Lamona LAM8900 User manual

User Instructions
LAM8900
www.howdens.com/appliance-registration
Built-in Washer Dryer
ISSUE v1.2 071223

2www.howdens.com

3
Exclusive to Howdens
Dear Customer
Congratulations on your choice of energy efficient washer dryer.
•This washer dryer complies with all current local and national safety
requirements. However, inappropriate use could lead to personal injury and
damage to property.
•Please read the operating instructions carefully before using the washer dryer.
They contain important information on safety, use and maintenance. This
prevents both personal injury and damage to the washer dryer.
•It is important that the Installation Instructions supplied with this machine are
followed carefully.
•Please keep these instructions in a safe place for your future reference.
This appliance is intended to be used in household and similar domestic
applications, see guarantee page for definition of domestic use*.
Welcome
If during initial use the machine does not fill / empty,
a symbol on the display flashes, codes , , ,
are displayed, then please check that the hoses have
not been kinked during installation.
Warning for Serious injury
or death risk.
Warning for injury or
property damage risk.
Warning for
electric shock.
Warning for
risk of fire / flammable
materials.
Throughout this manual the
following symbols are used.
DO NOT KINK HOSES
BEHIND MACHINE!
Machine will not work properly.

4www.howdens.com
Register my washer dryer........................p.2
Welcome .........................................p.3
Warning and safety information
Correct application............................p.6
Safety with children ...........................p.6
Technical safety ...............................p.6
Correct use ....................................p.7
Dryer - risk of fire ..............................p.8
Using the dryer ................................p.8
Caring for the environment
Disposal of packing material ..................p.9
Disposing of your old appliance ...............p.9
Operating the washer dryer
Washer dryer overview........................p.9
Control panel ..................................p.10
Before using the washer dryer for the first time
Running the first programme..................p.11
Opening the door at the end of the
programme....................................p.11
Washing environmentally and economically
Energy and water saving......................p.12
Choosing the correct function
(Pre-wash and Quicker Wash) ..............p.12
Detergent......................................p.12
1 - Prepare the laundry
Sort the laundry ...............................p.13
Pre-treating stains.............................p.13
General tips....................................p.13
2 - Load the washer dryer
Open the door .................................p.14
Close the door .................................p.14
3 - Select a programme
Programme selection .........................p.15
Selecting temperature and spin speed........p.15
Selecting auxiliary functions ..................p.15
Programme duration ..........................p.15
4 - Add detergent
Detergent dispenser drawer ..................p.16
Choosing detergent type ......................p.16
Adding liquid fabric softener ..................p.17
Tips on detergent usage ......................p.17
5 - Start the programme
Starting a programme.........................p.18
Adding laundry during a programme .........p.18
6 - End of programme
Open the door and removing the laundry .....p.18
Contents
Spinning
Final spin speeds - washing/drying. . . . . . . . . . . .p.19
Selecting rinse hold (final spin)................p.19
Delayed time adjustment
Selecting a delayed start......................p.19
Starting the Ending In timer ...................p.19
Changing or cancelling the delayed time .....p.19
Washing programmes
Cottons ........................................p.20
Eco 40-60 .....................................p.20
Eco 40-60 + Cupboard Dry ....................p.20
Synthetics .....................................p.20
Quick / Rapid 30° ..............................p.20
Hand Wash / Woollens ........................p.21
Quick / Rapid 30° + Quicker Wash .............p.21
Down Wear ....................................p.21
Delicates ......................................p.21
Cotton 20°C ...................................p.21
Special programmes
Spin & Drain ...................................p.21
Rinse ..........................................p.21
Drying programmes
Cotton Dry .....................................p.22
Synthetic Dry ..................................p.22
Anti allergy wash & dry........................p.22
5 kg wash & dry ...............................p.22
Mini wash & dry (0.5 kg) (1 kg) ................p.22
Auxiliary functions
Prewash .......................................p.23
Quicker Wash..................................p.23
Drying .........................................p.23
Ending in ......................................p.23
Steam .........................................p.23
AntiCrease.....................................p.24
Machine clean.................................p.24
Child lock ......................................p.24
Drying steps ...................................p.25
Auxiliary functions available
Wash programmes ............................p.25
Drying programmes ...........................p.26
Changing the programme
Changing an auxiliary function................p.26
Cancelling/changing a programme ...........p.26
Programme and consumption tables
For washing ...................................p.27
For Drying .....................................p.27

