ULTIMATE SPEED USKT 60 B2 User manual

SK
CZ
HU
IAN 359668_2101
PORTABLE CORDLESS
COMPRESSOR
HORDAZHATÓ AKKUS
KOMPRESSZOR
TRAGBARER AKKU-KOMPRESSOR
Operation and Safety Notes
Translation of the original instructions
Használati és biztonsági utasítások
Eredeti használati utasítás
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
GB
HU
DE AT CH
PORTABLE CORDLESS COMPRESSOR USKT 60 B2
PRENOSNÝ AKUMULÁTOROVÝ
KOMPRESOR
Návod na obsluhu a bezpečnostné upozornenia
Originálny návod na obsluhu
SK
PŘENOSNÝ AKU KOMPRESOR
Návod k obsluze a bezpečnostní pokyny
Originální návod k obsluze
CZ

GBBefore reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.HUOlvasás előtt lapozza ki az illusztrációkat tartalmazó oldalt, majd ismerkedjen meg a készülék összes funkciójával.CZNež začnete číst tento návod k obsluze, rozložte stránku s obrázky a seznamte se se všemi funkcemi zařízení.SKPrv než začnete čítať tento návod, rozložte si stranu s obrázkami a potom sa oboznámte so všetkými funkciami zariadenia.DEATCHKlappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.GB Operation and Safety Notes Page 5HU Összeszerelési, üzemeltetési és biztonsági utasítások Oldal 23CZ Návod k obsluze a bezpečnostní pokyny Strana 43SK Návod na obsluhu a bezpečnostné upozornenia Strana 61DE / AT / CH Montage-, Bedienungs- und Sicherheitshinweise Seite 79

B
20 21 18 1817 19
A
C
D
E F
16
15
21 3 4 567
11
89
10 14 13 12
5
22
kg/cm²

5
GB
Table of pictograms used ............................................ Page 6
Introduction .................................................................... Page 7
Intended use ...................................................................... Page 7
Package contents................................................................ Page 7
Equipment ......................................................................... Page 8
Technical specifications ....................................................... Page 8
General safety instructions......................................... Page 9
Specific safety instructions.......................................... Page 12
Using the device ............................................................ Page 13
Checking the capacity of the portable compressor.................. Page 13
Charging the portable compressor........................................ Page 13
Using the portable compressor ............................................. Page 14
Switch on lighting............................................................... Page 17
Troubleshooting............................................................. Page 18
Cleaning .......................................................................... Page 18
Storage ............................................................................ Page 18
Information about recycling and disposal .............. Page 18
EU Declaration of Conformity..................................... Page 19
Warranty and service information ........................... Page 20
Warranty conditions ........................................................... Page 20
Warranty period and statutory claims for defects.................... Page 21
Extent of warranty............................................................... Page 21
Processing of warranty claims .............................................. Page 21
Table of contents

6
GB
Table of pictograms used
Table of pictograms used
Read the operating
instructions! Use hearing protection!
The charger is only
suitable for indoor
operation.
Warning:
Risk of electric shock!
Danger to life!
Observe warnings and
safety instructions! Never use the device when it’s raining!
The LED bulb is not
suitable for domestic
room lighting.
Don’t throw away –
recycle!
-21°C
The LED bulb is suitable
for extreme tempera-
tures down to -21°C.
Dispose of packaging
properly. Do not
dispose of the appliance
in household waste!
Protection class 3 Protection type
Warning! Compressor
system can start without
warning.
Dispose of batteries
in an environmentally
friendly manner!
Direct current Protection class 2
Please note Polarity of the
charger plug.
Made from recycling
material. Attention! Hot surface!
Frequency of
50/60 Hertz Alternating voltage in volt.
Nominal ambient
temperature of the
charger 40°C.
Packaging material
corrugated cardboard
Suitable for cars,
bicycles or leisure items.
95
Guaranteed sound
power level 95 dB
ta= 40 °C

