KZ RV SPORTSMEN LE User manual

SPORTSMEN LE
SPORTSMEN LE
TOY HAULER
SPORTSMEN SE
GUIDEBOOK TO ENJOYMENT OF YOUR
KZRV
RECREATIONAL VEHICLE

2
THE PURPOSE OF THIS OWNER’S MANUAL IS TO PROVIDE
THE MOST CURRENT INFORMATION AVAILABLE FOR YOUR
RECREATIONAL VEHICLE ABOUT USAGE AND OPERATION.
ALSO MINOR MAINTENANCE AND CRITICAL SAFETY
WARNINGS ARE INCLUDED AND MUST BE READ AND
OBEYED.
ADDITIONAL MAINTENANCE INFORMATION IS FOUND IN
THE “MAINTENANCE MANUAL”SUPPLIED WITH YOUR
RECREATIONAL VEHICLE. FAILURE TO PROVIDE CARE FOR
YOUR COACH WILL RESULT IN LOSS OF WARRANTY
COVERAGE.
ADDITIONAL MANUALS MAY BE SUPPLIED AND AVAILABLE
BY THE MANUFACTURER OF THE COMPONENT AND/OR
APPLIANCE. SEE THE INFORMATION PACKET IN YOUR
COACH.
© 2020 KZRV
LITHO U.S.A.
10-2019
Conventional Travel
Trailer
Travel Trailer Toy Hauler
Fifth Wheel
Fifth Wheel Toy Hauler
Hybrid Travel Trailer

3
TABLE OF CONTENTS
Chapter 1 –Introduction to RV Ownership...................... 7
Safety Considerations................................................... 8
Reporting Safety Defects........................................... 8
Safety When Emergency Stopping............................ 9
Additional Safety Considerations............................... 9
Extended or Cold Weather Use................................. 9
Condensation............................................................. 10
Causes....................................................................... 10
Solutions .................................................................... 10
Interior Ventilation...................................................... 11
Chapter 2 –Service Procedures ....................................... 12
Basic Service Procedures............................................. 12
Dealer ........................................................................ 12
Factory....................................................................... 13
Parts........................................................................... 13
Owner’s Responsibility .............................................. 13
Seasonal Site............................................................. 14
Towable Limited Warranty......................................... 14
Chapter 3 –Using Your RV................................................ 17
Equipment..................................................................... 17
Tow Vehicle ............................................................... 17
Hitches –Travel Trailer.............................................. 17
Hitch Height Specifications –Travel Trailer............... 18
Hook-Up —Travel Trailer.......................................... 18
The Safety Chain (Travel Trailer) .............................. 19
Traveling ....................................................................... 19
Weights...................................................................... 19
Weighing Vehicle (Loaded or Unloaded)................... 20
Loading the Trailer—Distribution............................... 20
Toy Hauler-Cargo Information................................... 21
Interior, Cargo Area ................................................... 23
Rear Screen Door...................................................... 23
Rear Cargo Door........................................................ 23
Tires.............................................................................. 24
Understanding Tire Pressure and Load Limits .......... 24
Tire Size..................................................................... 25
Tire Tread .................................................................. 25
Tire Balance and Wheel Alignment ........................... 25
Tire Repair ................................................................. 26
Tire Fundamentals..................................................... 26
Tire Speed Rating...................................................... 26
Cargo Capacities ....................................................... 26

4
How Overloading Affects Your RV and Tires ............ 27
How to Change a Tire................................................ 27
Wheel Bearings.......................................................... 28
Wheel Lugs................................................................ 28
Brakes—Electrical...................................................... 28
Breakaway Switch...................................................... 29
Towing .......................................................................... 30
Setting Up and Using Your Recreational Vehicle...... 30
Travel Trailer - Unhooking......................................... 31
General Detector Information ....................................... 32
Safety Detectors ........................................................ 32
Fire Extinguisher........................................................ 32
Propane/ Carbon Monoxide Detector........................ 32
What is Carbon Monoxide? ....................................... 32
Dual Sensor Technology ........................................... 33
Operation ................................................................... 33
Gas Alarm.................................................................. 33
Lower Power Operation............................................. 34
Visual and Audible Alarm Signals.............................. 34
CO Alarm ................................................................... 34
Propane Gas Alarm ................................................... 34
End of Life Signal....................................................... 35
Smoke Alarm ............................................................. 35
Operation ................................................................... 35
Testing ....................................................................... 35
Steps............................................................................. 36
Windows ....................................................................... 36
Doors ............................................................................ 36
TV Antennas (Standard Roof Mount) ........................... 37
Slideouts ....................................................................... 38
Trailer Set-Up Requirements-General....................... 39
Below Floor Slide System.......................................... 40
Above Floor Slideout (All Brands and Types)............ 40
Power for Operation................................................... 40
Electrical Components............................................... 41
Schwintec Wall Slide ................................................. 41
Manual Override ........................................................ 41
Blinds ............................................................................ 42
Ladder, Exterior ............................................................ 42
Entertainment Components.......................................... 43
Murphy Bed .................................................................. 43
Chapter 4 –Systems .......................................................... 44
Water and Drainage Plumbing...................................... 45
Fresh Water System.................................................. 45
Tanks ......................................................................... 45