5
Exclusive to Howdens
Contents (continued)
Garment care labels ........................... p.28
Detergent and additives
The correct detergent .........................p.29
Dispensing aids ...............................p.29
Refill packs of detergent.......................p.29
Fabric conditioner and liquid starch...........p.29
Limescale prevention..........................p.29
Colour run and dye removers/dyes............p.29
Water softeners ...............................p.29
Using fabric conditioner or starch separately.p.29
Cleaning and care
Cleaning the external casing and
control panel ..................................p.30
Cleaning the detergent dispenser drawer.....p.30
Cleaning the siphon and
the compartment channels ...................p.31
Cleaning the detergent dispenser drawer
compartment ....................................p.31
Cleaning the water intake filters ...............p.32
Cleaning the filter in the inlet valve ............p.32
Cleaning the filter in the inlet hose.............p.32
Problem solving
Draining remaining water and
cleaning the pump filter .........................p.33
Open the door in case of power failure ........p.33
Problem solving ...............................p.34
Consumption data ............................. p.38
Technical specifications ....................... p.39
Information ....................................p.39
Error codes .................................... p.40
Guarantee ..................................... p.42

6www.howdens.com
Please read these instructions. The manufacturer is
not responsible if an incorrect installation and use
causes injuries and/or damage. Always keep the
instructions with the washer dryer for future reference.
Please take appropriate care when installing,
maintaining, cleaning and operating the washer dryer.
Correct application
•This appliance is intended to be used in household
and similar applications such as:
– staff kitchen areas in shops, offices and other
working environments;
– farm houses;
– by clients in hotels, motels and other residential
type environments;
– bed and breakfast type environments .
•The washer dryer is not intended for outdoor use or
commercial use.
•It must be used only as a domestic appliance
to wash items which are specified by the
manufacturer as being washable on the wash care
label. The manufacturer cannot be held liable for
damage resulting from incorrect or improper use or
operation.
•The washer dryer may be used by people with
reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, if they are
supervised whilst using it or have been shown how
to use it safely and recognise and understand the
consequences of incorrect operation.
Safety with children
•Children under 3 years of age must be kept away
from the washer dryer unless they are constantly
supervised.
•Children 8 years and older may only use the washer
dryer unsupervised if they have been shown how
to use it safely and recognise and understand the
consequences of incorrect operation.
•Children must not be allowed to clean or maintain
the washer dryer unsupervised.
•Please supervise children in the vicinity of the
washer dryer and do not let them play with it.
Technical safety
•Please observe the instructions in the “Installation
Manual” and “Technical data”.
•Before setting up the washer dryer, check it for any
externally visible damage. Do not install or use a
damaged machine.
•Before connecting the washer dryer, ensure that
the connection data on the data plate (fuse
rating, voltage and frequency) match the mains
electricity supply. If in any doubt, consult a qualified
electrician.
•Reliable and safe operation of this washer dryer
can only be assured if it has been connected to the
mains electricity supply.
•The electrical safety of this washer dryer can
only be guaranteed when correctly earthed. It is
essential that this standard safety requirement
is met. If in any doubt, please have the wiring
system of the building tested by a qualified
electrician. LAMONA cannot be held liable for the
consequences of an inadequate earthing system
(e.g. electric shock).
•Do not connect the washer dryer to the mains
electricity supply by a multi-socket adapter,
extension lead or similar. These do not guarantee
the required safety of the machine (fire hazard due
to the risk of overheating).
•Faulty components must only be replaced by
genuine LAMONA original spare parts. Only when
these parts are fitted can LAMONA guarantee the
safety standards of the machine.
•The electrical socket must be easily accessible
after installation so that the machine can be
disconnected from the electricity supply if
necessary.
•Unauthorised repairs could result in unforeseen
dangers for the user, for which the manufacturer
cannot accept liability. Repairs should only be
undertaken by a LAMONA Service Engineer,
otherwise any subsequent damage will not be
covered by the warranty.
Warning and safety information

