Kyocera K3000 User manual

K3000 Phone
User’s Manual

2
About this manual
Welcome to the K3000 Phone. This Phone comes with two parts.
‘Before you start’
‘Operation Instruction’
Before using your K3000 Phone, read ‘Before you start’ for overview of features, basic setup, and
other important details.
After you have become familiarized with its basic functionality, refer to the operation Instruction for
detailed features, less common tasks, and for maintaining your K3000 Phone.
These manuals can also serve as a source of information if you have problems operating your K3000
Phone.

3
I. Before you start
A. FEATURES
1.Unpacking
2.Phone Layout
3. Display Layout
4. Battery
5. SIM Card
6. T-Flash
7. Headset
8. USB Cable
B. Basic usages
1. Power On/Off
2. Call Function
3. Multimedia Function
4. Text Input mode
5. Phone Book

4
II. Operation Instruction
A. Menu Operation
1. Phone Book
2. Message Center
3. Call Histroy
4. Settings
5. Multimedia
6. Fun & Games
7. User Profiles
8. Organizer
9. Services
10. Communications
11. Shortcuts
B. Trouble Shooting
C. Safety Information
D. Glossary

5
I. Before you start
K3000 Phone

6
A. Features
1. Unpacking
Your package list is as shown below
Handset Manual Travel Adaptor Earphone
USB Cable
(Optional)
2. Phone Layout
The following illustration shows the main elements of your phone.
2.1 LCD
You can enjoy the more clear LCD color having 260K colors TFT with your K3000 phone
2.2 Camera
You can take a photo with K3000’s embedded digital camera. K3000 has 2.0 Mega pixels camera
module, you can enjoy highly qualify digital photo with your K3000 phone.
2.3 Slide Type
K3000 is slide type phone. You can open the slide as follows;

7

8
2.3 Keys Description
Function Keys
Left Soft Key
[Basic Function]
Performs the functions indicated by the text in the left-bottom line of the
display screen. Usually works as ‘selection’ key
[Idle Mode]
Enter main menu
[MPEG4 Mode]
Play & Pause MPEG4 file
Right Soft key
[Basic Function]
Performs the functions indicated by the text in the right-bottom line of
the display screen. Usually works as ‘backward’ key
[Idle Mode]
Enter Phonebook list menu
[MPEG4 Mode]
Stop playing MPEG4 file
Makes or answers a call. In the idle mode, launches the call log menu.
Ends a call. Also switches the phone on or off when pressed and held. In
the menu, returns to the idle mode or cancels your input.
Clear Key, Usually works as ‘cancel’ key
FWD(삭제요망) Play next MP3(K3000에는MP3외부키가 존재하지 않는다)
PLAY/PAUSE(삭제요망) Play or Pause MP3(K3000에는MP3외부키가 존재하지 않는다)
BACK(삭제요망) Play previous MP3(K3000에는MP3외부키가 존재하지 않는다)
Navigation Keys
[Idle Mode]
Enter WAP browser mode (press and hold)
Initiates the Audio Player (short press)
[Basic Function]
move the cursor or selection bar up (Text edit mode or menu mode)
[Idle Mode]
Initiates the Audio Player.
[Camera Mode]

9
Magnify the image (Digital Zoom Function)
[AudioPlayer Mode]
Play & Pause MP3 file
[Basic Function]
move the cursor or selection down (Text edit mode or menu mode)
[Idle Mode]
Enter the Alarm Menu.
[Camera Mode]
Reduce the image (Digital Zoom Function)
[Audio Player Mode]
Stop playing MP3 file
[Basic Function]
move the cursor or selection left (Text edit mode or menu mode)
[Idle Mode]
Enter the User Profiles Menu, Set up Alert tones.
[Camera Mode]
Adjust EV Level
[Audio Player Mode]
Go to previous MP3 file
[Video Player Mode]
Speed Rearward
[Basic Function]
move the cursor or selection right (Text edit mode or menu mode)
[Idle Mode]
Enter the Tone Setup menu.
[Camera Mode]
Adjust EV Level
[Audio Player Mode]
Go to next MP3 file
[Video Player Mode]
Speed Forward

