La Crosse S89102 User manual

Model: S89102
Instruction Manual
DC: 032614
NOAA WEATHER RADIO:
Reliable Emergency Information
Weather | Alerts | AM/FM
!
!
!
!
!
!
!
GET STARTED
!
Use battery power and/or A/C power for continuous operation.
!
Step 1: Insert the included 6 volt AC cord into the wall outlet then into the weather
radio.
Step 2: Insert 3 new “AAA” batteries (not included) into the radio. Observe the
correct polarity.
Step 3: Press the POWER button once to turn on the radio. The radio will default to
weather band and volume level 10.
Step 4: Press the TUNE button to select a weather band channel.
Model: S89102 www.lacrosseclock.com/support Page | !1
Blue Armed
Protected
Telescoping
Antenna
LED
Flashlight
Earphone
Jack
!
6 volt
AC Cord
Battery
compartment
3 “AAA”
Flashlight
ON/OFF
Button
LCD
Buttons

Note: When the radio is off, the time will be displayed.
RADIO MODES
!
The default mode is Weather Band (WB). While the radio is on, press the
AM/FM/NOAA button to toggle between radio modes:
•WB radio
•FM radio
•AM radio
!
ALERTS*
!
The radio must be in WB mode (default) to receive alerts* automatically.
!
During an alert*:
•The BLUE backlight will change to RED.
•The blue ARMED light and RED backlight will flash quickly
(every 2 seconds) for 5 minutes.
•The volume will increase to level 16.
•Press the VOLUME button to adjust the volume as
needed.
•Press the AM/FM/NOAA button to return to Stand By mode.
!
STAND BY
From WB mode, hold the AM/FM/NOAA button for 2
seconds to enter Weather Stand By.
•The blue ARMED indicator flashes slowly
(every 5seconds).
•Weather Alert: the blue ARMED indicator will
flash quickly (every 2seconds).
!
WEATHER BAND RADIO-Reliable Emergency
Information
!
The weather radio defaults to Weather Band. The radio
receives 7 weather band (WB) frequencies for up-to-
date weather information and public alerts.
•Press the TUNE button to change the WB channel
frequency.
!
!
Radio receives 7 weather band (WB) frequencies:
Channel 1: 162.400MHz
Channel 5: 162.500MHz
Channel 2: 162.425MHz
Channel 6: 162.525MHz
Channel 3: 162.450MHz
Channel 7: 162.550MHz
Model: S89102 www.lacrosseclock.com/support Page | !2

!
SET TIME
!
!
The radio
needs to be OFF to set the
time. With the radio OFF, hold the AM/FM/NOAA button for
2 seconds to enter time set mode.
•HOUR: The hour will blink. Press the TUNE button to set the desired
hour. Press the AM/FM/NOAA button to confirm the hour and move to
set the minutes.
•MINUTES: The minutes will blink. Press the TUNE button to set the
desired minutes. Press the AM/FM/NOAA button to confirm the
minutes.
Note: If no buttons are pressed for 20 seconds, the radio will automatically
time out of setting mode. The time will display when the radio is off.
!
FM RADIO
!
•Fully extend the antenna
•With the radio ON, press the AM/FM/NOAA button to select FM radio.
•Press the TUNE button to increase or decrease the radio frequency.
•Hold the TUNE button to quickly search for the next
available station.
!
!
AM RADIO
•Fully extend the antenna
•With the radio ON, press the AM/FM/NOAA button to
select AM radio.
•Press the TUNE button to increase or decrease the
radio frequency.
•Hold the TUNE button to quickly search for the next available station.
!
VOLUME
•Press the VOLUME button to adjust the volume.
•Hold the VOLUME button to change faster.
•Default volume is 10. Levels 1-16 are available.
!
LCD BACKLIGHT
!
•This radio has a high visibility BLUE color backlight for normal viewing.
•Backlight color changes to RED during a Weather Alert.
Channel 4: 162.475MHz
Model: S89102 www.lacrosseclock.com/support Page | !3