7
Exclusive to Howdens
•If the electrical connection cable is faulty it must
only be replaced by a LAMONA Service Engineer to
protect the user from danger.
•The machine must be isolated from the electricity
supply when cleaning and maintaining the machine
and in the event of a fault.
•The machine must only be connected to the on-site
water supply using a new hose kit. Old hose kits
must not be re-used. Check the condition of the
hoses regularly so that you can replace them in
good time and avoid the risk of any water damage.
•The water pressure required is 0.3 –10 bar (0.03-
1.0 Mpa). It is necessary to have a cold water flow
of between 10-80lpm for the appliance to operate
efficiently.
•In areas which may be subject to infestation by
cockroaches or other vermin, pay particular
attention to keeping the machine and its
surroundings in a clean condition at all times. Any
damage which may be caused by cockroaches or
other vermin will not be covered by the warranty.
•The machine must not be used in a non-stationary
location (e.g. on a ship)..
Correct use
•Do not install the washer dryer in a room where
there is a risk of frost. Frozen hoses may burst or
split. The reliability of the electronic control unit may
be impaired at temperatures below freezing point.
•Before using the machine for the first time, check
that the transit bolts at the rear of the machine have
been removed (see “Installation Manual - Removing
the transit bolts”). During spinning, a transit bar
which is still in place may result in damage to both
the machine and adjacent furniture or appliances.
•Turn off the stopcock if the machine is to be left for
any length of time (e.g. holiday), especially if there is
no floor drain (gully) in the immediate vicinity.
•Flooding danger.
Make sure the drain hose is secure, so that the
force of the water flowing out of the hose does not
dislodge it.
•Take care to ensure that foreign objects (e.g. nails,
pins, coins, paper clips) do not find their way into
the machine with the laundry. These may damage
components of the machine, it’s surroundings and
the laundry.
•Observe maximum load limits for laundry. See the
Programme chart for the maximum recommended
loads for individual programmes.
•Machine cleaning and descale treatments must
follow the manufacturer’s instructions. LAMONA
cannot be held responsible for any damage
resulting from these treatments.
•Textiles which have been pre-treated in solvent
based cleaning agents must be thoroughly rinsed in
clean water before being washed in the machine.
•Do not use solvent based cleaning agents, e.g.
those containing benzine, in or on this machine, as
this may result in damage to component parts and
create toxic fumes. Such agents also pose a fire and
explosion hazard.
•Only use dyes specified by the manufacturer as
being suitable for use in a domestic washer dryer.
Always observe the manufacturer’s instructions
carefully.
•Colour run and dye removers contain sulphur
compounds which can cause damage such
as corrosion. Do not use these products in this
machine.
•If detergent comes into contact with the eyes, rinse
them thoroughly with lukewarm water immediately.
If swallowed, seek medical assistance immediately
and retain the packaging or label for reference.
Those with skin problems or sensitive skin should
avoid their skin coming into contact with detergent.
Warning and safety information (continued)

8www.howdens.com
Dryer - risk of fire
•Laundry that has previously been washed,
cleaned, soiled or stained with petrol/gas, dry
cleaning solvents or other inflammable/combustive
substances must not be dried in the machine since
they emit inflammable/combustive vapour.
•Laundry soiled with vegetable oil, alcohol, petrol, gas
oil, stain remover, turpentine, wax or wax remover
must be washed with hot water and detergent
before drying.
•Rubber (latex) foam, shower caps, waterproof
fabrics, clothes and rubber-reinforced/rubber-foam
pillows must not be dried with the drying function.
•If you use laundry balls, measuring scoops or
cages in your machine; these might melt during the
drying process. If you are going to select the drying
function, do not use these products.
•If you are using industrial chemicals for cleaning, do
not use the drying function.
Using the dryer
•Do not touch the glass of the door with bare hands
after drying. There is the risk of burning.
•There is a final step, which is cooling, to keep the
laundry at a certain temperature to ensure that it is
not damaged. You may be exposed to hot steam if
you open the door before cooling is complete. There
is the risk of scalding.
•If the drying programmes are interrupted (due
to programme cancellation or power failure), the
laundry in the machine might be hot. Be careful.
•Do not stop the machine before the drying
programme is completed. If you have to do so,
remove all laundry, place it in an appropriate place
and wait for it to cool down.
•Your product is designed to work at temperatures
between 5 - 35°C.
•Do not let pets enter the product. Check inside of the
product before using it.
•Do not overload the machine to dry laundry.
Observe the maximum load levels stated for drying
•Do not use the machine to dry leather clothes or
clothes that contain leather (such as leather labels
on jeans). The colour of the leather parts might
affect other fabrics.
•If there is a problem you cannot solve by reading
these instructions; switch off and unplug the
machine and call the Authorised Service Agent.
•You can use your washer-dryer to only wash, only
dry or both wash and dry laundry. The machine
must not be used to dry wet laundry only for long
periods of time. When using the machine only for
drying purposes, run a washing programme with
the machine unloaded after every 15 drying cycles.
•Before loading the machine, check each laundry
item and make sure that there are no lighters, coins,
metal objects, needles etc. inside them or in their
pockets.
•Underwear with metal supports must not be dried
loose in the machine. Metal supports might come
off during the drying process and damage the
machine. Place them in a bag or a pillowcase.
•Do not use the machine to dry large laundry such
as tulle, curtains, heavy blankets or rugs. Your
laundry may be damaged
•Do not dry unwashed laundry in the machine.
•Do not use softeners or antistatic agents unless
recommended by the manufacturer.
•Products such as softeners must be used in
accordance with the manufacturer’s instructions.
•Do not use the machine to dry silk, wool and similar
delicate clothes. Clothes may be damaged or shrink.
•Check the symbols on the label of the clothes before
washing and drying.
LAMONA cannot be held liable for damage caused
by non-compliance with these Warning and Safety
instructions.
Warning and safety information (continued)