5
Filling Fresh Water System - Gravity Fill ................... 45
Filling Fresh Water System - City Water Fill.............. 45
12-volt Demand Pump............................................... 46
Faucets ...................................................................... 46
Bath and Shower ....................................................... 47
Outside Spray Port .................................................... 47
Fresh Water Lines...................................................... 48
Low Point Drains........................................................ 48
Sanitizing and Filling the Potable Water System....... 48
Drainage (Fresh Water)............................................. 49
Sanitation System......................................................... 49
Toilets ........................................................................ 49
Using Toilet and Tank System................................... 50
Vents.......................................................................... 50
Holding Tanks............................................................ 50
Draining the Tanks..................................................... 51
Flush System............................................................. 51
Maintenance for Holding Tanks................................. 52
Heated Holding Tanks ............................................... 52
Winterizing Your Recreational Vehicle ...................... 52
Bypass Kit.................................................................. 53
Using the Water System during Freezing Weather... 54
Propane Fuel System ................................................... 54
Propane Container..................................................... 55
Servicing and Filling Propane Containers ................. 55
Installing Propane Containers.................................... 56
Regulator ................................................................... 58
High Pressure Hoses with Acme Connectors............ 59
Main Supply Hose –Low Pressure............................ 59
Operation ................................................................... 59
Checking for Leak...................................................... 60
Propane Consumption............................................... 61
Electrical System .......................................................... 62
General Information................................................... 62
Changes and Modifications ....................................... 62
120-volt AC System................................................... 63
Power Cord 30 Amp or 50 Amp................................. 63
Circuit Breakers and Box........................................... 63
50 Amp....................................................................... 64
GFCI Protection......................................................... 65
12-volt DC System..................................................... 66
Converter ................................................................... 66
Auxiliary Battery......................................................... 67
Circuit Breakers and Fuses-12-volt DC..................... 67
Power Cut off Switch for Battery................................ 68

6
Exterior Lights and Connector, 12V........................... 69
Porch Lights............................................................... 69
Brake Wiring .............................................................. 69
Portable Solar Panel Recept ..................................... 70
Back Up Camera........................................................ 70
Chapter 5 –Appliances...................................................... 71
What to Do If You Smell Propane................................. 71
Furnace......................................................................... 71
Thermostat –with Air Conditioner ............................. 72
Thermostat –without Air Conditioner ........................ 72
Operating Instructions................................................ 72
To Turn Off Furnace .................................................. 73
External Vents............................................................ 73
Ducting....................................................................... 73
Range and Oven Top Burner Operation....................... 74
Operating Instruction ................................................. 75
Top Burners ............................................................... 75
Oven Burner .............................................................. 75
Water Heater................................................................. 77
Operating Instructions: Direct Spark Ignition............. 77
Operating Instructions: Electric Elements.................. 78
To Turn Off Water Heater.......................................... 78
Winterizing Your Water Heater.................................. 78
Refrigerator................................................................... 79
Leveling...................................................................... 79
Venting....................................................................... 79
Door Sealing.............................................................. 80
Refrigerator Storage .................................................. 81
Operating the Refrigerator Controls........................... 81
Outside Kitchen............................................................. 81
Monitor Panel................................................................ 82
Fireplace ....................................................................... 83

7
CHAPTER 1
INTRODUCTION TO RV OWNERSHIP
Welcome to the world of Recreational Vehicle travel. The purchase of
your KZRV product allows you to enter this type of camping and leisure
travel. Your coach has been designed and engineered to offer many of
the comforts of home. KZ Recreational Vehicles are designed and
constructed to be used as temporary living quarters for camping and
travel uses. The coaches are not intended for hauling cargo except Toy
Haulers and then only within weight limits.
This Owner’s Manual was prepared to assist you in understanding the
proper use and operation of various containment systems, servicing and
maintenance of component parts, as well as explanation of your warranty
protection. If this is your first RV travel coach, you will want to acquaint
yourself with all aspects and information found in this manual plus
manuals supplied by component manufacturers.
These materials will reflect the most current information available for the
user. Some components and items may not be in your coach as they
may be options on different models.
Keep this Owner’s Manual in your recreational vehicle for handy
reference. Get to know your new vehicle and howit operates. You should
carefully read and understand these instructions, as well as information
supplied by the manufacturers of separately warranted products, since
they contain important operating, safety, and maintenance instructions.
If you have questions that are not adequately answered by this manual
or other booklets, consult your dealer. If they cannot satisfactorily answer
your questions, they will call our staff for additional information.
Every effort has been made to provide you with a safe and dependable
product. Your vehicle complies with applicable requirements of Federal
Motor Vehicle Safety Standards, State Regulations, and Canadian
Standards Association (CSA), where applicable, and complies with
requirements of ANSI Standard 1192, the nationally recognized
“Standard for Recreational Vehicle – Installation of Plumbing, Heating
and Electrical System”. The Recreational Vehicle Industry Association
(RVIA) and Canadian Standards Association (CSA) periodically inspect
our production lines and assist us in maintaining strict compliance with
installation and safety standards for those systems. Your follow-up with
periodic safety inspections and a program of preventive
maintenance is important for the continuation of safe and trouble-
free operation.

