labtest SIEVE SHAKER 300MM User manual

1
Zeal international
INSTRUCTION MANUAL
INSTRUCTION MANUAL FOR SIEVE SHAKER 300/200MM
SIEVE SHAKER MOTORISED 300/200 MM
MAKE: LABTEST UK

2
1. DESCRIPTION
The unique action of this Sieve Shaker a circular motion to the material being sieved so that
it makes a slow progression over the surface of the sieve. At the same time, a rapid vertical
movement agitates the sample which assists in clearing the apertures. A time switch is
incorporated to set tests of varying duration.
Technical Specifications Table
Dimensions Length Width Height(mm)
525 x 510 x 1025
Weight
78 Kg
Capacity (200mm diameter sieve)
Up to twelve plus lid and receiver
Capacity (300mm diameter sieve)
Up to six plus lid and receiver
2. INSTALLATION
Assembly
* Screw a hexagon nut as possible onto each of the two clamping rods followed by a
plain washer.

3
* Screw the rods fully into the location plate and tighten the nuts.
* Position the shaker on a suitable level rigid and robust surface
(placing the machine on a level surface ensures even distribution of the sample over
the sieves )
3. SAFETY CAUTIONS
Whilst the test is in operation do not remover any covers or attempt to adjust any part of
the machine. Ensure all moving parts are thoroughly secured before attempting any
maintenance. Ensure all appropriate measures are taken to protect the operator from
excessive noise.
♣before removing any covers or performing maintenance repair and service, isolate
from electrical supply by removing mains plug. Where mains supply is required
during these activities, only competent persons should perform the work. Check
that the power supply is compatible with the requirements stated on the label and
connect in accordance with IEE regulations or to local requirements.
This machine may be operated through a standard 13 amp socket outlet when fitted
with an appropriate 3 pin plug fused in accordance with the label.
The Power cable is coded as follows :
Technical Specifications Table
Brown Wire
L
Live or Power
Blue Wire
N
Neutral
Green/Yellow Wire
E
Earth or Ground
♣This equipment must be correctly earthed
♣Exercise extreme caution when using the machine with wet
Hands. Before operating the machine, dry hands.
4. CONTROLS
Rear Panel
Power inlet and 5A fuse
Mains On/Off switch, machine will only run with this in the On position.

4
Photo: Sieve Shaker front Panel
Front Panel
Power warning light (green), illuminates when power is supplied to the machine.
Mains warning light (red), illuminates when main switch is on and machine is ready to run.
Timer 10-60 minutes turns clockwise to set duration of test, this also starts the machine
providing that the mains switch is ON. At the end of the set time the machine stops
automatically.
5. OPERATION
Sieve Stacking
Place the receiver centrally into the appropriate recess in the location plate. Stack the
required number of sieves on top of the receiver. Place the sample in the top sieve and fit
the lid.
Fitting the Clamp Plate
Locate the clamp plate into the two rods and slide down squarely onto the lid of the sieve
stack. Unscrew the hand wheels until there is approximately a gap of 5mm between the
lower face of the hand wheel and the washer, apply downward pressure to the clamp plate
and tighten the locking levers. The levers should be positioned pointing downwards; they
may be repositioned by pulling outwards and rotating to the correct position.
Fully tighten the hand wheels simultaneously to ensure that the clamp plate is square.
Running the test
Ensure the mains switch is on.
Start the machine by turning the timer knob clockwise to the desired duration of the test.

5
The machine may be stopped at any time during operation by turning the timer knob fully
anticlockwise to the zero position.
At the end of the test the clamp plate and sieve stack may be removed in the reverse order
to which they were assembled.
6. MAINTENANCE
The Sieve Shaker is maintenance free other than keeping it clean and free from
debris, especially with regard to the recesses in the location plate. The external surfaces
may be cleaned using a mild detergent solution; under no circumstances should solvents be
used. Periodically lightly oil the clamping mechanisms and rods.
7. CUSTOMER SUPPORT
LABTEST technical services group is available for your technical questions. The technical
service engineers are well-trained and experienced on Lab Test material testing
equipments and should be able to answer your questions.
It is recommended to reread the related test standard such as EN, ASTM etc. if your
questions are related with test procedures.
****************************
Sales Office : 1,Netaji Subhash Marg Darya Ganj,New Delhi –110 002(INDIA)
Ph: [phone] , 23244474 , 23277528 , 23278846
Fax : + 91-11-43580558 , 23273214
E-mail: [e-mail] Website: www.zealinternational.com
Zeal International