7
GB
Introduction
PORTABLE CORDLESS
COMPRESSOR USKT 60 B2
zIntroduction
Congratulations! You have pur-
chased one of our high-quality
products. Please familiarise yourself
with the product before using it for
the first time. To do so, please read
through the following operating and
safety instructions carefully.
KEEP OUT OF THE REACH OF
CHILDREN!
zIntended use
The integrated compressor unit is
designed to adjust the pressure in
tyres (e.g. vehicle and bicycle tyres),
and for the generation of pressure
for balls and other small-scale
inflatable articles. Do not use the
compressor to inflate tyres which
are completely flat or articles with
a large volume (e.g. airbeds), as it
can overheat rapidly in the absence
of back pressure. This portable
compressor is not designed for
continuous operation to generate
pressure for longer than 5 minutes
at a time.
Keep these instructions in a safe
place. Ensure you hand over all
documentation when passing the
product on to anyone else. Any
use that differs to the intended use
as stated above is prohibited and
potentially dangerous. Damage
or injury caused by misuse and
disregarding the above warning is
not covered by the warranty or any
liability on the part of the manufac-
turer. The device is not intended for
commercial use. If it is used commer-
cially then this voids the guarantee.
The product must only be started up
initially by people who have been
trained to do so.
The LED bulb is not suitable
for domestic room lighting.
-21°C
The LED bulb is suitable for
extreme temperatures down
to -21 °C.
zPackage contents
1 compressor, portable
1 set of operating instructions
Accessories:
1 storage bag
1 AC adapter
1 12V cigarette lighter adapter
3 valve adapters
1 compressed air hose with
threaded connection

8
GB
zEquipment
After unpacking the product,
please check that all of the
package contents are pres-
ent and that the portable compressor
is in perfect condition. Do not use
the device if it is defective.
1Portable compressor
2“–” button
3On/Off switch
4“+” button
5Digital pressure gauge
with pressure display
(not trade-approved)
6LED button
7On/Off switch for compressor
8Compressed air hose connection
9LED light
10 Car tyre valve adapter
11 Compressed air hose with
threaded connection
12 Valve adapter for inflatable items
13 Dunlop valve for bicycle tyres
14 Valve adapter for balls (ball
needle)
15 Cover cap for the accessory
compartment
16 Charging port 15 V /0.4 A
17
12V cigarette lighter adapter
18 Power cable
19 12V charge control LED
20 AC adapter
21 230V charge control LED
22 Storage bag
Note: The use of the term ‘product’
or ‘device’ in the following text
refers to the portable compressor
described in this instruction manual.
zTechnical specifications
Model: USKT 60 B2
Battery type: Lithium iron
phosphate
Battery capacity: 500 mAh,
12.8V ,
6.4Wh
Charge cycles: 1000
Charging time: up to 2hours
when using
an AC
adapter
Operating
temperature
for compressor: 0 °C – 60 °C
Operating
temperature
for LED:
-21 °C – 60 °C
Voltage: 12.8V
Input voltage
(charging port): 15V /
0.4A
Current consumption: max. 10A
Maximum
achievable pressure: 4.1bar
Continuous operation: max. 5min*
Air flow rate: 15 l/min
Motor rating: 90 W
Guaranteed sound
power level (LWA): 95 dB(A)
Measured sound
Introduction