8
Camping is a great way to relax and enjoy the outdoors with your friends
and family. Please remember to tread lightly on our beautiful land and
leave only your footprints so that others may enjoy nature as much as
you did.
Safety Considerations
The terms NOTE, CAUTION, WARNING, and DANGER have specific
meanings in this manual as well as component and vendor manuals.
A NOTE provides additional information to make a step or procedure
easier or clearer. Disregarding a NOTE could cause inconvenience, but
would not be likely to cause damage or personal injury.
A CAUTION emphasizes areas where equipment damage could result.
Disregarding a CAUTION could cause permanent mechanical damage.
However, personal injury is unlikely.
A WARNING is giving notice to user that potential injuries may occur to a
person from equipment and mechanical failure. Disregarding a
WARNING may result in serious physical injury to occupant.
A DANGER alerts the owner of areas where safety measures MUST be
strictly adhered to, as such failures can be dangerous. Disregarding a
DANGER could cause serious injury and possible loss of life.
Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or
could cause injury or death, you should immediately inform the National
Highway Traffic Safety Administration (NHTSA) in addition to notifying
KZRV.
If NHTSA, in addition, receives similar complaints, it may open an
investigation. If it finds that a safety defect exists in a group of vehicles,
it may order a recall and remedy campaign. However, NHTSA cannot
become involved in individual problems between you, your dealer, or
KZRV.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free
1-800-424-9393 or write to:
NHTSA
US Department of Transportation
Washington, DC 20590
You can also obtain other information about motor vehicle safety from the
Hotline.

9
Safety When Emergency Stopping
It is wise to carry road flags and/or triangular warning devices to be used
when necessary. When pulling off a highway, use your four-way hazard
lights as warning flashers, even if only to change drivers. Pull off the
roadway completely, if at all possible, to change flat tires or any other
emergency needs.
Additional Safety Considerations
1. Sanitize the fresh water supply system periodically (see
sanitizing instructions).
2. Keep water connection fittings from coming in contact with the
ground or drain hose to reduce chance of contamination.
3. Enlist services of a qualified technician to test, repair, or replace
any propane or electrical appliances.
4. Always have a serviceable fire extinguisher placed in an easily
accessible location.
5. Insure that tires are in good condition and properly inflated.
Watch tire inflation closely. Under-inflated tires will overheat.
Check the tire pressure before each trip while the tires are cold.
6. Check and tighten the wheel lugs regularly (every 50 miles when
new until 200 miles are reached, then check the lugs every 500
miles).
7. Check the brakes BEFORE entering a busy highway, not while
traveling.
8. Always block the trailer wheels solidly before unhitching.
9. Before leaving a camp area with a trailer in tow, insure:
a. The safety pin or locking lever is seated.
b. The breakaway wire is attached to the tow vehicle.
c. All jacks are raised so that they cannot touch the
ground.
d. The 110-volt electrical cord is properly stored.
e. The safety chains are connected.
f. All interior lights are off.
10. Observe and obey the warning labels attached to your vehicle
concerning propane, water, electricity, and loading.
11. Extinguish all campfires before leaving your campsite.
Extended Use or Cold Weather
Your KZ Recreational Vehicle has been built for enjoyment in a
recreational manner. This recreational vehicle is not intended to be used
as full time living quarters. Nor is this a four season unit. Using this unit
in freezing conditions is not recommended. However, if a unit is used in
freezing weather, following are guidelines to follow. Any problems
resulting from freezing are not covered under the warranty.

