Lab.gruppen Plm 10000q Instruction manual

▸▸2350▸W▸per▸channel▸@▸2▸ohms**

▸▸2300▸W▸per▸channel▸@▸4▸ohms**

▸▸2U▸chassis▸weighing▸only▸13.5▸kg▸(30▸lbs)

▸▸Class▸TD®▸output▸stage

▸▸Regulated▸Switch▸Mode▸Power▸Supply▸(R.SMPS™)

▸▸Copper-nned▸ Intercooler®▸ with▸ transverse-mounted▸ output▸

devices

▸▸Full▸suite▸of▸protection▸and▸fault▸monitoring▸features

▸▸Comprehensive▸loudspeaker▸preset▸database

▸▸LoadLibrary™▸load▸“Fingerprint”▸(identity▸and▸characteristics)▸data

▸▸Comprehensive▸ LoadSmart™▸ load▸ verication▸ and▸ SpeakerSafe™▸

continuous▸loudspeaker▸performance▸monitoring

▸▸Dante™▸low-latency▸digital▸network▸included▸as▸standard▸

▸▸Fully▸ compatible▸ with▸ Dolby▸ Lake▸ Processor,▸ Lake▸ Contour™,▸

and▸Lake▸Mesa▸Quad▸EQ™▸and▸Mesa▸Parametic▸EQ™▸devices

▸▸Primary▸and▸secondary▸network▸connections▸(for▸daisy▸chaining▸or▸

system▸redundancy)

▸▸Digitally▸controlled▸”amplier▸gain”▸adjustable▸in▸0.1▸dB▸steps▸from▸

22▸to▸44▸dB

▸▸Digital▸output▸attenuation▸in▸0.25▸dB▸steps▸from▸-inf▸to▸0▸dB

▸▸Binding▸ post▸ or▸ Neutrik®▸ Speakon®▸ (1▸ x▸ NLT8,▸ 2▸ x▸ NLT4)▸ power▸

output▸connectors▸

▸▸Digitally▸implemented,▸zero-overshoot▸ Inter-Sample▸ Voltage▸Peak▸

Limiting▸(ISVPL

™)▸adjustable▸in▸0.1▸V▸steps▸from▸17.8▸to▸153▸V▸

▸▸Power▸Average▸Limiter▸(PAL)▸

▸▸High-brightness▸front-panel▸LCD▸display

▸▸Moisture▸resistant▸silicone▸touchpad▸for▸front-panel▸display▸mode▸

selection▸and▸menu▸navigation

**▸▸More▸power▸available▸when▸driven▸asymmetrically.

▸▸Raised▸Cosine▸Equalization™

▸▸Linear▸phase▸and▸classical▸crossovers

▸▸LimiterMax™▸–▸peak▸and▸RMS▸limiters

▸▸Iso-Float™▸ground▸isolation

▸▸Super▸Module▸capability

▸▸Integration▸ of▸ third▸ party▸ frequency▸ measurement▸ and▸ analysis▸

system▸via▸the▸Lake▸Analyzer▸Bridge

▸▸Analog▸and▸AES▸digital▸inputs▸with▸loop-thru▸outputs

▸▸Auto-select▸input▸router▸for▸all▸inputs▸with▸user▸denable▸priorities▸

PLM 10000Q Powered Loudspeaker Management system

The▸ two-▸ input,▸ four-▸ output▸ PLM▸ 10000Q▸ seamlessly▸ integrates▸▸

networked▸digital▸signal▸distribution,▸drive▸processing,▸power▸ampli-

cation,▸and▸load▸verication▸plus▸performance▸monitoring▸in▸a▸single▸

hardware▸ unit▸ and▸ unied▸ software▸ controller.▸ This▸ new▸ approach,▸

designated▸Powered▸Loudspeaker▸Management▸(PLM),▸is▸a▸cohesive▸

blend▸of▸ Lake®▸ Processing▸and▸Lab.gruppen▸ power.▸As▸a▸complete▸

system,▸ the▸ PLM▸ 10000Q▸ affords▸ signicant▸ benets▸ when▸ com-

pared▸to▸conventional▸approaches▸utilizing▸separate▸components.