•Red backlight will flash every 2seconds for 5 minutes during a weather
alert.
•Blue backlight turns on for 10 seconds when any button is pressed.
!
EARPHONE USE
!
•Privately listen to the radio with a set of 3.5mm earphones (not
included). There is a 3.5mm earphone jack on the side of the radio.
!
PROTECTED TELESCOPING ANTENNA
!
•Fully extend the protected telescoping antenna to receive a
strong WB, FM or AM radio signal.
•Place the radio near a window when indoors for best reception.
!
WHITE LED FLASHLIGHT
!
•Press the LIGHT button on the side of the radio to operate the very
bright LED flashlight.
•The super bright LED flashlight is a full ½watt.
!
POWER BUTTON
•Press and release the POWER button to turn ON or turn OFF the
radio
Note: The radio saves the last channel you are listening to, mode and
volume used, when turned off.
!
SPECIFICATIONS
Dimensions: 3.04” L x 5.89” H x 1” D (77.3 L x 149.8 H x 25 D mm)
Weather Band
(7 Channels) -6dB 162.4000 - 162.5500MHz
AM 82dB 520-1710KHz
FM 10dB 87.5 -108 MHz
A/C Cord: 6 volt (included)
Battery: 3 x AAA LR3 Alkaline (not included)
Battery Life: 36 months with power off
22-24 hours in Weather Stand By mode
Operating
Temperature: 32 °F - 122°F (0 °C – 50 °C)
Storage
Temperature: 14 °F - 122°F (-10 °C – 50 °C)
Model: S89102 www.lacrosseclock.com/support Page | !4

MAINTENANCE AND CARE
!
•Extreme temperatures, vibration, and shock should be avoided to prevent
damage to the radio.
•Clean with a soft, damp cloth. Do not use solvents or scouring agents; they
may mark the radio.
•Do not submerge the weather radio in water. Radio is not waterproof
•Opening the casing invalidates the warranty. Do not try to repair the radio.
•Do not leave in vehicle in extreme temperatures.
!
* DISCLAIMER
!
La Crosse McCormick, LLC. (“La Crosse”) provides various alert options to aid
users. La Crosse shall not be liable for accuracy, usefulness or availability of
information transmitted via the service. Users are solely responsible for damages to
persons or property by service use.
!
FCC
!
This Device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
the device must accept any interference received, including interference that may
cause undesired operation.
!
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY TO
OPERATE THE EQUIPMENT
!
WARRANTY
!
La Crosse McCormick, LLC warrants that if the accompanying product proves to be
defective to the original purchaser in material or workmanship within 1-year from the
original retail purchase, La Crosse McCormick, LLC will, at La Crosse McCormick,
LLC ’s option, either repair or replace same without charge (but no cash refund will
be made).
CONDITIONS
!
Light: Super bright flashlight. Full 1/2 Watt white LED
Backlight: High visibility Blue backlight changes to Red for Weather
Alerts
Antenna: 6” Protected telescoping antenna
Jack: 3.5 mm Earphone Jack
Lanyard: Hands-free lanyard included.
Model: S89102 www.lacrosseclock.com/support Page | !5

1. You must deliver mail or ship the product, together with the original bill of sale and
this limited warranty statement as proof of warranty.
2. This warranty is void if any defects are caused by abuse, misuse, negligence or
unauthorized repairs.
3. All liability for incidental or consequential damages is specifically excluded. Some
states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights, which vary from
state to state.
!
!
Limitation of Liability and Remedies
!
La Crosse McCormick, LLC shall have no liability for any damages due to loss of
profits, loss of use or anticipated benefits, or other incidental, consequential, special
or punitive damages arising from the use of, or the inability to use, this product,
whether arising out of contract, negligence, tort or under any warranty, even if La
Crosse McCormick, LLC has been advised of the possibility of such damages. La
Crosse McCormick, LLC’s liability for damages in no event shall exceed the amount
paid for this product.
!
SERVICE PROCEDURE
!
Please follow the procedure below to ensure the radio is properly serviced and
returned. Failing to follow the procedures may result in delays or loss of product.
!
1. PROOF-OF-PURCHASE: Include some form of proof-of-purchase.
2. RADIO: Enclose the NOAA Weather Radio.
3. PROPER PACKING: Pack the radio securely to prevent damage during transit.
Use original packing material if possible.
4. PROBLEM DESCRIPTION: Enclose a detailed written description of the problem.
5. CONTACT INFORMATION: Enclose a typed or clearly printed name, address,
and phone number where you can be contacted during the day M-F.
6. PREPAID TRACEABLE CARRIER: Ship the package with the contents listed
above, prepaid and insured by way of traceable carrier (to avoid loss in transit). The
Manufacturer is not responsible for units not received if the package has not been
properly insured.
Mail to:
La Crosse McCormick
Warranty Department
2830 South 26th St.
La Crosse WI 54601
!
7. REPAIR/EXCHANGE: The radio will be repaired or exchanged
upon its receipt if it is under warranty.
8. SERVICE TIMELINE: Please allow approximately !
2-4 weeks for the radio to be serviced under warranty.
!
Contact Support:
1-608-782-1610
Model: S89102 www.lacrosseclock.com/support Page | !6

Product Registration:
www.lacrosseclock.com/register
Online:
www.lacrosseclock.com/s89102
!
