Labom PASCAL DELTA P CI133 User manual

BTA-No. 014 Rev. 0K9
Operating instructions for differential pressure transmitter PASCAL
DELTA P, reduced volume for diaphragm seal operation, Type Series CI133.
LABOM Mess- und Regeltechnik GmbH · P.O. Box 12 62 · 27795 Hude · Germany · Im Gewerbepark 13 · 27798 Hude · Germany
Tel. [phone] · Fax [phone] · e-mail: [email protected] · www.labom.com
Further information required? Hotline [phone]

Ex approval
These operating instructions refer to installation, commissioning,
servicing and adjustment. Statutory regulations, valid standards,
additional technical details in the relevant data sheet, details of the
type plate and any additional certificates are to be observed along
with these operating instructions.
Installation, operation and maintenance of the instrument may be
executed by authorized personnel, only, using suitable
equipment.
Warning: If the instrument is used incorrectly it is possible that
serious injuries or damage can occur!
Prior to the disassembly of the pressure transmitter the impulse
ducts between the measuring transmitter and the process have to
be locked and relieved from pressure.
The standard nominal pressure rating and the permissible
operating temperature of the gasket should be observed for all
process connections. Operation outside the allowed nominal
pressure rating, especially with clamp connections, is only
possible with suitable clamps. In this case, note DIN 32676 for
stipulations on heat resistance.
Pressure transmitters that are mechanically defective can cause
injuries or give rise to process faults. Suitable precautions should
be taken to avoid this.
The CE marking on the instruments certifies compliance with valid
EU directives for bringing products to market within the European
Union. The following directives are met:
EMC directives EMC 2004/108/EG
Pressure Equipment Directive PED 97/23/EG
Ex directive ATEX 94/9/EG
Lower Voltage Directive LVD 2006/95/EG
Electrical equipment in hazardous areas should only be installed
and commissioned by competent personnel. Modifications to
devices and connections destroy the operating safety, the ex
proofing and the guarantee. The limit values detailed in the
certificate of conformity are to be observed
certificate no. TüV 99 ATEX 1414 X
ex-protection intrinsically safe II 1/2 G EEx ia/ib IIC T4/T5/T6
.
Before mounting the instrument ensure that pressure range,
overpressure resistance, media compatibility, thermostability and
pressure port are suitable for the process at hand.
Conduct process installation before electrical installation.
Measuring instruments that should not have any oil or grease
residues in the pressure port are marked „Free of oil and grease“.
Gaskets must be chosen that are suited to the process
connection and resistant to the measured medium.
Excess pressure on the minus side of the measuring system can
damage the instrument.
Check for pressure tightness when commissioning the
transmitter.
Wire up the instrument with power switched off.
The housing in protection class IP67 consists of a two chamber
system in which the measuring cell is aerated directly in relation
to the environment by means of a PTFE filter system.
The mounting position should be taken into consideration when
checking the zero output. Standard transmitters are adjusted at
the factory for vertical mounting. Changes to the mounting
position can cause zero shifts at pressure ranges < 2 bar. These
drifts can be corrected by adjustment on site.
When the instrument is opened any contact with the electrical
connections can affect the signals. This situation can be avoided
by switching off the supply voltage or by disconnecting the signal
circuit.
The types of protection IP67 are only achieved, when the
threaded ring has been screwed tight after electrical
connection/parameterization.
The instrument requires no maintenance.
The instrument can only be protected against electromagnetic
interference (EMC) if the conditions for screening, earthing, wiring
and potential isolation are met during installation.
To avoid soiling and damage remove protective cap or wrapping
in front of the separating diaphragm before mounting.
Do not touch the flush mounted separating diaphragm, as there is
a danger of deformation at measuring ranges to 10 bar / 150 psi.
Instrument zero point and measuring characteristics could also be
affected.
Measuring instrument and diaphragm seal are a closed
system and should not be separated.
Avoid overtightening the process screw joints as this can result in
zero displacements at the pressure transmitter (fixing error).
When using systems with capillary for vacuum measurements
always mount the pressure transmitter underneath the diaphragm
seal. The instruments are set at the factory with pressure
transmitter and diaphragm seal at the same height. Correct any
differences in height between diaphragm seal and pressure
transmitter arising from conditions on site on the pressure
transmitter when placing the instrument into operation (see zero
point correction). When correcting for elevation be aware of the
adjustment limits.
Be sure to install and securely fasten the capillary to avoid
vibrations. Roll up overlengths with a minimum radius of 50 cm.
Shock and changes in temperature can impact on measurements.
Process and ambient temperatures can cause zero
displacements at the pressure transmitter with some system
designs. We can supply you with an error analysis.
Should you need to adjust the zero-point on site, then undo the
front threaded ring to gain access to the controls. You will find
instructions on using the keyboard in your manual. To set the
measuring span, you should apply an accurate reference pressure.
Store and transport pressure transmitters under dry, clean condition
and, where possible, in their original packaging.
Permissible storage temperature: –25°C.....+60°C. Avoid shock
and vibrations.
Safety instructions
Mounting and operating
CE marking
Instructions for the operation with diaphragm seal
General
Transportation and storage
Zero-point correction

