Label 16005 User manual

USER MANUAL
GB
English
TRANSLATION OF ORIGINAL INSTRUCTIONS
PEDESTRIAN
AUTOMATIC
SLIDING
DOOR
USER MANUAL - EVOLUS-16005 - GB - Rel.1.3 - 01/2017 - CD0555GB-MU
Made in Italy by
Italia
EVOLUS
EVOLUS-T

THIS INSTRUCTION MANUAL IS INTENDED FOR THE FINAL USER OF A LABEL AUTOMATIC
SLIDING DOOR SYSTEM; IT IS UNDERSTOOD THAT INSTALLATION AND TESTING MUST
HAVE BEEN CARRIED OUT BY SPECIALISED PERSONNEL.
GENERAL SAFETY WARNINGS
PROVISIONS
The automatism has been designed to be used exclusively with pedestrian automatic sliding doors.
The manufacturer accepts no responsibility for incorrect product usage, as well as for any damages
arising from changes to the system made without his prior consent.
When operating the system accident prevention regulations must be observed.
REMARKS
Always meet the usage and maintenance conditions provided for by LABEL.
Maintenance and repair operations must only be performed by qualified and properly trained
personnel.
PROPER BEHAVIOUR
Only use the automatic door if it is in perfect technical conditions.
In case of failure or malfunction that might affect safety immediately contact the service centre.
Inappropriate use of the system may cause serious injuries and damage.
!
RECOMMENDATIONS
BEFORE COMMISSIONING THE AUTOMATIC DOOR, PLEASE
CAREFULLY READ THIS MANUAL.

TABLE OF CONTENTS:
1) INDICATIVE SYSTEM DESCRIPTION page 4
2) TECHNICAL DATA 4
3) AUTOMATIC DOOR OPERATION 5
3.1) NORMAL DOOR OPERATION 5
3.2) DOOR OPERATION IN NIGHT LOCK MODE 5
4) PROGRAM SELECTORS 5
4.1) MECHANICAL KEY SELECTOR EV-MSEL 5
4.2) DIGITAL PROGRAM SELECTOR N-DSEL 6
4.2.1) GENERAL PROGRAMMING MENU 8
4.2.2) PASSWORD 9
4.2.3) LANGUAGE 11
5) OPERATION IN CASE OF POWER SUPPLY FAILURE 12
6) USE OF PANIC EXIT BREAKOUT SYSTEM FOR ESCAPE ROUTES 13
7) NOTIFICATION OF ERRORS AND OPERATION PROBLEMS 14
8) MAINTENANCE 15
9) DISPOSAL 15
AUTOMATIC SLIDING DOOR
models:
EVOLUS
EVOLUS-T

1) INDICATIVE SYSTEM DESCRIPTION
2) EVOLUS - EVOLUS-T OPERATOR TECHNICAL DATA
POWER SUPPLY
POWER
FREQUENCY OF USE
WORKING TEMPERATURE
PROTECTION DEGREE
EVOLUS TRANSOM DIMENSIONS (H x D)
POWER SUPPLY OF EXTERNAL ACCESSORIES
230Vac +/-10%, 50-60Hz
80W
continuous
-15°C +50°C
IP22
13 Vdc
OPERATOR MODEL
4
PAUSE TIME Max. 20 sec.
AUTOMATISM
POWER SUPPLY
OUTER
SIDE
INNER
SIDE
1
2
3
4
5
6
Internal movement and presence sensor for door opening and safety during closing
Emergency opening button
Digital programmer
External movement and presence sensor for door opening and safety during closing
Opening safety sensor
Key button
7EVOLUS operator
7
EVOLUS-T TRANSOM DIMENSIONS (H x D)
EVOLUS-90T EVOLUS-T T200T EVOLUS-150T EVOLUS-T T200T
130W
120 x150 mm
120 x210 mm

