KVMSwitchTech SCA-DVI-VGA User manual

Table of Contents
U SER’S MA NUAL
Digital to Analog
Converter
SCA-DVI-VGA
1. Introduction …….…………...........................…2
2. Features ….……………………………………....2
3. Model name …………………………….………2
4. Panel Descriptions ….………………….………3
5. Package contents .…………………….……….3
6. Installation .……………………………………….4
7. Specification ……………………………………..4
8. Precaution .……………………………………….5
9. Warranty ….……………………………………….6
10. Contact us …………………..…………………….7
www.kvmswitchtech.com 1

Introduction
Panel Descriptions
2
www.kvmswitchtech.com
www.kvmswitchtech.com
3
Model N ame
Input
Outpu t
SCA-DVI-VGA
DVI 24pin
D-sub 15pin
This unique DVI converter transports your PC’s DVI
signal to analog graphic signal so that analog display
devices without DVI output can be connected to your PC
and notebook with digital output easily and conveniently.
VGA(male) Output
Features
• Input Connector : DVI 24pin-Single Link (female)
• Output Connector : 15pin D-sub (male)
• Compatible with DVI standard by DDWG
• External power supply is available
• Support up to WUXGA, 1080p resolution
DVI(female) Inpu t
Package contents
Power supply(Optional)
• HDCP Compliant
Model name
Before you start installing SCA-DVI-VGA, please check the
package contents.
• Digital to Analog Converter (DDA)
• User’s Manual
• Power adapter(5V,2A) is optional (It’s not included in the package)
: If your source device does not supply enough power to DDA,
you may need power supply. Please inform us before order.

Ins t allation
Precaution
4
www.kvmswitchtech.com
www.kvmswitchtech.com
5
1. Connect DVI source to the converter’s DVI input using
user supplied DVI cable.
2. Connect VGA monitor to the converter’s VGA output.
3. Plug the external 5V DC power adapter optionally.
Specifications
• Connector
- Input : DVI 24Pin (female)
- Output : 15Pin D-sub(male)
• Video Bandwidth : 1.65Gbps (Single Link)
• Supporting Resolution : Up to WUXGA(1920x1200), 1080p
• Power Consumption : 0.54W (Max)
• Length : 350mm
• Power Adapter(+5V DC, 2A) is optional
• Environment
- Operating Temperature Range : 0 to 50 ° C
- Storage Temperature Range : -20 to 70 ° C
WARNING
•Do not dismantle the housing or modify the product.
Dismantling the housing or modifying the product may result
in electrical shock or burn.
•Refer all servicing to qualified service personnel.
Do not attempt to service this product yourself as opening
or removing housing may expose you to dangerous voltage
or other hazards.
•Keep the product away from liquids.
Spilling into the housing may result in fire, electrical shock,
or equipment damage. If an object or liquid falls/spills into
the housing, unplug the product immediately.
Have the product checked by a qualified service engineer
before using it again.
•Do not touch the Product with wet hands.
Touching the housing and plug with wet hands is dangerous
and can cause electrical shock.

Warranty
Contact us
6
www.kvmswitchtech.com
www.kvmswitchtech.com
7
We, KVMSwitchTech hereby warrant the final purchase of our product as
follows.
In the case of troubles on our products, please contact the shop purchased.
One(1) year limited warranty
Our customers have right to be served with free charge when
there is trouble in this product during one(1) year from the day
purchased.
Out of warranty services
When you request services (in the case of non manufacturing
defect but the troubles by misusage), may served with charge
of follows.
• Defects of products caused by accident, disaster.
• Damages of products caused by the customer’s carelessness or
mistaken application.
• Damages of products caused by the application of parts or
products not supplied or sold by our company.
• Damages of products and related defects caused by not our staff
or the man or group not nominated by us for services.
KVMSwitchTech
www.KVMSwitchTech.com
E-mail : [e-mail]
Revision version 1.0