Lab.gruppen Technology

Lake Processing Technology

PLM 10000Q

Technical Data

PLM™ Series: Powered Loudspeaker Management™

PLM 10000Q Neutrik Speakon connector version shown.

Power Amplier

Although▸ based▸ on▸ technology▸ in▸ Lab.gruppen’s▸ road-proven▸▸

FP+▸Series,▸the▸amplier▸platform▸in▸the▸PLM▸10000Q▸Powered▸Loud-

speaker▸ Management▸ system▸ incorporates▸ further▸ enhancements▸

for▸even▸greater▸sustained▸output▸power.▸The▸basic▸output▸topology▸

remains▸Lab.gruppen’s▸patented▸Class▸TD▸(offering▸Class▸D▸efciency▸

with▸the▸sonic▸purity▸of▸Class▸B▸designs),▸but▸with▸new▸circuitry▸for▸▸

substantially▸ greater▸ current-carrying▸ capabilities.▸ The▸ Regulated▸

Switch▸ Mode▸ Power▸ Supply▸ (R.SMPS)▸ is▸ optimized▸ to▸ deliver▸ full▸

power▸during▸long▸low-frequency▸bursts,▸as▸well▸as▸maintain▸stable▸

rail▸voltages▸despite▸uctuating▸line▸voltage.▸▸The▸PLM▸Series▸also▸of-

fers▸extreme▸power▸density,▸patented▸Intercooler▸cooling,▸a▸full▸suite▸

of▸protection▸features,▸and▸a▸Power▸Average▸Limiter▸(PAL)▸to▸prevent▸

tripping▸of▸mains▸breakers.▸▸

Load Verication and Continuous Performance Monitoring

The▸ PLM▸ 10000Q▸ includes▸ a▸ revolutionary▸ set▸ of▸ tools▸ for▸ fast,▸▸

accurate▸load▸verication▸and▸real-time▸performance▸monitoring.▸The▸

key▸to▸both▸features▸is▸the▸LoadLibrary,▸a▸comprehensive▸database▸that▸▸

provides▸ unique▸ “Fingerprints”▸ (load▸ characteristics)▸ for▸ each▸ loud-

speaker▸ model▸ in▸ the▸ system.▸ Using▸ this▸ data▸ and▸ on-board▸ DSP,▸

LoadSmart▸compares▸predicted▸response▸(using▸a▸brief▸test▸signal)▸to▸

the▸actual▸response,▸instantly▸identifying▸potential▸problems.▸When▸

activated,▸SpeakerSafe▸real-time▸performance▸monitoring▸helps▸the▸

operator▸ avoid▸ power▸ compression▸ and▸ provides▸ ongoing▸ detailed▸

critical▸information▸about▸system-wide▸driver▸integrity.

Lake Processing

The▸ PLM▸ 10000Q▸ contains▸ four▸ full-featured▸ Lake▸ Processing▸

modules,▸ each▸ offering▸ precise▸ settings▸ for▸ gain,▸ delay,▸ cross-

over▸ slope,▸ equalization,▸ and▸ limiting.▸ Exclusive▸ Lake▸ Proces-▸

sing▸ algorithms▸ are▸ included▸ for▸ Raised▸ Cosine▸ Equalization,▸ linear▸

phase▸crossovers,▸LimiterMax▸loudspeaker▸protection,▸and▸Iso-Float▸

ground▸ isolation.▸ Raised▸ Cosine▸ Equalization▸ is▸ the▸ foundation▸ for▸

the▸Lake▸Mesa▸EQ▸and▸the▸Ideal▸Graphic▸EQ,▸the▸two▸revolutionary▸

EQ▸ interfaces▸ used▸ by▸ the▸ Dolby▸ Lake▸ Processor.▸ Mesa▸ EQ▸ offers▸

asymmetric▸ ltering▸ to▸ match▸ the▸ asymmetric▸ responses▸ of▸ many▸

loudspeaker▸ systems.▸The▸ Ideal▸Graphic▸EQ▸offers▸true▸sum-to-at▸

response,▸so▸the▸adjustments▸provide▸uniform▸boost▸and▸cut▸along▸

with▸greater▸selectivity.

