KVMSwitchTech SCA-7P-HDD User manual

SCA-7P-HDD All to HDMI Converter Box Series
Thank you for purchasing the SCA-7P-HDD All to HDMI Converter Box. You will find this unit easy to install and highly
reliable but it is essential that you read this manual thoroughly before attempting to use the Converter Box.
SCA-7P-HDD: ALL TO HDMI CONVERTER BOX
INSTRUCTION MANUAL

SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power off and disconnect unit fromAC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
flow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualified service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports first, then remove the power cable; finally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualifier service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL

TABLE OF CONTENTS
INTRODUCTION
ALL TO HDMI CONVERTER BOX converts CVBS, YPbPr, VGA, HDMI and USB media to 720p and 1080p high definition HDMI output.
Respective stereo audio input is achieved for CVBS, YPbPr and VGA. Converter Box makes it convenient to connect such as DVD player,
game player, Set-top box, PC and USB device etc. video sources. All inputs will be converted to high definition output. Excellent picture
quality provided by the integrated noise reduction, advanced color process engine, dynamic luminance control, gamma control and 3D
video decoder features.
PACKAGE CONTENTS
1. SCA-7P-HDD All to HDMI Converter Box
2. Remote
3.User Manual
1
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update
or to keep current the information contained in this document.
We reserve the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part
translated into any language or computer file, in any form or by
any means—electronic, mechanical, magnetic, optical, chemical,
manual, or otherwise—without express written permission and
consent.
© Copyright 2013. All Rights Reserved.
Version 1.1 APR 2013
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
CONTENTS
Introduction...................................................................1
Package Contents ........................................................1
Features .......................................................................2
Input Formats ...............................................................2
Settings.........................................................................3

FEATURES & INPUT FORMATS
FEATURES
• 1x CVBS, 1xYPbPr, 1xVGA, 2x HDMI and, 2x USB inputs
• USB movie, picture and music playback
• 720p and 1080p high definition HDMI output
• PAL, NTSC and SECAM color systems supported
• -5% to +5% display ratio range control
• Auto Detect function (except USB)
• Brightness, contrast, color, sharpness, hue control
• Soft, Standard, Bright and Personal 4 preset picture modes
• Picture mode setting saved for respective source
• Geometry control for VGA input with auto tune function
• Capture USB picture and save as user defined logo
• Volume control
• Remote control
• Standby mode
• SCA-7P-HDD Input cards
INPUT FORMATS
• CVBS: PAL, NTSC, SECAM with stereo audio input
• YPbPr:1080p@50/60Hz, 1080i@50/60Hz, 720p@50/60Hz, 576i/p, 480i/p with stereo audio input
• VGA:640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x1024@60Hz, 1280x720@60Hz, 1360x768@60Hz,
1440x900@60Hz, 1680x1050@60Hz, 1920x1080@60Hz with stereo audio input
• HDMI: 1080p@50/60Hz, 1080i@50/60Hz, 720p@50/60Hz, 576i/p, 480i/p, 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz,
1280x1024@60Hz, 1280x720@60Hz, 1360x768@60Hz, 1440x900@60Hz, 1680x1050@60Hz, 1920x1080@60Hz
• USB: MPEG, H.264, RM/RMVB movie decode, JPEG, BMP, PNG
• Picture decode and MPEG1/2, MP3 audio decode
FRONT AND BACK VIEW SIDE VIEW
2

SETTINGS
REMOTE CONTROLLER
Power: Enter standby mode or re-enter normal mode
Source: Pop up source menu, press Up/Down button to select and press OK
button to enter
USB: Enter USB source directly
Picture: Soft, Standard, Bright and Personal picture mode selection
Ratio: Adjust display ratio, -5% to +5% range can be set
Navigation buttons: Left, Right, Up and Down to navigate menu items or USB
media files, press OK to enter
OK: Confirm and enter selection
Menu: Pop up main menu, press Menu button again to return
Exit: Close Menu or exit USB playback mode
Vol-: Decrease volume
Vol+: Increase volume
Output: Set 720p or 1080p output format
SOURCE MENU
1. Press Source button to pop up source menu
2. Press Up/Down button to select source item
3. Then press OK button to enter
3

