KVMSwitchTech SCA-DVI-ANA-UN User manual

User’s Guide
DVI to VGA Converter
SCA-DVI-ANA-UN
Thank you for purchasing SCA-DVI-ANA-UN
SCA-DVI-ANA-UN, This unique DVI Converter transports your DVI signal to analog graphic signal so that
display devices without DVI input can be connected to your PC and notebook with DVI output easily and
conveniently. www.kvmswitchtech.com

User’s Guide
EDID Switch Setting Application
EDID Setting: Mode is set on ETC when shipping
Resolution
Description
1 X G A
Internal EDID Set to 1024 x 768 @ 60Hz Mode.
2 S X G A
Internal EDID Set to 1280 x 1024@ 60Hz Mode.
3 S X G A +
Internal EDID Set to 1400 x 1050@ 60Hz Mode.
4 W S X G A +
Internal EDID Set to 1680 x 1050@ 60Hz Mode.
5 U X G A
Internal EDID Set to 1600 x 1200@ 60Hz Mode.
6 7 20P( HD )
Internal EDID Set to 1280 x 720 @ 60Hz Mode.
7 1080P(FULL HD)
Internal EDID Set to 1920 x 1080@ 60Hz Mode.
8 E T C
Mode that reads Analog EDID from monitor that’s connected
toVGAportandtransferstoDigitalEDID.
Use setting switchto set resolutionsafter trying SCA-DVI-ANA-UN onETCmode, if SCA-
DVI-ANA-UN operates normally on ETC mode you don’t have to change EDID
setting.
1. Disconnect power adapter andcablesfrom SCA-DVI-ANA-UN before setting EDID
switch.
2. Set EDID switch as shown on back of SCA-DVI-ANA-UN.
3. When EDID setting is ready connect power adapter and cables.
4. On ETC mode there can be compatibility issues, in this case setting one of
No.1~No.7 is recommended.

www.kvmswitchtech.com
Warranty
We, KVMSwitchTech hereby warrant the final purchase of our product as follows.
In the case of troubles on our products, please contact the shop purchased.
One year limited warranty
Our customers have right to be served with free of charge when there is trouble in this product during 1(one) year from the day purchased.
Out of warranty services
When you request services (in the case of non manufacturing defects but the troubles by misusage), may served with charge as follows.
- Defects of products caused by accident, disaster.
- Damages of products caused by the customer’s carelessness or mistaken application.
- Damages of products caused by the application of the parts or products not supplied or sold by our company.
- Damages of products and related defects caused by not our staff or the men or group not nominated by us for services.
The interchanged parts and products for maintenance services shall be replaced as new parts and products operating
normally, and the inter-changed parts and products shall be subjected to our company.

www.kvmswitchtech.com
RMA Request Form
RMA No.:
Customer Name:
Return Date:
Company Name:
Phone:
Model Name:
E-Mail:
Serial No:
Place of Purchase:
Address: (For RMA Return)
RMA details: (Please describe RMA status, application used and failure symptom)

REV. 1.0
Di str i b ute d By:
KVMSwitchTech
118 W. Market St., Suite 125
Hudson, OH 44236
Toll Free: 1 [phone]
[e-mail]
www.kvmswitchtech.com
