SDC-CF22AG
Hardware Integration Guide
Version 2.0

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
2
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
REVISION HISTORY
Version
Revision
Date
Change Description
Approvers
1.0
Transitioned Application Notes documentation to Hardware
Integration Guide format.
Ron Seide
1.1
1/31/13
Updated 5 GHz Channel and Frequency data.
Ron Seide
2.0
10/24/13
Laird formatting. Removed references to summitdata.com
Ron Seide

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
3
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
CONTENTS
Revision History............................................................................................................................................ 1
Scope............................................................................................................................................................. 4
Operational Description .............................................................................................................................. 4
Block Diagram.............................................................................................................................................. 5
Specifications ............................................................................................................................................... 5
Recommended Operating Conditions .................................................................................................... 9
Pin Definitions............................................................................................................................................ 10
Mechanical Specifications ......................................................................................................................... 11
Connector Overview ................................................................................................................................ 11
RF Layout Design Guidelines..................................................................................................................... 12
Regulatory .................................................................................................................................................. 12
Antenna Specifications ............................................................................................................................. 12
Antenna Patterns ................................................................................................................................. 13
Documentation Requirements .................................................................................................................. 13
FCC ..................................................................................................................................................... 13
Industry Canada................................................................................................................................... 15
European Union................................................................................................................................... 15

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
4
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
SCOPE
This document describes key hardware aspects of the SDC-CF22AG 802.11a/g
Compact Flash Radio Card. This document is intended to assist device manufacturers
and related parties with the integration of this radio into their host devices. Data in
this document is drawn from a number of sources and includes information found in
the Broadcom BCM4318E data sheet issued in July of 2006.
The information in this document is subject to change without notice. Please contact
Laird or visit the CF22AG page of the Laird website to obtain the most recent version
of this document.
OPERATIONAL DESCRIPTION
This device is an SDC-CF22AG 802.11a/g Compact Flash card with an integrated antenna, which operates in
the 2.4 GHz and 5 GHz portions of the radio frequency spectrum. The device is compliant with IEEE 802.11a,
802.11b, and 802.11g standards using Direct Sequence Spread Spectrum and Orthogonal Frequency Division
Multiplexing. The device supports all 802.11a, 802.11b, and 802.11g data rates and automatically adjusts
data rates and operational modes based on various environmental factors.
When operating on channels in the UNII-2 and UNII-2 Extended bands that are in the 5 GHz portion of the
frequency spectrum and are subject to Dynamic Frequency Selection requirements, the SDC-CF22AG fully
conforms to applicable regulatory requirements. In the event that specified types of radar are detected by the
network infrastructure, the SDC-CF22AG fully conforms to commands from the infrastructure for radar
avoidance.
The SDC-CF22AG is compliant with Compact Flash Type 2 mechanical specifications and interfaces to host
devices via a 50-pin connector. The device is based on the Broadcom BCM4318e chip which is an integrated
device providing a Media Access Controller (MAC), a Physical Layer Controller (PHY or baseband processor)
and a 2.4 GHz transceiver. The SDC-CF22AG incorporates an external 5 GHz transceiver to allow for dual
band operation. To maximize operational range, the SDC-CF22AG incorporates 2.4 GHz and 5 GHz Power
Amplifiers to increase transmit power to as much as 19 dBm (80 mW) and a 2.4 GHz Low Noise Amplifier to
improve receiver sensitivity. The frequency stability for both 2.4 GHz (802.11b and 802.11g) and 5 GHz
(802.11a) operation is +/- 20 ppm.
The SDC-CF22AG is powered by the host device into which it is installed and uses a DC to DC regulator. The
SDC-CF22AG incorporates four separate antenna “chip” elements to provide an omnidirectional coverage
pattern and to support dual band transmit and receive diversity. Typical host devices include: (1) Portable Data
Terminals (PDTs) and (2) Vehicle Mounted Terminals (VMTs).
The device is labeled with all applicable regulatory information in a manner that’s compliant with all regulatory
standards. Regulatory operational requirements are included with this document and may be incorporated
into the operating manual of any device into which the SDC-CF22AG is installed. The SDC-22AG is designed
for installation into mobile devices such as vehicle mount data terminals which typically operate at distances
greater than 20 cm from the human body and portable devices such as handheld data terminals which
typically operate at distances less than 20 cm from the human body. See “Documentation Requirements” for
more information.

