Kyocera TJEP 24/30-4 Guide

www.tjep.eu
UK Safety and operation instructions
Maintenance and trouble shooting
BG Инструкции за безопасност и работа
Поддръжка и отстраняване на неизправности
DA Sikkerheds- og driftsvejledning
Vedligeholdelse og fejlfinding
DE Sicherheits- und Bedienungsvorschriften
Instandhaltung und Fehlerbehebung
EE Ohutus- ja kasutusjuhised
Hooldus ja tõrkeotsing
FR Instructions de sécurité et d’utilisation
Maintenance et dépannage
IS Öryggis- og notkunarleiðbeiningar
Viðhald og bilanaleit
LT Saugos ir naudojimo instrukcijos
Priežiūra ir trikčių šalinimas
NL Veiligheids- en bedieningsinstructies
Onderhoud en probleemoplossing
NO Sikkerhets- og bruksanvisning
Vedlikehold og feilsøking
PL Instrukcja bezpieczeństwa i obsługi
Konserwacja i rozwiązywanie problemów
RO Instrucțiuni de siguranță și operare
Întreținere și depanare
SE Säkerhets- och driftinstruktioner
Underhåll och felsökning
SK Bezpečnostné a prevádzkové pokyny
Údržba a riešenie problémov
SL Varnostna navodila in navodila za uporabo
Vzdrževanje in odpravljanje težav
TJEP 24/30-4

www.tjep.eu
EXPLORE OUR WEBSITE FOR
MORE INFORMATION

UK Drawing and spare parts................................................................................4
Key parts and gures .....................................................................................8
UK English............................................................................................................9
BG Български....................................................................................................17
DA Dansk ...........................................................................................................26
DE Deutsch ........................................................................................................34
EE Eesti..............................................................................................................43
FR Français........................................................................................................51
IS Íslenska ........................................................................................................59
LT Lietuvis.. .......................................................................................................67
NL Nederlands...................................................................................................75
NO Norsk ............................................................................................................83
PL Polski............................................................................................................91
RO Română........................................................................................................99
SE Svenska......................................................................................................107
SK Slovenský................................................................................................... 115
SL Slovenščina................................................................................................123
3

4
TJEP 24/30-4

English
5
Spareparts
ITEM
NO.
PART NO. DESCRIPTION
1 BQL201.39.14 Self-Tapping Screw
ST3.9x14F
2 CE0902S.00.07 Clamp
3 CE0917S.30.00 Heat Shroud
4 BQL201.04.05 Screw M4×17
5 TATF04.03.05 Elbow Fitting
6 TAF101.01.01 Air Filter
7 FAQG01.01.02 Mu󰀪er
8 M14000Kal.00.00 Motor Pump Assembly
9 TATF02.03.12 Metal Tube
10 TARP01.02.07 Cushion Pad
11 BQN208.01.01 Nut M8
12 TQDX23.01.DX Connecting line
13 CE0929W.00.01 Solenoid Valve
14 TAVA02.CV.05 Check Valve
15 TAWH03.06.02 Wheel
16 BQL494.10.05 Shoulder Bolt
17 BQW210.01.01 Spring Washer Ø10
18 BQN110.01.01 Flange Nut M10
19 AT2305.00.00 Tank
20 CE0505W.00.03 Latch Assembly
21 TAVA02.DV.06 Drain Valve
22 TARP01.01.02 Rubber Foot
23 BQL494.10.01 Screw M10x20
24 TATF05.03.03 End Cap
25 BQW110.01.02 Washer Ø10
26 CE0901S.00.02 Capacitor xing ring
27 TACA22.45.08 Capacitor
28 CC1221W.00.01 Handle
29 TQJC03.01.02 Crimp Cap
30 TAGJ03.03.90 Quick Coupler
31 TAVA01.SV.02 T-junction
32 TAFA01.TY.T0 Pressure Regulator
ITEM
NO.
PART NO. DESCRIPTION
33 TQDX23.02.DX connecting line
34 TATF07.01.02 Straight Connector
35 TQDX23.03.PL Power Cord
36 TAPGRA.40.02 Pressure Gauge
37 TASWPS.00.27 Pressure Switch
38 TAFA01.AQ.30 Safety Valve
39 TAPGAX.40.02 Pressure Gauge
40 TQJC03.01.03 Crimp Cap
41 CC1103W.00.02 Clamp
42 BQL204.48.01 Self-Tapping Screw
ST4.8x14F
43 CE0902S.00.06 Capacitor Shroud