Lake▸Processing▸also▸offers▸both▸classical▸crossovers▸(selectable▸up▸

to▸48▸dB▸per▸octave)▸and▸linear▸phase▸crossovers.▸Capable▸of▸slopes▸

exceeding▸180▸dB▸per▸octave,▸linear▸phase▸crossovers▸offer▸greater▸

control▸to▸limit▸lobing▸and▸off-axis▸cancellation.

Lake Controller software

Lake▸ Controller▸ software▸ provides▸ a▸ unied▸ interface▸ for▸

control▸ and▸ monitoring▸ of▸ all▸ functions▸ of▸ the▸ Powered▸ Loud-

speaker▸ Management▸ system.▸ In▸ addition▸ to▸ controlling▸ all▸▸

parameters▸ of▸ standard▸ Lake▸ Processing▸ (therefore▸ appropriate▸ for▸

use▸with▸Dolby▸Lake▸Processors),▸all▸new▸versions▸provide▸control▸and▸

monitoring▸of▸exclusive▸PLM▸features:▸digital▸input▸gain▸and▸attenua-

tion,▸and▸load▸verication▸and▸performance▸monitoring▸via▸LoadSmart▸

and▸SpeakerSafe.

The▸ exible▸ Lake▸ Controller▸ software▸ environment▸ can▸ control▸ ex-

tensive▸ networks▸ of▸ powered▸ loudspeaker▸ management▸ systems▸

from▸ a▸ single▸ computer.▸ The▸ user▸ interface▸ is▸ based▸ on▸ discrete▸

processing▸modules,▸with▸each▸module▸assigned▸to▸power▸outputs▸

normally▸dened▸for▸sets▸of▸band-limited▸drivers▸(e.g.▸low,▸mid,▸high,▸

subs).▸ Adjustments▸ can▸ be▸ made▸ in▸ real▸ time▸ to▸ any▸ parameter▸ of▸

any▸ module▸ on▸ the▸ network.▸ Modules▸ may▸ be▸ assigned▸ to▸ groups▸

representing▸ subsystems▸ in▸ larger▸ systems,▸ such▸ as▸ main▸ arrays,▸

delays,▸and▸ lls▸ in▸an▸ arena▸system.▸Because▸ each▸module▸ can▸be▸

assigned▸to▸more▸than▸ one▸group,▸the▸Lake▸ Controller▸ can▸simulta-

neously▸address▸multiple▸groups▸for▸global▸adjustments▸ as▸ needed▸

while▸maintaining▸independent▸control▸of▸separate▸subsystems▸and▸

individual▸components.▸

The▸ Super▸ Module▸ functionality▸ allows▸ a▸ single▸ on-screen▸ module▸

interface▸ to▸ control▸ output▸ channels▸ in▸ different▸ PLM▸ units.▸ For▸▸

example,▸ a▸ three-way▸ Super▸ Module▸ could▸ be▸ congured▸ using▸ a▸

high-power▸LF▸channel▸in▸ one▸PLM▸unit▸along▸with▸ lower-powered▸

MF▸and▸HF▸channels▸in▸a▸different▸unit.

The▸Lake▸Controller▸software▸is▸optimized▸for▸a▸wireless▸Tablet▸PC.▸

Operation▸ is▸ easy▸and▸ intuitive,▸ with▸the▸ “feel”▸of▸real-time▸analog▸

faders▸and▸controls.▸The▸same▸Lake▸Controller▸interface▸can▸be▸used▸

to▸ operate▸ Dolby▸ Lake▸ Processors,▸ Lake▸ Contour,▸ and▸ Lake▸ Mesa▸

Quad▸EQ▸processors▸as▸part▸of▸a▸unied▸system.