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
5
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
BLOCK DIAGRAM
SPECIFICATIONS
Feature
Description
System Interface
16-bit Compact Flash Type 2 with 50-pin connector
Antenna
Omnidirectional dual band diversity
Chip Set
Broadcom BCM4318E
Input Voltage Requirements
3.3 VDC +/- 10%
Current Consumption
(At maximum transmit power setting)
Transmit: 440mA (1320mW)
Receive: 180mA (594mW)
Standby: 10mA (33mW)
Operating Temperature
-30° to 85°C (-22° to 185°F)
Operating Humidity
10 to 90% (non-condensing)
Storage Temperature
-40° to 80°C (-40° to 176°F)
Storage Humidity
10 to 90% (non-condensing)

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
6
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Maximum Electrostatic Discharge
4 kV
Length
67 mm (2.64 in.)
Width
43 mm (1.69 in.)
Card Thickness
5 mm (0.2 in.)
Antenna Thickness
8 mm (0.31 in.)
Weight
28 g (1.0 oz.)
Mounting
50-pin connector and standard compact flash rails
Wireless Media
Direct Sequence-Spread Spectrum (DSSS)
Orthogonal Frequency Divisional Multiplexing (OFDM)
Media Access Protocol
Carrier sense multiple access with collision avoidance
(CSMA/CA)
Network Architecture Types
Infrastructure and ad hoc
Network Standards
IEEE 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h,
802.11i
Data Rates Supported
802.11a (OFDM) 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b (DSSS) 1, 2, 5.5, 11 Mbps
802.11g (OFDM) 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation
BPSK @ 1, 6, and 9 Mbps
QPSK @ 2, 12, and 18 Mbps
CCK @ 5.5 and 11 Mbps
16-QAM @ 24 and 36 Mbps
64-QAM @ 48 and 54 Mbps
Regulatory Domain Support
FCC (Americas, Parts of Asia, and Middle East)
ETSI (Europe, Middle East, Africa, and Parts of Asia)
MIC (formerly TELEC) (Japan)
KCC (Korea)
2.4 GHz Frequency Bands
ETSI
2.4 GHz to 2.483 GHz
FCC
2.4 GHz to 2.473 GHz
MIC
2.4 GHz to 2.495 GHz
KCC
2.4 GHz to 2.483 GHz
5 GHz Frequency Bands
ETSI
5.15 GHz to 5.35 GHz
5.47 GHz to 5.725 GHz
FCC
5.15 GHz to 5.35 GHz
5.47 GHz to 5.725 GHz
5.725 GHz to 5.82 GHz
MIC
5.15 GHz to 5.35 GHz
KCC
5.15 GHz to 5.35 GHz
5.725 GHz to 5.82 GHz
2.4 GHz Operating Channels
ETSI: 13 (3 non-overlapping)
FCC: 11 (3 non-overlapping)
MIC: 14 (4 non-overlapping)

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
7
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
KCC: 13 (3 non-overlapping)
5 GHz Operating Channels
ETSI: 19 non-overlapping
FCC: 23 non-overlapping
MIC: 8 non-overlapping
KCC: 12 non-overlapping
Transmit Power Settings
Note: Maximum transmit power varies
according to individual country
regulations. All values nominal, +/-2 dBm
802.11a
15 dBm (30 mW)
10 dBm (10 mW)
0 dBm (1 mW)
802.11b
18 dBm (63 mW)
17 dBm (50 mW)
15 dBm (30 mW)
10 dBm (10 mW)
0 dBm (1 mW)
802.11g
15 dBm (30 mW)
10 dBm (10 mW)
0 dBm (1 mW)
Typical Receiver Sensitivity
802.11a:
6 Mbps
-85 dBm
9 Mbps
-84 dBm
12 Mbps
-83 dBm
18 Mbps
-80 dBm
24 Mbps
-76 dBm
36 Mbps
-73 dBm
48 Mbps
-70 dBm
54 Mbps
-65 dBm (PER <= 10%)
802.11b:
1 Mbps
-97 dBm
2 Mbps
-97 dBm
5.5 Mbps
-93 dBm
11 Mbps
-90 dBm (PER <= 10%)
802.11g:
6 Mbps
-94 dBm
9 Mbps
-91 dBm
12 Mbps
-89 dBm
18 Mbps
-88 dBm
24 Mbps
-83 dBm
36 Mbps
-78 dBm
48 Mbps
-76 dBm
54 Mbps
-75 dBm (PER <= 10%)
Delay Spread
600 ns @ 1 Mbps
500 ns @ 2 Mbps
400 ns @ 5.5 Mbps
400 ns @ 6 Mbps
400 ns @ 9 Mbps
200 ns @ 11 Mbps
350 ns @ 12 Mbps
350 ns @ 18 Mbps
250 ns @ 24 Mbps
250 ns @ 36 Mbps