6
TJEP 24/30-4 - motor

English
7
Spareparts - motor
ITEM
NO.
PART NO. DESCRIPTION
1 Q5531996001 End Cover
2 J3642450022 Circlip φ13
3 Q5537046001 Motor Fan B
4 J0782360022 Screw M8x10
5 J0781650464 Screw M4x8
6 J0656000170 Press Plate
7 X5530820229 Gasket O-Ring
8 J0645990198 Valve Flake
9 P5713072014 Valve Plate
10 J7663900198 Valve Flake
11 J3566010170 Limiter
12 X5530820231 Gasket Seal Ring
13 P5710412014 Head
14 J0195790040 Spring Washer φ6
15 J0786040157 Screw M6x50
16 J6993210289 Bushing
17 J0945970152 Cylinder
18 J1763720216 Bearing
19 A5562070649 Stator
20 X5530820250 Pipe O-Ring
21 J7026070152 Pipe
22 J7426030157 Cap
23 J0784910040 Screw M6x16
24 J6535950070 Rod Cover
25 X5532600228 Piston Ring
26 J0725940070 Rod
27 Q5537036001 Motor Fan A
28 J0784830022 Screw M8x15
29 J0780560032 Screw M5x8
30 J2981200040 Lock Washer φ5
31 P5716962014 Crankcase A
32 J1226050170 Plate
33 J0786210032 Screw M4x8
ITEM
NO.
PART NO. DESCRIPTION
34 A5532060635 Rotor
35 J0805930157 Screw M5x120
36 X5535630230 Crankcase Plug
37 J0190730040 Spring Washer φ5
38 P5716972014 Crankcase B
39 J1762350197 Bearing
40 J3535960065 Crank

8
Figures
Fig. A
2
3
1
31 cm
Fig. B
2
1
Fig. C
1
ON/OFF
Fig. D
1
OFF
ON
Fig. E
1
Fig. F Fig. G Fig. H
2
1
OFF
ON
Fig. I
Key parts
A
K
B
D
E
G
H
F
I
J
C

English
9
IMPROPER AND UNSAFE USE OF THE COMPRESSOR CAN RESULT IN DEATH OR SERI-
OUS INJURY. IT IS VERY IMPORTANT THAT THE INTENDED OPERATOR OF THE COM-
PRESSOR READS AND UNDERSTANDS THIS MANUAL BEFORE OPERATING THE
COMPRESSOR. KEEP THIS MANUAL AVAILABLE FOR OTHERS BEFORE THEY USE THE
COMPRESSOR.
Please keep this manual in safe place for future reference.
Important safety information
The manufacturer cannot possibly anticipate every possible circumstance that might involve a hazard. The warn-
ings in this manual, and the tags and decals a󰀩xed to the compressor are, therefore, not exhaustive. If you use
a procedure, work method, or operating technique that the manufacturer does not specically recommend, you
must make sure that it is safe for you and others. You must also make sure that the procedure, work method, or
operating technique that you choose does not render the compressor unsafe.
Figures
Please nd the relevant gures referenced in the instructions on page 8.
Table of content
Important safety information ............................................................................................................................. 8
Figures ............................................................................................................................................................... 8
Technical specications .................................................................................................................................... 9
Tool application.................................................................................................................................................. 9
Declaration of conformity .................................................................................................................................. 9
Explanation of symbols.................................................................................................................................... 10
Key parts ...........................................................................................................................................................11
General safety warnings...................................................................................................................................11
Assembly instructions.......................................................................................................................................12
Positioning of the air compressor ................................................................................................................12
Connect air hose to compressor..................................................................................................................12
Operating instructions ......................................................................................................................................12
Break in the pump ........................................................................................................................................12
Before each start-up.....................................................................................................................................12
How to start ..................................................................................................................................................12
How to shut down .........................................................................................................................................12
Maintenance .....................................................................................................................................................13
How to drain tank..........................................................................................................................................13
How to clean the air lter..............................................................................................................................13
Storage .........................................................................................................................................................13
Trouble shooting ...............................................................................................................................................14
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
TJEP 24/30-4
SAFETY AND OPERATION INSTRUCTIONS
MAINTENANCE AND TROUBLE SHOOTING

