L-1 3100-1L User manual

L-1 Standards and Technology, Inc.
www.L-1.biz
Model 3100-1L
One Channel
Temperature Controller
User Manual

©Copyright L-1 Standards and Technol-
ogy, Inc. 2013
No part of this manual may be repro-
duced in any form or by any means
(including electronic storage and retrieval
or translation into a foreign language)
without prior agreement and written con-
sent from L-1 Standards and Technology,
Inc. as governed by United States and
international copyright laws.
Warranty
The material contained in this document
is provided “as is,” and is subject to being
changed without notice. Further, to the
maximum extent permitted by applicable
law, L-1 Standards and Technology, Inc.
disclaims all warranties, either express
or implied, with regard to this manual
and any information contained herein,
including but not limited to the implied
warranties of merchantability and tness
for a particular purpose. L-1 shall not be
liable for errors or for any direct, indirect,
incidental, consequential, or other dam-
ages in connection with the furnishings,
use, or performance of this document or
of any information contained herein.
Manual Part Number
3100-1L-MANUAL
Edition
First Edition, November 2013
L-1 Standards and Technology, Inc.
209 High Street
New Windsor, MD 21776-0729
USA
[phone] Phone
[phone] FAX
[email protected]
www.L-1.biz

Table of Contents
1 Overview 1
2 Parts List 2
3 Identication    3
4 Setup 5
5 Software 6
6 GeneralSpecications   18

Model 3100-1L Temperature Controller User Manual 1
1 Overview
The Model 3100-1L Temperature Controller is a precision control unit which provides
closed loop temperature control of Peltier thermo-electric coolers/heaters at the <+/-
0.001 °C level. The controller is a microprocessor based unit with an Ethernet inter-
face which communicates through TCP/IP. The controller is optimized for use with L-1
Standards and Technology Inc.’s line of temperature controlled detectors which include
silicon photodiode trap detectors, single element silicon photodiodes, InGaAs pho-
todiodes, extended-IGA photodiodes and a 3-detector Windowed Integrating Sphere
Assembly that covers from 350 nm to 2400 nm in a single device. The Model 3100
comes in 3 versions: 1L – a low power model for single detectors; 3L – three channel
model to operate the detectors in the Integrating Sphere Detector, and 1H – which is a
higher power single channel model used for custom temperature control applications.
The temperature controller, when sold as part of a detector package, is precongured
to operate the detector automatically. All that is required is to connect the cabling and
power the unit on. The controller will then maintain the preset temperature on the
detector. If you wish to log data to a computer or change settings then an Ethernet
connection is required. The temperature controller is delivered with a LabVIEW virtual
instrument driver that will allow control and data logging from the controller using the
customer supplied LabVIEW program.

Model 3100-1L Temperature Controller User Manual
2
2 Parts List
•Model 3100-1L Temperature Controller 1 ea
•Model 3100 Temperature Controller One Channel Cable 1 ea
•Model 3100 Temperature Controller Power Suppy 1 ea
•Manual & Software CD 1 ea

Model 3100-1L Temperature Controller User Manual 3
3 Identication
Model 3100-1L Front
LCDScreen
Displays the temperature set point (SetPt) and current temperature of the
connected detector in degrees Celsius.

Model 3100-1L Temperature Controller User Manual
4
USB
Not currently active. Do not use.
Ethernet
Provides connection to a computer through an Ethernet cable (not provided).
Output
Provides connection to a L-1 temperature controllable detector using the
Model 3100 Temperature Controller One Channel Cable.
DC Power
Provides power using the Model 3100 Temperature Controller Power Supply.
Model3100-1LBack

Model 3100-1L Temperature Controller User Manual 5
4 Setup
1 Make sure the Model 3100 Temperature Controller is turned off by unplugging its
power supply.
2 Connect the Model 3100 Temperature Controller to a L-1 temperature controlla-
ble detector using the supplied One Channel Cable. The four pin LEMO connec-
tor of the One Channel Cable connects to the back of the detector and the DB-15
connector to the back of the temperature controller.
3 Power on the temperature controller by connecting the DB-9 “DC Power” connec-
tor of the power supply to the “DC Power” connector on the back of the tempera-
ture controller and then plugging the power supply into a wall outlet that provides
100-240 VAC, 50/60 Hz power. L-1 recommends using a surge protector
between the equipment and the wall outlet.
4 The temperature controller will immediately boot up and several screens of infor-
mation will appear on the LCD screen before the temperature set point and cur
rent temperature reading appears.
First Screen:
Det Temp Control
Model 3100-1L
Second Screen:
SWver1.1.1c.1t (code version; actual code version may vary)
User Name (actual user name may vary)
Third Screen:
IP Address:
10.0.1.10 (example IP address is used here; actual IP address may vary)
5 The nal screen will provide information on the set point (temperature setting)
and current temperature. The temperature controller is preprogrammed to auto-
matically control detector temperatures at a specic set point depending on the
detector type.
6 If a change in set point is needed or if automated recording of the temperatures
is desired, connect the temperature controller to a computer using an Ethernet
cable (not supplied) and use the Model 3100-1L Temperature Controller Soft-
ware. Please refer to the software section of this manual for further details.
NOTE Turn off power to the temperature controller before starting the below steps.