9
GB
power level (LWA): 92.1 dB(A)
Uncertainty (KWA): 2.55 dB(A)
Sound pressure level
(LPA): 81.1 dB(A)
Uncertainty (KPA): 3 dB(A)
Note: The noise emission values
were measured in accordance with
EN ISO 3744:1995.
Power supply:
Name or trade mark of the man-
ufacturer, commercial registration
number and address: Manufacturer:
Shenzhen Keyu Power Supply
Technology Co., Ltd.
Address: 2~3F, No.13, Lane3,
Yuquan East Road the 2nd Industrial
park, Yulv, Guangming District,
518000 Shenzhen, China
Importer: C.M.C. GmbH
Address: Katharina-Loth-Straße 15,
66386 St. Ingbert, Germany
Amtsgericht Saarbrücken,
HRB 15856
Model number: KC1601-
1500400EUS
Input voltage: 100–240 V
Input AC frequency:50/60 Hz
Output voltage: 15.0 V
Output current: 0.4 A
Output power: 6.0 W
Average efficiency
during operation: 81.45 %
Efficiency
at low load: not applicablePower consumption
at zero load: 0.08 W
* Continuous operation: Do not
operate the integrated compressor
unit for more than 5 minutes without
interruption. After this, a resting
period of 15 minutes should be
observed
Changes to technical and visual
aspects of the product may be made
as part of future developments with-
out notice. Accordingly, no warranty
is offered for the physical dimen-
sions, information and specifications
in these operating instructions.
The operating instructions cannot
therefore be used as the basis for
asserting a legal claim.
zGeneral safety
instructions
PLEASE READ
THROUGH THE
INSTRUCTION MANUAL
CAREFULLY BEFORE USE.
THESE FORM PART OF THE
PRODUCT AND MUST BE
AVAILABLE AT ALL TIMES!
This section covers the basic
safety instructions applicable
when working with the device.
Personal safety:
This device may be used by
Introduction / General safety instructions

10
GB
children aged 8 years and
older, and by persons with
reduced physical, sensory or
mental capacities, or a lack
of experience and knowl-
edge, if they are supervised
or have been instructed in
how to use the device safely
and understand the dangers
that may arise when using it.
Do not allow children to play
with the device. Cleaning
and day-to-day maintenance
must not be performed by
children without supervision.
Children must be supervised
to ensure that they do not
play with the device.
Keep the device away from
people – especially children –
and household pets.
Within the working area, the
user is responsible for any
damage or injury to third
parties that was caused by
the use of the device.
During operation, never point
the device at yourself or other
individuals, and keep the
device well way from your
ears and eyes. Otherwise
there is a risk of injury!
Do not leave the device unsu-
pervised while running. Com-
ply with the filling instructions
for the inflatable item. The
inflatable article could burst
and cause serious injuries.
Keep the device in a dry
location and out of the reach
of children.
This helps prevent device
damage and possible
personal injuries that
could result from it:
Working with the device:
Do not use the device while
driving the vehicle.
Before setup or first use,
check the device for any
damage and do not use
unless in perfect working
order.
Do not expose the device to
rain or wet weather. Do not let
the device come into contact
with water. Do not immerse
the device in water. There is a
risk of electric shock!
Keep all openings of the
device free during operation.
Do not block the openings
with your hands or fingers,
and do not cover the device.
There is a risk of overheating!
In hot weather, do not leave
the device in a car. This could
permanently damage the
device.
General safety instructions

11
GB
The device becomes warm
during use. There is a risk of
burn injuries from touching
the hot surfaces.
Take care to ensure that sand,
dust and other small foreign
objects cannot enter the air
inlet or air outlet openings.
Do not operate the device
near to flammable liquids or
gases. Do not use the device
to draw in hot fumes. Failure
to do so risks causing a fire
or explosion!
Switch the device off and
remove the mains plug from
the socket in the following
cases:
–When you are not using
the device;
–If you are leaving the
device unsupervised;
–If you are doing cleaning
work;
–If the connection cable is
damaged;
–If foreign objects have
got into the device or you
notice unusual noises.
Only use the accessories
supplied and recommended
by the manufacturer.
Do not dismantle or modify
the portable compressor.
This device must only be
repaired by a maintenance
technician.
Do not use the device in
areas with a risk of explo-
sion, e.g. near flammable
liquids, gases or powders.
Do not expose the device
to any source of heat.
Do not store in places where
the temperature can exceed
70 °C.
Only charge in an ambient
temperature between 0°C
and 40°C.
Only use the AC adapter
20
or
12 V cigarette lighter adapter
17
as supplied with the device.
CAUTION: How to
avoid accidents and
injuries resulting from
electric shock:
Electrical safety:
Do not use the device if the
switch cannot be switched on
and off. Arrange for dam-
aged switches to be replaced.
Do not carry the device by
the cable. Do not unplug
the plug from the socket by
pulling on the cable. Protect
the cable from heat, oil and
sharp edges.
If the cable is damaged,
unplug the plug immediately
General safety instructions