10
Technical specications
Technical info. TJEP 24/30-4
Tank size 24 L
Power 230V 50Hz 2×1.5 HP/2400W
RPM 1400
Rating Amps 11
Working pressure 8.0-10.0 bar
Motor type Induction
Oil free/Oil lube Oil-free
Quick coupler 2
Pressure switch 10 bar
Drain valve Ball valve
Duty cycle 50%
LPA 68.80 dBA
LWA 82.80 dBA
As we are constantly developing and improving our products, the information in this overview is subject to change without notice.
Updated information can be found at www.tjep.eu
Tool application
• Pneumatic nailers and staplers
Declaration of conformity
We;
Suzhou Alton Electrical & Mechanical Industry Co., Ltd, N.Linhu Road, E.Laixiu Road, Foho Hi-tech Development Zone, Suzhou 215211,
Jiangsu,China
declare under our sole responsibility that the;
TJEP 24/30-4 compressor
conforms with the directive(s), its amedment(s) and standard(s);
2014/30/EU, 2006/42/EC, 2011/65/EU+(EU)2015/863.
EN 1012-1:2010, EN 60204-1:2018, EN 55014-1:2017, EN 55014-2:2015, EN 61000-3-2:2014, EN 61000-3-3:2013/A1:2019
Notied Body: CEM International Ltd Westmead House, Westmead Farnborough, Hampshire, GU14 7LP UK(1942)
Authorized contact in EU to compile the Technical File;
KGK A/S, Møllevej 9 - H2, DK-2990 Nivå, Tel: [phone], Mr. Måns Spånberg
Serial number can be found on the front page.
Document ref. No. ZD202010 · Date: 10/08/2020
David Lu
Director, Suzhou Alton Electrical & Mechanical Industry Co., Ltd, Jiangsu,China

English
11
Explanation of symbols
Symbols in manual
!
The safety alert symbol indicates a potential hazard to personal injury. A signal word (DANGER,
WARNING, or CAUTION) is used with the alert symbol to designate a degree or level of hazard
seriousness. A safety symbol may be used to represent the type of hazard.
The signal word NOTICE is used to address practices not related to personal injury.
DANGER: Indicates a hazard which, if not avoided, will result in death or serious injury.
WARNING: Indicates a hazard which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a hazard which, if not avoided, could result in minor or moderate injury.
Read and understand compressor labels and manual. Failure to follow warnings could result in
serious injury.
Operators and others in work area shall wear impact-resistant eye protection with side shields.
Operators and others in work area shall wear hearing protection.
It is recommended that operator and others in work area wear CE-marked helmet at the job site.
Symbols on compressor
Read and understand compressor
labels and manual. Failure to follow
warnings could result in serious injury.
This compressor is CE-approved
according to applicable standards.
Dispose product according to the
WEEE directive.
The product complies with RoHS
regulations
Tank capacity
RPM Rounds per minute
MAX Maximum pressure
Power consumption
Risk of bursting tank if operating above
maximum operating pressure.
Risk of re. Never operate near am-
mable gasses or vapor.
Risk of accidental start-up in case of a
black-out and subsequent reset. Keep
clear of rotating parts.
Risk of eye injury. Always wear CE-ap-
proved safety glasses when operating
the compressor.
Risk of electrical shock could result in
death or serious injury. Only connect
the compressor to a properly grounded
receptacle.
Risk of high temperatures
Pressure discharge. Keep body parts
and bystanders away
2× 2424 Drain tank min 2 times a day.

12
Key parts
Parts description - see drawing on page 8
AAIR COMPRESSOR PUMP: The pump compresses the air and discharges it into the tank via the piston
that moves up and down in the cylinder.
B
ELECTRIC MOTOR: The motor is used to power the pump. It is equipped with a thermal overload
protector. If the motor overheats for any reason, the thermal overload protector will shut it down in order
to prevent the motor from being damaged.
CSAFETY VALVE: This valve is used to prevent the compressor from building too much pressure. If the
pressure reaches the preset level in the tank, it will automatically pop open.
D
PRESSURE SWITCH: This switch turns on the compressor and is operated manually. When in the
ON position, it allows the compressor to start up or shut down automatically, without warning, upon air
demand. ALWAYS set this switch to OFF when the compressor is not being used and before unplugging
the compressor.
E
PRESSURE REGULATOR: The regulator is used to adjust the pressure inside the line to the tool that
is being used. Turn the knob clockwise to increase the pressure and counter-clockwise to decrease the
pressure.
FTANK PRESSURE GAUGE: The gauge measures the pressure level of the air that is stored in the tank.
It cannot be adjusted by the operator and it does not indicate the pressure inside the line.
GOUTLET PRESSURE GAUGE: The gauge measures the regulated outlet pressure.
HQUICK COUPLER: The quick coupler is connected to a quick connector which is connecting to air hose.
IDRAIN VALVE: The drain valve is used to remove moisture from the air tank after the compressor is
shut o󰀨.
JAIR TANK: The tank is where the compressed air is stored.
K
POWER CORD: This product is for use on a nominal 230-volt circuit and should be grounded. A cord
with a grounding plug must be used. Make sure that the product is connected to an grounded outlet that
has the same conguration as the plug (see Fig. A). No adapter should be used with this product. Check
with a licensed electrician if the grounding instructions are not understood or there is doubt as to whether
the product is properly grounded. If the plug does not t the outlet, have a proper grounded plug installed
by a licensed electrician.
!DANGER:
Improper installation of the grounding plug will result in
a risk of electric shock. If repair or replacement of the
cord or plug is necessary, do not connect the ground-
ing wire to either at blade terminal. The outer surface
of grounding wire is mixed with yellow and green.
General safety warnings
• Do not operate the compressor until you have
read and understand this instruction manual for
safety, operation and maintenance instructions.
WARNING:
• Risk of re caused by sparks from motor and pres-
sure switch could result in death or serious injury.
• Do not operate compressor near ammable gas
or vapor. Never store ammable liquids or gas in
vicinity of compressor.
• High pressure air could result in death or serious
injury. Shut o󰀨 unit, unplug and release air pressure
prior to servicing.
• Never operate above maximum operating pressure
of the nailer/stapler.
• Drain water from tank after each use.
• Do not weld or repair tank.
• Do not operate with pressure switch or safety valve
set above maximum allowable working pressure.
• Hot compressors surfaces could result in serious
injury. Allow compressor to cool before touching.
• Using compressor to supply breathing air could
result in death or serious injury.
• Do not spray ammable materials in vicinity of any
ame or ignition sources including the compressor.
• Do not restrict compressor ventilation openings or
place objects against or on top of the compressor
• Operate compressor only in a clean, dry, well
ventilated area.
• Do not operate unattended. Always turn o󰀨 and
unplug the compressor when not in use.
• Risk of serious eye injury from moisture
and debris. Operators and others in work area
!