Another▸ Lake▸ Controller▸ software▸ feature▸ is▸ seamless▸ integration▸

with▸third▸party▸▸real-time▸sound▸system▸measurement,▸optimization,▸

and▸control▸software▸packages▸via▸the▸Lake▸Analyzer▸Bridge.▸Users▸

can▸measure▸spectrum▸and▸transferfunction▸and▸adjust▸system▸EQ▸at▸

the▸same▸time,▸using▸the▸same▸user▸interface.

Dante Digital Audio Network

The▸ PLM▸ Series▸ Powered▸ Loudspeaker▸ Management▸ systems▸ are▸

equipped▸ as▸ standard▸ with▸ Dante,▸ a▸ self-conguring▸ digital▸ audio▸

networking▸ solution▸ from▸ Audinate®▸ of▸ Australia.▸ Based▸ on▸ the▸

newest▸ developments▸ in▸ networking▸ technology,▸ Dante▸ provides▸▸

reliable,▸ sample-accurate▸ audio▸ distribution▸ over▸ Ethernet▸ with▸▸

extremely▸low▸latency.▸Dante▸incorporates▸Zen™,▸an▸automatic▸device▸

discovery▸and▸system▸conguration▸protocol▸which▸enables▸PLM▸Se-

ries▸products▸and▸other▸products▸with▸Dante▸(like▸Dolby▸Lake▸Proces-

sors)▸to▸nd▸each▸other▸on▸the▸network▸and▸congure▸themselves.

Powered Loudspeaker Management: Technology Overview

Input

Router

(Mute)

Input

Router

(Mute)

Input

Mixer A

Input

Mixer B

EQ Delay

Crossovers

Output Routing

AMP

Attenuator

Mute

Phase Rev

Attenuator

Mute

Phase Rev

Attenuator

Mute

Phase Rev

LoadSmart

SpeakerSafe

LoadSmart

SpeakerSafe

LoadSmart

SpeakerSafe

LoadSmart

SpeakerSafe

Amp Gain

Attenuator

Mute

Phase Rev

Module:

Gain

Phase Rev

Mute

Analog 1/2

AES 1

AES 2

Dante X

Dante Y

Analog 1/2

AES 1

AES 2

Dante X

Dante Y

AMP

ISVPL

Module:

Gain

Phase Rev

Mute

Output EQ LimiterMax

RMS / Peak

Module Output:

Gain/Delay

Phase Rev

Mute

Output EQ LimiterMax

RMS / Peak

Module Output:

Gain/Delay

Phase Rev

Mute

Output EQ LimiterMax

RMS / Peak

Module Output:

Gain/Delay

Phase Rev

Mute

Output EQ LimiterMax

RMS / Peak

Module Output:

Gain/Delay

Phase Rev

Mute

Output EQ LimiterMax

RMS / Peak

Module Output:

Gain/Delay

Phase Rev

Mute

Output EQ LimiterMax

RMS / Peak

Module Output:

Gain/Delay

Phase Rev

Mute

Ser. N:o Removed!

CH 2

CH 1

CH 4

CH 3

CLASS 2 WIRING

SPEAKER OUTPUTS INPUT 1INPUT 2LINK 1LINK 2

AES/EBU

INPUT 1-2 LINK 1-2 LINK SECPRIMACT LINKACT

SWITCHED 10/100 Base-TX

Must be grounded/earthed

Made in Sweden

PIN 1: SCRN 2: POS 3: NEG

ANALOG WITH ISO-FLOAT TM

200-240V 2500W

50-60Hz

PLM 0000Q1

Ser. N:o Removed!

