PulseTech RediPulse Pro-12 PRO-12-RP User manual

Operating Instructions
PRO-12-RP

800-580-75542
If you sell, inventory or service lead-acid batteries, you want the battery you take off the shelf to be
as new as the day it was manufactured. However, batteries that sit idle continually discharge and are
subject to a naturally occurring build-up of lead sulfate deposits that reduce the battery’s ability to
accept, store and release energy.
The RediPulse Pro-12-RP®tackles both problems. A continuous cycle of low amperage charging
reverses the normal discharge rate and optimized high frequency patented pulsing reduces the size
and number of lead sulfate deposits. Your batteries will stay “factory fresh,” no matter how long they
have been sitting on the shelf.
Connect from 1 to 12 stored 12 V batteries from a single AC outlet. Completely safe – there’s no sparking
between the battery leads because current doesn’t flow into the cables until connected to the battery.An
audible alarm signals if the cables are reversed. LED lights indicate the status of individual batteries.
Important Safety Instructions
1. SAVE THESE INSTRUCTIONS - This manual contains important safety and operating instructions
for the battery maintenance charger model Pro-12-RP.
2. Do not expose charger to rain or snow.
3. Use of an attachment not recommended or sold by the battery charger manufacturer may result
in a risk of fire, electric shock, injury to persons, or damage to product.
4. To reduce risk of damage to electric plug and cord, pull by plug rather than cord when discon-
necting charger.
5. An extension cord should not be used unless absolutely necessary. Use of improper extension cord
could result in a risk of fire and electric shock. If extension cord must be used, make sure:
a) That pins on plug of extension cord are the same number, size, and shape as those of plug on
charger;
b) That extension cord is properly wired and in good electrical condition; and
c) That wire size is large enough for ac ampere rating of charger as specified in Table 1 (pg. 4).
6. Do not operate charger with damaged cord or plug – replace the cord or plug immediately.
7. Do not operate charger if it has received a sharp blow, been dropped, or otherwise damaged in any
way; take it to a qualified serviceman.
8. Do not disassemble charger; take it to a qualified serviceman when service or repair is required.
Incorrect reassembly may result in a risk of electric shock or fire.
9. To reduce risk of electric shock, unplug charger from outlet before attempting any maintenance or
cleaning. Turning off controls will not reduce this risk.
10. WARNING – RISK OF EXPLOSIVE GASES.
a) WORKING IN VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE EX-
PLOSIVE GASES DURING NORMAL BATTERY OPERATION. FOR THIS REASON, IT IS OF UTMOST
IMPORTANCE THAT EACH TIME BEFORE USING YOUR CHARGER, YOU READ THIS MANUAL AND
FOLLOW THE INSTRUCTIONS EXACTLY.

www.pulsetech.net 3
b) To reduce risk of battery explosion, follow these instructions and those published by battery
manufacturer and manufacturer of any equipment you intend to use in vicinity of battery. Re-
view cautionary marking on these products and on engine.
11. PERSONAL PRECAUTIONS
a) Someone should be within range of your voice or close enough to come to your aid when you
work near a lead-acid battery.
b) Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or
eyes.
c) Wear complete eye protection and clothing protection.Avoid touching eyes while working near
battery.
d) If battery acid contacts skin or clothing, wash immediately with soap and water. If acid enters
eye, immediately flood eye with running cold water for at least 10 minutes and get medical
attention immediately.
e) NEVER smoke or allow a spark or flame in vicinity of battery or engine.
f) Be extra cautious to reduce risk of dropping a metal tool onto battery. It might spark or short-
circuit battery or other electrical part that may cause explosion.
g) Remove personal metal items such as rings, bracelets, necklaces, and watches when working
with a lead-acid battery. A lead-acid battery can produce a short-circuit current high enough
to weld a ring or the like to metal, causing a severe burn.
h) Use charger for charging LEAD-ACID batteries only. It is not intended to supply power to a low
voltage electrical system. Do not use battery charger for charging dry-cell batteries that are
commonly used with home appliances. These batteries may burst and cause injury to persons
and damage to property.
i) NEVER charge a frozen battery.
12. PREPARING TO CHARGE
a) Always remove battery from vehicle to charge. Always remove grounded terminal from battery
first. Make sure all accessories in the vehicle are off, so as not to cause an arc.
b) Be sure area around battery is well ventilated while battery is being charged. Gas can be force-
fully blown away by using a piece of cardboard or other nonmetallic material as a fan.
c) Clean battery terminals. Be careful to keep corrosion from coming in contact with eyes.
d) Add distilled water in each cell until battery acid reaches level specified by battery manufac-
turer. This helps purge excessive gas from cells. Do not overfill. For a battery without cell caps,
carefully follow manufacturer’s recharging instructions.
e) Study all battery manufacturer’s specific precautions such as removing or not removing cell
caps while charging and recommended rates of charge.
13. CHARGER LOCATION
a) Never place charger directly above battery being charged; gases from battery will corrode and
damage charger.
b) Locate the charger as far away from battery as dc cables permit.

