SERVICE
MANUAL
Published in July 2007
842JL112
2JLSM062
Rev. 2
KM-C2525E
KM-C3225E
KM-C3232E
KM-C4035E

CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
It may be illegal to dispose of this battery into the municipal waste stream. Check with your local
solid waste officials for details in your area for proper disposal.
ATTENTION
IL Y A UN RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN MODELE DE
TYPE INCORRECT. METTRE AU REBUT LES BATTERIES UTILISEES SELON LES INSTRUC-
TIONS DONNEES.
Il peut être illégal de jeter les batteries dans des eaux d’égout municipales. Vérifiez avec les fonc-
tionnaires municipaux de votre région pour les détails concernant des déchets solides et une mise
au rebut appropriée.

Revision history
Revision Date Replaced pages Remarks
1 April 25, 2007 CONTENTS, 1-1-1 to 1-1-3, 1-3-2 to 1-3-130, 1-4-3
to 1-4-9, 1-4-53, 1-4-56, 1-4-57, 2-1-12, 2-2-1,
2-2-3 to 2-2-8, 2-3-6 to 2-3-22, 2-4-1, 2-4-2, 2-4-7 to
2-4-17
-
2 July 18, 2007 1-1-1, 1-2-12, 1-2-15, 1-3-104, 1-3-109, 1-4-22 -

This page is intentionally left blank.

Safety precautions
This booklet provides safety warnings and precautions for our service personnel to ensure the safety of
their customers, their machines as well as themselves during maintenance activities. Service personnel
are advised to read this booklet carefully to familiarize themselves with the warnings and precautions
described here before engaging in maintenance activities.

Safety warnings and precautions
Various symbols are used to protect our service personnel and customers from physical danger and
to prevent damage to their property. These symbols are described below:
DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect
compliance with warning messages using this symbol.
WARNING: Serious bodily injury or death may result from insufficient attention to or incorrect compliance
with warning messages using this symbol.
CAUTION: Bodily injury or damage to property may result from insufficient attention to or incorrect
compliance with warning messages using this symbol.
Symbols
The triangle ( ) symbol indicates a warning including danger and caution. The specific point
of attention is shown inside the symbol.
General warning.
Warning of risk of electric shock.
Warning of high temperature.
indicates a prohibited action. The specific prohibition is shown inside the symbol.
General prohibited action.
Disassembly prohibited.
indicates that action is required. The specific action required is shown inside the symbol.
General action required.
Remove the power plug from the wall outlet.
Always ground the copier.

1.Installation Precautions
WARNING
• Do not use a power supply with a voltage other than that specified. Avoid multiple connections to
one outlet: they may cause fire or electric shock. When using an extension cable, always check
that it is adequate for the rated current. .............................................................................................
• Connect the ground wire to a suitable grounding point. Not grounding the copier may cause fire or
electric shock. Connecting the earth wire to an object not approved for the purpose may cause
explosion or electric shock. Never connect the ground cable to any of the following: gas pipes,
lightning rods, ground cables for telephone lines and water pipes or faucets not approved by the
proper authorities. ............................................................................................................................
CAUTION:
• Do not place the copier on an infirm or angled surface: the copier may tip over, causing injury. .......
• Do not install the copier in a humid or dusty place. This may cause fire or electric shock. ................
• Do not install the copier near a radiator, heater, other heat source or near flammable material.
This may cause fire. .........................................................................................................................
• Allow sufficient space around the copier to allow the ventilation grills to keep the machine as cool
as possible. Insufficient ventilation may cause heat buildup and poor copying performance. ...........
• Always handle the machine by the correct locations when moving it. ...............................................
• Always use anti-toppling and locking devices on copiers so equipped. Failure to do this may cause
the copier to move unexpectedly or topple, leading to injury. ...........................................................
• Avoid inhaling toner or developer excessively. Protect the eyes. If toner or developer is acciden-
tally ingested, drink a lot of water to dilute it in the stomach and obtain medical attention immedi-
ately. If it gets into the eyes, rinse immediately with copious amounts of water and obtain medical
attention. ......................................................................................................................................
• Advice customers that they must always follow the safety warnings and precautions in the copier’s
instruction handbook. .....................................................................................................................

