Kyocera 5135 User manual

82-K5247-1EN, Rev. 001
User Guide
Kyocera
5135
Kyocera 5100 Series

ii
User Guide for the Kyocera 5135 Phone
This manual is based on the production version of the Kyocera 5135 phone.
Software changes may have occurred after this printing. Kyocera reserves the
right to make changes in technical and product specifications without prior
notice. The products and equipment described in this documentation are
manufactured under license from UALCOMM Incorporated under one or more
of the following U.S. patents:
4,901,307 5,056,109 5,099,204 5,101,501 5,103,459 5,107,225
5,109,390 5,193,094 5,228,054 5,257,283 5,265,119 5,267,261
5,267,262 5,280,472 5,283,536 5,289,527 5,307,405 5,309,474
5,337,338 5,339,046 5,341,456 5,383,219 5,392,287 5,396,516
D356,560 5,408,697 5,414,728 5,414,796 5,416,797 5,426,392
5,437,055 D361,065 5,442,322 5,442,627 5,452,473 5,461,639
5,469,115 5,469,471 5,471,497 5,475,870 5,479,475 5,483,696
5,485,486 5,487,175 5,490,165 5,497,395 5,499,280 5,504,773
5,506,865 5,509,015 5,509,035 5,511,067 5,511,073 5,513,176
5,515,177 5,517,323 5,519,761 5,528,593 5,530,928 5,533,011
5,535,239 5,539,531 5,544,196 5,544,223 5,546,459 5,548,812
5,559,881 5,559,865 5,561,618 5,564,083 5,566,000 5,566,206
5,566,357 5,568,483 5,574,773 5,574,987 D375,740 5,576,662

User’s Guide for the Kyocera 5135 phone iii
5,577,022 5,577,265 D375,937 5,588,043 D376,804 5,589,756
5,590,069 5,590,406 5,590,408 5,592,548 5,594,718 5,596,570
5,600,754 5,602,834 5,602,833 5,603,096 5,604,459 5,604,730
5,608,722 5,614,806 5,617,060 5,621,752 5,621,784 5,621,853
5,625,876 5,627,857 5,629,955 5,629,975 5,638,412 5,640,414
5,642,398 5,644,591 5,644,596 5,646,991 5,652,814 5,654,979
5,655,220 5,657,420 5,659,569 5,663,807 5,666,122 5,673,259
5,675,581 5,675,644 5,680,395 5,687,229 D386,186 5,689,557
5,691,974 5,692,006 5,696,468 5,697,055 5,703,902 5,704,001
5,708,448 5,710,521 5,710,758 5,710,768 5,710,784 5,715,236
5,715,526 5,722,044 5,722,053 5,722,061 5,722,063 5,724,385
5,727,123 5,729,540 5,732,134 5,732,341 5,734,716 5,737,687
5,737,708 5,742,734 D393,856 5,748,104 5,751,725 5,751,761
5,751,901 5,754,533 5,754,542 5,754,733 5,757,767 5,757,858
5,758,266 5,761,204 5,764,687 5,774,496 5,777,990 5,778,024
5,778,338 5,781,543 5,781,856 5,781,867 5,784,406 5,784,532
5,790,589 5,790,632 5,793,338 D397,110 5,799,005 5,799,254
5,802,105 5,805,648 5,805,843 5,812,036 5,812,094 5,812,097
5,812,538 5,812,607 5,812,651 5,812,938 5,818,871 5,822,318
5,825,253 5,828,348 5,828,661 5,835,065 5,835,847 5,839,052
5,841,806 5,842,124 5,844,784 5,844,885 5,844,899 5,844,985
5,848,063 5,848,099 5,850,612 5,852,421 5,854,565 5,854,786

iv
5,857,147 5,859,612 5,859,838 5,859,840 5,861,844 5,862,471
5,862,474 5,864,760 5,864,763 5,867,527 5,867,763 5,870,427
5,870,431 5,870,674 5,872,481 5,872,774 5,872,775 5,872,823
5,877,942 5,878,036 5,870,631 5,881,053 5,881,368 5,884,157
5,884,193 5,884,196 5,892,178 5,892,758 5,892,774 5,892,816
5,892,916 5,893,035 D407,701 5,898,920 5,903,554 5,903,862
D409,561 5,907,167 5,909,434 5,910,752 5,911,128 5,912,882
D410,893 5,914,950 5,915,235 5,917,708 5,917,811 5,917,812
5,917,837 5,920,284 D411,823 5,923,650 5,923,705 5,926,143
5,926,470 5,926,500 5,926,786 5,930,230 5,930,692
Other patents pending.
T9 Text Input is covered by U.S. Pat. 5,818,437, U.S. Pat. 5,953,541, U.S. Pat.
6,011,554, Canadian Pat. 1,331,057 and patents pending worldwide.
Kyocera is a registered trademark of Kyocera Corporation. UALCOMM is a
registered trademark of UALCOMM Incorporated. Brick Attack is a trademark of
Kyocera Wireless Corp. Openwave is a registered trademark of Openwave
Systems Incorporated. T9 is a registered trademark of Tegic Communications,
Inc. Other product and brand names may be trademarks or registered
trademarks of their respective owners.