800-580-75544
c) Charger is designed to be installed on a battery
rack header card (Fig.1), but it may also be in-
stalled on the side of the battery storage rack, on
a shelf within reach, or permanently mounted to
the wall using the enclosed mounting hardware.
d) Never allow battery acid to drip on charger when
reading gravity or filling battery.
e) Do not operate charger in a closed-in area or re-
strict ventilation in any way.
f) Do not set a battery on top of charger.
14. DC CONNECTION PRECAUTIONS
a) Connect and disconnect dc output clips only after
setting any charger switches to off position and
removing ac cord from electric outlet. Never allow
clips to touch each other.
b) Attach clips to battery posts and twist or rock back and forth several times to make a good
connection. This tends to keep clips from slipping off terminals and helps to reduce risk of
sparking.
15. FOLLOW THESE STEPS WHEN THE BATTERY IS OUTSIDE VEHICLE. A SPARK NEAR THE BATTERY
MAY CAUSE BATTERY EXPLOSION. TO REDUCE RISK OF A SPARK NEAR BATTERY:
a) Check polarity of battery posts. POSITIVE (POS, P, +) battery post usually has a larger diameter
than NEGATIVE (NEG, N, –) post.
b) Connect POSITIVE (RED) charger clip to POSITIVE (POS,P, +) post of battery and the NEGATIVE
(BLACK) charger clip to the NEGATIVE (NEG, -) post of battery.
c) Do not face battery when making final connection.
d) A marine (boat) battery must be removed and charged onshore. To charge it on board requires
equipment specially designed for marine use.
Table 1
Recommended minimum awg size for extension cords for battery chargers.
AC input rating, amperes AWG size of cord
Length if cord, feet (m)
Equal to or
greater than But less than
25
(7.6)
50
(15.2)
100
(30.5)
150
(45.6)
12 14 16 12 10 8
12 16 16 12 10 8
16 18 14 12 8 8
18 20 14 12 8 8
Fig.1 Mounted on battery rack header card