9
Exclusive to Howdens
Control panel Water
inlet
Power
cable
Transit
bolts x 4
Drain hose
Adjustable
foot
Filter Rear adjustable
foot - RH
Adjustable
foot
Detergent
drawer
Door
Rear adjustable
foot - LH
The packaging is designed to protect the appliance
from damage during transportation. The packaging
materials should be recycled.
Recycling the packaging reduces the use of raw
materials in the manufacturing process and also
reduces the amount of waste in landfill sites.
Caring for the environment
Disposal of the packing material Disposing of your old appliance
Electrical and electronic appliances often
contain valuable materials. They also
contain specific materials, compounds and
components, which are essential for their
correct function and safety. These could
be hazardous to human health and to the
environment if disposed of with your domestic waste or
if handled incorrectly. Please do not, therefore, dispose
of your old appliance with your household waste.
Please dispose of it at your local community waste
collection / recycling centre for electrical and electronic
appliances, or contact your dealer for advice.
Operating the washer dryer
Washer dryer overview

10 www.howdens.com
1. Programme selection knob
(Uppermost position OFF)
2. Display
3. Start/Pause button
11. Temperature indicators
12. Spin speed indicators
13. Duration information
14. Door lock symbol
15. Programme follow-up indicators;
In progress, (flashes when in pause)
Wash
Spin
Drying
AntiCrease+
Delicates
Hand Wash / Woollens
Quick
Rapid 30°
Synthetics
CottonsOFF
Cottons 20°C
Cotton Dry
Synthetic Dry
Anti Allergy
Wash & Dry
5Kg Wash & Dry
Mini Wash & Dry
Down Wear
Rinse
Spin & Drain
Machine
Clean 3” 3”
Eco 40-60
Quicker
Wash
Prewash Drying Ending In Steam
Spin
Speed
Temp.
AntiCrease
+3”
1200
800
600
140090°
60°
40°
30°
20°
1200
800
600
140090°
60°
40°
30°
20°
21
36 47 5910 8
4. Steam option button
5. End time adjustment button
6. Drying level adjustment button
7. Quicker wash option button
16. No water indicator
17. Add laundry indicator
18. Steam
19. Delayed Start enabled indicator
20. Drying level indicators;
Timed drying
Extra dry
Cupboard dry
Iron dry
21. Child lock symbol
22. Quicker wash
23 Machine clean
Prewash
24. No spin indicator
25. Rinse hold indicator
26. Cold water indicator
Delicates
Hand Wash / Woollens
Quick
Rapid 30°
Synthetics
CottonsOFF
Cottons 20°C
Cotton Dry
Synthetic Dry
Anti Allergy
Wash & Dry
5Kg Wash & Dry
Mini Wash & Dry
Down Wear
Rinse
Spin & Drain
Machine
Clean 3” 3”
Eco 40-60
Quicker
Wash
Prewash Drying Ending In Steam
Spin
Speed
Temp.
AntiCrease
+3”
1200
800
600
140090°
60°
40°
30°
20°
1200
800
600
140090°
60°
40°
30°
20°
11 12 13 14 15
16
17
18
21 19 22 20
242526 23
8. Prewash option button
9. Spin speed adjustment button
10. Temperature adjustment button
Control panel
Operating the washer dryer (continued)

