Kyocera Urbano Progresso Service manual

Basic operation au かんたん設定 (au Easy Setting)
Setting up Google account Setting Wi-Fi®
April2012,1stEdition
Soldby:KDDICORPORATION
OKINAWACELLULARTELEPHONE
COMPANY
Manufacturedby:KYOCERACorporation
Thank you for buying the URBANO PROGRESSO (simply called the "product"
from here on). In this guide, settings and precautions for using the product are
described.
For explanations of basic functions, refer to "Basic Manual".
Company names and product names generally referred to in this manual are trademarks or
registered trademarks of respective companies.
The TM, ® may be omitted in this manual.
Screen illustrations shown in this manual may look different from the actual screens. In some cases,
upper or lower part of a screen may be omitted.
Display
F Power key
Tap
HHome key
Display the Home screen or use for canceling
sleep mode.
Return to the previous screen.
M Menu key
Display function (menu) corresponding operations.
《Character entry screen (10-key)》
Flick
Power On
Press and hold F.
Operate directly touching with your finger.
Long-touch
Character entry mode switch key
Tap to switch character type.
CBack key
For detailed operation method, refer to "Basic Manual".
Flick input
■Character entry
Enter character by flick input or tapping key repeatedly.
[ ] Applications list
Display the Applications list. By default, the Simple menu appears.
Unlocking
Tap " " to unlock.
Lightly touch a
screen and then
immediately
release your
finger.
Keep touching
an item or key.
Quickly move
(flicking) your finger
up, down, right, or
left.
Long-touch a key to display input candidates for flick input as follows. Flick to the
direction of character to enter.
The first time the product turns ON, "au かんたん設定 " which allows you to perform initial settings of au ID, au Wi-Fi SPOT, etc. collectively. After confirming the screen, tap " 次へ (Next)" and then
operate au ID setting etc.
・On the "au かんたん設定 "screen, press Cand then from the Home screen→[ ]→[設定 (Settings)]→[言語と入力 (Language & input)]→[言語 (Language)]→"English"to switch language, then set au ID later.
In that case, from the Simple menu→[Apps]→Tap "au Easy Settings" or "au ID Setting".
■au ID
au ID password
By setting au ID, you can use various services provided by au such as "au かんたん決済 (au easy payment)" which allows you to purchase applications from the au Market or "au スマートパス (au
smart pass)". Main setting items as follows.
Register password for using au ID.
Register your au phone number or any character string for au ID (user ID).
Setting Guide
Use your home wireless LAN (Wi-Fi®) or public wireless LAN to connect the Internet.
Main setting method is as follows.
* If you turn on wireless LAN (Wi-Fi®) function, battery consumption increases. You are recommended to turn wireless LAN (Wi-Fi®) function to OFF when not using wireless LAN (Wi-Fi®) function.
When access point is not detected, select "ADD NETWORK"to add
access point manually.
Simple menu/
Applications list
→[Settings] [AOSS settings]
When license
agreement screen
appears, [Agree]
[ ]
[EASY SETUPS]
[Wi-Fi] Tap "OFF" to
set to "ON"
Available Wi-Fi
networks are
detected
automatically
and the SSIDs
appear in the
Wi-Fi networks
field.
Keep pressing
AOSS button of
access point to set
to AOSS mode. An
access point is
automatically
detected and
registration starts.
Enter text displayed
on screen, then [Next]
Make purchase
settings of Play
Store as required
Enter "First name",
"Last name"
→[Next]
Enter a recovery
email address*,
security question
and answer when
you forgot the
password, then
[Next]
* If you have no
other mail address,
remain as blank.
On the Google
account setting
screen, [New]
If you have Google
account, tap "Existing".
Enter password, and
reenter the password
for confirmation,
then [Next]
[WPS button]
Keep pressing WPS
button of access
point to set to WPS
mode. An access
point is
automatically
detected and
registration starts.
Enter a user name
→[Next]
Checking registration
of username starts.
User name
Password
Set up Google account to use Google applications such as "Gmail", "Play Store", "Google Talk".
Setting items are as below (Registration of "Last name", "First name", "Security question and Answer" in addition to the items below is required).
Register your Google account (user ID) and any character string for mail address. Username which is already used by another user cannot be set.
Register password for the Google account.
Confirm the back
up setting and
[Next]
Google account
registration is
completed.
* This screen may not
be displayed.
Check the
contents, then
[I accept]
Set if you join
Google+.