User’s Guide for the Kyocera 5135 phone v
Copyright © 2002 Kyocera Wireless Corp. All rights reserved.
Ringer Tones Copyright © 2000–2002 Kyocera Wireless Corp.
82-K5247-1EN, Rev. 001
FCC/IC Notice
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
To comply with FCC radiation exposure requirements, use of this device for body-
worn operational configurations is limited to accessories tested and approved by
Kyocera Wireless Corp. Other accessories used with this device for body-worn
operations must not contain any metallic components and must provide at least
13.5 mm separation distance including the antenna and the user’s body. Other
accessories that have not been tested for body-worn SAR may not comply with
FCC radiation exposure limits and should be avoided.
This model phone meets the government’s requirements for exposure to
radio waves.

vi
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency
(RF) energy set by the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The guidelines are
based on standards that were developed by independent scientific organizations
through periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR limit set
by the FCC is 1.6W/kg.* Tests for SAR are conducted using standard operating
positions specified by the FCC with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is determined at the
highest certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power required to reach
the network. In general, the closer you are to a wireless base station antenna,
the lower the power output.

User’s Guide for the Kyocera 5135 phone vii
Before a phone model is available for sale to the public, it must be tested and
certified to the FCC that it does not exceed the limit established by the
government-adopted requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body) as required by
the FCC for each model. The highest SAR value for this model phone when
tested for use at the ear is 1.31 W/kg. and when worn on the body, as described
in this user guide, is 0.648 W/kg. (Body-worn measurements differ among phone
models, depending upon available accessories and FCC requirements).
While there may be differences between the SAR levels of various phones and at
various positions, they all meet the government requirement for safe exposure.
The body-worn measurements were performed on the following Kyocera
accessories:
Holster CV90-B1680
Leather Case CA90-B1691M
Leather Case CA90-B1691S
SAR testing was performed with production battery CV90-G8196,
Model # TXBAT10003.

viii
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF emission
guidelines. SAR information on this model phone is on file with the FCC and can
be found under the Display Grant section http://www.fcc.gov/oet/fccid
after searching on FCC ID OVFKWC-5135. Additional information on Specific
Absorption Rates (SAR) can be found on the Cellular Telecommunications and
Internet Association (CTIA) website at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones used by the
public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give additional protection for the
public and to account for any variations in measurements.
Caution
The user is cautioned that changes or modifications not expressly approved by
the party responsible for compliance could void the warranty and user’s authority
to operate the equipment.

User’s Guide for the Kyocera 5135 phone ix
Warning
Use only Kyocera approved accessories with Kyocera phones. Use of any
unauthorized accessories may be dangerous and will invalidate the phone
warranty if said accessories cause damage or a defect to the phone.
Optimize your phone’s performance
Use the guidelines on see page 4 to learn how to optimize the performance and
life of your phone, antenna, and battery.
Air ags
If you have an air bag, DO NOT place installed or portable phone equipment or
other objects over the air bag or in the air bag deployment area. If equipment is
not properly installed, you and your passengers risk serious injury.
Potentially unsafe areas
Posted facilities–Turn your phone off in any facility when posted notices
require you to do so.
Aircraft–FCC regulations prohibit using your phone on a plane that is in the air.
Turn your phone off before boarding aircraft.

x
Vehicles–RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer of the device
to determine if it is adequately shielded from external RF energy. Your physician
may be able to help you obtain this information.
Blasti g areas–Turn off your phone where blasting is in progress. Observe
restrictions, and follow any regulations or rules.
Pote tially explosive atmospheres–Turn off your phone when you are in
any area with a potentially explosive atmosphere. Obey all signs and
instructions. Sparks in such areas could cause an explosion or fire, resulting in
bodily injury or death.
Areas with a potentially explosive atmosphere are often, but not always, clearly
marked. They include:
• fueling areas such as gas stations
• below deck on boats
• transfer or storage facilities for fuel or chemicals
• vehicles using liquefied petroleum gas, such as propane or butane