11
Exclusive to Howdens
Delicates
Hand Wash / Woollens
Quick
Rapid 30°
Synthetics
CottonsOFF
Cottons 20°C
Cotton Dry
Synthetic Dry
Anti Allergy
Wash & Dry
5Kg Wash & Dry
Mini Wash & Dry
Down Wear
Rinse
Spin & Drain
Machine
Clean 3” 3”
Eco 40-60
Quicker
Wash
Prewash Drying Ending In Steam
Spin
Speed
Temp.
AntiCrease
+3”
1200
800
600
140090°
60°
40°
30°
20°
1200
60°
Delicates
Hand Wash / Woollens
Quick
Rapid 30°
Synthetics
CottonsOFF
Cottons 20°C
Cotton Dry
Synthetic Dry
Anti Allergy
Wash & Dry
5Kg Wash & Dry
Mini Wash & Dry
Down Wear
Rinse
Spin & Drain
Machine
Clean 3” 3”
Eco 40-60
Quicker
Wash
Prewash Drying Ending In Steam
Spin
Speed
Temp.
AntiCrease
+3”
1200
800
600
140090°
60°
40°
30°
20°
Before using the washer dryer for the first time
LAMONA cannot be held responsible for
any incorrect installation of the washer dryer.
The separate Installation Instructions must
be followed.
This washer dryer has undergone a complete
functional test at the factory and there may be
some water in the drum and detergent drawer.
If the machine door lock ‘clicks’ but does not begin
the cycle. Check that the emergency door release
lever is not misplaced, or affected by the plinth,
(see Section 2, open the door in case of power
failure).
Running the first programme
Opening the door at the end of
the programme
•Ensure water supply is switched on.
Run the machine EMPTY with a very small amount of
detergent and a 60° cycle quicker wash.
•Turn the programme selector to the Cottons position.
Select Temperature 60°C and Quicker Wash.
•Press the Start/Pause button .
The programme will start.
At the end of the programme, will be displayed.
• Wait until the Door Locked symbol goes off
completely.
• Turn the programme selector to the OFF
position to switch off the machine.

12 www.howdens.com
Washing environmentally and economically
Energy and water saving Choosing the correct function
(Pre-wash and Quicker Wash)
Detergent
•Water consumption and energy usage are
determined by the size of the load.
The most efficient use of the washer dryer is by
loading maximum dry load for the programme you
are using, (Do not overload).
•When smaller amounts of laundry are washed, the
automatic load control will reduce the amount of
water and energy used.
•Use the Quick Rapid 30” programme for lightly
soiled loads.
•Modern detergents make it possible to wash at
lower temperatures (e.g. 20 °C). The Eco 40-60
programme is able to clean normally soiled cotton
laundry declared to be at 40 °C or 60 °C, together in
the same cycle.
•Always select the lowest appropriate temperature.
The most efficient programmes in terms of energy
consumption are generally those that perform at
lower temperatures and longer duration.
•To maintain the hygiene of the machine, carry out a
hot wash (above 60 °C) at least 1 x per month.
•Water and power consumption may vary subject to
the changes in water pressure, water hardness and
water temperature, ambient temperature, type and
amount of laundry, selection of auxiliary functions
and spin speed, and changes in the mains voltage.
•Noise and remaining moisture content are
influenced by the spinning speed: the higher the
spinning speed in the spinning phase, the higher
the noise and the lower the remaining moisture
content.
Select:
•A wash programme together with the Quicker Wash
function for light soiling where there are no obvious
marks or stains.
•A wash programme without any functions for
normal to heavy soiling with visible marks or stains.
•The Pre-wash function for laundry with large
amounts of soiling (e.g. dust, sand). (Pre-treating
with a proprietary stain remover product may
assist in removing stubborn marks or stains).
•Do not exceed the amounts of detergent
recommended by the manufacturer on the
packaging.
•Adjust the dosage to the degree of soiling of the
laundry.
•Reduce the amount of detergent for smaller loads
(approx. ⁄ less than the amount recommended can
be used when washing a half load).
WARNING: Do not over fill the detergent drawer
with detergent as foaming and leakage will occur.
WARNING: Leaking from detergent drawer may
occur if too much detergent, or in wash treatment
additives are used with detergent. Please use as per
detergent manufacturer’s instructions and monitor
and adjust use accordingly.