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
8
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
150 ns @ 48 Mbps
150 ns @ 54 Mbps
Operating Systems Supported
Windows Mobile 6.1
Windows Mobile 6.0
Windows Mobile 5.0
Pocket PC 2003
Windows Embedded CE 6.0 R3
Windows Embedded CE 6.0 R2
Windows Embedded CE 6.0
Windows Embedded CE 5.0
Windows Embedded CE 4.2
Windows XP Professional and Embedded
Security
Standards
Wireless Equivalent Privacy (WEP)
Wi-Fi Protected Access (WPA)
IEEE 802.11i (WPA2)
Encryption
Wireless Equivalent Privacy (WEP, RC4 Algorithm)
Temporal Key Integrity Protocol (TKIP, RC4 Algorithm)
Advanced Encryption Standard (AES, Rijndael Algorithm)
Encryption Key Provisioning
Static (40-bit and 128-bit lengths)
Pre-Shared (PSK)
Dynamic
802.1X Extensible Authentication Protocol Types
EAP-FAST
EAP-TLS
PEAP-GTC
PEAP-MSCHAPv2
PEAP-TLS
LEAP
Compliance
Note: All ETSI, FCC, Industry Canada, and
MIC (formerly TELEC) certifications for
the SDC-CF10G are applicable to the
SDC-CF20G.
ETSI Regulatory Domain
EN 300 328
EN 301 489
EN 301 893
EN 62311
EN 60950-1
EU 2002/95/EC (RoHS)
FCC Regulatory Domain
Part 15.247 Subpart C
Grant
Test Report
Part 15.407 Subpart E
Grant
Test Report
Industry Canada

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
9
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
RSS-210
RSS-Gen Issue 2
MIC Regulatory Domain
Article 2 Item 19, Category WW (2.4GHz Channels 1-13)
Article 2 Item 19-2, Category GZ (2.4GHz Channel 14)
Certifications
Wi-Fi Alliance
802.11a, 802.11b, 802.11g
WPA Enterprise
WPA2 Enterprise
Cisco Compatible Extensions (Version 4)
Warranty
Limited Lifetime
All specifications are subject to change without notice
Recommended Operating Conditions
Parameter
Min.
Typical
Max.
Units
Comments
Supply Voltage
VDDIO, VDDBUS
VDDCORE, PLLVDD, AVDD
3.0
1.71
3.3
1.8
3.6
1.89
V
V
Logic Inputs
VINH, Input High Voltage
VINL, Input Low Voltage
2.0
–
–
–
–
0.8
V
V
Logic Outputs
VOH, Output High Voltage
VOL, Output Low Voltage
2.4
–
–
–
–
0.4
V
V
Current is determined
by the specific pad.

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
10
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
PIN DEFINITIONS
Pin #
Pin Name
I/O
Power Type
Description
1
GND
Ground
2
Slot0_data3
Data bus, bit 3
3
Slot0_data4
Data bus, bit 4
4
Slot0_data5
Data bus, bit 5
5
Slot0_data6
Data bus, bit 6
6
Slot0_data7
Data bus, bit 7
7
Slot0_nCE1
Enable for even-numbered address bytes. Active low.
8
Slot0_addr10
Address bus, bit 10
9
Slot0_nOE
Memory access output enable. Active low.
10
Slot0_addr9
Address bus, bit 9
11
Slot0_addr8
Address bus, bit 8
12
Slot0_addr7
Address bus, bit 7
13
VCC3_3
3.3V Module Power
14
Slot0_addr6
Address bus, bit 6
15
Slot0_addr5
Address bus, bit 5
16
Slot0_addr4
Address bus, bit 4
17
Slot0_addr3
Address bus, bit 3
18
Slot0_addr2
Address bus, bit 2
19
Slot0_addr1
Address bus, bit 1
20
Slot0_addr0
Address bus, bit 0
21
Slot0_data0
Data bus, bit 0
22
Slot0_data1
Data bus, bit 1
23
Rfu_data2
Data bus, bit 2
24
Slot0_nIOIS16
Current access is 16 bit. Active low.
25
Slot0_nCD2
Card detect. Tied to ground in module.
26
N/C
No Connect
27
Slot0_data11
Data bus, bit 11
28
Slot0_data12
Data bus, bit 12
29
Slot0_data13
Data bus, bit 13
30
Rfu_data14
Data bus, bit 14
31
Slot0_data15
Data bus, bit 15
32
Slot0_nCE1
Enable for even-numbered address bytes. Active low.
33
GND
Ground
34
Slot0_nIOR
IO access read enable. Active low.
35
Slot0_nIOW
IO access write enable. Active low.
36
Slot0_nWE
Memory access write enable. Active low.
37
Slot0_nIREQ
Interrupt request. Active low.
38
VCC3_3
3.3V Module Power