2.Precautions for Maintenance
WARNING
• Always remove the power plug from the wall outlet before starting machine disassembly. ...............
• Always follow the procedures for maintenance described in the service manual and other related
brochures. .......................................................................................................................................
• Under no circumstances attempt to bypass or disable safety features including safety mechanisms
and protective circuits. .....................................................................................................................
• Always use parts having the correct specifications. ..........................................................................
• Always use the thermostat or thermal fuse specified in the service manual or other related bro-
chure when replacing them. Using a piece of wire, for example, could lead to fire or other serious
accident. ..........................................................................................................................................
• When the service manual or other serious brochure specifies a distance or gap for installation of a
part, always use the correct scale and measure carefully. ................................................................
• Always check that the copier is correctly connected to an outlet with a ground connection. .............
• Check that the power cable covering is free of damage. Check that the power plug is dust-free. If it
is dirty, clean it to remove the risk of fire or electric shock. ..............................................................
• Never attempt to disassemble the optical unit in machines using lasers. Leaking laser light may
damage eyesight. ...........................................................................................................................
• Handle the charger sections with care. They are charged to high potentials and may cause electric
shock if handled improperly. ............................................................................................................
CAUTION
• Wear safe clothing. If wearing loose clothing or accessories such as ties, make sure they are
safely secured so they will not be caught in rotating sections. ..........................................................
• Use utmost caution when working on a powered machine. Keep away from chains and belts. ........
• Handle the fixing section with care to avoid burns as it can be extremely hot. ..................................
• Check that the fixing unit thermistor, heat and press rollers are clean. Dirt on them can cause
abnormally high temperatures. ........................................................................................................

• Do not remove the ozone filter, if any, from the copier except for routine replacement. ....................
• Do not pull on the AC power cord or connector wires on high-voltage components when removing
them; always hold the plug itself. .....................................................................................................
• Do not route the power cable where it may be stood on or trapped. If necessary, protect it with a
cable cover or other appropriate item. .............................................................................................
• Treat the ends of the wire carefully when installing a new charger wire to avoid electric leaks. ........
• Remove toner completely from electronic components. ...................................................................
• Run wire harnesses carefully so that wires will not be trapped or damaged. ....................................
• After maintenance, always check that all the parts, screws, connectors and wires that were
removed, have been refitted correctly. Special attention should be paid to any forgotten connector,
trapped wire and missing screws. ...................................................................................................
• Check that all the caution labels that should be present on the machine according to the instruction
handbook are clean and not peeling. Replace with new ones if necessary. ......................................
• Handle greases and solvents with care by following the instructions below: .....................................
· Use only a small amount of solvent at a time, being careful not to spill. Wipe spills off completely.
· Ventilate the room well while using grease or solvents.
· Allow applied solvents to evaporate completely before refitting the covers or turning the power
switch on.
· Always wash hands afterwards.
• Never dispose of toner or toner bottles in fire. Toner may cause sparks when exposed directly to
fire in a furnace, etc. .......................................................................................................................
• Should smoke be seen coming from the copier, remove the power plug from the wall outlet imme-
diately. ............................................................................................................................................
3.Miscellaneous
WARNING
• Never attempt to heat the drum or expose it to any organic solvents such as alcohol, other than the
specified refiner; it may generate toxic gas. .....................................................................................

This page is intentionally left blank.