13
Exclusive to Howdens
1 - Prepare the laundry
Sort the laundry General tips
Pre-treating stains
•Sort the laundry by colour and by care label.
Most garments have a textile care label in the collar
or side seam.
Tip: Dark textiles often contain excess dye and should
be washed separately several times before being
included in a mixed load. Always wash whites and
coloureds separately.
Place very small items or delicate items inside a
dedicated wash bag or pillow case when washing.
•Curtains: Remove all fixing hooks first.
•Any loose wiring in bras, shirt collar stiffeners, etc.
should be removed or sewn in.
•Close any zips, attach velcro fasteners, fasten hooks
and eyes etc. before washing.
•Fasten duvet covers, pillow cases etc. to prevent
small items from being rolled up inside them.
Do not wash any items in this washer dryer which are
specified by the manufacturer as not washable on the
care label ( symbol).
Do not wash footwear.
•Badly soiled areas and
stains should be pretreated
using a proprietary stain
treatment. Always follow the
manufacturer’s instructions.
•Empty all pockets, close zips and fasteners.
•Shake the laundry to loosen and be free of any
excess dust, flour etc.
WARNING: Damage due to foreign objects.
Nails, coins, paper clips, and so on can cause
damage to garments and components in the
machine.
Check the laundry before washing and remove any
foreign objects.
WARNING: Damage due to solvent-based
cleaning agents.
Cleaning agents containing benzine, stain remover,
etc., can damage plastic parts.
When pre-treating textiles, make sure that any
plastic parts (e.g. buttons) do not come into contact
with cleaning agent.
WARNING: Risk of explosion due to solvent
based cleaning agents.
When using solvent-based cleaning agents, an
explosive mixture may develop.
Never use solvent-based cleaning agents in the
washer dryer.

14 www.howdens.com
Overloaded
Full load
2 - Load the washer dryer
Open the door
Close the door
•Reach behind the door grip and pull the door open.
Check the drum for pets or foreign objects before
loading with laundry.
The most efficient use of energy and water is achieved
when a full load is washed. However, do not overload
as this can increase noise, affect wash performance
and shorten the machine’s service life.
•Unfold the laundry and load loosely into the drum.
Mixing both large and small items gives better wash
results and also helps distribute the load evenly during
spinning.
•Close the door (Do not slam closed). •Make sure no items are caught between the door
and seal.
Tip: Note the maximum load for each wash programme.
WARNING: Maximum load when using a drying
programme.

15
Exclusive to Howdens
Delicates
Hand Wash / Woollens
Quick
Rapid 30°
Synthetics
CottonsOFF
Cottons 20°C
Cotton Dry
Synthetic Dry
Anti Allergy
Wash & Dry
5Kg Wash & Dry
Mini Wash & Dry
Down Wear
Rinse
Spin & Drain
Machine
Clean 3” 3”
Eco 40-60
Quicker
Wash
Prewash Drying Ending In Steam
Spin
Speed
Temp.
AntiCrease
+3”
1200
800
600
140090°
60°
40°
30°
20°
1200
40°
Delicates
Hand Wash / Woollens
Quick
Rapid 30°
Synthetics
CottonsOFF
Cottons 20°C
Cotton Dry
Synthetic Dry
Anti Allergy
Wash & Dry
5Kg Wash & Dry
Mini Wash & Dry
Down Wear
Rinse
Spin & Drain
Machine
Clean 3” 3”
Eco 40-60
Quicker
Wash
Prewash Drying Ending In Steam
Spin
Speed
Temp.
AntiCrease
+3”
1200
800
600
140090°
60°
40°
30°
20°
1200
60°
Delicates
Hand Wash / Woollens
Quick
Rapid 30°
Synthetics
CottonsOFF
Cottons 20°C
Cotton Dry
Synthetic Dry
Anti Allergy
Wash & Dry
5Kg Wash & Dry
Mini Wash & Dry
Down Wear
Rinse
Spin & Drain
Machine
Clean 3” 3”
Eco 40-60
Quicker
Wash
Prewash Drying Ending In Steam
Spin
Speed
Temp.
AntiCrease
+3”
1200
800
600
140090°
60°
40°
30°
20°
Tip: Note the maximum load for each wash programme.
3 - Select a programme
Programme selection
The washer dryer is switched on by turning the
programme selector to a wash programme.
The estimated wash time is shown in the time display
and the pre-set temperature and spin speed light up in
the control panel.
Note: Wash times are a guide only and the wash
time displayed may vary according to:- load size
and type, detergent quantity etc.
Selecting temperature and
spin speed
Selecting auxiliary functions
Programme duration
Wash programme temperature Temp. and spin
speed Spin
Speed may be altered by using the function
buttons.
•Press to select desired setting.
Note: Functions offered may be limited to ensure
correct fabric care.
•Press the button for the Auxiliary Function you
desire. The indicator then lights up.
Please refer to Auxiliary Functions for permitted
functions.
•When selecting a programme, you can see the
washing duration on the display of your machine.
Depending on the amount of laundry you have
loaded into the machine, there might be a difference
of 1 to 1.5 hours between the duration shown on
the display and the actual duration of the washing
programme. The duration will be corrected
automatically after the start of the programme.