SETTINGS
MAIN MENU
General control
1. Press Left/Right button to select Soft, Standard, Bright or Personal picture mode
2. Note that only Personal picture mode settings can be adjusted, others are pre-set modes
3. Press Up/Down button to select menu item
4. Press OK button to enter
5. Then press Left/Right button to adjust
6. Press Menu button to return, or press Exit button to close menu
CONTROL FOR PICTURE MENU
1. Press Source button to pop up source menu
2. Press Up/Down button to select source item
3. Then press OK button to enter
4

5
SETTINGS
CONTROL FOR GEOMETRY MENU
1. Press Left/Right button to do Auto adjust
2. Note that Auto adjust will be done automatically when VGA source timing changed
3. Press Up/Down button to select menu item
4. Press Left/Right button to adjust
5. Press Menu button to return, or press Exit button to close menu
CONTROL FOR SETTING MENU
1. Press Left/Right button to set Auto Detect function On or Off
2. Note that whenAuto Detect is set On, the converter will automatically switch to the source which is connected with signal lately, except
for USB source.

6
SETTINGS
USB MENU
General control
1. Press USB button directly or select USB from source menu to enter USB
device playback mode
2. Press Menu button to pop up media type selection menu
3. Press Up/Down button to set which type of media to play
4. Press OK button to confirm
5. Press Left/Right to select USB device (disk alias)
6. Press OK button to browse media file
7. Press Left/Right/Up/Down button to select media file
8. Press OK button to play
MOVIE PLAYBACK CONTROL
Play Repeat
Pause Repeat A<->B
Fast Backward Media file information
Fast Forward Slow Forward
Previous Ratio
Next Brightness
Stop Contrast

7
SETTINGS
PICTURE PLAYBACK CONTROL
Slide show Zoom in
Pause Zoom out
Previous Move
Next Repeat
Stop Brightness
Rotate clockwise Contrast
Rotate anti-clockwise Capture and save as
logo
Background music

8
SETTINGS
AUDIO PLAYBACK CONTROL
Play Next
Pause Stop
Fast Backward Repeat
Fast Forward Mute
Previous Media file information