10
1. For winter use in freezing conditions, more protection may be
required. Use skirting and/or insulation below floor level to
provide additional protection.
2. Remember, water freezes at 32°F whether fresh or drainage.
Proper care must be used to protect any system at 32°F or
lower. Local recreational vehicle dealers and campground
personnel may be able to advise you on needed protection.
3. Energy requirements, such as propane and electrical supplies,
must be adequate. Protect your propane regulator from freeze
ups.
4. During cold weather, you will experience more condensation
than normal. Using ventilation or a dehumidifier may be needed.
Condensation
Causes:
A. Condensation occurs when warm moist air contacts a cold
surface, such as rain touching a tent. Awning fabric with people
breathing warm moist air against it inside, due to normal
breathing, is also a cause of condensation.
B. When cooking food or taking a shower, warm moist air circulates
throughout coach attaching itself to cooler surfaces. Forming
beads and running down walls or windows.
C. Normal breathing will emit approximately 1/2 pint of moisture
into the air per person, per day. The more occupants, the
greater quantity of condensation you may find.
Solutions:
1. When taking a shower, open bath roof vent approximately 1/2
inch allowing warm moist air to escape.
2. Use the power vent over range when cooking.
3. If condensation is found in cabinets or closets, open door slightly
to equalize temperature and provide ventilation.
4. Opening windows and roof vents, when possible, allowing warm
moist air to escape is the best way to reduce condensation.
5. Under extreme conditions, you may need to use a dehumidifier
to remove moist air conditions.
In camping, models which have tents or fabric bunk areas, it is even more
important to avoid condensation drops from roof areas. Opening the tent
window at the person’s head will allow air to flow across roof, reducing or
avoiding condensation.
Uncontrolled condensation can cause dampness, mildew, etc., inside
your recreational vehicle. Be sure to make strong efforts to control
condensation.

11
Interior Ventilation
A new coach always has a peculiar aroma in it due to all the components
used to build it, such as paneling, plywood, carpet, etc.
Allowing fresh air to move and circulate throughout a new recreational
vehicle for several minutes can remedy that smell.
Numerous ways are provided to circulate air:
1. Open windows.
2. Power hood vent above cooking stove.
3. Roof vents.
Different brands/models have different features, such as remote control,
rain sensor, variable speed control switch, etc.
Carefully read the operating instructions placed in your coach by the
manufacturer of the various components.
Continuous living in your recreational vehicle could cause
accelerated wear to components above recreational use.

12
CHAPTER 2
SERVICE PROCEDURES
Basic Service Procedures
Both KZRV and your KZRV Dealer has a strong and dedicated interest in
maintaining the highest quality customer relations with its owners. Your
satisfaction with your KZ recreational vehicle and your KZRV dealer is
our primary concern. By producing high quality products, we want to
assure our customers of our support with parts and service availability.
Our dealer network is the first choice to serve and supply your
needs for your recreational vehicle. Our authorized dealers will
pleasantly assist in providing service maintenance needs plus parts,
options, and information concerning your recreational vehicle.
Should you experience a problem with service availability, please follow
the steps in the order listed below:
1. Contact your selling dealer’s service department for an
appointment. Describe to the best of your knowledge the
nature of the problem. Please keep appointments to
establish a good, workable relationship.
2. Contact the owner or general manager of the dealership
should the initial attempt fail with the service department.
3. Contact: Customer Relations Department
KZRV
0985 N 900 W
Shipshewana, IN 46565
Phone: [phone]
Hours: 8am –5pm EST
Email: [email protected]
Website: http: //www.kz-rv.com
Give all the above information as requested along with the VIN
number of the coach in question. We will make every attempt
to resolve your problem.
Please bear in mind that most problems arise from misunderstandings
concerning warranty coverage and service. In most instances, you will
be referred to the dealer level and your concerns will be resolved with the
dealer’s facilities and personnel.
Dealer
Your authorized KZRV dealer has performed a PDI (pre-delivery
inspection) on your recreational vehicle. Since your dealer is authorized
to sell KZRV products, they are also there to supply parts, optional

13
equipment, and provide service repairs, warranty, etc. as needed. First
choice for warranty repairs is your selling dealer. Other dealers can be
used, however; prior approval is required.
Some recreational vehicle dealers may be authorized service centers for
certain manufacturers of products warranted separately. Check with your
dealer before contacting anyone else to reduce delays. If the dealer is
not an authorized service center for the product in question, they can
assist you in obtaining authorized service.
Factory
Service repairs can be performed at the manufacturing facility in
Shipshewana, Indiana. Should your KZRV product be in need of major
repairs and your dealer recommends factory repairs, please follow the
steps listed below for such work.
1. Your dealer must make an appointment with service personnel
at the factory PRIOR to your arrival.
2. Any freight costs are the responsibility of the owner as listed in
the warranty coverage schedule.
Parts
Stocking of parts varies from dealer to dealer. Any authorized dealer can
order any required part to be shipped to their dealership. All parts are
obtained through authorized KZRV dealers only.
Owner’s Responsibility
When owning and using a recreational vehicle, it is important to perform
regular and normal maintenance. This is recommended twice a year,
spring and fall, to prevent undesired deterioration of your coach. Weather
elements play an important function on sealants and other components
requiring normal maintenance.
As an owner and operator, it is your responsibility and obligation to
inspect and return your coach to an authorized dealer for repairs as
required. Your authorized selling dealer is always your first choice and
they certainly have continued interest in your satisfaction. As your
manufacturer, we recommend that inspection and service be performed
by your selling dealership.
If you are traveling and are unable to locate an authorized KZRV dealer,
or an authorized dealer for the component needing service, please call
our customer service office at [phone]. Service at a non-
authorized dealer MUST have prior authorization. You may be asked to
return any mechanical parts replaced before reimbursement