CLASS 2 WIRING

SPEAKER OUTPUTS INPUT 1INPUT 2LINK 1LINK 2

AES/EBU

INPUT 1-2 LINK 1-2 LINK SECPRIMACT LINKACT

SWITCHED 10/100 Base-TX

Must be grounded/earthed

Made in Sweden

PIN 1: SCRN 2: POS 3: NEG

ANALOG WITH ISO-FLOAT TM

1+/- CH 1+/-

2+/- CH 2+/-

1+/- CH 1+/-

2+/- CH 2+/-

3+/- CH 3+/-

4+/- CH 4+/-

1+/- CH 3+/-

2+/- CH 4+/-

200-240V 2500W

50-60Hz

PLM 0000Q

The front panel▸is▸the▸“local▸control▸center”▸for▸the▸PLM▸10000Q.▸An▸intuitive,▸menu▸driven▸interface▸allows▸quick▸access▸to▸key▸functions▸

using▸the▸moisture▸resistant▸silicone▸touchpad.▸Information▸is▸clearly▸displayed▸on▸the▸daylight-readable,▸2.5-inch▸LCD▸panel.▸The▸soft-button▸

keypad▸and▸precision▸rotary▸encoder▸provide▸control▸of▸processing▸and▸amplication▸functions,▸with▸key▸lock▸available.

The PLM 10000Q▸ is▸ available▸with▸ either▸binding▸posts▸or▸ an▸ “embedded▸patch▸ panel”▸with▸ Neutrik▸Speakon▸connectors▸ (2▸x▸NLT4▸ and▸

1▸x▸NLT8).▸Common▸connectors▸include;▸2▸x▸analog▸input▸XLR▸with▸switchable▸Iso-Float,▸2▸channels▸of▸AES/EBU▸with▸link-through▸capability▸

for▸daisy▸chaining,▸2▸x▸EtherCon®▸for▸linking▸or▸redundancy.▸A▸32▸amp▸PowerCon®▸connector▸is▸used▸for▸mains▸supply.

This signal ow block diagram▸illustrates▸the▸exible▸mixing▸and▸routing,▸as▸well▸as▸the▸powerful▸signal▸processing▸capabilities,▸offered▸by▸

the▸PLM▸Series.▸The▸input▸routers▸allow▸for▸redundant▸and▸prioritized▸inputs,▸with▸automatic▸switch▸over▸in▸case▸of▸signal▸failure.▸The▸input▸

mixers▸provide▸mixing▸capabilities▸between▸the▸outputs▸of▸the▸two▸input▸routers.▸The▸two▸Lake▸Processing▸modules▸(covering▸all▸red▸blocks)▸

provide▸user▸EQ,▸crossover▸and▸output▸lters▸along▸with▸gain▸adjustments,▸mute,▸phase▸reverse,▸delay,▸and▸limiters.▸Module▸outputs▸can▸be▸

routed▸to▸either▸power▸output▸channel.▸Each▸power▸output▸channel▸provides▸individual▸channel▸attenuation,▸mute▸and▸phase▸reversal.▸Each▸

power▸output▸channel▸also▸implements▸congurable▸amplier▸gain▸and▸an▸advanced▸peak▸limiter▸in▸the▸ISVPL.

The▸exible▸architecture▸of▸the▸PLM▸Series▸allows▸the▸settings▸for▸each▸unit▸to▸be▸stored▸in▸different▸hierarchies.▸The▸Lake▸Processing▸modules▸

can▸be▸instantly▸congured▸with▸module▸les▸that▸are▸cross▸compatible▸with▸Dolby▸Lake▸products.▸Settings▸can▸also▸be▸stored▸and▸recalled▸on▸

a▸system▸and▸subsystem▸level▸(system/subsystem▸les)▸as▸well▸as▸on▸a▸device▸level▸(frame▸presets).