9
END OF DOCUMENT
TERMS AND CONDITIONS OF USE
PLEASE READ THE FOLLOWINGTERMSAND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTSAND SOFTWARE PROVIDED
BY,THROUGH OR UNDER KVM SWITCH TECH, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify
your agreement to these Terms and Conditions. If you do not agree to theseTerms and Conditions, do not use the Product and return the Product to KVM SWITCH
TECH, Inc. at the return address set forth on the Product’s packing label at your expense. KVM SWITCH TECH, Inc. may modify these Terms and Conditions at
anytime, without notice to you.
RESTRICTIONS ON USE OF THE PRODUCT
It is your responsibility to read and understand the installation and operation instructions, both verbal and in writing, provided to you with respect to the Product.
You are authorized to use the Product solely in connection with such instructions. Any use of the Product not in accordance with such instructions shall void any
warranty pertaining to the Product. Any and all damages that may occur in the use of the Product that is not strictly in accordance with such instructions shall be
borne by you and you agree to indemnify and hold harmless KVM SWITCH TECH, Inc. from and against any such damage.
The Product is protected by certain intellectual property rights owned by or licensed to KVM SWITCH TECH. Any intellectual property rights pertaining to the
Productare licensedto you by KVM SWITCHTECH,Inc. and/or its affiliates, includingany manufacturersor distributors ofthe Product(collectively, “KVMSWITCH
TECH”) for your personal use only, provided that you do not change or delete any proprietary notices that may be provided with respect to the Product.
The Product is sold to you and any use of any associated intellectual property is deemed to be licensed to you by KVM SWITCH TECH for your personal use only.
KVM SWITCH TECH does not transfer either the title or the intellectual property rights to the Product and KVM SWITCHTECH retains full and complete title to the
intellectual property rights therein.All trademarks and logos are owned by KVM SWITCHTECH or its licensors and providers of the Product, and you may not copy
or use them in any manner without the prior written consent of KVM SWITCH TECH, which consent may be withheld at the sole discretion of KVM SWITCH TECH.
The functionality and usability of the Product is controlled by KVM SWITCH TECH, Inc. from its offices within the State of Texas, United States of America. KVM
SWITCH TECH makes no representation that materials pertaining to the Product are appropriate or available for use in other locations other than the shipping
address you provided with respect thereto. You are advised that the Product may be subject to U.S. export controls.
Disclaimers and Limitation of Liability
KVM SWITCH TECH may change or modify the Product at any time, from time to time.
THE PRODUCT IS PROVIDED “AS IS” AND WITHOUT WARRANTIES OF ANY KIND EITHER EXPRESS OR IMPLIED. KVM SWITCH TECH DOES NOT
WARRANT ORMAKEANYREPRESENTATIONS REGARDINGTHE USE ORTHE RESULTS OFTHE USE OFTHEPRODUCT’S CORRECTNESS,ACCURACY,
RELIABILITY, OR OTHERWISE.
KVM SWITCH TECH has no duty or policy to update any information or statements pertaining to the Product and, therefore, such information or statements should
not be relied upon as being current as of the date you use the Product. Moreover, any portion of the materials pertaining to the Product may include technical
inaccuracies or typographical errors. Changes may be made from time to time without notice with respect to the Product.
TOTHE FULLEST EXTENT PERMISSABLE PURSUANTTOAPPLICABLE LAW, KVM SWITCHTECH DISCLAIMSALLWARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR APARTICULAR PURPOSEAND NON-INFRINGEMENT.
KVM SWITCH TECH DOES NOT WARRANT THE ACCURACY, COMPLETENESS OR USEFULNESS OF ANY INFORMATION WITH RESPECT TO THE
PRODUCT. KVM SWITCH TECH DOES NOT WARRANT THAT THE FUNCTIONS PERTAINING TO THE PRODUCT WILL BE ERROR-FREE, THAT DEFECTS
WITH RESPECT TO THE PRODUCT WILL BE CORRECTED, OR THAT THE MATERIALS PERTAINING THERETO ARE FREE OF DEFECTS OR OTHER
HARMFUL COMPONENTS. KVM SWITCH TECH WILL USE ITS REASONABLE EFFORTS TO CORRECT ANY DEFECTS IN THE PRODUCT UPON TIMELY
WRITTEN NOTICE FROM YOU NOT TO EXCEED 10 BUSINESS DAYS AFTER RECEIPT BY YOU OF THE PRODUCT, BUT YOU (AND NOT KVM SWITCH
TECH) ASSUME THE ENTIRE COST OF ALL NECESSARY SERVICING, REPAIR AND CORRECTION THAT WAS CAUSED BY YOU UNLESS OTHERWISE
AGREED TO INASEPARATE WRITING BY KVM SWITCH TECH.
UNDER NO CIRCUMSTANCES, INCLUDING, BUT NOT LIMITED TO, NEGLIGENCE, SHALL KVM SWITCH TECH BE LIABLE FOR ANY SPECIAL OR
CONSEQUENTIALDAMAGESTHATRESULTFROMTHEUSEOF,ORTHEINABILITYTOUSETHEPRODUCTINACCORDANCEWITHITSSPECIFICATIONS,
EVEN IF KVM SWITCH TECH OR ITS REPRESENTATIVES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL KVM
SWITCH’S TOTAL LIABILITY TO YOU FROM ALL DAMAGES, LOSSES, AND CAUSES OF ACTION (WHETHER IN CONTRACT, OR OTHERWISE) EXCEED
THEAMOUNT YOU PAID TO KVM SWITCHTECH, IFANY, FOR THE PRODUCT.