www.pulsetech.net 5
Operating Instructions
PREPARATION FOR SERVICE & OPERATION
• Inspect the Pro-12-RP charger for visible damage which might have occurred during shipping and
delivery.
• Plug the AC adapter into an electrical outlet (110-volt or 220-volt depending on unit). NOTE: This
adapter is specially designed for this unit. DO NOT use any other adapter. If the adapter has to be
replaced at some point in time, contact PulseTech to order another one.
• Connect the separate positive and negative clamps to each battery (one single 12 V battery or two
6 V batteries connected in series to equal 12 volts — DO NOT use on12V batteries in series). For
single 12 V batteries: Attach the red positive (+) clamp to the positive (+)battery post and the black
negative (-) clamp to the negative (-) battery post. For 6 V batteries in series: Attach the positive
wire to the positive terminal on Battery 1 and the negative to the negative terminal on Battery 2. If
an audible alarm sounds, it indicates an improper connection.
• Turn the POWER switch to the ON position.
• The Pro-12-RP will initiate a self test during which each of the 12 battery LED indicators will come
on green, turn yellow and then red. Then the Pulse and Charge indicator LED will come on.
• Once the self test is complete, the unit will begin cycling through each of the batteries connected. A
RED LED indicates
the battery is dis-
charged; YELLOW
indicates marginal;
and GREEN indi-
cates the battery is
ready for issue. NOTE: The Pro-Series is capable of restoring recoverable batteries (no damaged plates or
cells) to their maximum potential, but results will vary per battery. Also, the amount of time it takes to effec-
tively clean the battery plates will vary depending on age and/or condition of each battery.
Precautions
DO NOT USE THIS PRODUCT ON BATTERIES INSTALLED IN VEHICLES. Always remove battery from
vehicle prior to charging.
•Use each set of wires only on one single 12V battery or two 6V batteries connected in series to
equal 12 volts. DO NOT use on 12V batteries in series.
• Make sure the correct terminal attachments are connected to the correct terminals (i.e. red on
positive and black on negative).
Technology
What makes the ReNew-IT Pulse Technology utilized by PulseTech products so unique — and so
effective — is the distinct pulse waveform that defines it. This patented waveform has a strictly con-
trolled rise time, pulse width, frequency, and amplitude of current and voltage pulse. No other battery
maintenance systems in the world has this specific waveform which means no other system can
provide the same exceptional benefits as PulseTech battery charging and maintenance systems.

800-580-75546
TWO-YEAR LIMITED WARRANTY
What Does This Warranty Cover? This warranty covers any defects in workmanship or materials in
any circuit board in the Pro-Series™products under normal use and service.
How Long Does The Coverage Last? This warranty runs for two (2) years from the date of pur-
chase.
What Will PulseTech Do? PulseTech will, at its option, replace or repair any defective circuit board
with a new or rebuilt circuit board at no charge.
What Does This Warranty Not Cover? This warranty does not cover any parts other than the circuit
board. In addition, PulseTech will not be responsible under this warranty if PulseTech determines that
(1) upon examination that the circuit board failure was (A) caused by misuse, neglect, accident, alter-
ation, or abnormal condition of operating or handling (including the failure to install the product in ac-
cordance with PulseTech’s instructions and observe the warnings on the product and the instruction
manual), or other conditions beyond the control of PulseTech or (B) damaged in transit to PulseTech,
or (2) the owner is not the original purchaser that purchased the product through an authorized
PulseTech dealer or distributor. IN NO EVENT SHALL PULSETECH BE LIABLE FOR ANY DIRECT, SPE-
CIAL, INDIRECT, CONSEQUENTIAL, INCIDENTAL, PUNITIVE OR EXEMPLARY DAM-AGES, EXPENSES,
LOST SAVINGS OR LOST PROFITS OR ANY OTHER DAMAGES OF ANY KIND FROM ANY BREACH OF
THIS WARRANTY OR OTHERWISE. Some states, provinces or countries do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation may not apply to you.
How To Get Service? Send the product postage prepaid with proof of purchase (sales receipt) within
the warranty period to the authorized reseller where the product was purchased or contact PulseTech
directly by calling 1-800-580-7554.
How Does State, Province or Country Law Apply? This warranty gives you specific legal rights,
and you may also have other rights which vary from state to state, province to province or country
to country.
LIMITATIONS OF LIABILITY
THIS WARRANTY IS THE SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WAR-
RANTIES EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
PATENTS
The Pro-Series™Charge/Maintenance System is protect-
ed by the following U.S. Patent Numbers: 7,834,592B2,
8,269,466B2, 8,269,465B2. Other U.S. and international
patents are pending.
The World Leader in Battery Performance
1100 S. Kimball Avenue, Southlake, Texas 76092
800-580-7554 • FAX: [phone]
www.pulsetech.net 998XM901 08/19
