Kyocera DURAXV EXTREME Installation and user guide

Kyocera DuraXV Extreme
Verizon Push-to-Talk (PTT+)
“How To” Guide

Table of Contents:
1. DuraXV Extreme Phone
•Overview ------------------------------------------------------------------------------------- 4
•Keyguard ------------------------------------------------------------------------------------ 8
•Customizing your Main Menu ---------------------------------------------------------- 9
2. PTT+ Activation --------------------------------------------------------------------------- 10
3. How to Assign PTT key to PTT+ App -------------------------------------------- 13
4. General PTT+ Settings
•How to Access the PTT+ App Settings ------------------------------------------------ 15
•Important Settings
•PTT+ Alert Tones -------------------------------------------------------------------------- 16
•PTT+ Speed Dial -------------------------------------------------------------------------- 17
•Call from Lock Screen --------------------------------------------------------------------- 18
•Call History -------------------------------------------------------------------------------- 19
•Sharing Text, Location and Media with your PTT+ contacts/groups ----------- 20
•How to switch PTT+ Call Audio from Speaker to Earpiece and vice versa ---- 23
2

Table of Contents:
5. PTT+ Basic User Interface
•PTT+ Menu ---------------------------------------------------------------------------------- 26
•One Touch Action -------------------------------------------------------------------------- 27
•Status Indicator ---------------------------------------------------------------------------- 28
•How to Add Contacts ------------------------------------------------------------------- 29
•How to Add Personal Groups -------------------------------------------------------- 30
•How to Make 1-to-1 PTT+ Calls (Flip Open) ------------------------------------- 31
•How to Make 1-to-1 PTT+ Calls (Flip Closed) ----------------------------------- 32
•How to Make PTT+ Group Calls (Flip Open) ------------------------------------ 33
•How to Make PTT+ Group Calls (Flip Closed) ---------------------------------- 34
3

DuraXV Extreme Phone
Overview
Model Numbers:
•E4810 (camera version)
•E4810NC (non-camera version)
4

DuraXV Extreme Phone Overview (cont.)
5

DuraXV Extreme Phone Overview (cont.)
6

Lets you place or receive
calls in speakerphone mode
(with the phone closed), turn
the speakerphone on and off
during a call, or unlock the
keyguard (if configured).
Lets you display the recent call
history (with the phone closed),
ignore an incoming call, end
the ongoing call, or unlock the
keyguard (if configured). You
can select a name or number
from the call list and place the
call with the phone closed by
using the external speaker key.
DuraXV Extreme Phone Overview (cont.)
7

DuraXV Extreme: Keyguard
Use this feature to lock the external keys while the phone is closed to prevent accidental key
presses.
Select one of the following options:
•On - Long press to temporarily disable the keyguard by pressing and holding the External
speaker key while the phone is closed.
•On - Press 2 keys to temporarily disable the keyguard by pressing the Call list key and the
Volume down key sequentially while the phone is closed.
•Off to disable the keyguard.
8

DuraXV Extreme: Customizing your Main Menu
To replace a Main Menu icon, press right soft key “Options” and select replace items.
Default Main Menu Custom Main Menu
In the above example, Media center has been replaced with PTT+ icon.
9

PTT+ Activation
10
Select “Settings & tools”
from main menu Select “3. Business tools”
from the menu Select “1. Push To Talk+”
from the menu

PTT Activation (cont.)
1. It will show “Push To Talk Plus Verizon”
2. On the next page, click “Yes” to activate the subscription.
3. It will show a message “Contacting server, please wait …”
4. Next page, it will ask to enable GPS. Click “YES”.
Note: “High Accuracy” setting under Location is recommended; when selected
it will give the 3rd pop-up above. With “Device only”, the 3rd pop-up will not be available.
11

PTT+ Activation (cont.)
5. Select one of the 3 options on Location.
6. It will next show the Terms and Conditions. Click the left softkey to select “Accept”
7. It will ask if you want to view a quick tutorial. If you want to view the quick tutorial, click “Yes”.
Otherwise, click “No”
8. The main page of the PTT+ will show.
Note: “High Accuracy” setting under Location is recommended; when selected it will give the 3rd pop-
up above. With “Device only”, the 3rd pop-up will not be available. 12

How to assign the PTT key to PTT+ Application
1. Press and hold PTT key until pop-up appears on LCD screen.
2. “Would you like to select the function for this key now?” Select “OK”.
3. In PTT Key menu, select “Push To Talk+”.
4. It will show “PTT key set”.
PTT Key
Note: As an alternate method, PTT Key can be assigned manually by navigating to the below path:
Settings & tools → Settings → Programmable keys, then under PTT Key menu, Select “Push To Talk+“.
13

General PTT+ Settings
14

How to Access the PTT+ App Settings
1. From PTT+ main menu, Select “Options” (right soft key).
2. Scroll down to “Settings” using the navigation down key and press the center soft key.
15

Important Settings
PTT+ Alert Tones
In Settings, scroll down to
select “Alert Tone”. Scroll down and select desired Alert Tone.
16

Important Settings
PTT+ Speed Dial
In Settings, scroll down
to select “Speed Dial”. Scroll down and select unassigned spot.
After Speed Dial is set up:
To make a Speed Dial call, press the speed dial # on the keypad and then press the
PTT button.
Select desired
contact. Contact is now added
to Speed Dial list.
17

Important Settings
Call from Lock Screen
To set up Lock screen, go to Phone
settings and select “Security”. Then select Screen lock type and finish set up.
Once this is set up, you can make PTT calls by pressing PTT key even though phone is
locked.
In PTT App, go to Settings and
select “Call from Lock Screen”.
18

Call History
Goto “Home” tab. Call
history is shown Select a contact and press “View”. Detailed
record of calls and alerts is shown.
To see a record of call history –with the newest at the bottom.
19

Sharing Texts, Location, and Media with your PTT Contacts/Groups
Select the Contact and
Press left soft key “Share”.
Scroll down and select item
you want to share.
Using Share feature, you can send text messages, your location,
images, videos, voice messages and files.
20
