La Hacienda 56107US User manual

UserInstructions-Pleasekeepforfuturereference
UserInstructions-Pleasekeepforfuturereference
SteelBBQSmokerPizzaOven
ProducedinChinaforLaHacienda UKLtd
Hangar27,SiteC,AstonDownAirfield,NrStroud,Glos,GL68HR,UK
www.lahacienda.co.uk
Toolslist
Toolsrequired(notincluded)
IMPORTANT – Carefully remove any packaging before use, but retain the safety instructions.
These instructions form part of the product.
Please take note of all of the safety warnings listed in these instructions.
Please read these instructions in their entirety and retain them for future reference.
These instructions should be stored with the product.
This product is for domestic use ONLY and should not be used commercially or for contract purposes.
56107US
V1.0
La Hacienda
®

2
Careandsafeuseguidelines
Ensure pizza oven has a minimum of 7ft
overhead clearance and has a minimum of
7ft clearance from any combustible materials
or items.
DO NOT use this pizza oven as a
furnace - ONLY use as a patio heater.
DO NOT handle or move the pizza oven
whilst alight as it will be hot.
ALWAYS USE the safety tool provided and
heat resistant gloves.
Ensure that the pizza oven is positioned on
a permanent flat, stable, heat resistant
non-flammable surface away from flammable
items.
The assembled product is heavy and once
positioned must not be moved whilst in use.
If it is necessary to move it once cooled, use
two persons to lift (DO NOT drag) the product.
year if a
protect it
The unit may be left outside all
pizza oven cover is used to help
from bad weather.
ce the
y
To help reduce surface rust, on
pizza oven is cool rub it with an oil
rag (vegetable oil).
If the pizza oven surface becomes scratched
or chipped, the damaged area should be
re-coated with a suitable non-toxic high
temperature paint.
For safety reasons, always inspect your
pizza oven prior to use for signs of fatigue
and damage and replace your model as
and when necessary.
As this model is made from steel, the surface
will age and develop surface rust as soon as
it is exposed to the natural weather elements
and also from first use.
This product is intended FOR OUTDOOR
USE ONLY.
DANGER Failure to read and observe all
warnings and directions for use and
extinguishing may result in unsafe conditions
leading to damage to property, injury or
death.
ALWAYS keep children and pets at a safe
distance from the pizza oven when in use.
Do not allow children to use the product.
NEVER leave a burning fire unattended.
DANGER of carbon monoxide
poisoning - NEVER light this product or
let it smoulder or cool down in confined
spaces.
DO NOT use this product in a tent,
caravan, car, cellar, loft or on a boat.
DO NOT use this pizza oven under
any outdoor awnings, parasols, sun
umbrellas or gazebos.
DO NOT use coal in this product.
DO NOT use this pizza oven on decking or
any other flammable surfaces such as dry
grass, wood chips, leaves or decorative bark.
This product is ONLY suitable for use with
untreated wood, logs or charcoal.
DANGER Plastic bags can cause
suffocation. Dispose of all packaging
materials properly.
FIRE HAZARD – Hot embers may emit
while in use. Always keep fire suppression
tools nearby.
DO NOT use gasolene, kerosene, white spirit,
lighter fluid, alcohol or other similar chemicals
for lighting or re-lighting the fire.
Always use heat resistant gloves during use
and when adding fuel.
Once the fire is alight close the safety door.
Only open the door to re-fuel.
NEVER touch the ground/surface or leave fuel
or other objects directly under this product, as
the ground/surface will be very hot and may
remain so for some time even after the product
has been extinguished.
ONLY use methods of ignition which are
acceptable in accordance with your local
fire safety codes.