10
Alphanumeric Keys
[Press]
Enter number and string
[Press and Hold]
: Enter ‘+’ (international call)
: On and Off silent mode
[Video Play Mode]
Wide screen view
Side Keys
[Basic Function]
move the cursor or selection bar up in menu mode
[Idle Mode]
Increase the Ring-Tone volume
[Audio/Video Player Mode]
Increase the volume
[Basic Function]
move the cursor or selection down (Text edit mode or menu mode)
[Idle Mode]
Decrease the Ring-Tone volume
[Audio/Video Player Mode]
Decrease the volume
[Short Press]
Enter the Camera Mode
[Press and Hold]
Enter the Take Video Record Mode
3. Display Layout
3.1 Display Screen

11
ÅFixed Icon Area
ÅNetwork Status Area
ÅUser Setting Screen Area
ÅTime & Date Area
ÅSoft Key Area
This images will be changed.
3.1.1 Fixed Icon Area:
8 fixed icons are displayed indicating the phone status.
3.1.2 Network Status Area:
Network name registered is displayed.
If there is no GSM network coverage, No Service is displayed.
If you are in the coverage area of a GSM network but you are not allowed to register to the
network, Emergency is displayed.
3.1.3 User Setting Screen Area:
Digital Clock , Analog Clock , Images is displayed according to the setting of Wallpaper Select
menu.
If you set to get the broadcast message from the network, you can see it on the idle screen. For
details of how to activate and deactivate it, please see Cell Broadcast menu in A2. In this case, the
User setting screen Area updates the received broadcast messages. If you want to go back to
default screen, press [END].
! Note:The broadcast message service may not be available on all networks.
3.1.4 Time & Date Area
Current time and date is displayed in the Time & Date Area.
3.1.5 Soft Key Area:
The functions assigned to the right and left soft keys.
3.1.6 Icons Descriptions
Icon Description
Rssi Bar Shows the received signal strength. The greater the number of bars, the

12
better the signal strength.
Battery Bar Shows the current battery charge level. The green area shows charge
level of battery.
Appears when the alarm clock is set.
Appears GPRS Mode is on
Indicate the phone number line you select
Show Phone Lock mode
Roaming
Appears when you miss call
Appear when e-mail has been received
Appear when FAX has been received
Appears when Voice mail has been received
Appears when SMS has been received
Appears when MMS has been received
Appears when MMS client is busy
Appears when phone is mute mode
Appears when alert mode is selected as ring
Appears when alert mode is selected as Silent
Appears when alert mode is selected as Vibrator
Appears when alert mode is selected as Vibration and Ring
Appears when alert mode is selected as Vibration then Ring
Appears when WAP push is arrived
Appears when stopwatch application is undergoing
3.2 Camera Mode Screen

13
3.2.1 Preview Area :
You can see a preview shot before you take a photo.
3.2.2 Control Area:
You can see the status of photo mode setting with this control area. Each icon of control area has
specific functions. The following table describes what the icons mean.
Functions Icons
Zoom
Exposure Value
LED Highlight
Delay timer
Continuous shot
Night mode
Image quality
Image size
3.3 MP3 Mode Screen
ÅMP3 File Info Area
ÅMP3 Control Area
ÅSoft Key Area
ÅMenu & Control Area
ÅPreview Area
ÅSoft Key Area

14
3.3.1 Icon Description
Icons Description
Play MP3 file
Pause MP3 file
Stop playing MP3 file
Go to Previous MP3 file
Go to Next MP3 file
Show volume strength level
Show phone icon when MP3 file from phone
Show memory card icon when MP3 file from RS MMC card
4. Battery
4.1 How to attach the battery
a. Align the bottom of the battery with the slot in the bottom of the phone.
b. Then sit the battery on the back of the phone until it clicks into place.
The image will be put later.
4.2 How to remove the battery
a. Turn off your phone first.
b. Push up the battery release latch
c. Slowly lift the battery away from the up.
The image will be put later.
4.3 How to charge the battery
a. Plug your charger in the wall socket.
b. Connect the other end to the interface connector on the bottom of the phone.