12
GB
from the socket.
Batteries:
CAUTION!
EXPLOSION HAZARD!
Do not open and/or short-
circuit the portable compres-
sor 1. This could cause the
device to overheat, ignite or
explode.
Do not expose the portable
compressor 1to high tem-
peratures. The battery could
explode.
Check the portable compres-
sor
1
regularly for leakage.
Leaking or damaged batteries
may cause burns if they come
into contact with skin. In this
situation, always wear suita-
ble safety gloves! Carefully
wipe up the liquid with a cloth
and avoid contact with skin
and eyes. In the event of con-
tact with skin or eyes, rinse
immediately with clean water
and seek medical attention.
zSpecific safety
instructions
We recommend charging the
portable compressor 1once
a month.
A slightly higher temperature
during charging is absolutely
normal and not a malfunction.
However, we do recommend
leaving the portable compres-
sor 1to rest for 15 minutes
before using.
Protect the portable compres-
sor 1from moisture and high
temperatures, including fires.
Store the portable compressor
1in a dry place and protect
the device from moisture and
corrosion.
If you notice the portable
compressor 1is leaking,
producing an unusual odour
or looking deformed in any
way, stop using the device
immediately and contact the
manufacturer.
Do not drop the portable
compressor 1while it is
being used.
The portable compressor
1is designed for use with
car tyres. It is not designed
for use with large tyres like
tractor or truck tyres.
Note: The digital pressure gauge
with pressure display 5of the
portable compressor 1is not
trade-approved. After pumping up
General safety instructions / Specific safety instructions

13
GB
inflatable items where the wrong
pressure could be dangerous
(e.g. bicycle tyres), always check
the pressure at a service point
with a trade-approved device.
Check the pressure of the inflatable
item there.
During inflation, high temper-
atures can be produced at
the air outlet. There is a risk
of burn injuries!
The device must not be used
while it is being charged.
There is a risk of overheating.
zUsing the device
Note: After being switched on,
the device switches off automati-
cally after approx. 30 seconds, if
the compressor or the LED is not
switched on.
zChecking the capacity
of the portable
compressor
 Switch the portable compressor
1on by pressing the On/Off
switch 3.
 The number of illuminated bars in
the battery symbol on the digital
pressure gauge with pressure
display 5indicates the charge
level of the battery of the portable
compressor 1.
 If the device is fully charged, all
four bars will be lit.
zCharging the portable
compressor
 Connect the portable compressor
1to a socket using the AC
adapter 20.
 To do this, connect the power
cable 18 of the AC adapter 20 to
the charging port (15 V /
0.4 A) 16 of the portable com-
pressor 1plug into a mains
power socket.
 During the charging procedure
the 230 V charge control LED
21
in the AC adapter
20
will light up
red. Once the charging procedure
has finished, the 230V charge
control LED
21
will light up green.
or:
 Connect the portable compressor
1to a 12 V cigarette lighter
using the 12 V cigarette lighter
adapter 17.
 To do this, connect the power
cable 18 of the 12 V cigarette
lighter adapter 17 to the charging
port (15 V /0.4 A) 16 of the
portable compressor 1. Then
connect the cigarette lighter
adapter 17 to a 12 V cigarette
lighter.
 During the charging procedure
the 12 V charge control LED 19 in
the 12 V cigarette lighter adapter
Specific safety instructions / Using the device

