Kutai electronics CH1112E User manual

KUTAI ELECTRONICS INDUSTRY CO., LTD.
TEL : [phone] FAX : [phone] Website : www.kutai.com.tw
Headquarters : No.3, Ln. 201, Qianfu St., Qianzhen Dist., Kaohsiung City 80664, Taiwan
CH1112/CH1124/CH2112/CH2124
Automatic Battery Charger User Manual

___________________________________________________________________________________________
2CH1112/CH1124/CH2112/CH2124
SECTION 1 : SPECIFICATION
1.1 Model Specification
Model
Input
Voltage
(AC)
Output
Voltage
(DCV)
Available
Battery
(V)
Output
Current Max.
(A)
Fu Fuse
Spec.
(A)
Power
Consumption
(W)
Weight
(kg +/- 2%)
CH1112E
1 Phase
110V
50/60 Hz
13.8
12
10
5
230
6.8
CH1124E
27.6
24
10
5
340
7.2
CH2112E
1 Phase
220V
50/60 Hz
13.8
12
10
5
230
6.8
CH2124E
27.6
24
10
5
340
7.2
1.2 Charge mode : Floating Charge.
1.3 Unit Power Dissipation : Max. 92 watt
1.4 Environment :
●Operation Temperature -20 to +60 ˚C
●Storage Temperature -20 to +40 ˚C
●Relative Humidity 20 to 90%
1.5 Protection :
●Fixed voltage, current limited, auto-feedback.
●Fuse protected Ø 6 * 30mm.
●Reverse polarity protected.
●Short-circuit protected.
1.6 Size : 245.0 (L) x 158.0 (W) x 192.0 (H) mm
SECTION 2 : OPERATION PROCEDURE
2.1 Ensure the type and output voltage before power
on.
2.2 Connect charger-line (accessory) with +/- terminals.
Warning : +/- terminals should not be shorted !
2.3 Plug in then switch on, voltage meter should be
read by 13.8V (12V) / 27.6V (24V).
2.4 If output voltage correct then power off. Connect
the red side of the charger-line to the “+” terminal
of the battery, the black one to the “” terminal.
2.5 Power on then charging is starting, the more
charge current the less time needed, current is
adjusted by current-adjust-knob on the panel. For
the long time charging, we suggest the current
less than 1A.
2.6 Factory setting of output voltage is 13.8V or
27.6V, on the conditon of old batteries the
voltage can be boost by turning the VR from the
hole located on the panel.
CAUTION !! High voltage will cause batteries
liguid vaporized and batteries damaged.
2.7 Our charger has voltage-feedback-sensor to
avoid batteries be over-charged, if the battery is
full charged then output current will be reduced to
zero, in order to extend the life of the battery.

___________________________________________________________________________________________
CH1112/CH1124/CH2112/CH2124 3
SECTION 3 : NOTICES
3.1 Avoid to place the charger in the environment
such as high temperature, humidity, acid & alkali,
Prevent from insolation, drench and caustic.
3.2 AC input voltage should fit the charger type. We
suggest to install a protection device (such as
MCCB) inter AC power and charger.
3.3 Never depart the charger.
3.4 Never change internal wiring of the charger.
3.5 Never adjust internal VRs of the PCB
intentionally.
3.6 Routine-check of output voltage is necessary.
3.7 Terminals of the charger and polarities of the
battery should be connected correctly, red to “+”,
black to “”.
Warning : Never short “+” (red terminal) and “”
(black terminal) polarities.
3.8 Please operate the charger under the max.
maximum capacities.
3.9 Beside charge battery, please do not use charger
for other purpose.
3.10 When install the output connect wires, please
references the figure below.
Correct
Incorrect
Incorrect

___________________________________________________________________________________________
4CH1112/CH1124/CH2112/CH2124
SECTION 4 : OUTLINE
SECTION 5 : TROUBLESHOOTING
SYMPTOM
POSSIBLE CAUSES
No output voltage
1. Check AC Power.
2. Check fuse.
3. Charge-line if poor connection or not.
4. Check if short exists or not.
5. Check if polarities are oppositely or not.
No charge current or the
current is unable battery
properly
1. Check if battery is full charged or not.
2. Check if poor connection exists or not.
3. Check if the type and the rate of the charger are correct or not.
4. Check if battery is out of order or not.
※If these steps above could not make the charger working still, Please contact with KUTAI.
※Please accept our sincere apology if any modification in performance, specification or appearance is made
without prior notice.
(1) Voltage Meter.
(2) Current Meter.
(3) Voltage Adjustment VR
(inside-mounted).
(4) Current Adjustment Button.
(5) Output terminal (Red).
(6) Output terminal (Black).
(7) Fuse.
(8) Power Switch & Lamp.
(9) Handle.