English
13
shall wear CE approved and impact-resistant eye
protection with side shields when working with the
compressor and/or opening the drain valve.
• Do not spray any part of the body.
• Shock risk could result in death or serious injury.
Only connect the compressor to a properly ground-
ed receptacle.
• Dust can be created when cutting, sanding,
drilling or grinding materials such as wood, paint,
metal, concrete, cement, or other masonry. To
reduce your exposure to these chemicals, work in
a well ventilated area and ALWAYS wear approved
safety equipment.
• KEEP CHILDREN AWAY FROM THE COMPRES-
SOR AT ALL TIMES.
CAUTION:
• High pressure air containing water condensation
could result in minor or moderate injury. Do not
spray at any person.
NOTICE:
• If the pump has been transported or turned upside
down (even partially), allow the pump to sit in a nor-
mal, upright position for approximately 10 minutes
before starting.
Assembly instructions
• Unpack the compressor. Inspect the compressor
for damages. If the compressor has been damaged,
contact your TJEP dealer immediately.
• Check the air compressor’s identication label to ensure
that you have purchased the intended model and that it
has the required pressure rating for its intended use.
• The carton should contain the compressor and
these safety and operation instructions.
Positioning of the air compressor
1. Position the air compressor (1) near an electrical
outlet (2) (Fig. B).
2. The compressor must be at least 31 cm from any
wall (3) or obstruction, in a clean, well-ventilated area
to ensure su󰀩cient air ow and cooling (Fig. B).
3. Place the compressor on the oor or a hard, level
surface.The compressor must be level to ensure prop-
er drainage of the moisture in the tank.
Connect air hose to compressor
1. Connect the air hose (1) to the compressor’s quick
coupler (2) (Fig. C).
Operating instructions
Break in the pump
1. Set the pressure switch (1) to the OFF position (Fig. D).
2. Open tank drain valve (1) by turning it counter-clock-
wise to permit the air to escape and prevent air
pressure build-up in the air tank during the break-in
period (Fig. E).
3. Turn the pressure knob (1) clockwise until it stops
(Fig. F).
4. Plug in the power cord
∙Use a dedicated circuit. The compressor will
use the full capacity of a typical 10A household
circuit. If any other electrical devices are drawing
from the compressor’s circuit, the compressor
may fail to start or an overload circuit can result
in sluggish starting that causes the motor over-
load protection system or circuit breaker to trip,
especially in cold conditions.
∙Disconnect the power cord only after break-in
process has been completed, otherwise the
motor might get damaged.
5. Set the pressure switch (1) to the ON position (Fig.
D). The compressor will start. Run the compressor for
30 minutes. If it fails, turn it o󰀨 immediately and contact
your local TJEP-dealer.
Please note that breaking-in the unit is only required
prior to rst use.
6. After 30 minutes, turn o󰀨 the pressure switch.
7. Close the tank drain valve (1) by turning it clockwise
(Fig. E).
8. Set the pressure switch to the ON position. (Fig. D)
The air receiver will ll to “cut-out” pressure and then
the compressor’s motor will stop. The compressor is
now ready for use.
Before each start-up
1. Set the pressure switch (1) to the OFF position (Fig.
D).
2. Turn the pressure regulator knob (1) counterclock-
wise until it stops (Fig. F).
3. Attach hose and accessories (Fig. C).
How to start
1. Close the tank drain valve (1) (Fig. I)
2. Plug-in the power cord (2) (Fig. I)
3. Set the pressure switch to the ON position and allow
the tank pressure to build (Fig. D). Motor will stop
when tank pressure reaches cut-out pressure.
4. Turn the air pressure regulator knob clockwise until
desired pressure is reached (Fig. F).
5. The compressor is ready for use.
How to shut down
1. Set the pressure switch (1) to the OFF position
(Fig. D).
2. Unplug the power cord (2) (Fig. I).
3. Set the tank drain valve (1) to ON to ensure the tank
is drained (Fig E).
!

