  9. Kustom Signals SMART 650 User manual

Kustom Signals SMART 650 User manual

SMART 650 Quick Reference Guide
Part # 006-9009-10 Rev 0
UP and DOWN User Interface Buttons:
Used to move between modes and to increase/decrease values.
SELECT User Interface Button:
Used to select modes and to set values.
OVERSPEED
Mode Indicator
OVERSPEED Indicator:
Illuminated whenever a target speed is greater than or equal to either of the overspeed
settings. Blinks when in overspeed changing mode.
BLANKING
Mode Indicator
BLANKING Indicator:
Illuminated whenever a target speed is greater than or equal to the blanking speed setting.
Blinks when in blanking speed changing mode.
VOLTAGE LEVEL
Mode Indicator
VOLTAGE LEVEL MENU Indicator:
Illuminated when the system voltage is being displayed. Blinks when in system menu or
changing options settings.
CLOCK
Mode Indicator
CLOCK Indicator:
Displays the current date and time of the sign. Blinks when changing date and time values.
Display Window:
Displays the current target speeds. It can also be used to view and change the system
settings. The rightmost decimal point is the Power LED which should constantly blink to
indicate the system is running. “nc” indicates the communication to the radar has been lost.
Changing Settings:
OVERSPEED 1
(Blinking Digits)
SETTING
To change the Overspeed1 setting, using user interface buttons:
1. move to the OVERSPEED LED → SELECT →
2. move to “OS1” → SELECT → SELECT →
3. choose new value → SELECT
OVERSPEED 2
(Flashing Strobes)
SETTING
To change the Overspeed2 setting, using user interface buttons:
1. move to the OVERSPEED LED → SELECT →
2. move to “OS2” → SELECT → SELECT →
3. choose new value → SELECT
BLANKING SPEED
SETTING
To change the Blanking Speed setting, using user interface buttons:
1. move to the BLANKING LED → SELECT →
2. choose new value → SELECT
DEMO MODE
To engage the demonstration mode, using user interface buttons:
1. move to the VOLTAGE LEVEL LED → SELECT →
2. move to “dE” → SELECT →
3. choose “On”/”OFF” → SELECT
STEALTH MODE
To engage the stealth mode, using user interface buttons:
www.kustomsignals.com
Sales (800) 4KUSTOM (800) 458-7866
Customer Service (800) 835-0156
1. move to the VOLTAGE LEVEL LED → SELECT →
2. move to “StL” → SELECT →
3. choose “On”/”OFF” → SELECT
SPEED
CONTROLLED
FLASH
To engage the speed controlled flash mode, using user interface buttons:
1. move to the VOLTAGE LEVEL LED → SELECT →
2. move to “SCF” → SELECT →
3. choose “On”/”OFF” → SELECT
STROBES ENABLE
(Option)
To engage the strobes enable mode, using user interface buttons:
1. move to the VOLTAGE LEVEL LED → SELECT →
2. move to “Stb” → SELECT →
3. choose “On”/”OFF” → SELECT
SETTING THE
DATE/TIME
WARNING: If you have a traffic counter installed, please make sure (tc) is OFF and reboot the
sign before changing the time or date. This will help avoid corrupting data in an active study.
To change the date and/or time, using user interface buttons:
1. move to the CLOCK LED → SELECT →
2. adjust the 2 digit year (00 to 99) → SELECT →
3. adjust the month (01 to 12) → SELECT →
4. adjust the date (01 to 31) → SELECT →
5. adjust the hours (00-23) → SELECT→
6. adjust the minutes (00 to 59) → SELECT
TRAFFIC COUNTER
POWER
(Option)
To engage the traffic counter enable mode, using user interface buttons:
1. move to the VOLTAGE LEVEL LED → SELECT →
2. move to “tc” → SELECT →
3. choose “On”/”OFF” → SELECT
TRAFFIC COUNTER
SCHEDULER
ENABLE (Option)
To engage the traffic counter scheduler enable mode, using user interface buttons:
1. move to the VOLTAGE LEVEL LED → SELECT →
2. move to “tcS” → SELECT →
3. choose “On”/”OFF” → SELECT
STARTING A
TRAFFIC COUNTER
STUDY
(Option)
1. Make sure the traffic counter power is ON. See TRAFFIC COUNTER POWER above.
2. Turn sign OFF then ON again. This will begin a new study.
3. As cars get added to the study, you may notice the blue LED flicker to indicate it has
acquired a target.
STOPPING A
TRAFFIC COUNTER
STUDY
(Option)
1. Turn sign OFF then ON again. This will stop the running study and write it to the
internal memory.
2. If a new study is ready, the blue LED next to the USB port will be flashing.
3. Insert a thumb drive (8GB or less) into the USB port. “bSy” will appear in the display
window.
4. When “bSy” goes away and the blue LED stops flashing, the studies have been
transferred to the thumb drive and it may be removed. DO NOT REMOVE thumb drive
while the blue LED is flashing or you could corrupt the thumb drive.
SMART 650 Quick Reference Guide
Part # 006-9009-10 Rev 0