15
The image will be put later.
! Note
The phone will automatically check the battery status while the charger connector is installed on the
phone. Once it detects that the battery level
zFull status, it automatically recharges the battery.
zNormally the phone completes battery charging in one hour.
zFor a new or completely discharged battery, it takes at least 4 hours of charging to achieve
optimum performance.
zYou can make calls while charging your phone.
zDo not charge the phone without the battery in place.
5. SIM Card
SIM Card provides additional services and functions besides making a call.
These functions will only display and work on the menu of the phone if your SIM card supports them.
Some menu may not be shown depending on the SIM card supplied.
The content and the terms of the function lists will depend on your network service provider.
Please contact your network service provider (a network operator or the service provider) regarding
availability of services related to the SIM card, application information and the costs.
5.1 How to place the SIM card
Ensure the phone is powered off and the travel charger is detached first before you start the following
steps.
Orientate your SIM card with its gold contacts facing downwards and push it fully into the
holder as show below.
The image will be put later.
5.2 How to remove the SIM card
Ensure the phone is switched off and the travel charger is detached first before you start the
following steps.
a. Remove the battery.
b. Remove the SIM card from the holder.

16
The image will be put later.
! Note: The SIM card is a computer chip containing information about your subscription, security,
phonebook etc. When you register as a subscriber with GSM network operator, you are provided with
the SIM card. Always handle the SIM card with care and insert with the gold contacts facing down.
6. T-Flash
T-Flash provides more big flash memories for MP3 and MPEG4 depend on memory card size.
5.1 How to place the T-Flash
Ensure the phone is powered off and the travel charger is detached first before you start the
following steps.
a. Pull out the T-Flash rubber in the direction of the arrow
b. Insert a T-Flash and then push into the T-Flash holder
c. Stop up the T-Flash rubber
The image will be put later.
5.2 How to remove the T-Flash
Ensure the phone is switched off and the travel charger is detached first before you start the
following steps.
a. Pull out the T-Flash rubber
b. Push the T-Flash card and then remove it
c. Stop up the T-Flash rubber
The image will be put later.
6. Headset
Insert the headset plug into the jack on the left side of your phone marked
You can answer or end a call by pressing the hook button on the headset.
When you receive an incoming call while a call is in progress, you can answer the incoming call by
pressing the hook button on the headset. (The first call is automatically put on hold.)
You can make the last number dialed call by pressing the hook button when the screen is idle.
The last number dialed is launched by pressing the hook button, and then the call will be made by
pressing the hook button again.

17
The image will be put later.
! Note: If the headset is plugged in, your phone’s standby time will be reduced. Therefore, please
remove the headset when not in use.
7. USB cable
1. Connect the USB connector to USB port of PC (Desktop or Notebook)
2. Connect the other end to the interface connector on the bottom of the phone
The image will be put later.
Two functions are available via USB connection.
7.1 Data transfer with PC
When you connect your phone with PC by USB cable, the following window is shown up on you phone
LCD.
zMass Storage : You can use your phone as external memory
=> MP3 file, Image File, Photo File
zWebcam: You can use your phone as a external camera.
zCOM port : You can synchronize your phone data with PC by using ‘Phonesuite’ program
=> Phonebook, SMS message, Image file, i-meldody file
! Note : Refer to additional manual ‘Phonesuite’ regarding Synchronization function.
7.2 Charging
Your phone is on charging status automatically while USB cable connected with PC.
B. Basic Operation
1. Power On/Off
To switch your phone On and Off, make sure that the battery is inserted.