16 www.howdens.com
4 - Add detergent
Detergent dispenser drawer Choosing the detergent type
Use detergents suitable for automatic washer dryers.
Observe manufacturer dosing instructions.
Detergent for the pre-wash
Detergent for the main wash
Liquid detergent for the main wash
Liquid fabric softener
– Depends on the
wash programme, fabric type and colour.
•Use different detergents for coloured and white
laundry.
•Wash very delicate fabrics with special detergents
(liquid detergent, wool shampoo, etc.) intended
solely for delicate fabrics and using suggested
programmes.
•When washing dark coloured fabrics and quilts it is
recommended to use liquid detergent.
•Modern liquids and detergent liquid tablets work
well for low temperature washes.
•Wash woollens using suggested programme with
special detergent for woollens.
•If odours begin to develop use a 60°C or 90°C wash
1 x per month or perform a Machine Clean cycle.
Adding detergent

17
Exclusive to Howdens
MAX
4 - Add detergent (continued)
•Add fabric conditioner (or liquid starch) to the
compartment.
Do not exceed the maximum level mark.
•Concentrated softener should be diluted, especially
if softener is present in drawer after wash cycle.
It will be automatically dispensed in the final rinse. At
the end of the programme a small amount of water
remains in the compartment.
If starching frequently, thoroughly clean the
dispenser compartment regularly.
Adding liquid fabric softener Tips on detergent usage
Adjust the detergent dosage to the level of soiling
of the laundry and the size of the load. Reduce the
amount of detergent with smaller loads (e.g. reduce
the amount of detergent by 1/3when washing a half
load).
Too little detergent
•Results in laundry not being cleaned properly and
may cause it to become grey and hard to the touch
over time.
•Can lead to a build-up of mould in the washer dryer.
•Results in grease not being completely removed
from the laundry.
•Can lead to limescale deposits on the heater
elements.
Too much detergent
•Causes poor wash, rinse and spin results.
•Causes higher water consumption as an extra rinse
cycle is automatically activated.
•Is a greater burden on the environment.
WARNING: Do not over fill the detergent drawer
with detergent as foaming and leakage will occur.
Using liquid detergent with a pre-wash
Liquid detergent cannot be used for the main wash if
the pre-wash has been selected.
Use powder detergent for the main wash.
Using tablets or liquid tabs
Always put detergent tablets or liquid tabs directly in
the drum with the laundry.
Follow manufacturer instructions - do not overdose.
Avoid using in wash treatments if machine foams
excessively and water leaks from dispenser area.
Using liquid bleach
Liquid bleach must be added manually either during
the pre-wash or during the first rinsing step of the
wash programme as the machine takes in water.
•Follow manufacturers guidelines.
•Do not mix detergents and bleach together.

18 www.howdens.com
5 - Start the programme
Starting a programme Adding laundry during a programme
•Press the Start/Pause button .
The door locks and the programme starts.
If the Ending In has been selected, this counts down
on the time display. At the end of the Ending In or
immediately after the programme has started, the
programme duration appears on the time display.
Energy savings
If after 10 minutes you have not started the
programme, the Display will go into standby.
To reactivate the Display:
•Turn the Programme Selection knob or press any
button and the display lights will turn on.
•Press the Start/Pause button .
•Wait until the Door is unlocked.
•Open the door and add or take out laundry.
Laundry can be added or removed at any time,
provided that the Door Locked symbol is not
illuminated on the control panel.
6 - End of programme
Open the door and removing the
laundry
At the end of the programme, will be displayed.
•Wait until the Door Locked symbol goes out.
•Turn the Programme Selection knob to OFF
•Reach behind the door grip and pull the door open.
•Remove the laundry
Items left in the drum could discolour other items in
the next wash or become discoloured themselves.
– Remove all items from the drum.
CAUTION: Water, laundry may be very wet and hot.
•Check the door seal for any foreign objects.
Tip: Dry door glass and seal with a clean cloth.
•Close the door.
•Make changes in auxiliary functions, temperature
and speed settings as necessary.
•Press the Start/Pause button .
The programme will continue.