14
GB
17 will light up red.
Attention: Only use the 12 V
cigarette lighter adapter 17 and
AC adapter 20 as supplied with the
device!
Note: An undervoltage protection
circuit is installed in the portable
compressor 1to protect the device
from damage. This prevents a deep
discharge of the portable compres-
sor 1and automatically switches
the device off once the battery is
fully discharged. In this case, the
device can no longer be switched on
or used. Please re-charge the porta-
ble compressor 1, as described.
zUsing the portable
compressor
 Take off the cover cap for the
accessory compartment 15 and
remove the compressed air hose
with threaded connection 11.
Screw the compressed air hose
with threaded connection 11 onto
the compressed air hose connec-
tion 8of the portable compressor
1(see Fig. B or C).
 Do not operate the device in a
dusty environment. This is a fire
risk and the device could also be
damaged.
Note: You can either use the
compressed air hose with threaded
connection 11 directly or use it
together with the valve adapters 12,
13 and 14 supplied in the scope of
delivery.
Connecting the compressed air
hose without a valve adapter
 Screw the free end of the com-
pressed air hose with threaded
connection 11 directly on to the
connection valve of the inflatable
item.
Connecting the compressed
air hose with a valve adapter
 The valve adapters 12, 13 and 14
are located under the cover cap
for the accessory compartment 15
(see Fig. C).
 First screw the required valve
adapter 12, 13 or 14 to the free
end of the compressed air hose
with threaded connection 11.
 Connect the valve adapters 12, 13
or 14 into the connecting valve
on the inflatable item (remove
valve cap on inflatable item first
if necessary).
Remove the compressed air
hose
 Connection without valve
adapters 12, 13 or 14: Screw the
compressed connection hose with
threaded connection 11 off the
valve of the inflatable item.
 Connect with the valve adapter
12, 13 or 14: First undo the valve
Using the device

15
GB
adapter from the connecting
valve of the inflatable item. Screw
the valve adapters 12, 13 or 14
off the compressed air hose with
threaded connection 11 (if neces-
sary, reattach the valve cap on to
the inflatable item).
Note: When disconnecting the
compressed air hose with threaded
connection 11, air can escape
from the valve of the inflatable
item. Ensure that you remove the
compressed air hose with threaded
connection 11 as quickly as possible.
Presetting the air pressure
 Switch the portable compressor
1on using the On/Off switch 3.
 Connect the compressed air hose
with threaded connection 11 of
the portable compressor 1to the
inflatable item which you want to
inflate. To do so, please proceed
as follows.
 Pressing the On/Off switch 3
again will allow you to select the
desired unit of pressure. There is
a choice between the following
units: pounds per square inch
(“PSI”), Bar (“Bar”) and kilo-
grammes per square centimetre
(“kg/cm²”) (see Fig. A).
 Use the “+” button 4and the
“–” button 2to select the desired
pressure. To speed up the selec-
tion, you can keep the respective
button pressed down for longer.
Pressure settings between 0.2 bar
and 4.1 bar are possible in
0.05 bar steps (see Fig. A).
Note: If a button is not pressed
for at least 5 seconds, the display
will show the ACTUAL value of the
pressure. The pressure which has
been set remains in the memory.
 Switch the integrated compressor
unit on by pressing the On/Off
switch for the compressor
7
once.
 The compressor will start and
pump up the inflatable item.
 You can switch off the compressor
at any time by pressing the On/
Off switch for the compressor 7
once more.
 Otherwise, the compressor will
switch off automatically once the
inflatable item has reached the
preset pressure.
 Disconnect the inflatable item
from the compressed air hose
with threaded connection 11 as
described in the previous section.
 At the end of work, screw the
compressed air hose with threaded
connection
11
back off the com-
pressed air hose connection
8
of
the portable compressor
1
.
Attention: During operation, the
compressed air hose connection 8
of the portable compressor 1will
get hot. Make sure that you do not
come into contact with the device
Using the device