2JL/2JJ/2JG/2JD-1
CONTENTS
1-1 Specifications
1-1-1 Specifications..........................................................................................................................................1-1-1
1-1-2 Parts names............................................................................................................................................1-1-4
(1) Body ..................................................................................................................................................1-1-4
(2) Operation panel.................................................................................................................................1-1-5
1-1-3 Machine cross section ............................................................................................................................1-1-6
1-2 Installation
1-2-1 Installation environment..........................................................................................................................1-2-1
1-2-2 Unpacking and installation......................................................................................................................1-2-2
(1) Installation procedure........................................................................................................................1-2-2
(2) Setting initial copy modes................................................................................................................1-2-11
1-2-3 Installing the key counter (option) .........................................................................................................1-2-12
1-2-4 Installing the memory (option)...............................................................................................................1-2-16
1-2-5 Installing the hard disk (option).............................................................................................................1-2-17
1-2-6 Installing the network interface card (option) ........................................................................................1-2-18
1-2-7 Installing the serial interface board (option) ..........................................................................................1-2-19
1-3 Maintenance Mode
1-3-1 Maintenance mode .................................................................................................................................1-3-1
(1) Executing a maintenance item ..........................................................................................................1-3-1
(2) Maintenance mode item list...............................................................................................................1-3-2
(3) Contents of maintenance mode items...............................................................................................1-3-8
1-3-2 Service mode......................................................................................................................................1-3-104
(1) Executing a service item ...............................................................................................................1-3-104
1-3-3 Management mode .............................................................................................................................1-3-110
(1) Using the management mode .......................................................................................................1-3-110
(2) Job accounting ..............................................................................................................................1-3-111
(3) Default settings for copying...........................................................................................................1-3-113
(4) Machine default.............................................................................................................................1-3-115
(5) Printer settings ..............................................................................................................................1-3-118
(6) Scanner default settings................................................................................................................1-3-123
(7) Fax default setting.........................................................................................................................1-3-124
(8) Setting MP tray..............................................................................................................................1-3-125
(9) Registering non-standard sizes for originals .................................................................................1-3-125
(10) User adjustment ............................................................................................................................1-3-126
(11) Setting document management defaults.......................................................................................1-3-128
(12) Hard disk management .................................................................................................................1-3-128
(13) Printing reports..............................................................................................................................1-3-128
(14) Checking total copy count .............................................................................................................1-3-128
(15) Language ......................................................................................................................................1-3-129
1-4 Troubleshooting
1-4-1 Paper misfeed detection .........................................................................................................................1-4-1
(1) Paper misfeed indication...................................................................................................................1-4-1
(2) Paper misfeed detection conditions ..................................................................................................1-4-2
(3) Paper misfeeds ...............................................................................................................................1-4-10
1-4-2 Self-diagnosis .......................................................................................................................................1-4-21
(1) Self-diagnostic function ...................................................................................................................1-4-21
(2) Self diagnostic codes ......................................................................................................................1-4-23
1-4-3 Image formation problems ....................................................................................................................1-4-49
(1) No image appears (entirely white)...................................................................................................1-4-50
(2) No image appears (entirely black)...................................................................................................1-4-50
(3) Dirty on the back side......................................................................................................................1-4-51
(4) Image is too light. ............................................................................................................................1-4-51
(5) The background is colored..............................................................................................................1-4-51
(6) Paper jams. .....................................................................................................................................1-4-52
(7) Toner drops on the paper conveying path.......................................................................................1-4-52
(8) Abnormal noise is heard..................................................................................................................1-4-52
(9) One side of the copy image is darker than the other.......................................................................1-4-53

2JL/2JJ/2JG/2JD
(10) Dots appear on the image...............................................................................................................1-4-53
(11) The leading edge of the image is consistently misaligned with the original. ...................................1-4-53
(12) The leading edge of the image is sporadically misaligned with the original....................................1-4-53
(13) Paper creases. ................................................................................................................................1-4-54
(14) Offset occurs. ..................................................................................................................................1-4-54
(15) Image is partly missing....................................................................................................................1-4-54
(16) Fusing is poor..................................................................................................................................1-4-55
(17) Image is out of focus. ......................................................................................................................1-4-55
(18) Colors are printed offset to each other............................................................................................1-4-55
(19) Image center does not align with the original center.......................................................................1-4-55
1-4-4 Electric problems ..................................................................................................................................1-4-56
1-4-5 Mechanical problems ............................................................................................................................1-4-60
1-5 Assembly and Disassembly
1-5-1 Precautions for assembly and disassembly............................................................................................1-5-1
(1) Precautions .......................................................................................................................................1-5-1
(2) Drum..................................................................................................................................................1-5-1
(3) Toner.................................................................................................................................................1-5-1
1-5-2 Paper feed section..................................................................................................................................1-5-2
(1) Detaching and refitting the forwarding, paper feed and separation pulleys ......................................1-5-2
(2) Detaching and refitting the MP unit ...................................................................................................1-5-4
(3) Detaching and refitting the MP forwarding, MP paper feed and MP separation pulleys ...................1-5-6
1-5-3 Optical section ........................................................................................................................................1-5-8
(1) Detaching and refitting the exposure lamp........................................................................................1-5-8
(2) Detaching and refitting the scanner wires .......................................................................................1-5-11
(3) Detaching and refitting the ISU (reference).....................................................................................1-5-15
(4) Detaching and refitting the laser scanner unit.................................................................................1-5-17
(5) Manual color registration adjustment ..............................................................................................1-5-22
1-5-4 Image formation section........................................................................................................................1-5-24
(1) Detaching and refitting the image formation holder.........................................................................1-5-24
(2) Detaching and refitting the developing unit .....................................................................................1-5-25
(3) Detaching and refitting the drum unit ..............................................................................................1-5-26
(4) Detaching and refitting the charger roller unit .................................................................................1-5-26
1-5-5 Transfer section ....................................................................................................................................1-5-27
(1) Detaching and refitting the transfer belt unit....................................................................................1-5-27
(2) Detaching and refitting the transfer roller ........................................................................................1-5-28
1-5-6 Fuser section ........................................................................................................................................1-5-30
(1) Detaching and refitting the fuser unit...............................................................................................1-5-30
1-5-7 Other.....................................................................................................................................................1-5-31
(1) Detaching and refitting the engine PWB .........................................................................................1-5-31
(2) Detaching and refitting the conveying drive unit..............................................................................1-5-35
(3) Detaching and refitting the registration clutch .................................................................................1-5-36
(4) Detaching and refitting the right filter and rear filter ........................................................................1-5-37
(5) Detaching and refitting the LSU cleaning clutch..............................................................................1-5-38
1-6 Requirements on PWB Replacement
1-6-1 Upgrading the firmware...........................................................................................................................1-6-1
1-6-2 Remarks on main PWB replacement......................................................................................................1-6-2
1-6-3 Remarks on scanner PWB replacement.................................................................................................1-6-2
1-6-4 Remarks on printer PWB replacement ...................................................................................................1-6-2
2-1 Mechanical construction
2-1-1 Paper feed section..................................................................................................................................2-1-1
(1) Cassette paper feed section..............................................................................................................2-1-1
(2) MP tray paper feed section ...............................................................................................................2-1-3
2-1-2 Drum section...........................................................................................................................................2-1-5
(1) Drum section .....................................................................................................................................2-1-5
2-1-3 Developing section..................................................................................................................................2-1-7
(1) Developing section............................................................................................................................2-1-7
2-1-4 Optical section ........................................................................................................................................2-1-9
(1) Image scanner section ......................................................................................................................2-1-9
(2) Laser scanner section .....................................................................................................................2-1-11