[次へ (Next)] Comfirm the contents,
then [OK]
[au ID の設定・保存
(Set/Save au ID)]
Enter au ID password,
[利用規約に同意して
新規登録(Agree terms of
service and register)]
Enter a security
password, then [OK]
Default value is 4-digit
security code written at
subscription.
au かんたん設定 screen
→[次へ (Next)]
* Registering new au ID
except au phone
number: Newly
register from [ お好き
なau ID を新規登録し
たい方はこちら (New
registration of au ID)]
* Registering your au
ID: Set from［au ID を
お持ちの方はこちら
(For au ID holder)］
■Basic operation
Describes the basic operations.
■au かんたん設定 (au Easy
Settings)
Describes how to set up when turning
the power on for the first time.
■Setting up Google account
Describes how to set up Google
account.
■Setting Wi-Fi®
Describes how to connect Wi-Fi®network
■E-mail setting
Make initial settings for E-mail
(〜@ezweb.ne.jp) etc.
■WiMAX setting
Describes how to connect WiMAX
network.
■Making a call
Describes how to make a call.
■Receiving a call
Describes how to receive a call.
■Importing/Exporting
contacts
Import/Export contacts between the
product and microSD™ memory card.
■Viewing/Playing data
Describes how to view/play images or
video data.
■Saving battery power
Describes how to set for saving battery
consumption using "E-saving settings".
■Using WEB de 請求書 (WEB
de Seikyu-syo)
Describes how to use "WEB de 請求書 "
for checking your monthly charge via
Internet.
■Settings in case of loss of
the product
Describes how to set "Anshin Security
Pack".
* "au ID" which is already used by another user cannot be set.
au ID*
AOSS
TM
system
Use for registration of access point with AOSSTM mark such as
AirStationTM of BUFFALOTM.
WPS system Use for registration of access point compatible with Wi-Fi Protected
SetupTM with WPS mark.
Using AOSSTM system access point
Using WPS system access point
Introduction
1 2 3 4 5 6 7
8 9 10
1 2 3
4 5
6 7
6 7
8
1 2 3 4 5 6
Enter "生年月日
(Date of birth)",
"秘密の質問
(secret question)",
"答え (Answer)" and
then "入力完了 (Done)"
8
[設定 (Setting)]
9
[設定画面へ
(Go to setting
screen)]
Register information
necessary for re-issue
of password.
7
[終了 (Done)]
10
[次へ (Next)]
→Confirm the contents and
[同意する (Agree)]
→[同意する (Agree)]
11
[設定完了 (Done)]
12
Confirm the contents
and select if you
accept it→
[次へ (Next)]
13
[完了 (Done)]
14

■Initial settings
PC-mail settings
You can use mail addresses except for E-mail ( 〜@ezweb.ne.jp). You need to set up a
PC-mail account to use PC-mail. For the first time use, make settings as follows.
Simple menu→[Apps]→[PC mail]→Enter mail address and password→
[Next]→Make account settings→[Next]→Enter account name and
display name→[Next]
[EXPORT]
Simple menu/
Applications list
→[Contacts]
You can transfer contacts data to the product via microSD™ memory card, or back up contacts data in the product to microSD™ memory card.
[Import from SD card]
[Export to SD card]
Home screen
→[ ]
M
→[E-mail settings]
■Direct input calling
Home screen
→[ ]
Input phone
number, [ ]
■Making a call from incoming/outgoing history
Phone number input
screen→[ ]
[ ] of a party to call
Enter E-mail
address and then
[送信 (Send)]→[OK]
Check the contents,
then [ 承諾する
(I agree)]
[E メールアドレスの
変更 (Change
E-mail address)]
Enter the security
code and then
[送信 (Send)]
[Other settings]
→[OK]
■Changing your E-mail address
After E-mail initial
settings, your E-mail
address appears.
Home screen
→[ ]
Check the contents,
then [OK]
To use E-mail ( 〜@ezweb.ne.jp), subscription to IS NET is required.
If you did not subscribe it when you purchased the product, contact an au shop or Customer Service Center.
E-mail ( 〜@ezweb.ne.jp) allows you to exchange mails with computers and mobile phones
that support E-mail. Your E-mail address is determined automatically after initial settings. You
can change the E-mail address later.
* If you have never activated E-mail ( 〜@ezweb.ne.jp), you cannot perform data communication
overseas. Be sure to make initial settings of E-mail ( 〜@ezweb.ne.jp) in Japan.
E-mail setting
Importing/Exporting contacts
Making a call Receiving a call
[Import]
Reading starts.