Item no. TDS-PLM10000Q_V13

L a b . g r u p p e n a b ▸ S w e d e n

i n t e r n a t i o n a L c o n t a c t ▸ i n f o @ L a b g r u p p e n . c o m | u S & c a n a d a c o n t a c t ▸ i n f o @ t c g - a m e r i c a S . c o m

w w w . l a b g r u p p e n . c o m

General

Number▸of▸input▸channels 2

Number▸of▸output▸channels 4

Peak▸total▸output▸all▸channels▸driven 10800▸W

Max.▸Peak▸output▸voltage▸per▸channel 153▸V

Max.▸output▸current▸per▸channel 50▸A▸peak

▸ ▸

Max. Output Power 2 ohms 4 ohms 8 ohms 16 ohms

All▸channels▸driven 2350▸W 2300▸W 1300▸W 660▸W

Channels▸1▸and▸2,▸while▸channels▸3▸and▸4▸are▸driven▸at▸-3▸dB▸2) 2350▸W 2400▸W 1300▸W 660▸W

All▸channels▸driven▸into▸optimal▸impedance▸interval▸ >▸2700▸W▸into▸2.4▸–▸3.2▸ohms

Audio Performance

THD▸+▸N▸20▸Hz▸-▸20▸kHz▸for▸1▸W <0.05%

THD▸+▸N▸at▸1▸kHz▸and▸1▸dB▸below▸clipping <0.04%

Dynamic▸range▸with▸digital▸inputs▸(for▸all▸supported▸sample▸rates) >116▸dB

Dynamic▸range▸with▸analog▸inputs >114▸dB

Frequency▸response▸(1▸W▸into▸8▸ohms,▸20▸Hz▸-▸20▸kHz) +▸/-0.05▸dB

Input▸Common▸Mode▸Rejection▸(CMR)▸20▸Hz▸to▸1▸khz >▸78▸dB

Internal▸sample▸rate 96▸k

Internal▸data▸path 32▸bit▸oating▸point

Product▸propagation▸delay,▸best▸case▸(96▸kHz▸AES) 1.61▸ms

Product▸propagation▸delay,▸analog▸input 1.68▸ms

Sample Rate Converters

THD▸+▸Noise 0.00003▸%,▸20▸Hz▸-▸20▸kHz,▸unweighted

Analog to Digital inputs

THD▸+▸Noise 0.00022▸%,▸typical▸at▸1▸kHz▸unweighted▸at▸+26▸dBu▸headroom▸setting

0.00033▸%,▸typical▸at▸20▸Hz▸and▸20▸kHz▸unweighted▸at▸+26▸dBu▸headroom▸setting

AES / EBU inputs

Supported▸resolutions ≤▸24▸bit

Supported▸sample▸rates 44.1,▸48,▸88.2,▸96,▸176.4,▸192▸kHz

Dante Audio Network

Supports▸redundant▸paths Yes

Flexible▸topology Yes

Network▸latency 0.8,▸1.3▸and▸4▸ms

Device presets

Local▸memory▸locations▸for▸the▸settings▸of▸the▸product 100

Limiters

Adjustable▸Inter-Sample▸Voltage▸Peak▸Limiter▸(ISVPL) 17.8▸-▸153▸V,▸step▸size▸0.1▸V

Current▸Peak▸Limiter▸<▸300▸ms 49▸A▸peak

Current▸Average▸Limiter▸(CAL)▸>▸300▸ms 25▸Arms

LimiterMax▸(rms▸and▸peak▸limiters)

▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸–▸MaxRMS▸(rms▸voltage▸limiter) Yes

▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸–▸MaxPeak▸(peak▸voltage▸limiter) Yes

Gain

Amplier▸gain 22▸-▸44▸dB,▸step▸size▸0.1▸dB

Analog▸attenuator -Inf▸to▸0▸dB,▸step▸size▸0.25▸dB

Back panel interface

AES▸/▸EBU▸/▸I/O▸(input▸+▸link) 2▸x▸3-pin▸XLR

Analog,▸2-channel▸I/O▸(input▸+▸link) 4▸x▸3-pin▸XLR,▸electronically▸balanced

Output▸connectors Neutrik▸Speakon▸(1▸x▸NLT8,▸2▸x▸NLT4)▸or▸4▸Binding▸Posts▸(pairs)▸(must▸be▸specied▸upon▸order)