2JL/2JJ/2JG/2JD-1
2-1-5 Transfer/separation section ..................................................................................................................2-1-12
(1) Primary transfer section ..................................................................................................................2-1-12
(2) Secondary transfer/separation section............................................................................................2-1-13
2-1-6 Fuser section ........................................................................................................................................2-1-14
(1) Fuser section...................................................................................................................................2-1-14
2-1-7 Eject/feedshift section...........................................................................................................................2-1-16
(1) Eject/feedshift section .....................................................................................................................2-1-16
2-1-8 Duplex section ......................................................................................................................................2-1-17
(1) Duplex section.................................................................................................................................2-1-17
2-2 Electrical Parts Layout
2-2-1 Electrical parts layout..............................................................................................................................2-2-1
(1) PWBs ................................................................................................................................................2-2-1
(2) Switches and sensors .......................................................................................................................2-2-3
(3) Motors ...............................................................................................................................................2-2-5
(4) Others................................................................................................................................................2-2-7
2-3 Operation of the PWBs
2-3-1 Power source PWB.................................................................................................................................2-3-1
2-3-2 Engine PWB............................................................................................................................................2-3-5
2-4 Appendixes
Maintenance parts list.............................................................................................................................2-4-1
Maintenance kits.....................................................................................................................................2-4-2
Periodic maintenance procedures ..........................................................................................................2-4-3
Chart of image adjustment procedures...................................................................................................2-4-7
Wiring diagram No.1 (25/25, 32/25 and 32/32 ppm models) ..................................................................2-4-9
Wiring diagram No.1 (40/35 ppm model)..............................................................................................2-4-10
Wiring diagram No.2 (25/25, 32/25 and 32/32 ppm models) ................................................................2-4-11
Wiring diagram No.2 (40/35 ppm model)..............................................................................................2-4-12
Wiring diagram No.3 (25/25, 32/25 and 32/32 ppm models) ................................................................2-4-13
Wiring diagram No.3 (40/35 ppm model)..............................................................................................2-4-14
Wiring diagram No.4 .............................................................................................................................2-4-15
Wiring diagram No.5 .............................................................................................................................2-4-16
Wiring diagram No.6 .............................................................................................................................2-4-17
INSTALLATION GUIDE
PAPER FEEDER
3000 SHEETS PAPER FEEDER
DOCUMENT FINISHER
3000 SHEETS DOCUMENT FINISHER
CENTER-FOLDING UNIT
MAILBOX
HOLE PUNCH UNIT
JOB SEPARATOR
DOCUMENT PROCESSOR
FACSIMILE SYSTEM
Data Security Kit (D)

2JL/2JJ/2JG/2JD
This page is intentionally left blank.