5
3) AUTOMATIC DOOR OPERATION
WARNING!!
Always contact the assistance technician before commissioning the door, to learn how the automation works.
Switch on the power supply by means of the system switch.
The automation electronic control unit beeps shortly to indicate that the automatic door is powered.
The first opening command starts a calibration cycle during which the door opening speed is very low until the end of the stroke, to find the
stop point; after the delay time has elapsed, the door closes back at normal speed.
3.1) NORMAL DOOR OPERATION
When something enters the motions sensor (internal and/or external radar) detection area the door opens and stays open until sensors
detect the presence, then once the pause delay has elapsed the door closes back.
When the manual door opening button is pressed the door opens and stays open until the command remains active, t h en o n c e t h e
pause delay has elapsed it closes back.
If the closing safety sensor detects a presence,the door immediately reopens, and stays open as long as the sensor remains engaged.
If the opening safety sensor detects a presence, the door slows down and proceeds very slowly until the opening stroke is
completed.
If during the opening motion the door bumps against an obstacle, it stops and closes back.
When it opens again, later, it slows down near the point where it had met the obstacle, to avoid further impact.
If during the closing motion the door bumps against an obstacle, it stops and opens back.
When it closes again, later, it slows down near the point where it had met the obstacle, to avoid further impact.
3.2) DOOR OPERATION IN NIGHT LOCK MODE
The door cannot be opened through the external and internal radars.
The door can only be opened by pressing the OPEN button, or using the Spyco radio-control, if any.
The safety function (sensors and behaviour in case of obstruction) are active and work as described in par. 3.1. for normal operation.
4) PROGRAM SELECTORS
The program selector allows the door user to select the operating mode.
Depending on one's preferences, the EV-MSEL mechanical key selector or the N-DSEL digital programmer can be used.
Each program selector is described in details below.
4.1) EV-MSEL MECHANICAL KEY SELECTOR
The key can be taken out of the selector when in any position in order to prevent the work program from undesired changes.
Open door program
The door stops in complete opening position.
Reduced opening during winter
For reducing the opening space
Bi-directional automatic program
The door automatically opens when each opening control activates.
Single-direction automatic program output only
To exclude the incoming detection on external radar input
Night lock program
The door can only be opened through the OPEN input or using the SPYCO remote control, if any.
OPERATING MODE
Insert and rotate the key in EV-MSEL selector to select the program desired.

6
4.2) DIGITAL PROGRAM SELECTOR N-DSEL
By pulse-pressing the button, choose the automatic door operating mode.
Each time a button is pressed, it switches from a work program to the next one.
The operating programs to be selected by button are described below
Bi-directional automatic program
The door automatically opens when each opening control activates.
Single-direction automatic program output only
To exclude the incoming detection on external radar input
Single-direction automatic program input only
To exclude the outgoing detection on internal radar input.
Open door program
The door stops in complete opening position.
Night lock program
The door can only be opened through the OPEN input or using the remote control, if any.
Free manual door
The automatic operation is disabled and door can be manually open.

7
Operation of other buttons located on N-DSEL program selector panel
REDUCED OPENING DURING WINTER
To reduce the passage opening.
To activate the reduced opening during winter press the button once;
the symbol on the display indicates that the function is on.
To disable the reduced opening during winter press the button once more;
CHEMIST'S OPENING
To open the door by a few centimetres.
(Only if the chemist's function was enabled on the operator during installation).
To enable the chemist's opening press the F2 button once; the F2 symbol appears on the
display.
To disable the chemist's opening press the F2 button once more; the F2 symbol goes off on
the display.
F2
F1
F3
Door opening command
Pressing the F1 button will open the door.
The F1 may open the door even when the "NIGHT LOCK" work program is selected, if the
operator electronic control unit is set accordingly.
It is only used if the N-DSEL digital programmer manages two automatic doors
The N-DSEL digital programmer can independently manage the operation of two EVOLUS
sliding automatic doors.
Pressing the F3 button allows to select the door on which the work program is set;
The number 1 appears on the display when door 1 is selected; the number 2 appears if door
2 is selected.

8
F1
»
F1
»
F1
»
F1
»
5”
UNUSED
UNUSED
F1
»
F1
»
F1
»
“LANGUAGE"
SECTION
“PASSWORD MANAGEMENT"
SECTION
EXIT EXIT EXIT EXIT
ENTER
EXIT EXIT EXITEXIT
ENTER
DIAGRAM 1
4.2.1) GENERAL PROGRAMMING MENU
The user can enter the general programming menu when he wishes to select the desired language for the texts that appear on the display, or
when he wishes to enable a password to prevent any unauthorised access to the N-DSEL digital programmer.
SECTION
RESERVED FOR
TECHNICAL STAFF
SECTION
RESERVED FOR
TECHNICAL STAFF
SECTION
RESERVED FOR
TECHNICAL STAFF
SECTION
RESERVED FOR
TECHNICAL STAFF
The paragraphs below explain the procedure to be followed to manage the user password and to select the language.