14
consideration is made. Unauthorized or improper repairs may void the
warranty of that component. Always keep your owner’s manual in your
coach along with a copy of your warranty registration with you when
traveling.
Seasonal Site
When placing your unit on a camp site in the spring and returning it in the
fall to your home, it’s classified as a “seasonal site”.
Performing repair work on such a site is not recommended for numerous
reasons: available parts, tools, space, weather conditions, etc.
Any service repairs which require a service technician also require the
unit to be taken to a service facility, preferably your selling dealer.
Warranty coverage does not include trip or service call costs for such a
trip. It is the owner’s responsibility to provide for such expenses.
TOWABLELIMITEDWARRANTY
OneYearLimitedWarranty
SUMMARY OF WARRANTY: KZRV warrants that every travel traier purchased from an authorized KZRV
dealertothefirstretailconsumertobefreefromsubstantialdefectsinmaterialsandworkmanshipwhenitarrived
on the dealer’s lot, except those exclusions set forth below. Nothing contained herein shall be interpreted as a
promise of future performance. This Towable Limited Warranty “TLW” is not transferableanddoesnotapplyto
towablerecreationslvehiclespurchasedfromandysourceotherthananauthorizedKZRVdealer. Thewarranty
period begins on the date f purchase or the sate the unit is first placed in service, whichever is earlier, and
terminatesone(1)yearthereafter.
EXCLUSIONSFROMWARRANTY: ExcludedfromcoverageundertheTLWare: (1)itemsadded,changed,
ormodifiedaftertheunitleftthepossessionofKZRV;(2)unitsusedforanycommercialpurpose;(3)unitsused
forfull-timeresidentaluseormorethanoccasionalrecreationaluse;(4)wearandtearcaused bynormalusage
bytheconsumer,includingbutnotlimitedto,fadingordiscolorationofsoftgoods[e.g.tents,upholstery,drapes,
carpet,vinyl,screens,cushions,andmattress],fadingordiscolorationofexteriororfiberglasscomponents,tears,
punctures, soiling, mildew, mold, and the effects of moisture condensation inside the unit; (5) the effects of
alteration, tampering, mishandling, neglect, abuse, misuse, weather, acts of nature, acts of God, or corrosive
atmospheresthatpromoterusting,oxidation,orpitting;(6)minorimperfectionsthatdonotinterfereoraffectthe
suitabilityoftheunit for its intended use; (7) the effects of consumer’s or transferee’s failure to perform normal
androutinemaintenance[e.ginspections,lubrication,adjustments,tighteningofscrewsand bolts,tigheningof
lugnutsandwheels,sealing,rotating,cleaning,orotherdamagesresultingfromfailingtofollowthemaintenance
schedule and procedures in the owners manual; (8) damages resulting from misalignment or alignments to
axles or spindles caused by improper maintenance, modification, loading, unloading, road hazards, road
defects,offroadtravel,ortirefailures;(9)damagescausedbythenegligentor intentional use ormisuse ofthe
unit bythe consumer or transferee, including but not limited to, occurences whiletowing the unit; (10) claims
madeforalignmentoradjustmentofpatiodoors[Note:anyunitwithapatiodoorisnotintendedtobetowedlike
atraveltrailer,andmustbepermanentlyparkedonalot. Ifsuchaunitistowedforrecreationaluse, thisTLWis
voided inregard to the patio door and thesurrounding structues]; (11)loss or damage causedbya personor
businessasaresultoftransportingtheunitaftersaletotheconsumer,deliveringtheunit,orparkingtheunit;(12)
loss ordamagetothe plumbingsystem causebyfreezeing; (13)claimsforpersonalinjuriesofanytype; (14)
costs of transportation of the unit for repairs; and (15) componets that are warranted separately by another
manufacturer [the warranty provided by a component manufacturer is the sole responsilbility of that