16
GB
during operation to avoid suffering
burns. At the end of work, wait
for at least 10 minutes before you
unscrew the compressed air hose
with threaded connection 11 back
off the device.
Note: After being switched on,
the device switches off automati-
cally after approx. 30 seconds, if
the compressor or the LED is not
switched on.
Note: The digital pressure gauge
with pressure display 5of the
portable compressor 1is not
trade-approved. After pumping up
inflatable items where the wrong
pressure could be dangerous (e.g.
bicycle tyres), always check the
pressure at a service point with a
trade-approved device. Check the
pressure of the inflatable item there.
Tips for use
The device is not intended for
continuous operation. The device
was designed to create air
pressure – not an air flow.
Please do not use the device for
more than 5 minutes at a time, to
avoid overheating and damage to
the device. After 5 minutes contin-
uous operation the “OH” display
flashes on the digital pressure gauge
with pressure display 5. This indi-
cates imminent overheating. Switch
the device off at that point in order
to protect it from overheating. Then
let the device cool down for at least
15 minutes. We recommend first
filling a large-volume item with air, in
order to then generate the required
pressure with the device.
Checking the air pressure with
the portable compressor
Note: The digital pressure gauge
with pressure display 5of the
portable compressor 1is not
trade-approved.
 Connect the inflatable item to
the compressed air hose with
threaded connection 11 of the
portable compressor 1, whose
pressure you want to check. To do
so, please proceed as described
in the section “Connecting the
compressed air hose with valve
adapter” or “Connecting the
compressed air hose without
valve adapter”.
 Switch the portable compressor
1on using the On/Off switch 3.
 Use the On/On/Off switch 3to
select the desired unit of pressure.
There is a choice between the fol-
lowing units: pounds per square
inch (“PSI”), Bar (“Bar”) and
kilogrammes per square centime-
tre (“kg/cm²”) (see Fig.A).
 The digital pressure gauge with
pressure display 5shows the
pressure of the connected inflata-
ble item in the preset unit.
 Disconnect the inflatable item
Using the device

17
GB
Using the device
from the compressed air hose
with threaded connection 11 of
the portable compressor 1.
To do so, please proceed as
described in the section “Remove
compressed air hose”.
Note: When disconnecting the
compressed air hose with threaded
connection 11, air can escape
from the valve of the inflatable
item. Ensure that you remove
the compressed air hose with
threaded connection 11 as quickly
as possible.
Safety fuse
If the device becomes overloaded or
malfunctions, the safety fuse triggers
to protect the device.
Never use a fuse with a
higher release current
strength. There is a risk
of fire!
Attention: To protect people and
property, an overheat protection
circuit has been installed for the
battery in the portable compressor
1
. This prevents an overheating of
the battery installed in the device
and automatically switches off the
portable compressor
1
if the battery
temperature is too high. If this hap-
pens, allow the device to cool down
prior to re-commissioning it again.
Attention: The compressor function
must not be used while the portable
compressor 1is being charged.
There is a risk of overheating.
zSwitch on lighting
Light mode
 To switch on the LED light
9
press
the LED button
6
once briefly.
 Press the LED button
6
three times
to turn the LED lights
9
off again.
Flash mode
 To switch on the LED light
9
press
the LED button
6
once briefly.
Then the LED light
9
will be
permanently lit.
 Briefly press the LED button
6
once again and the LED light
9
will switch to flashing mode.
 Briefly press the LED button
6
once again and the LED light
9
will switch to SOS mode. There
will be 3 short flashes, 3long
flashes and another 3 short
flashes.
 Briefly press the LED button
6
once again to switch off the LED
light
9
.
Caution! Do not look directly
at the LED lights
9
as this can
damage your eyes.
Attention: The light must not be
used while the portable compressor
1
is being charged. There is a risk
of overheating.

18
GB
zTroubleshooting
= problem
= cause
= remedy
No reaction when the On/Off
switch is pressed 3.
Undervoltage protection is
activated for the portable com-
pressor 1.
Connect the device to the
15V /0.4A charging port 16
using the AC adapter 20 to a
socket or using the 12V cigarette
lighter adapter 17 to a 12 V
cigarette lighter.
zCleaning
Attention: The device must not
come into contact with water
or be placed in water. There is
a risk of injury due to electric
shock if moisture enters the
device.
 Do not use cleaners or solvents.
These could damage the device
beyond repair.
 Keep the housing and device
accessories clean.
 Use a damp cloth or a soft brush
to clean the device and the
accessories.
zStorage
 Keep the device in a dry location
and out of the reach of children.
 To avoid damage, take care to
ensure that the compressed air
hose with threaded connection 11
does not become kinked.
 Store the valve adapters 12,
13 and 14, as well as the com-
pressed air hose with threaded
connection 11 under the cover
cap for the accessory compart-
ment 15 (see Fig. C).
 Store the device in the storage
bag provided 22.
zInformation about
recycling and disposal
Don’t throw away –
recycle!
According to European Direc-
tive 2012/19/EU, used electrical
devices must be collected separately
for environmentally compatible
recycling or recovery. Please return
this device to an approved waste
management company or use your
municipal waste collection service.
Please ensure you comply with
local regulations. If you have any
questions, please contact your local
authority or waste management
company.
... / Cleaning / Storage / Information about recycling and disposal