9
4.2.2) PASSWORD
To prevent the door work program from being modified, a password can be entered that must be input every time the N-DSEL programmer is
used.
To enable the password perform the operations listed below:
1. Press the SET button for 5 seconds to access the general programming menu (see Diagram 1 at para. 4.3.1)
2. Press the F1 button five times to switch to the Password Management sub-menu.
3. Press the Enter button to access the “Password management” section.
PASSWORD MANAGEMENT
This section displays the two passwords available to the final user, the primary password and the service password.
The technical password is only reserved for the technical staff members in charge of installation and maintenance operations.
PRIMARY PASSWORD (for the system's owner-user)
It is a 5-character password used by the user to prevent unauthorized persons from having access to N-DSEL programmer and change the
work program.
Using a primary password is optional and must be enabled by system's owner.
Default preset primary password is “A-A-A-A-A”.
WARNING!
When enabling the password, be careful not to forget the access combination.
SERVICE PASSWORD (for user)
It is a 5-character password that the system's owner may divulge to persons to be authorized to use N-DSEL programmer.
The service password only allows changing the automatic door work program.
Default preset service password is “A-A-A-A-A”.
To change the service password, it is necessary to have access by primary password.
Use the button to move the selection arrow downward, F2 button to move back upward.
HOW TO CHANGE THE PRIMARY PASSWORD
ŸSelect “PRIMARY PASSWORD”
ŸPress OK (F1) button.
ŸType the default preset primary password “A-A-A-A-A” by pressing 5 times on A
button.
(IF the primary password is not the default password as it had already been
changed before, type the currently-used primary password).
ŸType the new primary password, selecting a combination of 5 characters from the
letters A-B-C-D.

10
HOW TO CHANGE THE SERVICE PASSWORD
ŸSelect "SERVICE PASSWORD".
ŸPress OK (F1) button.
ŸIt is required to repeat the new password, so type the previous combination again.
ŸIf the typed password is correct the “PASSWORD OK” message appears on the
display for one second, then the system switches back to the PASSWORD
MANAGEMENT section; press the EXIT button to return to the general
programming menu
ŸIf the typed password doesn't match the previous one, the PASSWORD ERROR
message appears on the display; the system will switch back to the PASSWORD
MANAGEMENT section and the user will have to repeat the procedure.
ŸType the primary password.
ŸType the new service password, selecting a combination of 5 characters from the
letters A-B-C-D.
ŸIt is required to repeat the new password, so type the previous combination again.
ŸIf the password typed is correct, “PASSWORD OK” is shown on display for one
second and the system returns to the PASSWORD MANAGEMENT section.
Press the EXIT button to return to general programming menu.
If the typed password doesn't match the previous one, the PASSWORD ERROR message appears on the display; the system will switch
back to the PASSWORD MANAGEMENT section and the user will have to repeat the procedure.

ENABLING USER PASSWORD USAGE (primary and service)
ŸSelect “PASSWORD ON / OFF”
ŸPress OK (F1) button.
ŸPress the ON button to enable the usage of user passwords and return to the PASSWORD MANAGEMENT menu.
To return to the work program view press the EXIT button twice.
ŸFrom this moment on, whenever the user wants to access to N-DSEL digital programmer to change the automatic door work program,
the primary or service password must be typed.
When the user decides to enable the password usage, it is recommended to change the combination of both primary and service
password.
DISABLING USER PASSWORD USAGE
ŸFrom the PASSWORD MANAGEMENT section, select “PASSWORD ON / OFF”
ŸPress OK (F1) button.
ŸPress the OFF button (F1) to disable user password usage.
To return to the general programming menu press the EXIT button twice
From this moment on, the access to N-DSEL digital programmer like program selector is free.
4.2.3) LANGUAGE
To select the language perform the operations listed below:
1. Press the button for 5 seconds to enter the general programming menu.
(see Diagram 1 in the previous paragraph)
2. Press the F1 three times to switch to the Language sub-menu.
3. Press the Enter button to access the “Language” section.
! Use the F2 and buttons to move arrow to the desired language.
! Press the EXIT button to return to general programming menu.
! Press the EXIT button again to return to the main view of the automatic door work
program.
11
ŸType the primary password.