15
manufacturer, and KZRV does not warrant those components. Please refer to the warranties issued by the
componentmanufacturerforthetermsandconditionsofsuchwarranties.]
TO OBTAIN WARRANTY SERVICE: Warranty service may be performed only at KZRV or at KZRV
authorized dealers and service centers. Contact KZRV for a list of authorized dealers and service centers.
REPAIRSOR REPLACEMENTS BYUNAUTHORIZEDDEALERSOR SERVICE CENTERSWILLVOID
THISTLW. IftheconsumerbelievesthataclaimeddefectiscoveredbytheTLW,contactmustbemadewith
an authorized dealer or service center WITHIN THE WARRANTYPERIOD. Sufficient information must be
given to attempt to resolve the claimed problem. Should KZRV determine that repair or replacment is
appropriate,theconsumermustdelivertheunittothedealerorservicecenterasdirected. Deliveryshalloccur
nolaterthanthirty(30)daysaftertheauthorizationforrepairorreplacement. DonotdeliveryourunittoKZRV,
an authorized dealer or service center without prior authorization. All costs incurred by the consumer for
transportationforwarrantyserviceshallbethesoleresponsilbilityoftheconsumer. Thedealerorservicecenter
shall repair or replace any warranted defect withina reasonable time, but no later than ninety (90) days after
delivery by the consumer. Should the unit not be repaired or replaced within said period of time, then the
consumermustcontactKZRVbyCERTIFIEDMAILwithawrittendescriptionoftheclaimed warranteddefect
and the efforts to remedyit. FAILURE TO SO NOTIFY KZRV IN THIS REGARD SHALL RENDER THIS
TLW VOIDASTOTHE CLAIMEDDEFECT. Afterreceiptofsuchnotice,KZRV shall repairor replacesuch
warranted defect withina reasonable time, but not later than ninety(90) days afterdeliverybythe consumer.
TheschedulingofwarrantyworkatanauthorizeddealerorservicecenterisnotcontrolledbyKZRVanddelays
may be experienced. KZRV is not responsible for loss of use of theunit, expenses for fuel, telephone, food,
lodging,travel,lossofincomeorrevenue,orlossofordamagetopersonalproperty.
DISCLAIMERANDLIMITATIONS OFWARRANTIES: NEITHER KZRVNOR ITS DEALERSSHALLBE
LIABLEFORINCIDENTAL,CONSEQUENTIAL,INDIRECT,SPECIAL,ORPUNITIVEDAMAGESOFANY
KINDORANYOTHERFINANCIALLOSSARISINGOUTOFORINCONNECTIONWITHTHESALEOR
USEOFTHISPRODUCT,WHETHERBASED IN CONTRACT,TORT,STRICT LIABILTY, EQUITY, OR
ANY OHER THEORY, EVEN IF KZRV HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. KZRV’S ENTIRE LIABILITY SHALL BE LIMITED TO REPAIR OR REPLACEMENT, AT
KZRV’S SOLE OPTION.
THE UNITED NATIONS CONVENTION ON CONTRACTS FOR THE INTERNATIONAL SALE OF
GOODSISHEREBYEXCLUDEDINITSENTIRETYFROMAPPLICATIONTOTHETLW.
THIS TLW, AND THE REMEDIES HEREUNDER, ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES,EXPRESSORIMPLIED,INCLUDINGWARRANTIESOFMERCHANTABILITY,FITNESS
FOR A PARTICULAR PURPOSE, CORRESPONDENCE WITH DESCRIPTION, AND NON-
INFRINGEMENT, ALL OF WHICH ARE EXPRESSLY DISCLAIMED BY KZRV. THIS TLW GIVES YOU
SPECIFICLEGALRIGHTSANDYOUMAYALSOHAVEOTHERRIGHTSTHATVARYDEPENDINGON
LOCALLAW. SOMESTATESLIMITORPROHIBITLIMITATIONSOFWARRANTIES,SOTHEABOVE
MAY NOT APPLY TO YOU. YOU SHOULD CONSULT A COMPETENT ATTORNEY FOR LEGAL
ADVICE.
MISCELLANEOUS: Norepairor replacementeffectedshallcauseanyextensionorrenewalofthewarranty
period. KZRV may make parts and/or design changes from time to time without notice and repairs or
replacementsmaybemadewithnewordifferentparts. KZRVreservestherighttomakechangesinthedesign
ormaterialofitsproductswithoutincurringanyobligationtoincorporatesuchchangesinanyproductpreviously
manufactured. At KZRV’s sole option, any dispute concerning any warranted defect may be resolved through
mediationor arbitration. ThisTLW shall begovernedbythe laws oftheState ofIndiana, andanylegalaction
shallbebroughtonlyintheCircuitorSuperiorCourtofLaGrangeCounty,Indiana.
ALTERNATIVEDISPUTERESOLUTION: Thepartiesshallattempt,ingoodfaith,toresolveanydisputesby
negotiations. If unsuccessful,KZRV may, at its solediscretion, electtosubmitthematter to binding arbitration
andifsuchelectionisexcersized,theconsumercovenantsandagreesthathe,she,they,oritshallsubmitany
suchdisputestosuchbindingarbitration. ThearbitralbodyshallbeeithertheAmericanArbitrationAssociation
or the National Arbitration Foundation, and the rules of the bodychosen by KZRV shall govern except to the
extent same are in conflict with the Indiana Uniform Arbitration Act, which shall govern. The arbitrators is
expresslyempowered toenter an award of defaultagainst anypartinthe event of(a) the failureorrefusalof