Techn. Data
nominal
range
measuring range measuring spans overload limits max. static excess adjustable engineering units
min. max. +side max. pressure both sides mbar bar mmHg mWC KPa psi % mA
160 mbar ¹) -160...160 mbar 16 mbar 320 mbar 2 bar -0.5...75 bar x o o o o o
1000 mbar -1000...1000 mbar 100 mbar 2 bar 6 bar -0.5...75 bar x o o o o o o
4000 mbar -1000...4000 mbar 400 mbar 5 bar 16 bar -0.5...75 bar x o o o o o o
16 bar -1...16 bar 1,6 bar 17 bar 30 bar -0.5...75 bar x o o o o o
1) with diaphragm seals -> DN 80, only xstandard (preselected) ounit adjustable
Case design
stainless steel with hardened surface,
mat.no. 1.4305
type of protection with closed case IP 67
Electrical connection
cable entry conduit thread for cable diameter
5...10 mm, terminal screw connection up to
2.5 mm²
Process connection
with capillary welded to diaphragm seal
Positioning process connection
can be mounted in any position and adjusted
to suit with:
· a housing that can be progressively
(± 170°) rotated
· adjusted indicating unit (standard orien-
tation):
6 o'clock, options: 3, 9, and 12 o'clock)
Measuring system
piezoresistive sensor element
Filling material
silicone-free synthetic oil (standard)
Window
safety glass
Weight
transmitter without process connection
approx. 1.2 kg
Operating temperature range
ambient temperature -10...+55 °C
process temperature -20...+90 °C
CIP up to 140 °C with horizontal mounted
ange, max. 1/2 h
Allowed storage temperature
-25...+60 °C
Inuence ambient temperature on trans-
mitter depending on nominal renge
temperature range +10...+30 °C
Adjustment (example)
temperature range -10...+10 °C or
+30...+55 °C
Inuence process temperature on
diaphr. seal system (one side)
DN 25 st. st 7.4 mbar/10 K
DN 32 st. st 2.1 mbar/10 K
DN 40 st. st 1.4 mbar/10 K
DN 50 st. st 0.7 mbar/10 K
DN 80 st. st 0.4 mbar/10 K
DN 80 Hastelloy C276 0.2 mbar/10 K
DN 80 Tantalum 0.2 mbar/10 K
If necessary, we can provide you with a
detailed error calculation.
Supply voltage
standard version
· function range 12...50 V DC
· max. permiss. 50 V DC
Ex-design
· permiss. voltage range
function range 12...30 V DC
max. permiss. 30 V DC
Output signal
U - 12 V
23 mA
Output function
adjustable:
· linear
· inverse
· root function
· function table 12 points
Load
R ≤(Ohm)
output signal (2-wire) 4...20 mA
lower limit 3.8 mA
upper limit 20.8 mA
malfunction lower limit < 3.6 mA
malfunction upper limit > 21 mA
Damping
digital lter (only current output)
0...30 s selectable in steps of 0.2 s
basic electrical damping 0.2 s
Measuring cycle
standard: typ. 0.8 s
Current sensing function
3.6...21.5 mA selectable in steps
of 0.01 mA
Non-conformity of a curve
with reference of nominal range
≤ 0.2 % (xed point adjustment)
≤0.1 % as option
Nominal pressure
max. 75 bar (both sides)Long-term drift
with reference to nominal range
typ. ≤ 0.1 %/year
Overload inuence
< 0,01 % of nominal range x
EMC-Test
as per directive 89/336/EW
emitted interference EN55011
noise immunity EN61000-4-2:2001-
EN61000-4-6:2001
EN61000-4-16/
NAMUR NE21:1998
nom. range ≥1000 mbar 160 mbar
lower range value ≤ 0.1 %/10 K ≤ 0.2 %/10 K
upper range value ≤ 0.1 %/10 K ≤ 0.2 %/10 K
st. pressure
bar
nom. range ≥1000 mbar 160 mbar
lower range value ≤ 0.2 %/10 K ≤ 0.4 %/10 K
upper range value ≤ 0.2 %/10 K ≤ 0.4 %/10 K
BTA-No. 014
Type plate
manufacturer
type
designation
certifcate
number
type of
ex-protection
limit values
technical
description
marking
serial
number

Dimensions and design modications
Connection diagram/connection examples
BTA-No. 014

BTA-No. 023
A
TEX certificate
Modifications reserved