19
Exclusive to Howdens
Spinning
Delayed time adjustment
Final spin speeds - washing/drying
Selecting rinse hold (final spin)
Selecting a delayed start
Starting the Ending In timer
Changing or cancelling the
delayed time
When a programme is selected, the optimum spin
speed for that programme will be brightly lit in the
control panel.
The spin speed may then be adjusted if necessary to
suit the washload.
The highest selectable spin speed is indicated in the
programme tables.
•Press the Spin Speed button Spin
Speed until the
illuminates.
The laundry is not spun after the final rinse and
remains in the rinse water. This helps to prevent
creasing if the laundry is not going to be removed from
the drum immediately after the end of the programme.
If you don’t want to spin the clothes.
• Press the Start/Pause button and the water will
drain away.
To spin the clothes, adjust the spin speed.
• Press the Spin Speed button Spin
Speed and press the
Start/Pause button .
Programme for washing rpm
Cottons 1400
Eco 40-60 1400
Synthetics 1200
Quick / Rapid 30° 1400
Quick / Rapid 30° + Quicker Wash 1400
Hand Wash / Woollens 1200
Down Wear 800
Delicates 800
Cotton 20°C 1400
Programme for drying rpm
Cotton Dry 1400
Synthetics Dry -
Anti Allergy Wash & Dry 1400
5 kg Wash & Dry 1400
Mini Wash & Dry 1200
With the Ending In you can choose when you want
the programme to end. You can delay the end of the
programme up to a maximum of 24 hours.
•Select the programme required.
•Press the Ending In button and select the
desired end time.
The Ending In display lights up.
•Press the Ending In button repeatedly
until the required delayed time is displayed.
The programme can be delayed by up to 24 hours.
•Press the Start/Pause button .
The Ending In process starts and counts down the
delayed time before starting the programme.
If the selected Ending In has started, it is no longer
possible to change the time.
•To change the end time, turn the programme
selector to the OFF position.
•Select a programme and a new delayed time.

20 www.howdens.com
Washing programmes
Cottons
Cold to 90°C Max. spin speed 1400 Max. load 8 kg
Items Durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.)
Tip Press the Quicker Wash function key, programme duration becomes notably
shorter but effective washing is ensured thanks to intense washing movements.
If the quick wash function is not selected, superior washing and rinsing
performance is ensured for your heavily soiled laundry.
Synthetics
Cold to 60°C Max. spin speed 1200 Max. load 3 kg
Items Wash t-shirts, synthetic/cotton mix fabrics etc.
Tip Programme duration is notably shorter and efficient washing performance is
ensured. If the Quicker Wash function is not selected, superior washing and
rinsing performance is ensured for your heavily soiled laundry.
Eco 40-60
40°C *** Max. spin speed 1400 Max. load 8 kg
40°C *** Max. spin speed 1400 Max. load 4 kg
40°C *** Max. spin speed 1400 Max. load 2 kg
Items The eco 40-60 programme is able to clean normally soiled cotton laundry
declared to be washable at 40 °C or 60 °C, together in the same cycle, and
that this programme is used to assess the compliance with the EU ecodesign
legislation.
Tip Although it washes longer than all other programmes, it provides high energy
and water savings. Actual water temperature may be different from the stated
wash temperature. When you load the machine with less laundry (e.g. ½ capacity
or less), periods in programme stages may automatically get shorter. In this case,
energy and water consumption will decrease.
Note for test institutes:
***Eco 40-60 with 40 °C temperature selection is the washing performance test programme in accordance with EN 625120 and energy label test programme
in accordance with Commission Delegated Regulation (EU) 2019/2014
Eco 40-60 + Cupboard Dry
40°C *** Max. spin speed 1400 Max. load 5 kg
40°C *** Max. spin speed 1400 Max. load 2.5 kg
Items As per Eco 40-60 above
Tip As per Eco 40-60 above
Note for test institutes:
***Eco 40-60 with 40 °C temperature and cupboard dry selection is the wash and dry cycle test programme in accordance with EN 625120 and energy label
test programme in accordance with Commission Delegated Regulation (EU) 2019/2014
Quick / Rapid 30°
Cold to 90°C Max. spin speed 1400 Max. load 8 kg
Items Mixed load of lightly soiled cotton garments.
Tip Use for shorter programme duration.