16
suchpartytocomplywithadeadlinefixedbythearbitrator,(b)thefailureorrefusalofsuchpartytomaketimely
paymentofanyfees,expenses,orotherchargesbilledbythearbitrator,or(c)anyotherfailureorrefusalbysuch
party to cooperate and participate in and aspect of the arbitration proceedings. The arbitrator will admit only
relevantandreliableevidenceatthehearingbutnoparticularrulesofevidencearespecifiedforuse. Thehearing
shall be electronically recorded by an Indiana Notary Public or other officer authorized by Indiana law to
administeroaths,andallwitnesseswhoshalltestifyshallbeswornanoathtotellthetruth. Thearbitratormay
awardinjunctiverelief, interest, andattorney feesinan equitable amount based upon the degree to whichthe
prevailing party on the meritrs; however, the arbitrator is not empowered to award punitive or exemplary
damages. Allcostsofthearbitration,includingtherecordingthereof,shallbesharedequallybytheparties. The
arbitration proceedings and award shall remain confidential, and no partymay disclose any person, except
attorneysfortheparties,anyaspect oftheproceddings.
WARRANTYREGISTRATIONANDCONTACTINFORMATION: Thewarrantyregistrationforcomponent
parts should be completed and delivered in accordance with the instructions contained therein. The TLW
registatrtion must be completed and returned to KZRV within fifteen (15) days of delivery of the unit to the
consumer. FailuretodosocanvoidthisTLWorcausedelaysinobtainingbenefits. TheTLWregistration,and
all inquiries, must be directed to: KZRV, LP, Warranty Department, 0985 N 900W, Shipshewana, Indiana,
46565,Telephone: [phone].
Model#:___________________________ VIN#: __________________________________________
DealerInfo: ________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
________________________________________________________
CustomerInfo
Name: ________________________________________________________
Address: ________________________________________________________
________________________________________________________
Phone: ________________________________________________________
I HEREBY ACKNOWLEDGE THATI HAVE RECEIVED, READ, AND UNDERSTAND THIS TOWABLE
LIMITED WARRANTY, AND THAT I HAVE INSPECTED THE UNIT AND FIND IT IN THE CONDITION
REPRESENTED.
Date: ____________________ Purchaser: ____________________________________

17
CHAPTER 3
USING YOUR RV
In this chapter, you will find three areas of useful information to assist you
with equipment, traveling, and finally, actually using your recreational
vehicle.
Equipment
Tow Vehicle
Begin your camping experiences by obtaining a tow vehicle which will
adequately transport your recreational vehicle to and from your chosen
destinations. Your most important measuring tool is the GVWR, Gross
Vehicle Weight Rating, to cross match the capability of your selected tow
vehicle.
Most auto and truck manufacturers provide trailer towing guides for their
products. Ask your local automotive dealer for a copy or call the factory’s
direct lines for information. Many tow vehicles, including mini-vans, have
special towing package options available for small travel trailers. Tow
vehicles with long wheel bases perform better than those with short wheel
bases.
A second factor is GCWR, Gross Combined Weight Rating, which refers
to the total weight of the tow vehicle and any vehicle in tow as a
“combined” weight. This information, supplied by the tow vehicle
manufacturer, is related to the capability of the tow vehicle.
The condition of the suspension in your tow vehicle is also an important
factor. Make sure your tow vehicle is in good operating condition and
follow the factory recommended maintenance guidelines.
Hitches - Travel Trailer
After obtaining your tow vehicle, it is very important to choose, and have
installed, a correct hitch system with weight distributing bars to
accommodate your coach, if so required. This selection and installation
should be done by a professional hitch service center, which may or may
not be your selling dealer.
Weight distributing hitches apply leverage between the tow vehicle and
trailer. This assists in equalizing the weight distribution between vehicles,
resulting in both vehicles traveling level. The condition of the tow
vehicle’s suspension system will affect the towing performance capability
of your equipment.

18
Hitch Height Specifications - Travel Trailer
Due to axles being either straight or drop bars, the ball
height will vary. To find the correct height for the ball
hitch, set your trailer on a flat surface in level position.
Measure from the inside of the ball socket to the
ground, approximately 18 to 22 inches as shown, for
correct spacing. You may wish to add 1 to 2 inches
to this amount to compensate for sag of suspension
of the tow vehicles when hooked to the trailer.
Hook-Up - Travel Trailer
Hooking up your travel trailer is not difficult and gets easier with practice.
The following procedure will help you until you become more
experienced.
1. To raise the tongue of the trailer above the hitch ball on hitch,
turn the crank on the jack or use optional power jack.
2. Open the coupler latch.
3. Back the tow vehicle into proper position.
4. Turn the crank on the jack to lower the coupler onto the ball
hitch.
5. Close the coupler latch after completely seated. To secure
coupler latch, it is recommended that you install a latch pin or a
lock.
6. Install weight distributing bars (equalizer), when required, as
recommended by hitch supplier.
7. Retract the tongue jack completely.
8. Attach the cable for the breakaway switch to the tow vehicle.
9. Attach safety chains as per your state laws.
10. Plug in your 12-volt, 7-way electrical cord and connector from
the trailer to the tow vehicle connector.
Below are listed numerous items that should be inspected and tested
before traveling:
- All lights working on outside of coach.
- Stabilizer jacks in retracted position.
- Steps in retracted position.
18-22” off ground
FRAME &
COUPLER
GROUND
Trailers with tandem axles need to travel as level as possible,
avoiding different weights on each axle plus handling
conditions.
Using an oversized or undersized hitch can cause damage to
the frame of your travel trailer and/or tow vehicle.