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
11
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Pin #
Pin Name
I/O
Power Type
Description
39
BT_ACTIVE
Input from BT device.
When high, indicates that Bluetooth is transmitting
or receiving. The Summit radio does not transmit when
BT_ACTIVE is high.
Tie to GND when not used
40
Slot0_nVS2
Not Used. Leave Open (Float)
41
Slot0_RESET
Card reset. Active high.
42
Slot0_nWAIT
Current access is extended.
Active low.
43
INPACK
This signal must be inactive until the card is configured.
44
Slot0_nREG
Current access is to attribute memory. Active low.
45
WLAN_ACTIVE
Output to BT device. When high, indicates that WLAN is
transmitting or receiving.
Do not connect when not used
46
Slot0_nSTSCHG
Module status change. Active low.
47
Slot0_data8
Data bus, bit 8
48
Slot0_data9
Data bus, bit 9
49
Slot0_data10
Data bus, bit 10
50
GND
Ground
MECHANICAL SPECIFICATIONS
Connector Overview
CF22AG connector: 50-pin connector

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
12
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
RF LAYOUT DESIGN GUIDELINES
The following is a list of RF layout design guidelines and recommendation when installing a Summit radio into
your device.
Do not run antenna cables directly above or directly below the radio.
Do not place any parts or run any high speed digital lines below the radio.
If there are other radios or transmitters located on the device (such as a Bluetooth radio), place the
devices as far apart from each other as possible.
Ensure that there is the maximum allowable spacing separating the antenna connectors on the Summit
radio from the antenna. In addition, do not place antennas directly above or directly below the radio.
Summit recommends the use of a double shielded cable for the connection between the radio and the
antenna elements.
Summit has provided three plated mounting holes that can be used for grounding. When additional
ground plane is required, you may use some or all of these grounded mounting holes.
REGULATORY
Antenna Specifications
The SDC-CF22AG incorporates an integrated dual band antenna that supports transmit and receive diversity:
Type: Dipole
Maximum 2.4 GHz Gain: 0 dBi
Maximum 5 GHz Gain: 0 dBi

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
13
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Antenna Patterns
Documentation Requirements
In order to maintain regulatory compliance, when integrating the SDC-CF22AG into a host device and
leveraging Summit’s grants and certifications, it is necessary to meet the documentation requirements set
forth by the applicable regulatory agencies. The following sections (FCC, Industry Canada, and European
Union) outline the information that must be included in the user’s guide for the host devices into which the
SDC-CF22AG is integrated.
FCC
User’s Guide Requirements
As outlined in the Operational Description, the SDC-CF22AG complies with FCC Part 15 Rules for a
Limited Modular Approval. To leverage Summit’s grant, the two conditions below must be met for the
host device into which the SDC-CF22AG is integrated:
1. The antenna is installed with 20 cm maintained between the antenna and users.

