HIGH EFFICIENCY MULTICRYSTAL PHOTOVOLTAIC MODULE
KD 200-60 F Series
KD 200-60 Series
Cutting Edge Technology As a pioneer with 35
years in solar, Kyocera demonstrates leadership in the
development of solar energy products. Kyocera’s Kaizen
Philosophy, commitment to continuous improvement, is
shown by repeatedly achieving world record cell efficiencies.
Quality Built In
• UV stabilized, aesthetically pleasing black anodized frame
• Supported by major mounting structure manufacturers
• Easily accessible grounding points on all four
corners for fast installation
• Proven junction box technology with PV wire to
work with transformerless inverters
• Quality locking plug-in connectors to provide safe &
quick connections
New Process Improvements
• All solar cells are fabricated with a new proprietary
etching and coating process which translates into
a ‘smoother’ appearance while maintaining the
same gridline and bus-bar design.
• All modules have added crossbars on the back side
of the module for greater support and stability in
harsh conditions, including high wind and snow
load regions.
Reliable
• Superior built-in quality
• Proven superior field performance
• Tight power tolerance
Warranty
• Kyocera standard 20 year power output warranty
and 5 year workmanship warranty applies in USA
• Extended warranties available per project
requirements
• Kyocera standard 20 year power output warranty
and 2 year workmanship warranty applies
outside of USA
• Refer to Kyocera warranty policy for details
NEC 2008 Compliant UL 1703, ISO 9001 and ISO 14001
Certified and Registered Class C
Also available:
UL Listing
QIGU.E173074
QUALIFIED FOR “BUY AMERICAN”
Manufactured in San Diego, California

Standard Test Conditions
KD230GX-LFB KD235GX-LFB KD240GX-LFB
Pmp
2230 235 240 W
Vmp 29.8 29.8 29.8 V
Imp 7.72 7.89 8.06 A
Voc 36.9 36.9 36.9 V
Isc 8.36 8.55 8.59 A
Ptolerance +5/-3 +5/-3 +5/-3 %
ELECTRICAL SPECIFICATIONS
Nominal Operating Cell
Temperature Conditions (NOCT)
TNOCT 45.0 45.0 45.0 OC
Pmax 165 169 172 W
Vmp 26.8 26.8 26.7 V
Imp 6.18 6.31 6.45 A
Voc 33.7 33.7 33.7 V
Isc 6.77 6.92 6.95 A
Temperature Coefficients
Pmax -1.04 -1.07 -1.10 W/oC
Voc -0.133 -0.133 -0.133 V/oC
Isc 0.00502 0.00513 0.00515 A/oC
Operating
Temp -40~90 -40~90 -40~90 OC
System Design
Series Fuse Rating 15 A
Maximum DC System Voltage (UL) 600 V
Kyocera reserves the right to modify these specifications without notice.
All specification at 25°C. cell temperature, 1.5 AM and 1000W/m2.
NEC 2008 Compliant
UL 1703 Listed
KYOCERA SOLAR, INC. 800-223-9580 toll-free 800-523-2329 fax www.kyocerasolar.com
111810
MECHANICAL SPECIFICATIONS
MOUNtINg HOLEs gROUNDINg HOLEs DRAINAgE HOLEs
Legend
AUTHORIZED DISTRIBUTOR
1.8in
46mm
stABILIzER BAR
LABEL
CABLE w/
CONNECtOR
JUNCtION
BOx
4.25in
108mm
4.13in
105mm
40.55in/1030mm
32.68in/830mm
.49in
12.5mm
37.99(±0.1)in
965±2.5mm
Weight: 46.3lbs (21.0kg)
11.06in
281mm
11.06in
281mm
21.65in
550mm
21.65in
550mm
65.43in
1662mm
stABILIzER BAR
KD 200-60 F Series