•When cooking on your product, ensure that the food is cooked thoroughly prior to consumption.
• The Pizza Stone and Grill can be washed using a mild detergent. They are not suitable for dishwasher use.
• The Pizza Stone will develop soot on the underside – this may be difficult to remove and should be expected. It is not a fault
LIGHTING & REFUELLING
• DO NOT burn fuel directly on the oven base. ALWAYS use the fuel grate.
• This product is ONLY suitable for use with charcoal, untreated wood or logs.
• Prepare a stack of loosely crumpled newspaper and place on top of the fuel grate.
• Pile finely split dry firewood or kindling on top of the paper.
• To light the newspaper, use long safety matches or a long nosed lighter.
• Once sufficiently alight, add logs or larger pieces of untreated wood or charcoal to the unit to increase the heat slowly.
• DO NOT overload with fuel, 3kg charcoal or 2 small logs is sufficient.
• ALWAYS use heat resistant gloves when adding fuel and handling the doors, as the unit will become very hot.
• ALWAYS ensure that the doors are closed when in use.
COOKING ON YOUR PIZZA OVEN
• Light as above
• Place untreated wood or charcoal into the lower fuel area. DO NOT use more fuel than 75% of fuel area capacity, e.g. 3kg
• Allow the fuel to heat up and be kept red hot for at least 30 minutes prior to the first cooking on the Grill/Pizza Stone.
• DO NOT cook before the fuel has a coating of ash. If required, using heat resistant gloves, place the Pizza Stone on top of the
• Once the fuel has a coating of ash, place your food onto the Grill or Pizza Stone.
• If you wish to use as a smoker unit, add wood chips to the fuel and restrict air flow to the unit by closing the baffle plate on the
• To keep meat moist, add a small amount of water to a small foil tray, separate the coals in the lower fuel section and place the
• Top up liquid as necessary.
• Air flow can be adjusted as required via the baffle plate and damper on the flue.
• If refuelling is required, ALWAYS use heat resistant gloves to open the lower door.
• When finished DO NOT remove the Pizza Stone or grill until the unit has completely cooled.
charcoal or 2 small logs.
Grill. For grilling or smoking, remove the pizza stone.
lower door and the damper on the flue.
tray between the fuel.
and will not affect use.
Careandsafeuseguidelines
Careandsafeuseguidelines
FOOD COOKING INFORMATION
•DO NOT cook before the fuel has a coating of ash.
•ALWAYS wash your hands before and after handling uncooked meat and before eating.
•ALWAYS keep raw meat away from cooked meat and other foods.
•Before cooking ensure grill surfaces and tools are clean and free of old food residues.
•DO NOT use the same utensils to handle cooked and uncooked foods.
•Ensure all meat is cooked thoroughly before eating.
•CAUTION – eating raw or under cooked meat can cause food poisoning (e.g. bacteria strains such as E.coli).
•To reduce the risk of under cooked meat cut open to ensure it is cooked all the way through.
•CAUTION – if meat has been cooked sufficiently the meat juices should be clear and there should be no traces of pink/red juice
or meat colouring.
•Pre-cooking larger pieces of meat and joints is recommended before finally cooking on your grill.
•After cooking ALWAYS clean the grill cooking surfaces and utensils.
EXTINGUISHING
• To extinguish, stop adding fuel and allow fire to die or douse with sand. DO NOT use water as this may damage the
product.
STORAGE
• When not in use, and if stored outside, cover the product once it has cooled completely with a Pizza Oven Cover.
• Remove loose paint and rust with a wire brush when needed and re-paint the product using high temperature paint.
3
To extinguish unit – stop adding fuel
and allow fire to die or douse with
sand.
DO NOT use water as this may damage
the product.
If covering the product, only position once
the fire has died and the unit has completely
cooled.
DO NOT use alcohol, intoxicants, narcotics
or any form of non-prescription drug when
handling the product as the ability to safely
assemble and operate will be impaired.
Use care when working near fire, do not stand
over fire when lighting or during use, loose
clothing can catch fire easily. If clothing catches
fire always remember to stop, drop and roll.

Partslist
4
WARNING - DO NOT over tighten bolts; only tighten with moderate pressure to avoid damaging the bolts or
components of the Pizza Oven.
Prior to assembly: read the instructions carefully. Check all parts against the parts list.
Carry out assembly on a soft surface to avoid scratching the paint. Please retain this information for future reference.
For ease of assembly only loosely tighten bolts and then tighten fully when assembly is complete.
Assemblydiagram
M5 Screw
A (26x)
2 (1x)
3 (1x)
4 (1x) 10 (1x)
11 (1x)
13 (1x)
12 (2x)
14 (1x)
15 (1x)
16 (1x)
17 (2x)
D (2x)
5 (1x)
6 (1x)
7 (1x)
8 (2x)
9 (1x)
1 (1x)
10
2
A
A
12
4
5
9
13
A
17
15
14
3
1
6
7
8
8
11
D
B
16
C (4x)
B (2x)
E (4x)

5
IMPORTANT - Remove any packaging before use, but retain the safety instructions and store them with this
product.
ASSEMBLY
STEP 1 - Attach trolley bracket (12) to wheel trolley section (13) and trolley section (14) using 4 screws (A) each
side - total 8 screws.
STEP 2 - Attach trolley shelf (15) to wheel trolley section (13) using 4 screws (A). Attach trolley shelf (15) to trolley
section (14) using 4 screws (A).
STEP 3 - Feed wheel axle (16) through holes in wheel trolley section (13) and attach wheels (17) securing with
one nut (B) per wheel. Cover nut with wheel cap (D).
STEP 4 - Attach body (3) to wheel trolley section (13) and trolley section (14) using 4 screws (A) and washers (E).
STEP 5 - Attach lower door with baffle (5) to body (3) using 1 x hinge bar (8). Secure using 2 x split pin (C).
STEP 6 - Attach upper door (4) to body (3) using 1 x hinge bar (8). Secure using 2 x split pin (C).
STEP 7 - Attach chimney (2) to body (3) using 3 screws (A).
STEP 8 - Attach chimney cap (1) to chimney (2) using 3 screws (A).
STEP 9 - Attach handle (7) to body (3) using preassembled nuts, bolts and washers.
STEP 10 - Place 2-part fuel grate (9) on the ledge in the lower oven.
STEP 11 - Place 2-part cooking grill (6) on the ledge in the upper oven, adding the pizza stone (11) if required.
STEP 12 - Slide in the ash drawer (10) between the body (3) and the trolley sections (13 and 14).
The Pizza Oven / Smoker is now ready to use but please ensure you have read these instructions
thoroughly prior to use.
AssemblyInstructions
Note A large fire can damage or shorten
the life of the unit.
Note The unit is manufactured with high
temperature paint. However, due to the
nature of steel, some rusting can occur. This
is not a cause for concern and will not affect
the performance of your pizza oven.
WARNING Do not leave the unit unattended
while the fire is burning.
Note Check the pizza oven for any signs of
damage or disrepair before each use.
Note Follow all local, state and national
codes when using this unit. Contact your
local fire department for information on
outdoor burning.
