Labtech MultiVap 54 User manual

MultiVap 54
AUTOMATIC EVAPORATION SYSTEM
USER MANUAL

MultiVap 54 –User Manual
2
Thank you for selecting our MultiVap 54 system.
We are sure that you will be completely satisfied with the performance of
this new unit entering your laboratory. We invite you to read carefully this
user manual and to keep it close to the instrument for convenient and fast
consulting. For any possible clarification or any request for assistance
please contact either our local Representative or:
LabTech Srl
Via Fatebenefratelli, 1/5
24010 Sorisole (BG) Italy
Tel [phone]
Website www.labtechsrl.com
E-mail [e-mail]

MultiVap 54 –User Manual
3
INDEX
1. INTRODUCTION .............................................................4
CONDITION OF USE ............................................................................................ 4
FEATURES .......................................................................................................... 4
2. SAFETY RULES................................................................5
3. INSTALLATION...............................................................6
MULTIVAP 54 OVERVIEW ..................................................................................... 6
INSTALLATION .................................................................................................... 7
4. SOFTWARE INTERFACE ................................................12
5. ACCESSORIES ..............................................................17
6. SOLVENTS TABLE .........................................................19
7. SERVICE .......................................................................20
The information contained in this document may be the object of patent applications by LABTECH.
The possession of this document does not confer any license rights in and to such patents.
The following names are LABTECH trademarks throughout the world:
LABTECH
MultiVap 54
All Reproduction Rights Reserved

MultiVap 54 –User Manual
4
1. INTRODUCTION
The MULTIVAP 54 is an automatic multichannel and multi-functional parallel instrument
designed and processed by LabTech, including all accessories and functions to grant the
highest standard of efficiency, speed, reliability, throughput and safety for any concentration
process.
Nitrogen sweeping, needle level adjustment and visible concentration process are only few of
the advantages offered by LabTech.
Condition of use
Power: 230 VAC, 50/60 Hz, 10 A Minimum
Nitrogen requirement: Nitrogen pressure 30 psi-100 psi
Nitrogen consume: 140l/min @ 12PSI
Room temperature: 10°C-30°C (283.15 K-303.15 K)
Relative humidity: 20%-80%
Dimensions: 51cm x 51cm x 48cm
Net weight: 34 kg
Features
6 channels of 9 needles each (for a total of 54 samples) able to work either individually or
simultaneously
Automatic adjustment of nitrogen needles according to the sample volume reduction (via
software)
Visible concentration process thanks to the front window and internal lights
Auto-locked cover during operations
Easy replacement of nitrogen needles
7” touch-screen colour control panel
Intuitive control interface
Possibility to use different vials from 10 mL up to 200 mL
Nitrogen flow controlled by software
Exhaust line to remove solvent vapours
Possibility to change individual gas nozzles for consistent flow gas
Possibility to reconfigure nozzles for other racks and glassware
Stainless steel liquid bath, temperature from ambient up to 100°C (373.15 K)

MultiVap 54 –User Manual
5
2. SAFETY RULES
General Information
Please read carefully this user manual before starting the system and follow its prescriptions
with the utmost care. This user manual is part of the delivery, hence must be always kept
together with the instrument on its working place.
It is imperative that every person operating with this system has read and fully understood this
manual. The non-observance of the instructions contained herein or improper use may involve
damages/injuries that are not covered by product liability.
Electrical safety
The instrument has to be used within the rated voltage. Prior to use, please check if the wire is
aged. In case of aged wires, please contact the after-sales service for inspection. It is
forbidden to disassemble the instrument and to connect internal circuit parts, in order
to avoid a short circuit or open circuit.
Fire safety
Most reagents used in the MULTIVAP 54 are flammable and explosive. When the solvent vapor
concentration reaches a certain level, it would be flammable and could cause fire. The
instrument should be kept away from the sources of ignition and high temperature
places. If there is solvent pungent smell, carefully check whether there is gas or liquid
leakage, and turn off the power.
Chemical safety
The MULTIVAP 54 system is an instrument for organic chemical sample pretreatment. The
involved chemical solvents have harmful effects on the human health. Despite the
instrument is fully closed and features full vent design, it is recommended to pay
attention to the personal safety during the use. Regular check of liquid waste barrels
as well as working conditions of the vent fan are required to avoid the risk of leakage caused by
corrosion and to avoid the formation of organic solvent vapors affecting operators’ health. If
there is a fault, please contact the Labtech Service Team.