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
14
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
2. The transmitter module is not co-located with any other transmitter or antenna that is capable of
simultaneous operation.
As long as the two conditions above are met, further transmitter testing is typically not required. However,
the OEM integrator is still responsible for testing its end-product for any additional compliance
requirements required with this module installed, such as (but not limited to) digital device emissions and
PC peripheral requirements.
IMPORTANT!
In the event that the two conditions above cannot be met (for example certain
device configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID cannot be used on the
final product. In these circumstances, the OEM integrator will be responsible for
re-evaluating the end product (including the transmitter) and obtaining a separate
FCC authorization.
When using Summit’s FCC grant for the SDC-CF22AG, the integrator must include specific information in the
user’s guide for the device into which the SDC-CF22AG is integrated. The integrator must not provide
information to the end user regarding how to install or remove this RF module in the user’s manual of the
device into which the SDC-CF22AG is integrated. The following FCC statements must be added in their
entirety and without modification into a prominent place in the user’s guide for the device into which the
SDC-CF22AG is integrated:
“IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must
not be co-located or operating in conjunction with any other antenna or transmitter.”
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
15
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
IMPORTANT NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
Industry Canada
User’s Guide Requirements
As outlined in the Operational Description, the SDC-CF22AG complies with Industry Canada (IC) rules for
a Limited Modular Approval. To leverage Summit’s grant, the two conditions below must be met for the
host device into which the SDC-CF22AG is integrated:
1. The antenna is installed with 20 cm maintained between the antenna and users.
2. The transmitter module is not co-located with any other transmitter or antenna that is capable of
simultaneous operation.
As long as the two conditions above are met, further transmitter testing is typically not required. However,
the OEM integrator is still responsible for testing its end-product for any additional compliance
requirements required with this module installed, such as (but not limited to) digital device emissions and
PC peripheral requirements.
IMPORTANT!
In the event that the two conditions above cannot be met (for example certain
device configurations or co-location with another transmitter), then the IC
authorization is no longer considered valid and the IC ID cannot be used on the
final product. In these circumstances, the OEM integrator will be responsible for
re-evaluating the end product (including the transmitter) and obtaining a separate
IC authorization.
When using Summit’s IC grant for the SDC-CF22AG, the integrator must include specific information in the
user’s guide for the device into which the SDC-CF22AG is integrated. The integrator must not provide
information to the end user regarding how to install or remove this RF module in the user’s manual of the
device into which the SDC-CF22AG is integrated. . In addition to the required FCC statements outlined above,
the following IC statements must be added in their entirety and without modification into a prominent place
in the user’s guide for the device into which the SDC-CF22AG is integrated:
To prevent radio interference to the licensed service, this device is intended to be operated indoors and
away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed
outdoors is subject to licensing.
European Union
User’s Guide Requirements
The integrator must include specific information in the user’s guide for the device into which the SDC-CF22AG
is integrated. In addition to the required FCC and IC statements outlined above, the following R&TTE
statements must be added in their entirety and without modification into a prominent place in the user’s
guide for the device into which the SDC-CF22AG is integrated:
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test
methods have been applied in order to prove presumption of conformity with the essential requirements
of the R&TTE Directive 1999/5/EC:
EN60950-1:2001 A11:2004

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
16
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Safety of Information Technology Equipment
EN 300 328 V1.7.1: (2006-10)
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband Transmission systems;
Data transmission equipment operating in the 2,4 GHz ISM band and using spread spectrum
modulation techniques; Harmonized EN covering essential requirements under article 3.2 of the
R&TTE Directive
EN 301 489-1 V1.6.1: (2005-09)
Electromagnetic compatibility and Radio Spectrum Matters (ERM); ElectroMagnetic Compatibility
(EMC) standard for radio equipment and services; Part 1: Common technical requirements
EN 301 489-17 V1.2.1 (2002-08)
Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility
(EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband
transmission systems and 5 GHz high performance RLAN equipment
EN 301 893
Electromagnetic compatibility and Radio spectrum Matters (ERM); Broadband Radio Access Networks
(BRAN); Specific conditions for 5 GHz high performance RLAN equipment
EU 2002/95/EC (RoHS)
Declaration of Compliance –EU Directive 2003/95/EC; Reduction of Hazardous Substances (RoHS)
This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all EU member states
and EFTA countries, except in France and Italy where restrictive use applies.
In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain
authorization to use the device for setting up outdoor radio links and/or for supplying public access to
telecommunications and/or network services.
This device may not be used for setting up outdoor radio links in France and in some areas the RF output
power may be limited to 10 mW EIRP in the frequency range of 2454 –2483.5 MHz. For detailed
information the end-user should contact the national spectrum authority in France.
Česky
[Czech]
[Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se
základními požadavky a dalšími příslušnými ustanoveními směrnice
1999/5/ES.
Dansk
[Danish]
Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr
[udstyrets typebetegnelse] overholder de væsentlige krav og øvrige relevante
krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
17
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Eesti
[Estonian]
Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme
tüüp = type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja
nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
English
Hereby, [name of manufacturer], declares that this [type of equipment] is in
compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [nombre del fabricante] declara que el [clase de
equipo] cumple con los requisitos esenciales y cualesquiera otras
disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of
equipment] ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ
ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est
conforme aux exigences essentielles et aux autres dispositions pertinentes de
la directive 1999/5/CE.
Italiano
[Italian]
Con la presente [nome del costruttore] dichiara che questo [tipo di
apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of
equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka
esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in
overeenstemming is met de essentiële eisen en de andere relevante
bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott]
jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li
hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z
zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami
Dyrektywy 1999/5/EC.
Português
[Portuguese]
[Nome do fabricante] declara que este [tipo de equipamento] está conforme
com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami
in ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky
a všetky príslušné ustanovenia Smernice 1999/5/ES.

SDC-CF22AG
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/bluetooth
18
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
[Slovak]
Suomi
[Finnish]
[Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen
tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten
ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som
framgår av direktiv 1999/5/EG.