On the confirmation
screen, [OK]
Saving starts.
■Calling from a contact
Phone number input
screen→[ ]
Tap a party to call
■Calling
Receiving screen
→Drag [ ] right
Start calling. To end the call,
[ ]
■Answering with answering memo
Receiving screen
→Press M
[Reply Auto answering] The caller hears
the guidance.
Answer by the answering memo message and record a message of the party when you
cannot answer calls.
To answer the call,
drag [ ] right.
To import contacts
Attach a microSD™ memory card with transferring data saved in advance.
To export contacts
Attach a microSD™ memory card to the product in advance.
[0 items selected]
→[Select all]
Alternatively, select
importing data from
the list.
[0 items selected]
→[Select all]
Alternatively, select
exporting data from
the list.
M
→[Import/export]
Simple menu/
Applications list
→[Contacts]
M→[Import/export]
If you do not set an
account, tap
"Import/Export
contacts".
If a selection screen
appears, select a
saving location.
Using WEB de 請求書 (WEB de Seikyu-syo)
Simple menu
→[Apps]
"WEB de 請求書 " allows you to check your monthly charge using the Internet.
●For the product, check WEB page on a PC.
●Support ID is required for checking your charge on "WEB de 請求書". If you have no
account, register* one.
* For registration, "au phone number", "security code", "customer number (on copy of new/change
service agreement)" and "birth date" are required.
[確認する (Confirm)] [WEB de 請求書
(WEB de Seikyu-syo)]
For details about
operations, see the site.
[au お客さまサポート
(au Customer Support)]
If terms of use appears,
confirm the contents and
then tap " 同意する (Agree)".
Simple menu
→[Apps]
[サポート＆サービス
(Support & services)]
[安心セキュリティパック
(Anshin Security pack)]→
[3LM Security]/[ ウィルス
バスター モバイル for au
(VirusBuster mobile for
au)]/[ リモートサポート
(Remote support)]
[au お客さまサポート
(au Customer Support)]
Simple menu/
Applications list
→[E-saving settings]
Mark "E-saving
settings"
Using "E-saving settings" to set backlight timeout or screen brightness to the minimum value,
or set Auto-rotate screen, Wi-Fi®, WiMAX, Bluetooth®, GPS, Live Wallpaper, Wallpaper,
Pedometer, Use wireless networks to "OFF", you can save the battery power.
Saving battery power
Select "My e-saving settings"
to set items for saving battery
power individually.
Simple menu/
Applications list
→[Files]
Tap a category
and data to be
displayed
By transferring data from the previously used au phone to a microSD™ memory card, you
can view/play* the data such as photos or movies using "Files" in the product.
Viewing/Playing data
* Copyrighted data on the previously used au phone cannot be transferred to the product. However,
some 着うたフル®, ビデオクリップ, 着うたフルプラス®may be able to be transferred and played on
the product with the same phone number by backing up with LISMO Port Ver4.2 or later.
Data is played.
WiMAX setting
Use +WiMAX service to communicate large amount of data such as streaming playback of
video or downloading music outside of home.
* WiMAX is set to ON by default (or of reset).
* Monthly usage charge will be applied for using WiMAX.
* This service supports WiMAX provided by UQ Communications Inc.
* If you turn ON WiMAX, battery consumption increases. You are recommended to turn WiMAX to
OFF when not using WiMAX.
●WiMAX network is automatically detected. You do not need to operate for the
connection.
●When WiMAX is disconnected, operate from the Simple menu/Applications list
→[Settings]→[WiMAX] to scan WiMAX network again.
Simple menu/
Applications list
→[Settings]
Tap "OFF" of WiMAX
to set to "ON"
WiMAX is ON.
Available WiMAX
networks can be
detected. When
detected, " "
appears on the
status bar.
When an explanation
screen of E-saving
settings appears, set
whether to display
the explanation next
time.
From here on, follow
the onscreen instructions.
If terms of use appears,
confirm the contents and
then tap " 同意する (Agree)".
1 2 3
21 3
4 5 6 7
1 2 3
1 2
1 2
1 2
1 2 3
1 2 3
4
1 2 3 4 5
1 2 3 4 5 6
1 2
1 2 3 4
1 2
1 2 3 4
Settings in case of loss of the product
If you subscribe to Anshin Security Pack, set up "3LM Security", " リモートサポート (Remote
Support)" and " ウィルスバスター™ モバイル for au (VirusBuster mobile for au)".
●Anshin Security Pack is a charged service.