Auto▸10/100,▸Auto▸Uplink 2▸x▸RJ45▸EtherCon

Control▸and▸monitoring▸interface Via▸Ethernet▸for▸Lake▸Controller▸software

Detachable▸mains▸cord Neutrik▸PowerCon▸32▸A

Cooling Two▸fans,▸front-to-rear▸airflow,▸temperature▸controlled▸speed

Front-panel user interface:

Display,▸daylight▸readable▸LCD 2.5▸inch

Fault/Warning/Limit/Clip▸indicators RGB▸LEDs

Mute▸and▸soft▸function▸buttons 8▸provided

Standby▸Power▸button On/Off

Mute▸Enable▸button Enables▸muting▸of▸outputs▸and▸inputs▸via▸soft-button▸keypad

Meter▸button Toggles▸through▸meter▸views

Menu▸button Provides▸a▸menu▸driven▸interface▸for▸full▸function▸front▸panel▸control

Rotary▸Encoder Yes

Exit▸button Provides▸a▸“back”▸function

Power

Operating▸voltage,▸230▸V▸/▸115▸V▸nominal▸1) 140-265▸V▸/▸70-135▸V▸(45▸-▸66▸Hz)

Soft▸start▸/▸Inrush▸Current▸Draw Yes▸/▸max.▸5▸A

Mains▸Power▸Average▸Limiter▸(PAL) Yes

Dimensions (W/H/D) W:▸483▸mm▸(19”),▸H:▸88▸mm▸(2▸U),▸Overall▸D:▸470▸mm▸(18.5”)▸deep▸including▸handles▸and▸rear▸support.▸

Weight 13.5▸kg▸(30▸lbs.)

Finish Black▸painted▸steel▸chassis▸with▸black▸painted▸steel▸/▸aluminum▸front

Approvals CE,▸ANSI/UL▸60065▸(ETL),▸CSA▸C22.2▸NO.▸60065,▸FCC

Note 1):▸Separate▸230▸V▸or▸115▸V▸versions▸available.▸Not▸selectable▸on▸the▸product.

Note 2):▸Assymetrically▸loading▸the▸output▸channels▸(as▸shown,▸for▸example):▸If▸one▸channel▸has▸reduced▸output▸power▸requirements,▸the▸voltage▸drop▸from▸the▸power▸supply▸will▸be▸reduced,▸▸

▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸▸resulting▸in▸a▸higher▸voltage▸and▸power▸output▸for▸the▸other▸channel.▸

▸All specifications are subject to change without notice.

Intercooler,▸Class▸TD▸and▸Lake▸are▸national▸and/or▸international▸registered▸trademarks▸of▸Lab.gruppen▸AB.▸PLM,▸Powered▸Loudspeaker▸Management,▸R.SMPS,▸LoadLibrary,▸LoadSmart,▸▸

▸ SpeakerSafe▸and▸ISVPL▸are▸trademarks▸of▸Lab.gruppen▸AB.▸Dolby▸and▸the▸double-D▸symbol▸are▸registered▸trademarks▸of▸Dolby▸Laboratories.▸Contour,▸Mesa▸Quad▸EQ,▸Mesa▸Parametric▸EQ,▸Raised▸▸

▸ Cosine▸Equalization,▸LimiterMax▸and▸Iso-Float▸are▸trademarks▸of▸Dolby▸Laboratories.▸▸Audinate▸is▸a▸registered▸trademark▸of▸Audinate▸Pty▸Ltd.▸Dante▸and▸Zen▸are▸trademarks▸of▸Audinate▸Pty▸Ltd.All▸▸

▸ other▸trademarks▸remain▸the▸property▸of▸their▸respective▸owners.