MultiVap 54 –User Manual
6
3. INSTALLATION
Setting up your LabTech MULTIVAP 54 is simple. Once completed the setup, take some time to
explore the features of your system. The user manual provides tips and instructions to help you
learn the basics of your MULTIVAP 54.
MultiVap 54 Overview
1
Front view: Front
Window to check the
evaporation status and
Control Panel to set, save
and load different
methods
2
Side view: Manual
Needle Level Control to
handle needles position
and Drain System to
empty water bath with
the provided kit

MultiVap 54 –User Manual
7
3
Back view: Power
Switch to switch OFF and
ON the instrument, N2
Inlet tube, Power Cord
and Exhaust solvent
vapours tube
Installation
STEP
DESCRIPTION
1
Put the instrument on thea
bench
2
Take out the white top cover

MultiVap 54 –User Manual
8
2
Fix it to the main unit body by
the 8 provided screws
3
Fix the cover handle with the
provided Allen wrench from
the internal side

MultiVap 54 –User Manual
9
4
Fix the exhaust pipe to the
exhaust port on the back side
of the instrument by the
provided metallic clamp.
Connect the other end on the
laboratory exhaust line
5
Connect the nitrogen inlet
connector to the gas source
through a 6mm gas tube
Connect the plug to the
electric socket
6
Switch ON the unit
7
Move down the needle plate
by the Manual Needle Level
Control button on the right
side of the instrument
8
Unscrew the six red head
screws and fit the two ends of
nitrogen needle channels into
each line

MultiVap 54 –User Manual
10
8
Fix the nitrogen channels by
screwing tightly the red head
screw
9
Install the nitrogen needle
channels taking care that the
arrows are directed to the red
hex head screw
10
Check that all the needles are
perfectly aligned with the
vials top mouth

MultiVap 54 –User Manual
11
11
Fill the bath (8 L volume) with
a proper liquid (to avoid
precipitation and
contamination)
WARNING: needles must be set at the up position during opening or closing of the
instrument cover to avoid needles damaging
12
Insert the rack (6x9
positions ) with the
provided vials in the liquid
bath
13
The level of the liquid bath
depends on user’s needs.
Standard procedures
suggest to immerse at
least half sample vials to
optimize the heating
function
Now your MULTIVAP 54 is ready to be used!

MultiVap 54 –User Manual
12
4. SOFTWARE INTERFACE
STEP
DESCRIPTION
1
The software is composed by two main interfaces: Main interface and
Method list interface
2
Main interface is composed of two
main parts:
•concentration method
•nitrogen channel method
3
Concentration method interface:
4
Click to open method
details
5
Sample name

MultiVap 54 –User Manual
13
6
Solvent name
7
Vials size parameters:
Diameter from 0 to 10 cm
Height from 0 to 15 cm
8
Temperature (°C) of liquid bath:
set value (red color)
present value (blue color)
not working heating function,
working heating function
9
Pressure function:
set value (red color)
present value (blue color)
The maximum pressure is 100 psi
(6.89 bar). The common application
range is about 10-20 psi (0.69
bar-1.38 bar).
The nitrogen consumption is about
24 L/min at a pressure of 12 psi
(0.85 bar)
10
Automatic control: needles
automatically move down 5 mm
every X minutes depending on set
interval time. The time value in the
blue box is the total experiment time
based on automatic control time plus
vial dimensions
11
Manual needle controller allows
the control of needles deep via the
up and down arrows button

MultiVap 54 –User Manual
14
12
Nitrogen channel method interface:
13
Activate the 6 nitrogen needle channels
according to specific needs.
There are 3 different status:
•gray = unselected
•blue = selected
•red = currently on process
If a channel is unselected, thr nitrogen
flow is automatically stopped
14
Light switch bottom:
•OFF
•ON
15
Run: the concentration method starts according the selected
parameters
Pause: the nitrogen blow function stops and nitrogen needles reset to
the initial position. The instrument can be opened and samples taken
out. Once the cover is closed, the nitrogen needles descend
automatically to the last position and the method restarts
Stop: all channels stop working and nitrogen needles reset to the initial
position. A single channel can be stopped

MultiVap 54 –User Manual
15
16
Method List Interface
This interface allows to develop, save, delete and load methods
17
Storage method list
18
create a new method
edit a selected method
delete the current method

MultiVap 54 –User Manual
16
19
Method parameters setting
Interval: period to move down the
nitrogen needles of 5mm
20
Save or load methods. Click the arrow
to go back to main
interface
The MultiVap 54 includes a low level liquid alarm to prevent the bath to be dry; when the
liquid level reaches the sensor (about half window), the instrument automatically alerts the
operator with the message below:

MultiVap 54 –User Manual
17
5. ACCESSORIES
1
N° 54 spare needles
2
N°54 disposable PP vials
3
N°54 nitrogen flow
stoppers; after the
needle removal, stoppers
have to be used to avoid
nitrogen flowing
4
Connect the white tube
to the drain connector to
flow out the liquid and
empty the bath

MultiVap 54 –User Manual
18
5
In case of needle vertical
lift blockage, switch off
the instrument and use
the provided tool to move
up and down the needles
manually.

MultiVap 54 –User Manual
19
6. SOLVENTS TABLE

MultiVap 54 –User Manual
20
7. SERVICE
