l-com HG8909P User manual

www.L-com.com
OUTDOOR INSTALLATION WARNING
IMPORTANT SAFETY PRECAUTIONS:
LIVES MAY BE AT RISK!Carefully observe these instructions and any special instructions that are included with the equipment you are installing.
IMPORTANT:Look over the site before beginning any installation, and anticipate possible hazards, especially these:
CONTACTING POWER LINES CAN BE LETHAL.Make sure no power lines are anywhere where possible contact
can be made. Antennas, masts, towers, guy wires or cables may lean or fall and contact these lines. People may be injured or
killed if they are touching or holding any part of equipment when it contacts electric lines. Make sure there is NO possibility
that equipment or personnel can come in contact directly or indirectly with power lines.
Assume all overhead lines are power lines.
The horizontal distance from a tower, mast or antenna to the nearest power line should be at least twice the total length of the
mast/antenna combination. This will ensure that the mast will not contact power if it falls either during installation or later.
TO AVOID FALLING, USE SAFE PROCEDURES WHEN WORKING AT HEIGHTS ABOVE GROUND.
• Select equipment locations that will allow safe, simple equipment installation.
• Don’t work alone. A friend or co-worker can save your life if an accident happens.
• Use approved non-conducting ladders and other safety equipment. Make sure all equipment is in good repair.
• If a tower or mast begins falling, don’t attempt to catch it. Stand back and let it fall.
• If anything such as a wire or mast does come in contact with a power line, DON’T TOUCH IT OR ATTEMPT TO MOVE IT. Instead, save your life by
calling the power company.
• Don’t attempt to erect antennas or towers on windy days.
MAKE SURE ALL TOWERS AND MASTS ARE SECURELY GROUNDED, AND ELECTRICAL CABLES CONNECTED TO ANTENNAS
HAVE LIGHTNING ARRESTORS. This will help prevent fire damage or human injury in case of lightning, static build-up, or short circuit within equipment
connected to the antenna.
IF A PERSON COMES IN CONTACT WITH ELECTRICAL POWER, AND CANNOT MOVE:
Copyright © This drawing is property of L-com Global Connectivity. All rights reserved.
• The base of the antenna mast or tower must be connected directly to the building protective ground or to one or more approved grounding rods, using 1 O AWG
ground wire and corrosion-resistant connectors.
• Refer to the National Electrical Code for grounding details.
• Lightning arrestors for antenna feed coaxial cables are available from HyperLink Technologies, Inc.
• DON’T TOUCH THAT PERSON, OR YOU MAY BE ELECTROCUTED.
• Use a non-conductive dry board, stick or rope to push or drag them so they no longer are in contact with electrical power.
• Once they are no longer contacting electrical power, administer CPR if you are certified, and make sure that emergency medical aid has been requested.
L-com Global Connectivity | 50 High St., West Mill, 3rd floor, Suite #30 | North Andover, MA 01845 | USA
© L-com, Inc. All Rights Reserved. L-com Global Connectivity and the L-com Logo are registered marks.
Toll Free Ordering and Technical Support: 1-800-343-1455

www.L-com.com
L-com Global Connectivity | 50 High St., West Mill, 3rd floor, Suite #30 | North Andover, MA 01845 | USA
© L-com, Inc. All Rights Reserved. L-com Global Connectivity and the L-com Logo are registered marks.
Toll Free Ordering and Technical Support: 1-800-343-1455
IP-00125 Rev. A – 07/12 Page 2/2
INSTALLATION INSTRUCTIONS: HG8909P
(Shown for Down-Tilt Mounting)
Mounting
This antenna can be mounted in an up or down tilt
position based on how the L-Bracket is attached
to the mast. The above photo shows the correct
orientation for down-tilt mounting (for up-tilt, rotate
L-Bracket 180 degrees).
Attach the L-Bracket to mast using supplied U-Bolt
and hardware. This mounting kit can be used with
masts 1.25" (32mm) to 2.12" (54mm) O.D.
Vertical or Horizontal Polarized Mounting
This antenna can be vertical polarized or horizontal polarized
mounted. To mount antenna, attach to L-Bracket as shown
using supplied hardware. Note orientation label on rear of antenna
for proper mounting.
To help prevent moisture build-up inside the antenna, drain holes
are provided. To ensure proper draining, these holes must be
orientated on the bottom of the antenna as shown.
L-Bracket U-Bolt
Mast Clamp Orientation Label
Drain Hole
Locations
Copyright © This drawing is property of L-com Global Connectivity. All rights reserved.