14
Maintenance
Item Description / reason Service
interval
Drain the
tank
Through normal operation of your
compressor, condensation of water
will accumulate in the tank. To prevent
corrosion of the tank from the inside,
condensation must be drained twice a
day. Be sure to wear safety glasses.
Relieve the air pressure in the system
then open the drain valve on the bottom
of the tank to drain. Under cold condi-
tions it is especially important to drain
the tank after each use to reduce the
chance of problems resulting from the
freezing of condensation water.
NOTE: Refer to instructions on how to
drain tank.
Twice a
day
Test for
leaks
Check that all connections are tight.
Small leaks in the tank, hoses, connec-
tions or transfer tubes will substantially
reduce the compressor and tool perfor-
mance. Spray a small amount of soapy
water around the area of suspected
leaks with a spray bottle. If bubbles
appear, repair, replace or reseal the
faulty component. Do not over-tighten
any connections.
Monthly
Clean the
air lter
A dirty air lter will reduce compressor
performance and life. To avoid contam-
inating the pump, the lter should be
cleaned frequently and replaced on a
regular basis. Clean the cartridge lter
by blowing on it with a blow gun.
NOTE: Refer to instructions on how to
clean the air lter.
Weekly
How to drain tank
1. Set the pressure switch (1) to the OFF position (Fig.
D).
2. Unplug the power cord (2) (Fig. I).
3. Turn air pressure regulator knob counter-clockwise
to set the outlet pressure to zero (Fig. F)
4. Place suitable container under unit to catch water.
5. Slightly tilt unit and gently turn drain valve coun-
ter-clockwise to open. (Fig. G)
6. After the water has been drained,close the drain
valve (clockwise) (Fig. G). The air compressor can now
be stored.
How to clean the air lter
A dirty lter will reduce the unit s performance and life.
To avoid any contamination inside the pump, the lter
should be cleaned weekly and replaced on a regular
basis. The cartridge lter should be cleaned with blow
gun (Fig. H).
Storage
Before storing the air compressor:
1. Drain tank
2. Use an air blow gun to clean all dust and debris from
the compressor.
3. Disconnect and wind up the power cord.
4. Clean the ventilation openings on the motor enclo-
sure with a damp cloth.
5. Drain all moisture from the tank.
6. Open the drain valve to release all pressure from
the tank.
WARNING:
• Storage covers could cause a re resulting in death
or serious injury.
• Do not place a storage cover over a hot air com-
pressor.
• Let equipment cool for a su󰀩cient time before plac-
ing the cover on the equipment.
• Store the air compressor in a clean and dry loca-
tion.
• In cold weather, store the compressor in a warm
building when it is not in use. This will reduce prob-
lems related to starting the motor and the freezing
of water condensation.
!

English
15
Trouble shooting
Problem Possible cause Solutions
The motor will not run or start
The power cord is not
plugged in. Plug the power cord into a grounded outlet.
The pressure switch is in the
O (OFF) position. Set the pressure switch to the ON position.
The extension cord is the
wrong wire gauge or is too
long.
Check extension cord information for the proper wire gauge and
cord length.
The motor’s thermal overload
protection has tripped.
Turn the air compressor o󰀨, unplug the power cord and wait until the
motor has cooled down. Plug in the power cord only after the motor
has cooled down, and wait at least 5 minutes to make sure the
thermal overload protector has recovered.
A fuse has blown or a circuit
breaker has been tripped.
Replace the fuse or reset the circuit breaker.
Verify that the fuse has the proper amperage.
Check for low voltage conditions.
Disconnect any other electrical appliances from the circuit or oper-
ate the compressor on a dedicated circuit.
The air tank pressure
exceeds the preset pressure
switch limit.
The motor will start automatically when the tank pressure drops
below the cut-in pressure.
The safety valve is stuck
open. Clean or replace the safety valve.
Electrical connections are
lose. Contact your TJEP dealer for repair
The motor, capacitor or safety
valve is defective. Contact your TJEP dealer for repair
The motor runs continuously
when the pressure switch is in
the ON position.
The pressure switch does
not shut o󰀨 the motor when
the air compressor reaches
the cut-out pressure and the
safety valve activates.
Set the pressure switch to the OFF position. If the motor does
not shut o󰀨, unplug the air compressor. If the pressure switch is
defective, replace it.
The compressor’s capacity is
not enough.
Check the air requirements of the accessory that is being used. If it
is higher than the air ow (litre per minute) and pressure supplied by
the compressor, a larger capacity compressor is needed.
The regulator does not
regulate the pressure.
The regulator or its internal
parts are dirty or damaged. Replace the regulator.

