THANK YOU FOR BUYING OUR PRODUCT.
To ensure your safety and satisfaction, carefully read through this OWNER’S
MANUAL before using the product.
CAUTION! Read, understand and follow all Safety Rules and Op-
erating Instructions in this Manual before using this product.
SAFETY INSTRUCTIONS
WARNING: BE SURE to read and understand all instructions in this manual before
using this product. Failure to follow all instructions may result in hazardous radiation
exposure, electric shock, and/or bodily injury.
CAUTION: Do not attempt to modify the performance of the laser device in any way.
This may result in a dangerous exposure to laser radiation.
WARNING: LASER RADIATION. Do not stare into beam. Class II laser product.
Turn the laser beam on only when using this tool.
WARNING: Use of controls, adjustments, or the performance of procedures other than
those specied in this manual may result in hazardous radiation exposure.
WARNING: The use of optical instruments such as, but not limited to, telescopes or
transits to view the laser beam will increase eye hazard.
This laser distance measure has a built-in laser light. The laser is a Class II and
emits output power of a maximum 1mW and 630-670nm wavelengths. These lasers
do not normally present an optical hazard. However, do not stare at the beam, as
this can cause ash blindness.
The following label is on your laser measuring tool. It indicates the location from
which the laser measuring tool emits the laser light. Be aware of the laser light
location when using the tool. Always make sure that any bystanders in the vicinity of
use are made aware of the dangers of looking directly into the laser.
•Do not remove or deface any product labels.
•Avoid direct eye exposure. The laser beam can cause ash blindness.
•The laser distance measure is not a toy. Always keep it out of the reach
of children. The laser light emitted from this device should never be directed
toward any person for any reason.
•Do not operate the tool around children or allow children to operate the tool.
•Do not place the tool in a position that may cause anyone to stare at the laser
beam, whether intentionally or unintentionally.
2
•Do not use on surfaces such as sheet steel that have shiny, reective surfaces.
The reective surface could reect the beam back at the operator.
•Always turn the laser tool o when not in use. Leaving the tool on increases
the risk of someone inadvertently staring into the laser beam.
•Do not attempt to modify the performance of this laser device in any way. This
may result in a dangerous exposure to laser radiation.
•Do not attempt to repair or disassemble the laser distance measure. If unqualied
persons attempt to repair this product, serious injury may occur. Any repair
required on this laser product should be performed only by authorized service
personnel.
•Do not operate the tool in combustible areas, such as in the presence of
ammable liquids, gases, or dust.
•Use of other accessories that have been designed for use with other laser tools
could result in serious injury.
3
1
2
3
5
4
9
8
6
7
4
DESCRIPTION
1. Display
2. Measuring button
3. On/O button
4. Mode switch button
5. Reference mark for wheel measurement
6. Receiver lens
7. Laser output part
8. USB port (Micro B)
9. Wheel
SPECIFICATIONS
Measurement range 0.2 - 40m *1
Measurement accuracy ±3mm *2
Minimum measurement unit 1 mm
Wheel measurement range 0 - 40 m
Wheel measurement accuracy ± 1 %
Laser class Class II
Laser type 630 - 670 nm, < 1mW
Measuring unit Meter
Battery Li-Ion (built-in)
Dimensions 100 × 37 × 24mm
Weight 63g
＊1 The measurable range varies depending on the brightness of surrounding
area and how well the laser light is reflected from the surface of the
measuring object.
＊2 The deviation of the measurement can be up to ±3.0-5.0mm depending on
the operating environment.
STANDARD ACCESSORIES
USB cable, Adapter for tripod
5
DISPLAY
1. Measurement reference (Front/Rear)
2. Laser indicator
3. Battery level
4. Previously measured value
5. Current measured value
6. Measuring unit
CHARGING
This product has a built-in lithium battery. Please use the original USB cable
while charging.
Laser distance meter may heat up a little when charging, it's normal, has no
eect on the device performance and service life. If it is not used for a long time,
unplug the charger.
SWITCH
Press On/O button for 1 second to turn on the device. The laser indicator
ashes on the display.
When no button is pressed for about 30 seconds, the laser beam is automatically
turned o, and then the device is automatically turned o after about 3 minutes.
To turn o the device, press On/O button for 1 second.
SET MEASURING REFERENCE
Measuring reference can be set at 2 dierent position, at the rear edge and at
the front edge. Rear edge is selected as the standard. It can be changed by
pushing measuring button and On/O button simultaneously.
3
1
2
4
6
5
6
OPERATION
1. Single Measurement
The device will enter single measurement when it is powered ON, press
measuring button after aiming at target to get result at bottom of the
screen.
2. Continuous Measurement
Long press measuring button to activate continuous measurement,
aiming at the target and press measuring button to stop, the current data
will be displayed accordingly.
*The continuous measurement will stop automatically after 5 minutes.
3. Wheel Measurement
Press mode switch button to activate wheel measurement. Wheel
measurement icon shows and ashes. Align the reference mark for wheel
measurement (5) with the starting point. Roll the wheel from the starting
point to the end point until the reference mark align with the end point, press
mode switch button again to stop the measurement, the current data will
be displayed accordingly.
To continue wheel measurement, press mode switch button again.
To end wheel measurement, press measuring button to change the mode
or long press mode switch button to turn o the device.
Wheel measurement icon
7
Mode switch button
Wheel
Reference mark
Start point
End point
USING TRIPOD
Use the adapter included as a standard accessory when mounting the device on
a commercially available tripod.
Attaching the adapter
Peel o the paper on the double sided tape and paste the adapter at the center
of the device.
Adapter
Screw hole
Double sided tape
8
ERROR CODE-REASON AND SOLUTION
All information will be showed as code or “Error’, the following are all codes and
corresponding solutions.
Code Cause Corrective measure
204 Calculation error Switch on/o the device several times and
measure again.
220 Battery low Charge the device
255 Received signal is too
weak
Improve the reective surface. (Use target
plate or white paper)
256 Received signal is too
strong
Improve the reective surface. (Use target
plate or white paper)
261 Out of measuring range Measure within the appropriate range.
500 Read error Switch on/o the device several times and
measure again.
“ WARNING To reduce the risk of injury, user must read instruction manual ”
9
- NOTE -
10
- NOTE -