Model 3100-1L Temperature Controller User Manual
6
5 Software
The Model 3100-1L Temperature Controller can be controlled with computer software
written in LabVIEW. Using the provided software with LabVIEW 2012 or higher, a
user can modify the temperature set point, change the IP address and user name
of the temperature controller, modify various parameters and record data (including
temperatures) to le.
Starting the Model 3100-1L Temperature Controller Software
You must have LabVIEW 2012 or higher installed to run the provided software.
Copy the Model 3100-1L Temperature Controller v1.llb from the provided CD
toyourcomputerortoalocationonanaccessiblenetwork.ThisisaLabVIEW
librarylethatcontainsallthevirtualinstruments(vi’s)neededtorunthesoft-
ware.Doubleclickonthis.llbleandintheLLBManagerwindowthatopens,
doubleclickthetoplevel“Model3100-1LTemperatureControllerv1.vi”(rst.vi
inthelist).

Model 3100-1L Temperature Controller User Manual 7
Running the Model 3100-1L Temperature Controller Software
1 Click the Run button (button with the white arrow in the upper left of the screen
underneath the edit menu of the software) of the Model 3100-1L Temperature
Controller v1.vi. The Run button starts LabVIEW running.
LabVIEW “Run” button

Model 3100-1L Temperature Controller User Manual
8
2 Verify the IP address on the screen and if needed, change it to match the tem-
perature controller’s IP address shown on the LCD screen during system boot up.
The preset IP address of the unit is also labeled on the top of the Model 3100-1L
Temperature Controller unit upon shipment.
3 The default folder path shown can be changed if desired. If it does not already
exist, the folder will be created when the program runs.
4 If the Model 3100-1L Temperature Controller has just been powered on, please
wait one minute after the temperature reading appears on the LCD screen before
continuing to the next step to allow the unit to fully power on.
5 Click the green Start Communication button to initialize communication with the
temperature controller. It may take up to 5 seconds for communication to be
established.

Model 3100-1L Temperature Controller User Manual 9
7 When communication is established, the Detector Temperature Control and
Manual Commands buttons, which were unavailable during connection estab-
lishment, become available. The IP Address and Folder Path controls become
unavailable as they cannot be changed after communication is established.
6 If communication fails, a pop-up window will appear stating that the connection
failed and giving instructions to restart the program after checking power, Eth-
ernet connection, and IP address. Pressing the OK button will close the pop-up
window and stop the Model 3100-1L Temperature Controller v1.vi.

Model 3100-1L Temperature Controller User Manual
10
8 Clicking either the Detector Temperature Control or Manual Commands button
opens the corresponding program’s front panel and starts the vi and program
running (Detector Temperature Control v1.vi and Manual Commands v1.vi
respectively). When either of these two programs is running, the Stop Communi-
cation button and the program buttons are unavailable within the Model 3100-1L
Temperature Controller v1.vi. To switch between these two programs, close the
current program using the Stop Program button and then click the other program
button in the Model 3100-1L Temperature Controller v1.vi.
9 Use the Detector Temperature Control v1.vi to monitor data and control the user
adjustable parameters.

Model 3100-1L Temperature Controller User Manual 11
DetectorTemperatureControlv1.vicomponents:
Stop Program Button
Stops the program and closes the program window.
Pause Button
Pauses the program.
Target Temp (ºC)
Sets the set point (target temperature) in degrees Celsius.
Minimum: -28.000; Maximum: 35.000.
Control Mode
If set to 0, the DAC value is set to the Open Loop Setting value.
If set to 1, the DAC value is controlled by the PID Settings.
Open Loop Setting
Sets the digital DAC value using a 16-bit digital number between 0 and
65535 which corresponds to a voltage from 0 to 5 volts. The Control Mode
must be set to 0 for the DAC value to be set to the Open Loop Setting
value.
PID Settings
The temperature controller DAC value can be controlled using a PID
control algorithm in which the DAC setting is automatically varied based
on the PID settings and the temperature error. The temperature error is
the difference between the set point (target temperature) and the current
detector temperature.
.p: Proportional Term
.i: Integral Term
.d: Derivative Term
.kloop: Multiplier of all Terms
Sample Period
The sample time in seconds for acquiring and graphing the data.
Default is 1 second.
Storage Period
The time in seconds for writing data to le. Default is 3 seconds.
Store Temps Only Button
Toggle this button to store all data or store temperatures only.
Default is to store temperatures only.