2JL/2JJ/2JG/2JD-2
1-1-1
1-1 Specific ations
1-1-1 Specifications
Type ................................................Desktop
Copying system ..............................Dry static transfer copy system (Laser), Tandem drum system
Originals..........................................Sheets, books and three-dimensional objects
Maximum size: A3/11" x 17"
Original feed system ....................... Fixed
Copy paper .....................................Weight
Cassette: 60 - 105 g/m2
MP tray : 60 - 220 g/m2
Types
Cassette: Plain, Rough, Vellum, Recycled, Preprinted, Bond, Color (Colour),
Prepunched, Letterhead, High Quality, Custom 1 - 8
MP tray : Plain, Transparency, Rough, Vellum, Labels, Recycled, Preprinted, Bond,
Cardstock, Color (Colour), Prepunched, Letterhead, Thick paper, Envelope,
Coated, High Quality, Custom 1 - 8
Copy sizes ......................................Cassette: A3, B4, A4, A4R, B5, B5R, A5R, Folio, 11 x 17", 8 1/2 x 14", 11 x 8 1/2",
81/2 x 11", 5 1/2 x 8 1/2", 8 1/2 x 13", 8 1/2 x 13 1/2", 8K, 16K, 16KR
MP tray : A3 - A6R, 11 x 17" - 5 1/2 x 8 1/2", 8K, 16K, 16KR, YOUKEI 2, YOUKEI 4
During duplex copying: A3 - A5R, 11 x 17" - 5 1/2 x 8 1/2"
Magnification ratios.........................Manual mode: 25 - 400%, 1% increments
Auto copy mode: Fixed ratios
Copying speed................................At 100% magnification in memory copy mode:
25/25 ppm model
Monochrome Color
A3/11 x 17": 13 sheets/min. A3/11 x 17": 13 sheets/min.
B4/8 1/2" x 14": 13 sheets/min. B4/8 1/2" x 14": 13 sheets/min.
A4/11" x 8 1/2": 25 sheets/min. A4/11" x 8 1/2": 25 sheets/min.
A4R/8 1/2" x 11": 17 sheets/min. A4R/8 1/2" x 11": 17 sheets/min.
B5: 25 sheets/min. B5: 25 sheets/min.
B5R: 17 sheets/min. B5R: 17 sheets/min.
32/25 ppm model
Monochrome Color
A3/11 x 17": 16 sheets/min. A3/11 x 17": 13 sheets/min.
B4/8 1/2" x 14": 16 sheets/min. B4/8 1/2" x 14": 13 sheets/min.
A4/11" x 8 1/2": 32 sheets/min. A4/11" x 8 1/2": 25 sheets/min.
A4R/8 1/2" x 11": 22 sheets/min. A4R/8 1/2" x 11": 17 sheets/min.
B5: 32 sheets/min. B5: 25 sheets/min.
B5R: 22 sheets/min. B5R: 17 sheets/min.
32/32 ppm model
Monochrome Color
A3/11 x 17": 16 sheets/min. A3/11 x 17": 16 sheets/min.
B4/8 1/2" x 14": 16 sheets/min. B4/8 1/2" x 14": 16 sheets/min.
A4/11" x 8 1/2": 32 sheets/min. A4/11" x 8 1/2": 32 sheets/min.
A4R/8 1/2" x 11": 22 sheets/min. A4R/8 1/2" x 11": 22 sheets/min.
B5: 32 sheets/min. B5: 32 sheets/min.
B5R: 22 sheets/min. B5R: 22 sheets/min.
40/35 ppm model
Monochrome Color
A3/11 x 17": 20 sheets/min. A3/11 x 17": 18 sheets/min.
B4/8 1/2" x 14": 20 sheets/min. B4/8 1/2" x 14": 18 sheets/min.
A4/11" x 8 1/2": 40 sheets/min. A4/11" x 8 1/2": 35 sheets/min.
A4R/8 1/2" x 11": 28 sheets/min. A4R/8 1/2" x 11": 25 sheets/min.
B5: 40 sheets/min. B5: 35 sheets/min.
B5R: 28 sheets/min. B5R: 25 sheets/min.
First copy time ................................25/25, 32/25 and 32/32 ppm models
7.9 s or less/5.9 s or less [Full color-single color/Monochrome] (A4/11 x 8 1/2",
100% magnification)
40/35 ppm model
7.5 s or less/5.5 s or less [Full color-single color/Monochrome] (A4/11 x 8 1/2",
100% magnification)