19
- Refrigerator door latched completely.
- Loose items in secure position.
- Test brakes for operation before entering roadway.
The Safety Chain - Travel Trailer
Safety chain requirements will vary from state to state. The chain
supplied with your coach meets SAE requirements for maximum gross
trailer weight.
1. Cross the left chains under the coupler and attach to the right
mounting ring on the receiver hitch.
2. Take right chain under the coupler and attach it to the ring on
the left on the receiver hitch.
Traveling
Weights
For safety reasons and federal regulations, KZRV provides accurate
weight specifications to owners. On the exterior left front corner of the
coach you will find the Federal “Vehicle Identification Number” sticker, as
required by the federal government. This tag supplies information
concerning your coach, such as: VIN number, date/month of
manufacture, tire size rating, plus information about weights as described
in this manual.
Gross Axle Weight Rating (GAWR) is the value specified as the load
carrying capacity of a single axle system, as measured at the tire-ground
interfaces. Tires will be rated 10% higher or more than the axle,
becoming the GAWR rating.
Gross VehicleWeight Rating (GVWR) is the maximum permissible weight
of this trailer when fully loaded. It includes all weight at the trailer axle(s)
MANUFACTIRED BY/FABRIQUE KZRV DATE: 03/2012
GVWR/PNBV: 2727 KG (6000 SHIPSHEWANA, IN ST205/75R14 C
GAWR (EACH AXLE)/PNBE (CHAQUE ESSIEU) 1591 KG (3500 LB) TIRE/PNEU
RIM/JANTE 14X5.5JJ
COLD INFL. PRESS./PRESS. DE GONFL. A FROID 345KPA (50PSI/LPC)
THIS VEHICLE CONFORMS TO ALL APPLICABLE U.S. FEDERAL MOTOR VEHICLE SAFETY
STANDARDS IN EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE. THIS VEHICLE
CONFORMS TO ALL APPLICABLE STANDARDS PRESCRIBED UNDER THE CANADIAN MOTOR
VEHICLE SAFETY REGULATORS IN EFFECT ON THE DATE OF MANUFACTURE –CE VEHICULE
EST CONFORMS A TOUTES LES NORMES QUI LUI SONT APPLICABLES EN VERTU DU
REGLEMENT SUR LA SECURITE DES
VEHICULES AUTOMOBILES DU CANADA EN VIGUER A LA DATE DE SA FABRICATION.
V.I.N./N.I.V. 4EZTS2420C5036114 TYPE/TYPE DE VEICULE: TRAILER TRA/REM TRA
Remember –Always have the safety chains attached to the
tow vehicle, as required in your state.

20
and tongue. This includes ALL cargo, options and liquids.
Unloaded Vehicle Weight (UVW) is the weight of this trailer as
manufactured at the factory. It includes all weight at the trailer axle(s)
and tongue. If applicable, it also includes full generator fluids, including
fuel, engine oil and coolants.
Cargo Carrying Capacity (CCC) is equal to the GVWR minus each of the
following: UVW, full fresh (potable) water weight (including water heater),
and full propane weight.
Weighing Vehicle (Loaded or unloaded)
The proper method to weigh the coach is to use a truck scale. Place
coach axles (tires) and tongue jack 12” to 24” from the edge. Unhook the
tow vehicle and move forward 6” to 8”. Now record total weight. Re-hook
the tow vehicle and remove the weight from the front support. Be sure
no part of tow vehicle is on the scale. Now record the axle weight only.
The difference between the two weights is the hitch weight.
KZRV suggests you also weigh each side (2 tires) separate to find
balance of pounds per side. It is possible to have 1 side correct and the
other side overloaded. Often, the slide side or refrigerator side will be
slightly heavier than the other side.
The second sticker is about the allowed weight of cargo to be placed in
your coach. Location of the sticker is on the inside of your coach, on the
screen door, or inside of a cabinet door. It provides listed total allowable
weight of cargo minus liquids allowed, water and propane.
RECREATIONAL VEHICLE TRAILER CARRYING CARGO CAPACITY
VIN #: ____________________________________
The weight of cargo should neverexceedkg _______ lbs. ________
CAUTION
A load of water equals _____ kg / ____ lbs. of cargo
@ 3.78 kg / 8.34 lbs. per gallon.
Loading the Trailer - Distribution
Your recreational vehicle has been engineered to make maximum use of
the available space for living and storage areas. The equipment and
supplies you take along while traveling can be carried safely, provided
the additional weight is distributed properly. Proper weight distribution
within your trailer is an important factor in safety and efficiency of your
trailer brakes, hitching, and how your tow vehicle will pull the trailer. DO
NOT put excess weight in the rear only. Excessive weight in the rear area
tends to develop sway and “fishtailing” of the trailer.
