDP/RTP Port
7 UDP/RTP Port Range
8 Stun Server
9 Registrar
VoIP
VoIP Parameter
Input
1...960 ms
1...960 ms
0,0...5,0
0...6400 s
1...65.535
Off / On
Off / On
Off / On
Off / On
Input
Input
Input
Input
Input
On
Registrar
0 Proxy
On
Proxi Address
1...65.535
Off / On
Input
Off / On
Input
< >

Operating Manual KE3500 xDSL MULTITEST
KE-Manager
The KE-Manager is a flexible tool to manage the
KE3500 and download the data of the
measurements. The KE-Manager is like the
KE3500 very clearly designed and largely intuitive
and comes with the included CD-ROM (or Kurth
Electronic Homepage).
Setup of the PC
When installing the KE-Manager, the user must
have administrative rights and possibly turn off the
virus protection and the Windows Firewall.
Connection to the PC
The KE3600 can be connected directly via the
device management port to the Ethernet port of the
PC. Optimally, however, is the use of an available
Ethernet interface on the same network, so the PC
can remain in the network. It will automatically
determine an IP address (UPnP address) and the
KE3500 appears with the IP address and serial
number in the select list of the KE-Manager.
Opening the KE-Manager
Click on the KE-Manager icon on your PC desktop.
The KE-Manager starts and displays by various
colors on the connection status to the PC. If there
are problems getting a connection to the device
you can use the option Reset Management IF in
the Setup menu.
The green coloured background indicates the
established connection.You are now ready to
control KE3600 through the KE-Manager.
19
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Configuration
Settings for several basic options and
licensing, transmitter list (IPTV profiles) and
the profil set can be executed here.
x-DSL
Gives close information to the active and
stored tests.

Operating Manual KE3500 xDSL MULTITEST
20
KURTH ELECTRONIC Test & Measurement www.kurthelectronic.de [email protected]
Changing the LiPo Battery
The decreasing battery charge is clearly identifiable on the display provided that the initial adjustment was
done during first start-up.
The battery can be charged, the charge control display red LED goes off, but the battery display still will not
show full. As long as the displayed capacity does not go under 50%, the KE3500 can be safely used; it only
has to be charged more frequently. If the display goes below 50%, you need to change the battery. You can
either send in the device and the battery will be changed for a fee, or you can order a replacement battery.
Changing the battery
First remove the two lower compartment screws. Pull the bottom downward. The battery is in a plastic holder
in the bottom part and it is plugged into the board with a plug protected against polarity reversal. After the
housing is opened, this must be pulled out. Insert the new battery and securely fasten the holder. Plug the
connection cable into the board and screw on the housing. Make sure to only hand-tighten the housing
screws.
Loop Test
Here you can consider the stored loop
analysis tests from KECT3 Cooper
Interface
ISDN
Here you can consider the ISDN tests