2JL/2JJ/2JG/2JD-1
1-1-2
Warm-up time .................................45 s or less
Recovery from low power mode: 30 s or less
Recovery from sleep mode: 45 s or less
(room temperature 22 °C/71.6 °F, 60% RH)
Paper feed system..........................Automatic feed (two cassettes)
Capacity:
Cassette 1: 500 sheets (80 g/m2, 11" x 8 1/2"/A4 or smaller), 250 sheets (80 g/m2,
81/2" x 14"/B4 or larger)
Cassette 2: 500 sheets (80 g/m2)
Manual feed
Capacity:
MP tray: 100 sheets (80 g/m2, 11" x 8 1/2"/A4 or smaller), 50 sheets (80 g/m2, 8 1/2"x
14"/B4 or larger)
Paper eject system .........................Output tray: 250 sheets (80 g/m2)
Eject tray (optional job separator): 150 sheets
Multiple copying ..............................1 - 999 sheets
Photoconductor...............................a-Si (drum diameter 30 mm)
Recording system ...........................Semiconductor laser
Charging system.............................Charging roller
Developing system .........................Hybrid developing
Developer: 2-component
Toner replenishing: Automatic from a toner container
Transfer system ..............................Primary: Transfer belt
Secondary: Transfer roller
Separation system ..........................Separation electrode
Fusing system.................................Melt fusing (Fuser belt)
Heat source: Halogen heaters
Fuser heater 1: 600W, Fuser heater 2: 400 W, Fuser heater 3: 600 W
Abnormally high temperature protection devices: thermostats
Charge erasing system...................Exposure by cleaning lamp
Cleaning system .............................Blade and roller
Scanning system ............................Flat bed scanning by CCD image sensor
Resolution.......................................Scanning: 600 x 600 dpi
Printing: 600 x 600 dpi
Light source ....................................Inert gas lamp
Memory...........................................768 MB (standard for copying/for scanner)
256 MB (standard for printing)
Image storage memory...................40 GB (standard)
Dimensions .....................................605 (W) x 660 (D) x 745 (H) mm
23 13/16" (W) x 26" (D) x 29 5/16" (H)
Figure 1-1-1
a
c
b
a: 605 mm/23 13/16"
b: 660 mm/26"
c: 745 mm/29 5/16"