Model 3100-1L Temperature Controller User Manual
12
File Name
Name of the data le (data le is in text format; le extension .txt). An
example le name is 3100TC_MC_1311011459.txt where MC stands for
manual commands and the numeric code after the underscore character
indicates that the year was 2013, the month was November, the day was
01, and the time in 24 hour format was 14:59 when the le was created.
The le name is not displayed until it is created after the Send button is
pressed for the rst time. The le name cannot be changed.
New File Button
Starts a new data le and starts writing data to this new le at the next
storage time. A new data le will not be created within a minute of the
last le created.
File Path
The full path to the data le recorded (includes the le name). For
informational purposes only. The le path cannot be changed on this
screen. If you need to change what folder the data le is saved to, see
step 3 in the software section of this manual.
DAC Value Graph & Digital Display
The voltage applied to the Peltier cooler in a digital number (16-bit
number which corresponds to a voltage from 0 to 5 volts) is graphed and
numerically displayed.
Detector Temperature Graph & Digital Display
The current detector temperature in degrees Celsius is graphed and
numerically displayed.
X Scale Maximum
The maximum number of data points to be graphed at any one time.
Default is 100. Click the Set button to activate.
Clear Graphs Button
Click this button to clear the DAC Value and Detector Temperature graphs.

Model 3100-1L Temperature Controller User Manual 13
10 Use the Manual Commands v1.vi to send get and set commands directly to the
temperature controller.
Manual Commands v1.vi showing the
Get/Set toggle in the Get position.
Manual Commands v1.vi showing the
Get/Set toggle in the Set position.

Model 3100-1L Temperature Controller User Manual
14
ManualCommandsv1.vicomponents:
Stop Program Button
Stops the program and closes the program window.
Get/Set Toggle button
Toggle to Get to access the get commands and toggle to Set to access
the set commands, parameters and set accepted light. The get and set
commands are not simultaneously accessible.
Get Command
Allows selection of get commands from a drop down list. The Get/Set
toggle button must be toggled to Get for this drop down list to be
available. The get command is not sent to the temperature controller
until the Send button is pressed.
Get Commands are:
get_code_version
Code version (example: Temp Controller
PCB2024v1 Code1.1 April 2012; 117010254)
get_hsk_data
frame counter, 4 target temperatures in digital
numbers, 4 detector temperatures in degrees
Celsius, 4 Open Loop DAC setting values, 4 DAC
voltage values
get_control_status
frame counter, 4 enable values, 4 mode type
values, 4 Open Loop DAC setting values, 4 target
temperatures in degrees Celsius, 4 error codes,
4 p terms of PID control, 4 i terms of PID control,
4 d terms of PID control, 4 kloop terms of PID
control
get_user_data
IP address, user net mask, user name, detector
type, 4 target temperatures in degrees Celsius,
4 p terms of PID control, 4 i terms of PID control,
4 d terms of PID control, 4 kloop terms of PID
control
Set Command
Allows selection of set commands from a drop down list. The Get/Set
toggle button must be toggled to Set for this drop down list to be
available. The set command is not sent to the temperature controller
until the Send button is pressed.

Model 3100-1L Temperature Controller User Manual 15
Set Commands are:
set_user_IP_address
format = n.n.n.n (up to 3 numbers per n; example
= 10.0.1.13)
set_user_net_mask
format = n.n.n.n (up to 3 numbers per n; example
= 255.255.255.0)
set_user_name
up to 16 characters
set_save_user_data
1 = save
Set Accepted? Light
Displays green if set command is accepted and red if set command is
rejected. The Get/Set toggle button must be toggled to Set for this
function to be available.
Parameters
Input parameters to be used with the set command that was chosen. The
Get/Set toggle must be toggled to Set for this function to be available.
Send Button
Sends the command (and any parameters if applicable) to the
temperature controller in the correct format.
Sent String
Displays the string that was sent to the temperature controller after the
send button was pressed.
Reply String
Displays the string the temperature controller sends back after receiving
a command.
File Name
Name of the data le (data le is in text format; le extension .txt). An
example le name is 3100TC_MC_1311011459.txt where MC stands for
manual commands and the numeric code after the underscore character
indicates that the year was 2013, the month was November, the day was
01, and the time in 24 hour format was 14:59 when the le was created.
The le name is not displayed until it is created after the Send button is
pressed for the rst time. The le name cannot be changed.

Model 3100-1L Temperature Controller User Manual
16
New File Button
Starts a new data le and starts writing data to this new le at the next
storage time. A new data le will not be created within a minute of the
last le created.
File Path
The full path to the data le recorded (includes the le name). For
informational purposes only. The le path cannot be changed on this
screen. If you need to change what folder the data le is saved to, see
step 3 in the software section of this manual.

Model 3100-1L Temperature Controller User Manual 17
Stopping Model 3100-1L Temperature Controller Software
To stop the Model 3100-1L Temperature Controller Software, rst, if open, stop the
Detector Temperature Control v1.vi or the Manual Commands v1.vi program by
pressing the Stop Program button and wait until the program window closes.
Within the Model 3100-1L Temperature Controller v1.vi, press the Stop Communica-
tion button. Allow the program several seconds to disconnect with the temperature
controller and stop running. Never stop any of the programs by pressing the Lab-
VIEW Abort button.
LabVIEW “Run” button,
shown here running. LabVIEW “Abort” button.
NEVER use this button to
stop the program.
