KVMSwitchTech SCA-VGA-DVI User manual

www.ophit.com
1
Table of Contents
U SER’S MANUAL
1. Introduction …….…………...........................…2
Analog to digital 2. Features ….……………………………………....2
Converter
SCA-VGA-DVI
3. Model name …………………………….………2
4. Panel Descriptions ….………………….………3
5. Package contents .…………………….……….3
6. Installation .……………………………………….4
7. Specification ……………………………………..4
8. Precaution .……………………………………….5
9. Warranty ….……………………………………….6
10. Contact us …………………..…………………….7

www.kvmswitchtech.com
2
www.kvmswitchtech.com
3
U ’ M l
Model N ame
I nput
Output
SCA-VGA-DVI
1 D-sub
1 D-sub
1 DVI
Introduction Panel Descriptions
KVMSwitchTech DVI converter (SCA-VGA-DVI)
transports analog graphic signal of your PC’s to DVI
signal so that your PC and notebook without DVI output
can be connected to digital display devices such as
LCD monitor and projector with DVI input easily and
conveniently.
Front
Back
LED indicator
for Power
LED indicator
for reso lut i o n
Features
• Input : 15pin D-sub(female)
• Output : DVI 24pin(female), 15pin D-sub(female)
• Compatible with DVI standard by DDWG
• Manual screen control key for corresponding to versatile
resolution
• Support up to UXGA resolution
Output port
Package contents
Input por t sPower
po rt
Model name Before you start installing SCA-VGA-DVI, please check the
package contents
• Converter(SCA-VGA-DVI)
• Power Adapter(+5V DC ,2.0A)
• User’s Manual

www.kvmswitchtech.com
4
www.kvmswitchtech.com
5
Input : 15Pin D
f
Operating Temperature Range : 0 to 50 C
Installation
Installation
WARNING
Precaution
1. Connect the VGA source to SCA-VGA-DVI input port.
2. Connect the DVI display to SCA-VGA-DVI output port.
3. Plug the 5V DC power supply. •Do not dismantle the housing or modify the product.
Dismantling the housingor modifying the product may result
in electrical shock or burn.
Specifications
• Connector
- Input : 15Pin D-sub (Female)
- Output : DVI 24Pin (Female) 1 , 15Pin D-sub(Female) 1
• Video Bandwidth : 1.65Gbps (Single Link)
• Supporting Resolution : UXGA (1600X1200)
• Power Consumption : 2.3W
• Power Supply : 100~240V with DC 5V Adapter
• Dimension : 160 X 108 X 25 (mm)
Weight : 467 (g)
• Environment
- Operating Temperature Range : 0 to 50°C
- Storage Temperature Range : -20 to 70°C
•Refer all servicing to qualified service personnel.
Do not attempt to service this product yourself as opening
or removing housing may expose you to dangerous voltage
or other hazards.
•Keep the product away from liquids.
Spilling into the housing may result in fire, electrical shock,
or equipment damage. If an object or liquid falls/spills into
the housing, unplug the product immediately.
Have the product checked by a qualified service engineer
before using it again.
•Do not touch the Product with wet hands.
Touching the housing and plug with wet hands is dangerous
and can cause electrical shock.

www.kvmswitchtech.com
6
www.kvmswitchtech.com
7
Warranty Contact us
We, KVMSwitchTech hereby warrant the final purchase of our product as
follows.
In the case of troubles on our products, please contact the shop purchased.
One(1) year limited warranty
Our customers have right to be served with free charge when
there is trouble in this product during one(1) year from the day
purchased.
Out of warranty services
KVMSWITCHTECH
www.KVMSwitchTech.com
E-mail : [e-mail]
When you request services (in the case of non manufacturing
defect but the troubles by misusage), may served with charge
of follows.
• Defects of products caused by accident , disaster.
• Damages of products caused by the customer’s carelessness or
mistaken application.
• Damages of products caused by the application of parts or
products not supplied or sold by our company.
• Damages of products and related defects caused by not our staff
or the man or group not nominated by us for services.
REVISION VERSION 1.0