16
Problem Possible cause Solutions
The pressure is low or there is
not enough air.
There is a leak at one of the
ttings.
Check the ttings with soapy water. Tighten or reseal leaking ttings
(apply plumber s tape on threads). Do not over tighten.
The tank drain valve is open. Close the drain valve.
The air intake is restricted. Clean or replace the air lter elements.
Prolonged excessive use
of air. Decrease the amount of air used.
There is a hole in the air
hose. Check the air hose and replace it if necessary.
The tank leaks. Replace the tank immediately. Do not attempt to repair it.
The valve is leaking. Check for worn parts and replace them if necessary.
There is moisture in the
discharge air.
There is condensation in the
air tank caused by a high
level of atmospheric humidity
or because the compressor
has not been running long
enough.
Drain the air tank. Drain the air tank more often in humid weather
and use an air-line lter.
The compressor overheats.
The ventilation is inadequate. Relocate the compressor to an area with cool, dry and well-circu-
lated air.
Cooling surfaces are dirty. Clean all cooling surfaces on the pump and the motor thoroughly.
The valve is leaking. Replace worn parts and reassemble using new plumber’s tape.
For failure other than above situations, please stop using the compressor and contact your local TJEP dealer for service.

Български
17
ИЗПОЛЗВАНЕТО НА КОМПРЕСОРА ПО НЕПРАВИЛЕН ИЛИ ОПАСЕН НАЧИН МОЖЕ ДА
ДОВЕДЕ ДО СМЪРТ ИЛИ СЕРИОЗНО НАРАНЯВАНЕ. МНОГО Е ВАЖНО ПОТРЕБИТЕ-
ЛЯТ, КОЙТО ЩЕ ИЗПОЛЗВА КОМПРЕСОРА, ДА ПРОЧЕТЕ И РАЗБЕРЕ ТОВА РЪКОВОД-
СТВО, ПРЕДИ ДА ЗАПОЧНЕ РАБОТА С КОМПРЕСОРА. АКО ДРУГИ ХОРА ЗАПОЧВАТ ДА
ИЗПОЛЗВАТ КОМПРЕСОРА, ОСИГУРЕТЕ ИМ ДОСТЪП ДО РЪКОВОДСТВОТО ПРЕДИ
ТОВА.
Пазете това ръководство на безопасно място за бъдеща справка.
Важна информация за безопасност
Производителят не може по никакъв начин да предвиди всички възможни случаи, които може да
включват опасност. Следователно предупрежденията в това ръководство, както и етикетите и марки-
ровките, прикрепени към компресора, не са изчерпателни. Ако използвате процедура, работен метод
или оперативна техника, която производителят не препоръчва специално, трябва да се уверите, че това
е безопасно за вас и другите. Трябва също така да гарантирате, че процедурата, работният метод или
оперативната техника, която избирате, не предизвиква небезопасна работа на компресора.
Изображения
Намерете съответните фигури, споменати в инструкциите на страница 8.
Съдържание
Важна информация за безопасност ........................................................................................................... 16
Изображения.................................................................................................................................................. 16
Технически спецификации............................................................................................................................17
Приложение на инструменти ........................................................................................................................17
Декларация за съответствие........................................................................................................................17
Описание на символите ................................................................................................................................18
Ключови части ................................................................................................................................................19
Общи предупреждения за безопасност......................................................................................................19
Монтажни инструкции................................................................................................................................... 20
Позициониране на въздушния компресор ............................................................................................ 20
Свържете маркуча за въздух към компресора..................................................................................... 20
Инструкции за работа ................................................................................................................................... 20
Пускане в експлоатация на помпата...................................................................................................... 20
Преди всяко стартиране .......................................................................................................................... 21
Начин на стартиране ................................................................................................................................ 21
Как се изключва......................................................................................................................................... 21
Поддръжка...................................................................................................................................................... 21
Начин на дрениране на резервоара....................................................................................................... 21
Начин на почистване на въздушния филтър........................................................................................ 22
Съхранение................................................................................................................................................ 22
Отстраняване на неизправности ................................................................................................................ 23
ПРЕВОД НА ОРИГИНАЛНИТЕ ИНСТРУКЦИИ
TJEP 24/30-4
ИНСТРУКЦИИ ЗА БЕЗОПАСНОСТ И РАБОТА
ПОДДРЪЖКА И ОТСТРАНЯВАНЕ НА НЕИЗПРАВНОСТИ