2JL/2JJ/2JG/2JD-1
1-1-3
Weight.............................................98 kg/215.6 lbs (excluding toner containers and waste toner box)
Floor requirements..........................889 mm (W) x 660 (D) mm
35" (W) x 26" (D) (when using MP tray)
Functions ........................................Duplex mode, split mode, offset mode, combine mode, margin mode, centering origi-
nals, border erase, poster, page numbering, cover mode, booklet, memo mode, batch
scanning, sharpness adjust, background exposure adjust, proof copy, repeat copy,
OHP backing sheet mode, EcoPrint, inverted copying, mirror copying, image repeat
copy, color balance adjust, hue adjust, one touch image adjust, Color/B&W selection,
single color copy, programmed copying, job build, shared data box, synergy print box,
output management, job accounting, language setting
Power source..................................120 V AC, 60 Hz, 12.0 A/220 - 240 V AC, 50 Hz, 7.2 A
Power consumption ........................120 V AC: 1440 W/220 - 240 V AC: 1656 W
Options ...........................................DP, paper feeder, 3000-sheet paper feeder, document finisher, 3000-sheet document
finisher, centerfold unit, mailbox, punch unit, job separator, key counter, fax kit and
security kit
Printer functions
CPU ................................................PowerPC 750FL/600 MHz (25/25 and 32/25 ppm model)
PowerPC 750GL/800 MHz (32/32 and 40/35 ppm model)
Printing speed.................................Same as copying speed
First Print Time................................Same as first copy time
Resolution.......................................600 dpi (2/4 bit)
Applicable OS .................................Windows 95 OSR2, Windows 98 Second Edition, Windows NT 4.0 Service Pack 5 or
later, Windows 2000 Service Pack 2 or later, Windows Me, Windows XP, Windows
Server 2003, Apple Macintosh OS 9.x/OS X 10.x
Interface..........................................Parallel port interface: 1 IEEE1284
Network interface: 1
USB: 1 Hi-Speed USB
Network interface cards (option): 1
Serial interface (option): 1
PDL.................................................PRESCRIBE
Emulation........................................PCL6 (5e, XL), KPDL3, KC-GL
Standard memory ...........................256 MB
Optional memory ............................Max. 1024 MB
Options ...........................................Hard disk, additional memory, network interface card
Scanner functions
Hardware ........................................IBM PC/AT Compatible
Applicable OS .................................Windows 95 OSR2, Windows 98 Second Edition, Windows NT 4.0 Service Pack 5 or
later, Windows 2000 Service Pack 2 or later, Windows Me, Windows XP, Windows
Server 2003, Mac OS 9.1 - 9.2.2, Mac OS 10.1.5 - 10.4 (TWAIN: Mac 10.2 -10.4)
Operating Environment...................CPU Pentium 133 MHz or higher (Windows Me 150 MHz or higher, Windows XP
Celeron 600 MHz or higher, Macintosh PowerPC G3 or higher)
RAM 64 MB or greater (Windows XP 128 MB)
HDD 20 MB or greater
Recommended Environment ..........CPU Celeron 266 MHz or higher (Windows XP Celeron 800 MHz or higher)
RAM 64 MB or greater
HDD 300 MB or greater
CD-ROM .........................................1 drive
Ethernet ..........................................10BASE-T/100BASE-TX
Network Protocol ............................TCP/IP
Communications Protocols .............Proprietary (image transferring, setting via utility), SMTP (e-mail sending), HTTP (set-
ting via web), FTP (When sending FTP), TWAIN (When using TWAIN)
NOTE: These specifications are subject to change without notice.

2JL/2JJ/2JG/2JD
1-1-4
1-1-2 Parts names
(1) Body
Figure 1-1-2
3
1
4
11
2
5
7
6
89
10
12
13
14 15 17 16 18
19 20
22
21
23
24
25
26
28
27
29
30
31
1. Original platen (option)
2. Contact glass
3. Original size indicator plates
4. Operation panel
5. MP tray (multi-purpose tray)
6. Sliders
7. MP tray extension
8. Cassette 1
9. Cassette 2
10. Paper length guide
11. Paper width guides
12. Paper width adjusting tab
13. Interface cover
14. Network interface connector (printer)
15. USB interface connector
16. Parallel port interface connector
17. Memory card (CompactFlash) slot
18. Network interface connector (scanner)
19. Main power switch
20. Main power switch cover
21. Output tray
22. Left cover 1
23. Left cover 2
24. Front cover
25. Toner container (black)
26. Toner container (yellow)
27. Toner container (cyan)
28. Toner container (magenta)
29. Toner container lock lever
30. Waste toner box
31. Carrying handles

2JL/2JJ/2JG/2JD
1-1-5
(2) Operation panel
Figure 1-1-3
2
1101112131415161719
920
22
21
3
4
5
6
78
18
23
24
1. Brightness adjustment dial
2. Copier key (indicator/lamp)
3. Printer key (indicator/lamp)
4. Scanner key (indicator/lamp)
5. Fax key (indicator/lamp)
6. System menu/Counter key
7. Auto color key
8. Full-color key
9. Black&White key
10. Document management key/indicator
11. Print management key/indicator
12. Repeat copy key/indicator
13. Job build key/indicator
14. Auto selection key/indicator
15. Job accounting key
16. Interrupt key/indicator
17. Energy saver key/indicator
18. Power key/indicator
19. Main power indicator
20. Touch panel
21. Numeric keys
22. Reset key
23. Stop/clear key
24. Start key/indicator

2JL/2JJ/2JG/2JD
1-1-6
1-1-3 Machine cross section
Figure 1-1-4 Machine cross section
1. Image scanner section
2. Laser scanner section
3. Cassette paper feed section
4. MP tray paper feed section
5. Developing section (Black)
6. Developing section (Yellow)
7. Developing section (Cyan)
8. Developing section (Magenta)
9. Drum section (Black)
10. Drum section (Yellow)
11. Drum section (Cyan)
12. Drum section (Magenta)
13. Primary transfer section
14. Secondary transfer/separation
section
15. Fuser section
16. Eject/feedshift section
17. Duplex section