18
zTo switch your phone on, press and hold down [END] until you hear the power-on melody.
zTo switch your phone off, press and hold down [END] until you hear the power-off melody.
! Note : Some SIM card may be protected with PIN. If Enter PIN is prompted, enter your PIN and then
press [Ok soft key]. For more details, please see Security Setting in ‘Operation – Menu’.
2. Call Function
2.1 Making a Call
To make a call with your phone, insure that phone screen is idle mode, then key in the area code and
phone number using the numeric keys and press the Dial & Menu confirmation key.
You can hear the connect tone when the call is answered by the called person, if you set the Connect
tone to ON.
2.2 Making International Calls
Press and hold the ‘0’ key to display “+” character.
Please Key in the country code, area code (without the leading zero) and the phone number. And then
press the Dial & Menu confirmation key. The ‘+’ tells the network that the call is international.
2.3 Edit Phone Number
Key Description
[Press]
Delete a digit on the left side of cursor
[Press and Hole]
Delete the whole digit
Move cursor to the digit you want to edit
2.4 Using Phonebook
You can store the names and phone numbers dialed regularly in the SIM card and phone memory.
zSee Phonebook List : If you want to go to the phonebook list, push right soft key, and then
choose the name what you want to find using Navi-Up & Down keys. Push Dial key when you
want to make a call or push left soft key to go to option menu.
zSearch Phonebook : If you want to search phonebook list with special name, push right soft
key and then push navi-down key, and then enter the name what you want to find. Input full

19
name or even a start letter and select “OK” menu. If there is the name you want to call, choose
the name by moving navi-up & down key. Push Dial key when you want to make a call or push
left soft key to go to option menu.
2.5 Making a Call from Message
You can make a call from message by pushing Dial & Menu Confirmation key when the message you
want to call back is highlighted. And you can also make by choosing “Call Back” Menu in the option of
“Inbox” after you read a message.
2.6 Redialing the last Number
The phone stores the last 30 numbers dialed. To recall any of these numbers, proceed as follows.
zPress the Dial key to display a list of the last numbers.
zUse Up & Down navigation keys to scroll through the numbers until the required number is
highlighted.
zDial the number highlighted
2.7 Ending a Call
When you have finished your call, briefly press the Menu exit key, or close the slide.
2.8 Answering a Call
When you answer a call, the phone rings or vibrates according to the setting with the incoming call
animation.
When the caller can be identified, the caller’s phone number and name, if stored in phonebook, will be
displayed. If the caller cannot be identified, only the caller’s phone number will be displayed.
zPress the Dial & Menu confirmation key. If the Any key Answer option is set to ON, you can
press any key to answer a call except for the power on/off key when the slide is open.
To reject an incoming call, press and hold the volume keys on the right side of the phone
without opening the slide.
If the Cover Answer option is set to ON, you do not need to press any key. You can
answer the call simply by opening the slide when the slide is closed.
zEnd the call by closing the phone or pressing the Menu exit key.
z
2.9 Emergency Call
Ensure that the phone is switched on and in service.
Enter the emergency number (Official emergency number or another official emergency number) and
press the Dial & Menu confirmation key. Give your location. Do not end the call until given permission

20
to do so.
End the call by closing the slide or pressing the Menu exit key.
! Note : In the situation such as power-on that Enter Lock Code or Enter PIN is prompted, Some
network may not allow the emergency call and may request to insert SIM card.
2.10 Entering a “Pause” Character in a Dial String
A pause (“P”) character may be entered into a dial string by pressing the left special function key( “*” )
three times.
2.11 Adjusting Earpiece Volume
During a call, you can adjust the earpiece volume by pressing up side or down side of key on the
right side of this phone. If you want to change keypad tone, press up side or down side of volume key
in idling mode.
2.12 Using the Earphone
If you insert the earphone to the jack of your phone, you can use it in the same way as your phone’s
earpiece and microphone.
You can answer or end a call by pressing the hook button on the earphone.
To answer another call while you are on the phone, you can answer the waiting call by pressing the
hook button on the earphone.
3. Multimedia Function
3.1 Camera
If you want to take a photo, please follow the procedure as below
zOpen the slide.
zPress ‘Camera’ key to enter camera mode
zPress ‘Wap’ key to take a photo
zIf you want to save the image, press save button and write the title, otherwise press back
button.