19
GB
... / EU Declaration of Conformity
Please return this device,
accessories and packaging to
your local recycling depot.
Do not dispose of electrical appli-
ances in household waste!
As the consumer you are
legally obliged (by the Ger-
man Battery Ordinance) to
return any and all used batteries.
Batteries containing harmful sub-
stances are labelled with the adja-
cent symbol, which indicates the
prohibition on disposal in household
waste. The abbreviations for the
relevant heavy metals are:
Cd = cadmium, Hg = mercury,
Pb = lead.
Take used batteries to a waste
management company in your city
or community or return them to
your dealer. This satisfies your legal
obligations while also making an
important contribution to protecting
the environment.
Note: The installed battery cannot
be separately removed for disposal.
zEU Declaration of
Conformity
We,
C. M. C. GmbH
Responsible for documentation:
Dr Christian Weyler
Katharina-Loth-Str. 15
66386 St. Ingbert
GERMANY
hereby take sole responsibility for
declaring that the product
Portable cordless compressor
IAN: 359668_2101
Art. no.: 2384
Year of manufacture: 2021/39
Model: USKT 60 B2
meets the basic safety requirements
as specified in the European
Directives
Electromagnetic Compatibility:
(2014/30/EU)
Low Voltage Directive:
(2014/35/EU)
RoHS Directive:
(2011/65/EU)
Ecodesign Directive:
(2009/125/EU)
Machinery Directive:
(2006/42/EU)
Directive:
(2000/14/EC)
Annex III
Motor rating: 90 W
Guaranteed sound
power level LWA: 95 dB(A)
Measured sound
power level LWA: 92.1 dB(A)
and the amendments to these

20
GB
EU Declaration of Conformity / Warranty and service information
Directives.
The object of the declaration
described above meets the require-
ments of Directive 2011/65/EU
of the European Parliament and
of the Council of 8 June 2011 on
the restriction of the use of certain
hazardous substances in electrical
and electronic equipment.
This conformity assessment is based
on the following harmonised stand-
ards:
EN 55014-1:2017
EN 55014-2:2015
EU 1194/2012
EN 1012-1:2010
EN 63000:2018
EN 60335-1:2012
+A13:2017
EN 61000-3-2:2019
EN 61000-3-3:2013/A1:2019
EN 62233:2008
EN 62471:2008
St. Ingbert, 01/04/2021
pp Dr Christian Weyler
– Quality Assurance –
zWarranty and service
information
Warranty from Creative
Marketing & Consulting
GmbH
Dear Customer,
The warranty for this equipment is
3 years from the date of purchase.
In the event of product defects, you
have legal rights against the retailer
of this product. Your statutory rights
are not affected in any way by our
warranty conditions, which are
described below.
zWarranty conditions
The warranty period begins on the
date of purchase. Please retain the
original sales receipt. This document
is required as your proof of purchase.
Should this product show any defect
in materials or manufacture within
3 years from the date of purchase,
we will repair or replace it – at
our discretion – free of charge.
This warranty service requires that
you retain proof of purchase (sales
receipt) for the defective device for
the three year period and that you
briefly explain in writing what the
fault entails and when it occurred.
If the defect is covered by our war-
ranty, we will repair and return your
product or send you a replacement.
The original warranty period is not