18
Технически спецификации
Техническа информация TJEP 24/30-4
Размер на резервоара 24 L
Захранване 230V 50Hz 2× 1,5 HP/ 2400W
RPM 1400
Номинални ампери 11
Работно налягане 8,0-10,0 bar
Тип мотор Индукционен
Безмаслен/Смазочно масло Безмаслен
Бързосменен адаптер 2
Превключвател за налягане 10 bar
Дренажен клапан Сферичен кран
Режим на работа 50%
LPA 68,80 dBA
LWA 82,80 dBA
Тъй като непрекъснато развиваме и подобряваме нашите продукти, информацията в този общ преглед подлежи на
промени без уведомление за това. Актуализираната информация може да се намери на www.tjep.eu
Приложение на инструменти
• Пневматични такери и телбоди
Декларация за съответствие
Ние;
Suzhou Alton Electrical & Mechanical Industry Co., Ltd, N.Linhu Road, E.Laixiu Road, Foho Hi-tech Development Zone, Suzhou 215211,
Дзянсу, Китай
декларираме на своя еднолична отговорност, че;
компресорът TJEP 24/30-4
съответства на директивите, техните изменения и стандарти;
2014/30/EU, 2006/42/EC, 2011/65/EU+(EU)2015/863.
EN 1012-1:2010, EN 60204-1:2018, EN 55014-1:2017, EN 55014-2:2015, EN 61000-3-2:2014, EN 61000-3-3:2013/A1:2019
Нотифициран орган: CEM International Ltd Westmead House, Westmead Farnborough, Хемпшир, GU14 7LP Обединеното кралство
(1942)
Упълномощен контакт в ЕС за окомплектоване на Техническата информация;
KGK A/S, Møllevej 9 - H2, DK-2990 Nivå, Тел: [phone], г-н Måns Spånberg
Серийният номер може да се намери на заглавната страница.
Референтен номер на документа ZD202010 · Дата: 08.10.2020 г.
David Lu
директор, Suzhou Alton Electrical & Mechanical Industry Co., Ltd, Jiangsu, Китай

Български
19
Описание на символите
Символи в ръководството
!
Предупреждаващият символ за безопасност указва потенциална опасност от нараня-
ване. Сигнална дума (ОПАСНОСТ, ПРЕДУПРЕЖДЕНИЕ или ВНИМАНИЕ) се използва с
предупреждаващия символ, за да обозначи степен или ниво за сериозност на опасността.
Символът за безопасност може да се използва за представяне на типа опасност.
Сигналната дума БЕЛЕЖКА се използва за насочване към практики, които не са свързани
с телесна повреда.
ОПАСНОСТ: Указва опасност, която, ако не бъде избегната, ще причини смърт или сериоз-
на телесна повреда.
ПРЕДУПРЕЖДЕНИЕ: Указва опасност, която, ако не бъде избегната, може да причини
смърт или сериозна телесна повреда.
ВНИМАНИЕ: Указва опасност, която, ако не бъде избегната, може да причини лека или
средна телесна повреда.
Прочетете и разберете ръководството и етикетите на компресора. Несъблюдаването на
предупрежденията може да доведе до сериозно нараняване.
Операторите и другите лица в работната област трябва да носят устойчиво на удари обо-
рудване за защита на очите със странични щитове.
Операторите и другите лица в работната област трябва да носят защита за слуха.
Препоръчва се операторът и другите лица в работната област да носят маркиран по CE
шлем на работния обект.
Символи на компресора
Прочетете и разберете ръковод-
ството и етикетите на компресора.
Несъблюдаването на предупрежде-
нията може да доведе до сериозно
нараняване.
Този компресор е одобрен по CE
съгласно приложимите стандарти.
Изхвърляйте продукта съгласно из-
искванията на директивата относно
ОЕЕО.
Продуктът спазва изискванията на
директивата относно RoHS
Капацитет на резервоара
RPM Обороти в минута
MAX Максимално налягане
Консумация на енергия
Риск от избухване на резервоара,
ако функционира над максималното
работно налягане.
Риск от пожар. Никога не използ-
вайте до запалими газове или
изпарения.
Риск от случайно стартиране в
случай на загасване и последващо
нулиране. Пазете се от въртящите
части.
Риск от увреждане на очите. Винаги
носете одобрени по CE очила за
безопасност, когато работите с
компресора.
Риск от токов удар може да доведе
до смърт или сериозна телесна по-
вреда. Свързвайте компресора само
към правилно заземен приемник.
Риск от високи температури
Освобождаване на налягането. Па-
зете частите на тялото и странични-
те наблюдатели
2× 2424
Дренирайте резервоара
минимум 2 пъти на ден.