5 - OPERATION IN CASE OF POWER SUPPLY FAILURE
If the battery module is installed in the operator, automatic door operation is guaranteed by an emergency battery.
Depending on the programming of the automation electronic control unit, the door may operate as follows:
a) Automatically open and stay open if the program selector is not set to Night Lock.
b) The door stays closed, but it can be opened by activating any opening command (motion radars, buttons, etc.).
ŸPOWER SUPPLY LIGHT DISPLAY ON N-DSEL PROGRAMMER
Mains power supply on and connected battery being charged.
Mains power supply off and door operating with charged battery.
ŸMains power supply off and door operating with almost exhausted battery.
ŸMains power supply on with inefficient battery.
1LOCKED 2RELEASED
Remember to turn the MANUAL RELEASE knob back to position 1 LOCKED to restore the electric
lock operation with mains power supply on.
45°
When the battery is exhausted or there is no emergency battery, door motion is free and wings may be opened manually if the EV-
EBFSE closing electric lock is not installed.
If the EV-EBFSE electric lock is installed and the door is closed wings cannot be moved manually. In this case, to unlock the door,
release the electric lock by turning the MANUAL RELEASE knob clockwise by about 45° - 50° (see fig. below, item 2 ); under these
conditions you can manually open the door.
12

Evolus Evolus
LEAVE OPENING ACHIEVED MANUALLY
BY PUSHING THE DOOR
LEAVES RETURN BEFORE DOOR CLOSURE
6 - BREAKOUT SYSTEM APPLICATION FOR ESCAPE ROUTES
SEMI-FIXED LEAF MOBILE LEAF
1 2
MOBILE LEAF
CONNECTION
13

14
7 - NOTIFICATION OF ERRORS AND OPERATION PROBLEMS
PROBLEM LIKELY CAUSE SOLUTION
The door opens but it doesn't close
back.
The motion radars or the closing safety
sensor detect the presence of an
object or of a person.
Check that the radars or the sensors
are not engaged.
The door stops during the stroke and
inverts the running direction.
The door detects an obstacle along its
stroke.
The fixture experiences friction along
its stroke.
Identify the obstacle and remove it.
Properly arrange the fixture;
for this operation please contact the
service centre.
The electronic control units beeps
multiple times and door operation is
irregular.
The defect depends on the number
and length of the beeps.
Contact the service centre to resolve
the problem.
The symbol appears on the display The system has detected a machine
operation error.
Contact the service centre to resolve
the problem.
The door opens very slowly. The opening safety sensor detects an
obstacle.
Identify the obstacle and remove it.
The door doesn't respond to the
opening commands.
The MANUAL FREE DOOR function
can be activated.
Check the setting of the program
selector.
Should any malfunction occur, the Customer must contact the Support Centre and use the door manually, without powering it.

15
8 - MAINTENANCE
9 - DISPOSAL
At the end of its life, this system must be disposed of in accordance with national provisions.
To this purpose we recommend that you contact specialised operators.
LABEL service centre
Each maintenance operation is recorded into the maintenance register.
The final user must limit himself to cleaning the glass surfaces, the fixture profiles and if necessary the motion and presence
sensors, taking care to lock the door while performing these operations.
The maintenance plan must be observed to ensure the life and safe operation of the automatic door. We recommend that you
sign a maintenance contract providing for periodic intervention on the system by specialised technicians.
If the user has the N-DSEL program selector, he will be warned that the
maintenance interval has expired when the message "PROGRAMMED
MAINTENANCE" message is shown on the display.

Via Ilariuzzi, 17/A - S. Pancrazio P.se - 43126 PARMA - ITALIA
Tel. [phone] - Fax [phone]
[email protected] - www.labelspa.com
S.p.A.
Made in Italy
by
EVOLUS
Italia