20
Ключови части
Описание на частите – вижте схемата на страница 8
АПОМПА НА ВЪЗДУШНИЯ КОМПРЕСОР: Помпата компресира въздуха и го освобождава в
резервоара чрез буталото, което се движи нагоре и надолу в цилиндъра.
В
ЕЛЕКТРИЧЕСКИ МОТОР: Моторът се използва за захранване на помпата. Той е оборудван с
протектор от прегряване. Ако моторът прегрее поради каквато и да е причина, протекторът от
прегряване ще го изключи, за да предпази мотора от увреда.
С
ПРЕДПАЗЕН ВЕНТИЛ: Този вентил се използва за предпазване на компресора от изграждане
на прекомерно налягане. Ако налягането достигне предварително зададеното ниво на резерво-
ара, той автоматично ще се отвори.
D
ПРЕВКЛЮЧВАТЕЛ ЗА НАЛЯГАНЕ: Превключвателят включва компресора и се управлява
ръчно. Когато е в позицията ВКЛЮЧЕНА, това ще позволи на компресора да се стартира или
изключи автоматично, без предупреждение, при необходимост от въздух. ВИНАГИ задавайте
този превключвател на ИЗКЛЮЧЕНА позиция, когато компресорът не се използва и преди да се
изключи компресорът от мрежата.
E
РЕГУЛАТОР НА НАЛЯГАНЕТО: Регулаторът се използва за регулиране на налягането вътре
в линията към инструмента, който се използва. Завъртете копчето по посока на часовниковата
стрелка, за да увеличите налягането, и обратно на часовниковата стрелка, за да го намалите.
F
МАНОМЕТЪР НА НАЛЯГАНЕТО НА РЕЗЕРВОАРА: Манометърът измерва нивото на наляга-
нето на въздуха, който се съхранява в резервоара. Той не може да се регулира от оператора и
не указва налягането вътре в линията.
GМАНОМЕТЪР НА ИЗХОДЯЩОТО НАЛЯГАНЕ: Манометърът измерва регулираното изходно
налягане.
HБЪРЗОСМЕНЕН АДАПТЕР: Бързосменният адаптер е свързан към бърз конектор, който е
свързан към маркуча за въздух.
IДРЕНАЖЕН КЛАПАН: Дренажният клапан се използва за премахване на влагата от въздушния
резервоар след изключване на компресора.
JВЪЗДУШЕН РЕЗЕРВОАР: Резервоарът е там, където се съхранява сгъстеният въздух.
K
ЗАХРАНВАЩ КАБЕЛ: Този продукт е предназначен за употреба с номинална 230-волтова
верига и трябва да се заземи. Трябва да се използва кабел със заземяващ щепсел. Уверете
се, че продуктът е свързан към заземен контакт, който има същата конфигурация като щепсела
(вижте фиг. A). Не трябва да се използва адаптер с този продукт. Консултирайте се с лицензиран
електротехник, ако инструкциите за заземяване не са ви ясни или ако имате съмнение дали
продуктът е правилно заземен. Ако щепселът не пасва на контакта, лицензиран електротехник
трябва да ви инсталира правилно заземен контакт.
!ОПАСНОСТ:
Неправилното инсталиране на заземяващия
щепсел може до доведе до риск от електрически
удар. Ако е необходима поправка или подмяна
на кабела или щепсела, не свързвайте заземя-
ващия проводник в нито един от плоските клеми.
Външната повърхност на заземяващия проводник
е смесена с жълто и зелено.
Общи предупреждения за безопасност
• Не работете с компресора, докато не
прочетете и не разберете това ръководство
с инструкции за инструкциите за безопасност,
работа и поддръжка.
!ПРЕДУПРЕЖДЕНИЕ:
• Риск от пожар, причинен от искри от мотора и
превключвателя за налягането, може да дове-
де до смърт и сериозна телесна повреда.
• Никога не работете с компресора до запалими газо-
ве или изпарения. Никога не съхранявайте запали-
ми течности или газове в близост до компресора.
• Въздухът под високо налягане може да доведе
до смърт или сериозна телесна повреда.
Изключете уреда, разкачете го от мрежата и
освободете въздушното налягане преди серви-
зно обслужване.
• Никога не работете над максималното работно
налягане на такера/телбода.
• Дренирайте водата от резервоара след всяка
употреба.
